*Some models.7–29
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning
Headlight
Auto-Leveling Malfunction
Indicator Light
*
This indicator light stays on for a few seconds when the ignition is swi\
tched ON.
Thereafter, the indicator light will illuminate when the headlight auto-leveling s\
ystem has a
malfunction.
If the indicator light illuminates, contact an Authorized Mazda Dealer.
NOTE
Vehicles with the adaptive front lighting system (AFS) are not equipped with the headlight
auto-leveling malfunction indicator light. If there is a malfunction with the headlight auto-
leveling function, the AFS OFF indicator light fl ashes.
(Amber)
High Beam Control System (HBC)
Warning Light
*
When illuminated
The warning light illuminates if the area of the windshield in front of \
the forward sensing
camera (FSC) is fogged or obstructed.
When fl ashing
This light fl ashes if there is a malfunction in the high beam control system (HBC).\
Have
your vehicle inspected by an Authorized Mazda Dealer.
(Amber)
(Flashing)
Mazda Radar
Cruise Control
(MRCC) Warning Light
*
The warning light fl ashes if there is a malfunction in the system while the Mazda Radar
Cruise Control (MRCC) system is on. Have your vehicle inspected at an \
Authorized Mazda
Dealer.
Taking Action
Take the appropriate action and verify that the warning light turns off.
Signal Warning Action to be taken
Low Fuel
Warning Light The light turns on when the remaining fuel is
about 9.0 L (2.3 US gal, 1.9 Imp gal). NOTE
The light illumination timing may vary because
fuel inside the fuel tank moves around according
to the driving conditions and the vehicle posture.
Add fuel.
Check
Fuel Cap Warning Light If the check fuel cap warning light illuminates
while driving, the fuel-fi
ller cap may not be
installed properly. Stop the engine and reinstall the fuel-fi
ller cap.
Refer to Fuel-Filler Cap on page 3-31
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 502 of 592
*Some models.7–30
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
Seat Belt
Warning Light
The seat belt warning light illuminates if the driver or front passenger\
's seat is occupied and the
seat belt is not fastened with the ignition switched ON.
Seat belt reminder
If the vehicle is driven with the driver or front passenger's seat belt \
unfastened, the seat belt
warning light illuminates and a warning beep sounds.
NOTE
If the driver or front passenger's seat belt is unfastened (only when the front passenger seat is
occupied) and the vehicle is driven at a speed faster than about 20 km/\
h (12 mph), the warning
light will fl ash and a beep sound will be heard. After a short time, the warning light stops fl ashing,
but remains illuminated, and the beep sound stops.
Until a seat belt is fastened or a given period of time has elapsed, the\
beep sound will not stop even
if the vehicle speed falls below 20 km/h (12 mph).
NOTE
yThe warning light fl ashes and a beep sound will be heard for about 6 seconds if the driver's seat
belt is not fastened when the ignition is switched ON.
yIf a driver or front passenger's seat belt is unfastened after the beep sound turns off (\
warning light remains illuminated), and the vehicle speed exceeds 20 km/h (12 mph), \
the warning light fl ashes
and beep sound activates again.
yPlacing heavy items on the front passenger seat may cause the front passenger seat belt warning function to operate depending on the weight of the item.
yTo allow the front passenger seat weight sensor to function properly, do not place and sit on an additional seat cushion on the front passenger seat. The sensor may not function properly because
the additional seat cushion could cause sensor interference.
yWhen a small child sits on the front passenger seat, it is possible that the warning light will not operate.
Door-Ajar Warning Light The light turns on if any door is not closed
securely.
Close the door securely.
Low Washer
Fluid Level Warning Light
*
This warning light indicates that little washer
fl uid remains. Add washer fl
uid (page 6-31 ).
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 503 of 592
*Some models.7–31
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
Tire
Pressure
Monitoring System
Warning Light
*
When the warning light illuminates, and the
warning beep sound is heard (about 3 seconds),
tire pressure is too low in one or more tires.
WARNING
If the tire pressure monitoring system
warning light illuminates or fl ashes, or the
tire pressure warning beep sound is heard,
decrease vehicle speed immediately and
avoid sudden maneuvering and braking: If the tire pressure monitoring system
warning light illuminates or fl ashes, or the
tire pressure warning beep sound is heard,
it is dangerous to drive the vehicle at high
speeds, or perform sudden maneuvering
or braking. Vehicle drivability could worsen
and result in an accident.
To determine if you have a slow leak or a
fl at, pull over to a safe position where you
can check the visual condition of the tire
and determine if you have enough air to
proceed to a place where air may be added
and the system monitored again by an
Authorized Mazda Dealer or a tire repair
station.
Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is
dangerous, even if you know why it is
illuminated. Have the problem taken care of
as soon as possible before it develops into
a more serious situation that could lead to
tire failure and a dangerous accident. Inspect the tires and adjust to the specifi
ed
infl ation pressure (page 6-42 ).
NOTE
yPerform tire pressure adjustment when the tires
are cold. Tire pressure will vary according to
the tire temperature, therefore let the vehicle
stand for 1 hour or only drive it 1.6 km (1 mile)
or less before adjusting the tire pressures.
When pressure is adjusted on hot tires to the
cold infl ation pressure, the TPMS warning
light/beep may turn on after the tires cool and
pressure drops below specifi cation.
Also, an illuminated TPMS warning light,
resulting from the tire air pressure dropping
due to cold ambient temperature will remain
illuminated even if the ambient temperature
rises. In this case, it will also be necessary
to adjust the tire air pressures. If the TPMS
warning light illuminates due to a drop in tire
air pressure, make sure to check and adjust the
tire air pressures.
y Tires lose air naturally over time and the TPMS cannot tell if the tires are getting too soft over
time or you have a fl at. However, when you
fi nd one low tire in a set of four-that is an
indication of trouble; you should have someone
drive the vehicle slowly forward so you can
inspect any low tire for cuts and any metal
objects sticking through tread or sidewall. Put
a few drops of water in the valve stem to see if
it bubbles indicating a bad valve. Leaks need
to be addressed by more than simply reinfl ating
the tire as leaks are dangerous — take it to an
Authorized Mazda Dealer.
(Amber) Forward
Obstruction Warning/ Smart
City Brake Support(FOW/SCBS)
Warning Light
*
The light turns on if the windshield and the radar
sensor are dirty or there is a malfunction in the
system. Verify the reason why the warning light is
illuminated on the center display (page 7-24 ).
If the reason why the warning light is
illuminated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because of a
dirty radar sensor, clean the front emblem.
For any other reasons, have the vehicle
inspected at an Authorized Mazda Dealer.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 504 of 592
7–32
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
KEY Warning Light
Take the appropriate action and verify that the warning light turns off.
Signal Cause Action to be taken
(Red)
(Flashing) The advanced key battery is dead. Replace the battery (page 6-39 ).
The advanced key is not within the
operation range.
Bring the advanced key into the operation
range (page 3-7 ).
The advanced key is placed in areas inside
the cabin where it is diffi
cult for the key to
be detected.
A key from another manufacturer similar to
the advanced key is in the operation range. Take the key from another manufacturer
similar to the advanced key out of the
operation range.
Without the ignition switched off, the
advanced key is taken out of the cabin, and
then all the door are closed. Bring the advanced key back into the
cabin.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 505 of 592
*Some models.7–33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated on Display *
If a message is displayed in the center display (Type B audio), take appropriate action (in a
calm manner) according to the displayed message.
(Display example)
Stop Vehicle in Safe Place Immediately
If the following messages are displayed in the center display (Type B audio), a vehicle
system may be malfunctioning. Stop the vehicle in a safe place and conta\
ct an Authorized
Mazda Dealer.
Display Indicated Condition
Displays if the engine coolant temperature has
increased excessively.
Displays if the charging system has a malfunction.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 506 of 592
7–34
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Make Sure the Message is No Longer Displayed
Displays in the following cases:
Display Indicated Condition/Action to be taken
Displays if i-ELOOP requires charging. Leave the
engine idling and wait until the message disappears.
NOTE
yIf the vehicle is driven while the message is displayed,
the buzzer will sound.
yIf you turn the steering wheel while the message is displayed, it will feel heavier than normal, but
this does not indicate an abnormality. The steering
operation will return to normal after the message has
disappeared.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 507 of 592
7–35
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Warning Sound is
Activated
Lights-On Reminder
The lights-on reminder is operable when
the time setting *1 of the auto headlight off
function is off.
If lights are on and the ignition is switched
to ACC or the ignition is switched off, a
continuous beep sound will be heard when
the driver's door is opened.
*1 If the light switch is left on, the auto headlight off function automatically
turns off the lights about 30 seconds
after switching the ignition off. The
time setting can be changed.
Refer to Personalization Features on page 9-12 .
NOTE
y When the ignition is switched to ACC,
the “Ignition Not Switched Off (STOP)
Warning Beep” (page 7-36 ) overrides
the lights-on reminder.
y A personalized function is available to
change the sound volume for the lights-
on reminder.
Refer to Personalization Features on page 9-12 .
Air Bag/Front Seat Belt Pretensioner System Warning
Beep
If there is a problem with the air bag/seat
belt pretensioner systems and the warning
light illumination, a warning beep sound
will be heard for about 5 seconds every
minute.
The air bag and seat belt pretensioner
system warning beep sound will continue
to be heard for approximately 35
minutes. Have your vehicle inspected at
an Authorized Mazda Dealer as soon as
possible.
WARNING
Do not drive the vehicle with the air
bag/seat belt pretensioner system
warning beep sounding:
Driving the vehicle with the air bag/
seat belt pretensioner system warning
beep sounding is dangerous. In a
collision, the air bags and the seat belt
pretensioner system will not deploy
and this could result in death or serious
injury. Contact an Authorized Mazda
Dealer to have the vehicle inspected as
soon as possible.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 508 of 592
7–36
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Seat Belt Warning Beep
If the driver's seat belt is not fastened
when the ignition is switched ON, a beep
sound will be heard for about 6 seconds. If
the driver or the front passenger's seat belt
is not fastened and the vehicle is driven
at a speed faster than about 20 km/h (12
mph), a beep sound will be heard again for
a specifi ed period of time.
NOTE
y Placing heavy items on the front
passenger seat may cause the front
passenger seat belt warning function to
operate depending on the weight of the
item.
y To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion
on the front passenger seat. The sensor
may not function properly because the
additional seat cushion could cause
sensor interference.
y When a small child sits on the front
passenger seat, it is possible that the
warning beep will not operate.
Ignition Not Switched Off (STOP) Warning Beep
If the driver's door is opened while
the ignition is switched to ACC, a
continuous beep sound will be heard to
notify the driver that the ignition has not
been switched off (STOP). Left in this
condition, the keyless entry system will
not operate, the car cannot be locked, and
the battery power will be depleted.
Key Removed from Vehicle Warning Beep
A beep sound will be heard 6 times and
the KEY warning light (red) will fl ash
continuously if the ignition has not been
switched off, all the doors are closed, and
the key is removed from the vehicle. This
is to notify the driver that the key has been
removed from the vehicle and the ignition
has not been switched off.
NOTE
Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key is
carried together with a metal object or it
is placed in a poor signal reception area.
Request Switch Inoperable Warning Beep (With the advanced
keyless function)
If the request switch is pressed with a door
open or ajar or the ignition has not been
switched off while the key is being carried,
a beep will be heard for about 2 seconds
to indicate that the doors and the liftgate/
trunk lid cannot be locked.
Key Left-in-luggage Compartment Warning Beep (With the advanced
keyless function)
If the key is left in the trunk with all doors
locked and the trunk lid closed, a beep
sound is heard for about 10 seconds to
remind the driver the key has been left in
the trunk. If this happens, open the trunk
lid by pressing the electric trunk lid opener
and remove the key. A key removed from
the trunk may not function because its
functions may have been temporarily
suspended. To restore the key function,
perform the applicable procedure (page
3-8 ).
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 509 of 592
*Some models.7–37
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Key Left-in-vehicle Warning Beep (With the advanced keyless
function)
If a key is left in the vehicle cabin and all
the doors and the trunk are locked using
a separate key, a beep sound is heard for
about 10 seconds to remind the driver
that the key has been left in the vehicle
cabin. If this happens, open the door and
remove the key. A key removed from the
vehicle this way may not function because
its functions may have been temporarily
suspended. Perform the applicable
procedure to restore the functions of the
key (page 3-8 ).
i-ELOOP Warning Beep *
The beep will activate if you attempt to
drive the vehicle under the following
conditions.
y The i-ELOOP indicator light is fl ashing
green.
y “i-ELOOP Charging” is indicated in the
center display (Type B audio).
The beep will stop when the vehicle is
stopped. Make sure the indicator light is
no longer illuminated and the message
is no longer displayed before driving the
vehicle.
Tire Infl ation Pressure Warning
Beep*
The warning beep sound will be heard
for about 3 seconds when there is any
abnormality in tire infl ation pressures
(page 4-103 ).
Lane Departure Warning System (LDWS) Warning Sound *
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
y The volume of the LDWS warning sound
can be changed.
Refer to Personalization Features on page 9-12 .
y The type of the LDWS warning sound
can be changed.
Refer to Personalization Features on page 9-12 .
Blind Spot Monitoring (BSM) System Warning Beep *
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Monitoring (BSM) warning
light is illuminated.
NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Personalization Features on page
9-12 .
Reversing
If a moving object such as a vehicle or
two-wheeled vehicle approaches on the
left or right from behind your vehicle, the
Blind Spot Monitoring (BSM) warning
sound is activated.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
Page 510 of 592
*Some models.7–38
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Mazda Radar Cruise Control (MRCC) System Warnings *
The Mazda Radar Cruise Control (MRCC)
system warnings notify the driver of
system malfunctions and cautions on use
when required.
Check based on the beep sound.
Cautions What to check
The beep sounds 1 time
while the Mazda Radar
Cruise Control (MRCC)
is operating The vehicle speed is
slower than 25 km/h (16
mph) and the Mazda
Radar Cruise Control
(MRCC) system has
been canceled.
The beep sounds
continuously while
driving The distance between
your vehicle and the
vehicle ahead is too
close. Verify the safety
of the surrounding area
and reduce vehicle
speed.
When the Mazda
Radar Cruise Control
(MRCC) is operating,
the beep sounds and the
Mazda Radar Cruise
Control (MRCC)
warning light (amber)
in the instrument cluster
fl ashes. A malfunction in
the system may be
indicated. Have your
vehicle inspected at
an Authorized Mazda
Dealer.
Collision warning *
If there is the possibility of a collision
with a vehicle ahead, the beep sounds
continuously and a warning is indicated in
the display.
Power Steering Warning Buzzer
If the power steering system has
a malfunction, the power steering
malfunction light turns on or fl
ashes and
the buzzer operates at the same time.
Refer to Warning/Indicator Lights on page
4-20 .
Over Rev. Buzzer *
The buzzer sounds to notify the driver if
the engine speed is about to exceed the
permissible engine speed.
CAUTION
Operate the accelerator and shift gears
according to the driving conditions so
that the buzzer does not sound. If the
engine speed exceeds the permissible
engine speed, the engine could be
damaged.
. B [ E B @ % 9 & " ' @ & E J U J P O J O E C . B [ E B @ % 9 & " ' @ & E J U J P O J O E C
