WA R N I N G
Never touch the glass portion of a halogen
bulb with your bare hands and always
wear eye protection when handling or
working around the bulbs:
When a halogen bulb breaks, it is
dangerous. These bulbs contain
pressurized gas. If one is broken, it will
explode and serious injuries could be
caused by the flying glass.
If the glass portion is touched with bare
hands, body oil could cause the bulb to
overheat and explode when lit.
Always keep halogen bulbs out of the reach
of children:
Playing with a halogen bulb is dangerous.
Serious injuries could be caused by
dropping a halogen bulb or breaking it
some other way.
CAUTION
When removing the lens or lamp unit using
a flathead screwdriver, make sure that the
flathead screwdriver does not contact the
interior terminal. If the flathead screwdriver
contacts the terminal, a short circuit may
occur.
NOTE
To replace the bulb, contact an
Authorized Mazda Dealer.
If the halogen bulb is accidentally
touched, it should be cleaned with
rubbing alcohol before being used.
Use the protective cover and carton for
the replacement bulb to dispose of the
old bulb promptly and out of the reach
of children.
▼Replacing Exterior Light Bulbs
Headlights (With LED headlights),
Daytime running lights/Parking lights
(With LED headlights), Fog lights*
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
Headlights (With halogen headlights)
Low-beam bulbs
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right, and turn
off engine.
2. Make sure the headlight switch is off.
3. Pull the center of each plastic retainer and remove the retainers.

Removal
Installation
Maintenance and Care
Owner Maintenance
*Some models.6-43
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

4. Turn the screw counterclockwise andremove it, and then partially peel back
the mudguard.

5. Disconnect the connector from the unitby pressing the tab on the connector
with your finger and pulling the
connector downward.

6. Turn the socket and bulb assembly to
remove it. Carefully remove the bulb
from its socket in the reflector by
gently pulling it straight backward out
of the socket.

7. Install the new bulb in the reverseorder of the removal procedure.
High-beam bulbs/Daytime running
lights
1. Make sure the ignition is switched off, and the headligh t switch is off.
2. Lift the hood.
3. Disconnect the connector from the unit by pressing the tab on the connector
with your finger and pulling the
connector downward.

Maintenance and Care
Owner Maintenance
6-44
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

4. Turn the socket and bulb assembly toremove it. Carefully remove the bulb
from its socket in the reflector by
gently pulling it straight backward out
of the socket.

5. Install the new bulb in the reverseorder of the removal procedure.
Front turn signal lig hts, Parking lights/
Front side-marker lights (With halogen
headlights), Front side-marker lights
(With LED headlights)
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right, and turn
off engine.
2. Make sure the headlight switch is off.
3. Pull the center of each plastic retainer and remove the retainers.

Removal
Installation
4. Turn the screw counterclockwise andremove it, and then partially peel back
the mudguard.

Maintenance and Care
Owner Maintenance
6-45
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

5.(Front turn signal lights)
Disconnect the connector from the unit
by pressing the tab on the connector
with your finger and pulling the
connector.

6. Turn the socket and bulb assembly
counterclockwise and remove it.
7. Disconnect the bulb from the socket.
Front turn signal lights

Parking lights/Front side-marker
lights (With halogen headlights),
Front side-marke r lights (With LED
headlights)

8. Install the new bulb in the reverse order of the removal procedure.
Side turn signal lights
*, Brake lights
(LED type), Taillights/Rear side-marker
lights (LED type), Ta illights (Trunk lid
side/Liftgate side), High-mount brake
light
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
Maintenance and Care
Owner Maintenance
6-46*Some models.
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Rear turn signal lights, Brake lights/
Taillights/Rear side-marker lights (Bulb
type)
4–Door
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Pull the center of each plastic retainer
and remove the retainers.
3. Remove trunk end trim.
InstallationRemoval
4. Pull the center of each plastic retainer
and remove the retainers.
5. Peel back the trunk side trim.
Removal
Installation
6. Turn the socket and bulb assembly counterclockwise and remove it.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

Maintenance and Care
Owner Maintenance
6-47
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

7. Disconnect the connector from the unitby pressing the tab on the connector
with your finger and pulling the
connector.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

8. Disconnect the bulb by pulling it out. Rear turn signal lig hts, Brake lights/
Taillights/Rear side-marker lights
(Bulb type)

Maintenance and Care
Owner Maintenance
6-48
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

9. Install the new bulb in the reverseorder of the removal procedure.
5–Door
(Left side)
1. Make sure the ignition is switched off, and the headlight switch is off.
2. Remove the cover.

3. Turn the socket and bulb assemblycounterclockwise and remove it.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

4. Disconnect the connector from the unit
by pressing the tab on the connector
with your finger and pulling the
connector.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

Maintenance and Care
Owner Maintenance
6-49
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

5. Disconnect the bulb by pulling it out.Rear turn signal lights, Brake lights/
Taillights/Rear side-marker lights
(Bulb type)

6. Install the new bulb in the reverseorder of the removal procedure.
7. Insert the cover tabs and install the cover.
Tabs
NOTE
Verify that the cover is securely
installed.
(Right side)
1. Make sure the ignition is switched off,and the headligh t switch is off.
2. Turn the knob and remove the cover.
3. Turn the wing bolt and jack screw
counterclockwise.

4. Remove the jack
5. Turn the socket and bulb assemblycounterclockwise and remove it.
Maintenance and Care
Owner Maintenance
6-50
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Rear turn signal lights

Brake lights/Taillights/Rear
side-marker lights (Bulb type)

6. Disconnect the connector from the unitby pressing the tab on the connector
with your finger and pulling the
connector.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

7. Disconnect the bulb by pulling it out. Rear turn signal lights, Brake lights/
Taillights/Rear side-marker lights
(Bulb type)

8. Install the new bulb.
9. Insert the wing bolt into the jack with
the jack screw pointing to the down
and turn the wing bolt clockwise to
temporarily tighten it.
Maintenance and Care
Owner Maintenance
6-51
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

10. Turn the jack screw in the directionshown in the figure.

11. Turn the wing bolt completely tosecure the jack.
NOTE
If the jack is not completely secured, it
could rattle while driving. Make sure
the jack screw is sufficiently tightened.
12. Install the cover in the reverse order of the removal procedure.
13. Insert the cover tabs and install the cover.
Tabs
NOTE
Verify that the cover is securely
installed.
Reverse lights
4–Door
1. Make sure the ignition is switched off,
and the headligh t switch is off.
2. Pull the center of each plastic retainer
and remove the retainers.
3. Peel back the trunk lid trim.

Removal
Installation
4. Disconnect the electrical connectorfrom the bulb by pressing the tab on
the connector with your finger and
pulling the connector.

5. Turn the socket and bulb assemblycounterclockwise and remove it.
Maintenance and Care
Owner Maintenance
6-52
