height MAZDA MODEL 3 4-DOOR 2015 Owners Manual

2–5
Essential Safety Equipment
Seats
Front Seat
Seat Operation
*1: With power operation seat only
Power operation*1
Seat Slide
(Manual Seat)
To move a seat forward or backward, raise the lever and slide the seat to\
the desired position
and release the lever.
Make sure the lever returns to its original position and the seat is loc\
ked in place by
attempting to push it forward and backward.
(Power Seat)
To slide the seat, move the slide lifter switch on the outside of the sea\
t to the front or back
and hold it. Release the switch at the desired position.
Height Adjustment (Driver's Seat)
(Manual Seat)
To adjust the seat height, move the lever up or down.
(Power Seat)
To adjust the seat height, move the switch up or down.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










2–8
Essential Safety Equipment
Seats
Rear Seat
Split/One-piece Folding the Seatback
By lowering the rear seatback(s) the
luggage compartment space can be
expanded.
WARNING
Do not drive the vehicle with occupants
on folded down seatback(s) or in the
luggage compartment.
Putting occupants in the luggage
compartment is dangerous because
seat belts cannot be fastened which
could lead to serious injury or death
during sudden braking or a collision.

Do not allow children to play inside the
vehicle with the seatback(s) lowered. Allowing children to play in the
vehicle with the seatback(s) folded
down is dangerous, If a child enters
the luggage compartment and the
seatback(s) were raised back up, the
child may become trapped in the
luggage compartment which could
lead to an accident.

Tightly secure cargo in the luggage
compartment when it is transported
with the seatback(s) folded down. Driving without tightly securing cargo
and luggage is dangerous as it could
move and become an obstruction to
driving during emergency braking or
a collision resulting in an unexpected
accident.

When transporting cargo, do not allow
the cargo to exceed the height of the
seatback(s). Transporting cargo stacked higher
than the seatback(s) is dangerous as
visibility to the rear and sides of the
vehicle is reduced which could interfere
with driving operations and lead to an
accident.
Lowering the seatback(s)
CAUTION
Check the position of a front seat
before folding a rear seatback.
Depending on the position of a front
seat, it may not be possible to fold
a rear seatback all the way down
because it may hit the seatback of
the front seat which could scratch or
damage the front seat or its pocket.
Lower or remove the head restraint on
the rear outboard seat if necessary.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.2–11
Essential Safety Equipment
Seats
Head Restraints
Your vehicle is equipped with head
restraints on all outboard seats and the
rear center seat
* . The head restraints
are intended to help protect you and the
passengers from neck injury.
WARNING
Always drive with the head restraints
installed when seats are being used and
make sure they are properly adjusted: Driving with the head restraints
adjusted too low or removed is
dangerous. With no support behind
your head, your neck could be seriously
injured in a collision.
Height adjustment
To raise a head restraint, pull it up to the
desired position.
To lower the head restraint, press the stop-
catch release, then push the head restraint
down.
Adjust the head restraint so that the center
is even with the top of the passenger's ears.
Front outboard seat
Rear outboard seat
Rear center seat*
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










2–44
Essential Safety Equipment
SRS Air Bags
Do not attach objects on or around the area where a side air bag deploys: Attaching objects to the front seat in such a way as to cover the outboard side of the
seat in any way is dangerous. In an accident the object could interfere with the side
air bag, which infl ates from the outboard side of the front seats, impeding the added
protection of the side air bag system or redirecting the air bag in a way that is dangerous.
Furthermore, the bag could be cut open releasing the gas.
Do not hang net bags, map pouches or backpacks with side straps on the front seats.
Never use seat covers on the front seats. Always keep the side air bag modules in your
front seats free to deploy in the event of a side collision.

Do not attach objects on or around the area where a curtain air bag deploys: Attaching objects to the areas where the curtain air bag activates such as on the
windshield glass, side door glass, front and rear window pillars and along the roof edge
and assist grips is dangerous. In an accident the object could interfere with the curtain
air bag, which infl ates from the front and rear window pillars and along the roof edge,
impeding the added protection of the curtain air bag system or redirecting the air bag in
a way that is dangerous. Furthermore, the bag could be cut open releasing the gas.
Do not place hangers or any other objects on the assist grips. When hanging clothes,
hang them on the coat hook directly. Always keep the curtain air bag modules free to
deploy in the event of a side collision or roll-over accident.

Do not touch the components of the supplemental restraint system after the air bags
have infl ated:
Touching the components of the supplemental restraint system after the air bags have
infl ated is dangerous. Immediately after infl ation, they are very hot. You could get burned.

Never install any front-end equipment to your vehicle: Installation of front-end equipment, such as frontal protection bar (kangaroo bar, bull
bar, push bar, or other similar devices), snowplow, or winches, is dangerous. The air bag
crash sensor system could be aff ected. This could cause air bags to infl ate unexpectedly,
or it could prevent the air bags from infl ating during an accident. Front occupants could
be seriously injured.

Do not modify the suspension: Modifying the vehicle suspension is dangerous. If the vehicle's height or the suspension is
modifi ed, the vehicle will be unable to accurately detect a collision or roll-over accident
resulting in incorrect or unexpected air bag deployment and the possibility of serious
injuries.

.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










4–19
When Driving
Instrument Cluster and Display
The active driving display indicates the following information:
 y Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control (MRCC) on page 4-90 . y Lane Departure Warning System (LDWS) Operation Conditions and Warnings Refer to Lane Departure Warning System (LDWS) on page 4-118 . y Smart City Brake Support (SCBS) Operation Conditions and Warnings Refer to Smart City Brake Support (SCBS) on page 4-71 . y Forward Obstruction Warning (FOW) Operation Conditions and Warnings Refer to Forward Obstruction Warning (FOW) on page 4-115 . y Vehicle Speed Setting Using Cruise Control Refer to Cruise Control on page 4-99 . y Turn-by-Turn (TBT) (Direction and Distance) and Lane Guidance y Vehicle Speed
Each setting/adjustment for the active driving display can be performed \
on the center
display (Type B audio).
1. Select the (
) icon on the home screen and display the Settings screen.
2. Select the AD-Disp tab.
3. Select the desired item and perform the setting/adjustment.
yHeight : Active driving display positionyBrightness Control : Method for adjusting screen brightness (Automatically/Manually)yCalibration : Brightness initialization setting (when selecting automatic adjustment\
)yBrightness : Brightness adjustment (when selecting manual adjustment)yNavigation : On/OffyActive Driving Display : On/OffyReset
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










4–66
When Driving
Radar Sensor
NOTE
 y In the following cases, the radar sensor may not be able to detect vehic\
les ahead or
obstructions.
 y The rear surface of a vehicle ahead does not refl ect radio waves effectively, such as
an unloaded trailer or an automobile with a loading platform covered by a soft top,
vehicles with a hard plastic tailgate, and round-shaped vehicles.
 y Vehicles ahead with low vehicle height and thus less area for refl ecting radio waves. y Visibility is reduced due to a vehicle ahead casting off water, snow, or sand from its
tires and onto your windshield.
 y The trunk/luggage compartment is loaded with heavy objects or the rear passenger
seats are occupied.
 y Ice, snow, or soiling is on the front surface of the front emblem. y During inclement weather such as rain, snow, or sand storms. y When driving near facilities or objects emitting strong radio waves.
 y In the following cases, the radar sensor may detect vehicles in the oppo\
site lane or
surrounding obstructions, or it may not be able to detect vehicles ahead or \
obstructions.
 y The beginning and end of a curve. y Roads with continuous curves. y Narrow lane roads due to road construction or lane closures. y The vehicle ahead enters the radar sensor's blind spot. y The vehicle ahead is running abnormally due to accident or vehicle damag\
e.  y Roads with repeated up and down slopes y Driving on poor roads or unpaved roads. y The distance between your vehicle and the vehicle ahead is extremely short. y A vehicle suddenly comes close such as by cutting into the lane.
 y To prevent incorrect operation of the system, use tires of the same specifi ed size,
manufacturer, brand, and tread pattern on all four wheels. In addition, do not use tires
with signifi cantly different wear patterns or tire pressures on the same vehicle. (Including
the temporary spare tire)
 y If the battery power is weak, the system may not operate correctly. y When driving on roads with little traffi c and few vehicles ahead or obstructions for the
radar sensor to detect, Forward Obstruction Warning/Smart City Brake Support (FOW/
SCBS) warning light (amber) temporarily illuminates, however, this does not indicate a
problem.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–107
When Driving
Blind Spot Monitoring (BSM) System
Blind Spot Monitoring (BSM) System *
The Blind Spot Monitoring (BSM) system is designed to assist the drive\
r by monitoring
blind spots on both sides of the vehicle to the rear in certain situatio\
ns such as when
changing lanes on roads and freeways or reversing the vehicle from a par\
king garage.
The Blind Spot Monitoring (BSM) System consists of the Blind Spot Moni\
toring (BSM)
and Rear Cross Traffi c Alert (RCTA).
WARNING
Do not rely completely on the Blind Spot Monitoring (BSM) system. Always look over
your shoulder before changing lanes or reversing the vehicle from a parking garage:
The Blind Spot Monitoring (BSM) system can assist the driver in confi rming the safety of
the surroundings but is not a complete substitute. The driver is responsible for assuring
lane changes and other maneuvers. Always pay attention to the direction in which the
vehicle is traveling and the vehicle's surroundings.
NOTE
 y The detectability of the radar sensors has its limitations. The Blind Sp\
ot Monitoring
(BSM) System may not operate properly under the following conditions:
 y Ice, snow, or soil adheres to the rear bumper surface around the radar sensors. y During adverse weather conditions such as rain or snow, or under conditions where
water is sprayed.
 y The rear bumper area around the radar sensors is blocked by foreign material (such as
stickers or a bicycle carrier).
 y The radar sensors do not detect human, animal, shopping cart, bicycle, o\
r static objects
such as fences.
 y The radar sensors may not detect all types of vehicles around your vehicle, especially the
following types of vehicles:
 y Motorcycles y Vehicles with body shapes that radar may not refl ect such as a fl atbed trailer with no
cargo.
 y Vehicles with lower body height such as sports cars.
 y Although the system may detect objects on the road side such as parked vehicles or
guardrails and operate the warning light/beep, it does not indicate a malfun\
ction.
 y If the vehicle is driven on a road with less traffi c and few vehicles that the radar sensors
can detect, the system may pause (the Blind Spot Monitoring (BSM) OFF\
indicator light
in the instrument cluster fl ashes). However, it does not indicate a malfunction.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










4–109
When Driving
Blind Spot Monitoring (BSM) System
NOTE
 y The Blind Spot Monitoring (BSM) does not operate when the vehicle spee\
d is lower than
about 10 km/h (6.2 mph).
 y The detection area of the Blind Spot Monitoring (BSM) has been determined based on
the lane width of general freeways. Therefore on a road with a narrower lane width, the
system may detect vehicles on a lane next to the adjacent lane and opera\
te the warning
light/beep. On a road with wider lane width, the system may not detect vehicles on the
adjacent lane and may not operate the warning light/beep.
 y Under the following conditions, the system may be unable to detect vehic\
les, or detection
may be delayed.
 y The vehicle accelerates from a standing-start with a vehicle alongside. y A vehicle moves from a lane two lanes over to the adjacent lane. y The difference in vehicle speed between your vehicle and another vehicle is larger
when passing or being passed, and the vehicle passes the detection area within a short
period of time.
 y On a steep incline, or when there is a difference in height between lanes. y Immediately after the system has been activated by pressing the Blind Spot Monitoring
(BSM) OFF switch again after it has been turned off (Blind Spot Monit\
oring (BSM)
OFF indicator light in instrument cluster illuminates) by pressing the switch.
 y (Automatic transaxle vehicles) The shift lever is shifted to the R position, or directly after being shifted from the R
position.
 y The system may not operate normally when towing a trailer. Turn off the system by
operating the Blind Spot Monitoring (BSM) OFF switch when towing a tra\
iler.
 y The system switches to the Rear Cross Traffi c Alert function when the shift lever (Manual
transaxle) or the selector lever (Automatic transaxle) is shifted to \
the R position.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










4–119
When Driving
Lane Departure Warning System (LDWS)
CAUTION
Do not modify the suspension. If the vehicle height or the damping force of the
suspensions is changed, the LDWS may not operate correctly.
NOTE
 y If your vehicle deviates from its traffi c lane, the LDWS operates (warning sound and
indicator light). Steer the vehicle adequately to drive the vehicle to \
the center of the lane.
 y When the turn signal lever is operated for a lane change, the LDWS warni\
ng is
automatically canceled. The LDWS warning becomes operable when the turn \
signal lever
is returned and the system detects the white or yellow lines.
 y If the steering wheel, accelerator pedal, or brake pedal is operated abr\
uptly and the
vehicle moves close to a white or yellow line, the system determines tha\
t the driver is
making a lane change and the LDWS warning is automatically canceled.
 y The LDWS may not operate during the period immediately after the vehicle\
has deviated
from its lane and the LDWS has operated, or the vehicle deviates from its lane repeatedly
within a short period of time.
 y The LDWS does not operate if it does not detect the white or yellow line\
s of the traffi c
lane.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–55
Interior Features
Audio System
Settings
NOTE
Depending on the grade and specifi cation, the screen display may differ.
Select the
icon on the home screen and display the Settings screen.
Switch the tab and select the setting item you want to change.
You can customize settings in the setup display as follows:
Tab Item Function
AD-Disp Height
Brightness Control
Other Refer to Active Driving Display on page 4-18 .
Display Refer to Volume/Display/Sound Controls on page 5-42 . Safety Smart City Brake Support
Blind Spot Monitoring Volume
Other Refer to Personalization Features on page 9-12 .
Sound Refer to Volume/Display/Sound Controls on page 5-42 .
Clock Adjust Time
Displays the currently set time is displayed.
Press
to advance the hour/minute, and select to move the hour/minute back.
AM/PM can only be selected with the 12-hour
clock display.
GPS Sync When ON is selected, “Adjust Time” is
disabled.
Time Format Changes the display between 12 and 24-hour
clock time.
Time Zone Select Selects the time zone.
Daylight Savings Time Turns the daylight saving time setting on/off.
When ON, the time advances 1 hour. When
OFF, it returns to normal time.
Vehicle Rain Sensing Wiper
Door Locks
Other Refer to Personalization Features on page 9-12 .
Devices Bluetooth
® Refer to Bluetooth ® Preparation (Type B) on
page 5-94 .
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC
