3–47
Before Driving
Driving Tips
Rocking the Vehicle
WARNING
Do not spin the wheels at more than
56 km/h (35 mph), and do not allow
anyone to stand behind a wheel when
pushing the vehicle: When the vehicle is stuck, spinning the
wheels at high speed is dangerous.
The spinning tire could overheat and
explode. This could cause serious
injuries.
CAUTION
Too much rocking may cause engine
overheating, transaxle failure, and tire
damage.
If you must rock the vehicle to free it from
snow, sand or mud, depress the accelerator
slightly and slowly move the shift lever
from 1 (D) to R.
Winter Driving
Carry emergency gear, including tire
chains, window scraper, fl ares, a small
shovel, jumper cables, and a small bag of
sand or salt.
Ask an Authorized Mazda Dealer to check
the following:
 y  Have the proper ratio of antifreeze in the
radiator.
 Refer to Engine Coolant on page 6-29 . y  Inspect the battery and its cables. Cold
reduces battery capacity.
 y  Use an engine oil appropriate for the
lowest ambient temperatures that the
vehicle will be driven in (page 6-27 ).
 y  Inspect the ignition system for damage
and loose connections.
 y  Use washer fl uid made with antifreeze—
but do not use engine coolant antifreeze
for washer fl uid (page 6-31 ).
NOTE
 y  Do not use the parking brake in freezing
weather as it may freeze. Instead, shift
to P with an automatic transaxle and to
1 or R with a manual transaxle. Block
the rear wheels.
 y Remove snow before driving. Snow left
on the windshield is dangerous as it
could obstruct vision.
 y Do not apply excessive force to a
window scraper when removing ice or
frozen snow on the mirror glass and
windshield.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–21
When Driving
Instrument Cluster and Display
Warning Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Warning Lights Page
Master Warning Light *1 7-24
Brake System Warning Light *1*2 7-24
ABS Warning Light *1 7-24
Charging System Warning Light *1 7-24
Engine Oil Warning Light *1 7-24
Check Engine Light *1 7-24
(Red) High Engine Coolant Temperature Warning Light
*1
7-24
* Automatic Transaxle Warning Light *1 7-24
Power Steering Malfunction Indicator Light *1 7-24
Air Bag/Front Seat Belt Pretensioner System Warning Light *1 7-24
Low Fuel Warning Light 7-24
Check Fuel Cap Warning Light *1 7-24
Seat Belt Warning Light 7-24
Door-Ajar Warning Light 7-24
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–21
Interior Features
Audio System
 y The CD player has been designed to
play CDs bearing the identifi cation logo
as shown below. No other discs can be
played.
 y  Use discs that have been legitimately
produced. If illegally-copied discs such
as pirated discs are used, the system may
not operate properly.
 y  Be sure never to touch the signal surface
when handling the CDs. Pick up a CD
by grasping the outer edge or the edge of
the hole and the outer edge.
 y  Do not stick paper or tape on the CD.
Avoid scratching the reverse side (the
side without a label). The disc may not
eject resulting in a malfunction.
 y  Dust, fi nger smudges, and dirt can
decrease the amount of light refl ected
from the signal surface, thus affecting
sound quality. If the CD should become
soiled, gently wipe it with a soft cloth
from the center of the CD to the edge.
 y  Do not use record sprays, antistatic
agents, or household spray cleaners.
Volatile chemicals such as benzine and
thinner can also damage the surface of
the CD and must not be used. Anything
that can damage, warp, or fog plastic
should never be used to clean CDs.
 y  The CD player ejects the CD if the CD
is inserted upside down. Also dirty and/
or defective CDs may be ejected.
 y  Do not insert cleaning discs in the CD
player.
 y  Do not insert any disc with a peel-off
seal affi xed to it.
 y This unit may not be able to play certain
CD-R/CD-RWs made using a computer
or music CD recorder due to disc
characteristics, scratches, smudges, dirt,
etc., or due to dust or condensation on
the lens inside the unit.
 y  Storing CDs in the vehicle exposed to
direct sunlight or high temperature may
damage the CD-R/CD-RWs, and make
them unplayable.
 y  CD-R/CD-RW exceeding 700 MB
cannot be played.
 y  This unit may not be able to play certain
discs made using a computer due to the
application (writing software) setting
used. (For details, consult the store
where the application was purchased.)
 y  It is possible that certain text data, such
as titles, recorded on a CD-R/CD-RW
may not be displayed when musical data
(CD-DA) is playing.
 y  The period from when a CD-RW is
inserted to when it begins playing is
longer than a normal CD or CD-R.
 y  Completely read the instruction manual
and cautions for CD-R/CD-RWs.
 y  Do not use discs with cellophane tape
adhering, partially peeled off labels,
or adhesive material exuding from the
edges of the CD label. Also, do not use
discs with a commercially-available
CD-R label affi xed. The disc may not
eject resulting in a malfunction.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










6–4
Maintenance and Care
Scheduled Maintenance
Scheduled Maintenance (U.S.A., Canada, and Puerto
Rico)
Follow Schedule 1 if the vehicle is operated mainly where none of the fo\
llowing conditions
(severe driving conditions)apply.
 y Repeated short-distance driving y Driving in dusty conditions y Driving with extended use of brakes y Driving in areas where salt or other corrosive materials are used y Driving on rough or muddy roads y Extended periods of idling or low-speed operation y Driving for long periods in cold temperatures or extremely humid climate\
s y Driving in extremely hot conditions y Driving in mountainous conditions continually
If any do apply, follow Schedule 2. (Canada and Puerto Rico residents follow Schedule \
2.)
Vehicles using Engine Oil Flexible Maintenance
Engine Oil Flexible Maintenance is available for U.S.A. and Puerto Rico \
residents whose
vehicle is operated mainly where none of the following conditions apply:\

 y  Extended periods of idling or low-speed operation such as police car, taxi or driving
school car
 y  Driving in dusty conditions
If any do apply, follow Schedule 2 with engine oil fi xed maintenance.
Once engine oil fl exible maintenance is selected, the vehicle calculates the remaining oil\
life
based on engine operating conditions. The vehicle lets you know when an oil change is due
by illuminating the wrench indicator light in the instrument cluster. Change the oil as soon
as possible within the next 500 km (250 miles) or 15 days. Refer page 6-20 for the details.
Mazda Genuine 0W-20 Oil and Castrol
® 0W-20 Oil are required to achieve optimum
performance.
NOTE
 y  Please ensure that the Flexible Oil Maintenance Setting is reset after each Oil and Filter
replacement.
 y For maintenance guidelines beyond the miles/months listed, follow the ma\
intenance
intervals provided in the Scheduled Maintenance Tables.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










6–28
Maintenance and Care
Owner Maintenance
Except U.S.A., Canada, and Puerto Rico
Use SAE 5W-30 engine oil.
Oil container labels provide important
information.
A chief contribution this type of oil makes
to fuel economy is reducing the amount of
fuel necessary to overcome engine friction.
For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol
® (Mexico only).
(ILSAC)
(Mexico)
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 5W-20
engine oil.
The quality designation SM, or ILSAC
must be on the label.
80
60
40
20
0
–40 –20
30
100
40
20
10
0
–10
–20
–30
–40
Inspecting Engine Oil Level
1. Be sure the vehicle is on a level
surface.
2. Warm up the engine to normal operating temperature.
3. Turn it off and wait at least 5 minutes for the oil to return to the oil pan.
4. Pull out the dipstick, wipe it clean, and reinsert it fully.
Full
OK
Low
5. Pull it out again and examine the level.
The level is normal if it is between Low and Full.
If it is near or below Low, add enough oil to bring the level to Full.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










6–29
Maintenance and Care
Owner Maintenance
CAUTION
Do not add engine oil over Full. This
may cause engine damage.
6. Make sure the O-ring on the dipstick is positioned properly before reinserting
the dipstick.
7. Reinsert the dipstick fully.
Engine Coolant
Inspecting Coolant Level
WARNING
Do not use a match or live fl ame in the
engine compartment. DO NOT ADD
COOLANT WHEN THE ENGINE IS HOT: A hot engine is dangerous. If the
engine has been running, parts of the
engine compartment can become very
hot. You could be burned. Carefully
inspect the engine coolant in the
coolant reservoir, but do not open it.

Switch the ignition to off and make
sure the fan is not running before
attempting to work near the cooling
fan: Working near the cooling fan when it
is running is dangerous. The fan could
continue running indefi nitely even if
the engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.

Do not remove either cooling
system cap when the engine and
radiator are hot: When the engine and radiator are hot,
scalding coolant and steam may shoot
out under pressure and cause serious
injury.
NOTE
Changing the coolant should be done by
an Authorized Mazda Dealer.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.6–69
Maintenance and Care
Appearance Care
WARNING
Dry off brakes that have become
wet by driving slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the brake
performance returns to normal: Driving with wet brakes is dangerous.
Increased stopping distance or the
vehicle pulling to one side when
braking could result in a serious
accident. Light braking will indicate
whether the brakes have been aff ected.
Aluminum Wheel Maintenance *
A protective coating is provided over the
aluminum wheels. Special care is needed
to protect this coating.
CAUTION
Do not use any detergent other than
mild detergent. Before using any
detergent, verify the ingredients.
Otherwise, the product could discolor
or stain the aluminum wheels.
NOTE
 y Do not use a wire brush or any abrasive
cleaner, polishing compound, or solvent
on aluminum wheels. They may damage
the coating.
 y Always use a sponge or soft cloth to
clean the wheels.
 Rinse the wheels thoroughly with lukewarm or cold water. Also, be sure
to clean the wheels after driving on
dusty or salted roads to help prevent
corrosion.
 y Avoid washing your vehicle in an
automatic car wash that uses high-
speed or hard brushes.
Plastic Part Maintenance
 y When cleaning the plastic lenses of the
lights, do not use gasoline, kerosene,
rectifi ed spirit, paint, thinner, highly
acidic detergents, or strongly alkaline
detergents. Otherwise, these chemical
agents can discolor or damage the
surfaces resulting in a signifi cant loss
in functionality. If plastic parts become
inadvertently exposed to any of these
chemical agents, fl ush with water
immediately.
 y  If plastic parts such as the bumpers
become inadvertently exposed to
chemical agents or fl uids such as
gasoline, oil, engine coolant, or battery
fl uid, it could cause discoloration,
staining, or paint peeling. Wipe off any
such chemical agents or fl uids using a
soft cloth immediately.
 y  High water temperature and high water
pressure car washers are available
depending on the type of high pressure
car washer device. If the car washer
nozzle is put too close to the vehicle or
aimed at one area for an extended period
of time, it could deform plastic parts or
damage the paint.
 y  Do not use wax containing compounds
(polish). Otherwise, it could result in
paint damage.
 y  In addition, do not use an electrical or
air tool to apply wax. Otherwise, the
frictional heat generated could result
in deformation of plastic parts or paint
damage.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










10–4
Index
F
Flasher Hazard warning ............................. 4-58
Headlights ..................................... 4-40
Flat Tire ................................................. 7-3 Mounting the Spare Tire................ 7-11
Removing a Flat Tire ....................... 7-7
Floor Mat ............................................ 3-46
Fluid Brake/Clutch ................................. 6-31
Washer ........................................... 6-31
Fluids Classifi cation ................................... 9-5
Fog Lights ........................................... 4-50
Foot Brake ........................................... 4-67
Forward Obstruction Warning
(FOW) ............................................... 4-115 Collision Warning ....................... 4-117
Forward Obstruction Warning (FOW)
Indicator Light (Red)................... 4-117
Rader Sensor ............................... 4-117
Forward Sensing Camera .................... 4-62
Front Seat .............................................. 2-5
Fuel Filler lid and cap............................ 3-30
Gauge ............................................ 4-14
Requirements................................. 3-27
Tank capacity .................................. 9-5
Fuel Consumption Display ................. 4-85
Fuel Economy Monitor ....................... 4-85 Control status display .................... 4-86
Ending screen display ................... 4-86
Fuel consumption display ............. 4-85
G
Gauges ................................................. 4-11
Glove Compartment .......................... 5-140
H
Hazard Warning Flasher ...................... 4-58
Hazardous Driving .............................. 3-46
Head Restraint ..................................... 2-11
Headlights Control........................................... 4-40
Flashing ......................................... 4-44
High-low beam .............................. 4-44
Leveling......................................... 4-44
High Beam Control System (HBC) .... 4-47
Hill Launch Assist (HLA) ................... 4-69
HomeLink Wireless Control System ... 4-58
Hood Release ...................................... 6-24
Horn .................................................... 4-57
I
i-ELOOP ............................................. 4-82 Control status display .................... 4-84
Display .......................................... 4-82
i-ELOOP indicator light ................ 4-84
i-ELOOP warning beep ....................... 7-37
If a Warning Light Turns On or
Flashes................................................. 7-24
If the Active Driving Display does not
operate ................................................. 7-41
Ignition Switch .............................................. 4-4
Ignition not switched off (STOP) warning
beep ..................................................... 7-36
Immobilizer System ............................ 3-41
Indicator Lights ................................... 4-23 AFS OFF ....................................... 4-45
BSM OFF .................................... 4-113
Low engine coolant temperature ... 4-25
Wrench .......................................... 4-25
Inside Trunk Release Lever ................ 3-25
Inspecting Brake/Clutch Fluid Level ... 6-31
Inspecting Coolant Level .................... 6-29
Inspecting Engine Oil Level ............... 6-28
Inspecting Washer Fluid Level............ 6-31
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC
