Interior Equipment (View D)
ƒSeat belts............................................................................................................... page 2-12
„ SRS air bag............................................................................................................page 2- 44
… Bottle holder.................................................. ..................................................... page 5-135
† Overhead lights...................................................................................................page 5-130
‡ Moonroof switch................................................................................................... page 3-38
ˆ Sunvisor....................................................... ....................................................... page 5-1 29
‰ Vanity mirror...................................................................................................... page 5-129
Š Rearview mirror................................................ .................................................... page 3-33
‹ Cup holders.................................................... .....................................................page 5-134
ΠFront seat................................................................................................................. page 2-5
Center console................................................. ................................................... page 5-136
Ž Accessory sockets............................................................................................... page 5-132
External input terminal........................................ .................................................. page 5-54
Rear seat...................................................... ............................................................ page 2-7
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-5
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Trunk button (4–door)
To open the trunk lid, press and hold the
trunk button until the trunk lid opens.
Panic button
If you witness from a distance someone
attempting to break into or damage your
vehicle, press and hold the panic button to
activate the vehicle's alarm. Call
emergency services if necessary.
NOTE
The panic button will work whether any
door or the liftgate/trunk lid is open or
closed.
(Turning on the alarm)
Pressing the panic button for 1 second or
more will trigger the alarm for about 2
minutes and 30 seconds, and the following
will occur:
The horn sounds intermittently.
The hazard warning lights flash.
(Turning off the alarm)
The alarm stops by pressing any button on
the key.
▼ Operational Range
The system operates only when the driver
is in the vehicle or
within operational
range while the key is being carried.
Starting the Engine
NOTE
Starting the engine may be possible even
if the key is outside of the vehicle and
extremely close to a door and window,
however, always start the engine from
the driver's seat.
If the vehicle is started and the key is not
in the vehicle, the vehicle will not restart
after it is shut off and the ignition is
switched to off.
The luggage compartment/trunk is out of
the assured operational range, however,
if the key (transmitter) is operable the
engine will start.
With the advanced keyless function

Interior antenna
Operational range
Before Driving
Keys
3-7
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

5Interior Features
Use of various features for ride comfort, including air-conditioning and
audio system.
Climate Control System.................... 5-2 Operating Tips.............................. 5-2
Vent Operation.............................. 5-3
Manual Climate Control............... 5-5
Automatic Climate Control.......... 5-9
Dual-Zone Automatic Climate
Control........................................ 5-12
Audio System................................... 5-16 Antenna.......................................5-16
Operating Tips for Audio
System........................................ 5-17
Audio set [Type A (non-
touchscreen)].............................. 5-26
Audio set [Type B
(touchscreen)]............................. 5-32
Audio Control Switch Operation
*.....
.................................................... 5-53
AUX/USB mode.........................5-54
Bluetooth®....................................... 5-69
Bluetooth
®*................................ 5-69
Bluetooth
® Hands-Free (Type
A)
*.............................................. 5-94
Bluetooth
® Hands-Free (Type
B)
*............................................ 5-101
Bluetooth
® Audio (Type A)*.... 5-111
Bluetooth
® Audio (Type B)*.... 5-114
Troubleshooting
*...................... 5-125
Interior Equipment....................... 5-129 Sunvisors.................................. 5-129
Interior Lights...........................5-130
Accessory Sockets.................... 5-132
Cup Holder............................... 5-134
Bottle Holder............................ 5-135
Storage Compartments............. 5-136
*Some models.5-1
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Interior Lights
NOTE
Do not leave the lights on for long periods
while the engine is turned off. Otherwise
the battery power could be depleted.
Overhead Lights
Switch Posi-tion Overhead Lights
Light off
Light is on when any door is openLight is on or off
when the illumi-
nated entry system is on
Light on
With Map Lights
Front
Rear
Without Map Lights
NOTE
(With map lights)
The rear overhead light also turn on and
off when the front o verhead light switch is
operated.
Map Lights
*
When the overhead light switch is in the
door or off position, press the lens to
illuminate the map lights, and then press
the lens again to turn them off.
NOTE
The map lights will not turn off even if the
lens is pressed in the following cases:
The overhead light switch is in the ON
position.
The overhead light switch is in the door
position with the door open.
The illuminated entry system is on.
Interior Features
Interior Equipment
5-130*Some models.
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Luggage Compartment Lights (5–door)
Switch Posi-tion Luggage Compartment Light
Light off
Light on when the liftgate is open
Trunk Light (4–door)
The trunk light is on when the lid is open
and off when it's closed.
NOTE
To prevent the battery from being
discharged, do not leave the trunk open
for a long period when the engine is not
running.
▼
Illuminated Entry System
The overhead lights turn on when any of
the following operations is done with the
overhead light switch in the DOOR
position.
The driver's door is unlocked with the
ignition is switched OFF.
The ignition is sw
itched OFF with all
doors closed.
NOTE
The illumination tim e differs depending
on the operation.
Battery saver
If an interior light is left on with the
ignition switched OFF, the light is
turned off automatically after about 30
minutes to prevent battery depletion.
The operation of the illuminated entry
system can be changed.
Refer to Personalization Features on
page 9-12.
Interior Features
Interior Equipment
5-131
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

WA R N I N G
Never touch the glass portion of a halogen
bulb with your bare hands and always
wear eye protection when handling or
working around the bulbs:
When a halogen bulb breaks, it is
dangerous. These bulbs contain
pressurized gas. If one is broken, it will
explode and serious injuries could be
caused by the flying glass.
If the glass portion is touched with bare
hands, body oil could cause the bulb to
overheat and explode when lit.
Always keep halogen bulbs out of the reach
of children:
Playing with a halogen bulb is dangerous.
Serious injuries could be caused by
dropping a halogen bulb or breaking it
some other way.
CAUTION
When removing the lens or lamp unit using
a flathead screwdriver, make sure that the
flathead screwdriver does not contact the
interior terminal. If the flathead screwdriver
contacts the terminal, a short circuit may
occur.
NOTE
To replace the bulb, contact an
Authorized Mazda Dealer.
If the halogen bulb is accidentally
touched, it should be cleaned with
rubbing alcohol before being used.
Use the protective cover and carton for
the replacement bulb to dispose of the
old bulb promptly and out of the reach
of children.
▼Replacing Exterior Light Bulbs
Headlights (With LED headlights),
Daytime running lights/Parking lights
(With LED headlights), Fog lights*
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
Headlights (With halogen headlights)
Low-beam bulbs
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the left, and turn off engine.
If you are changing the left bulb, turn
the steering wheel to the right, and turn
off engine.
2. Make sure the headlight switch is off.
3. Pull the center of each plastic retainer and remove the retainers.

Removal
Installation
Maintenance and Care
Owner Maintenance
*Some models.6-43
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Replacing Interior Light Bulbs
Overhead lights (F
ront)/Map lights*,
Overhead lights (Front)*, Overhead
lights (Rear)*, Vanity mirror lights*
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with the flathead screwdriver.
2. Disconnect the bulb by pulling it out.
Overhead lights (F ront)/Map lights
*


Overhead lights (Front)*

Edge
Overhead lights (Rear)*

Edge
Vanity mirror lights*

3. Install the new bulb in the reverse
order of the removal procedure.
Maintenance and Care
Owner Maintenance
*Some models.6-55
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Light bulbCategory
Wa t t ag e UNECE*1 (SAE)
Reverse lights 4–Door 18 W16W (921)
5–Door 21 W21W (7440)
License plate lights 5 W5W (―)
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.
Interior light
Light bulb Category
Wat tage UNECE*1
Trunk light (4–Door) 3―
Luggage compartment light (5–Door) 5―
Overhead lights (Front)/Map lights
*8―
Overhead light (Front)
*10 ―
Overhead light (Rear)
*10 ―
Vanity mirror lights
*2―
*1 UNECE stands for United Nations Economic Commission for Europe.
▼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label fo
r tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 6-38.
After adjusting the tire pressur e, initialization of the tire pressure monitoring system is
necessary to make the system operates normally.
Refer to Tire Pressure Monitorin g System Initialization on page 4-148.
Standard tire
(U.S.A. and Canada)
Tire size Inflation pressure
Front Rear
P205/60R16 91H 250 kPa (36 psi)250 kPa (36 psi)
215/45R18 89W 250 kPa (36 psi)250 kPa (36 psi)
Specifications
Specifications
9-10*Some models.
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

ItemFeatureFactory Set-
ting Available Set-
tings Settings
Change
Method
Advanced key-
less entry system
(page 3-9) Method for unlocking door using request
switch/transmitter
Driver's:
Once, All
Doors: Twice Touch Once: All
Doors/
Once: Driver's, Twice: AllDoors A
E,
FTime for locking door automatically 60 seconds90 seconds/
60 seconds/
30 seconds A―
Auto-lock function operation/non-operational Off On/Off A ―
Beep volume when locking/unlocking
MediumHigh/
Medium/ Low/Off A
E,
F
Illuminated en-
try system (page
5-131) Time until interior lights turn off after closing
door
15 seconds60 seconds/
30 seconds/
15 seconds/
7.5 seconds A―
Time until interior lights turn off automatically
when any door is not closed completely
30 minutes60 minutes/
30 minutes/
10 minutes A―
Auto-wiper con-
trol (page 4-49)
Operational/non-operational On
On/Off*4A―
Daytime running
lights (page 4-
47)Operational/non-operational On On/Off ― ―
Auto headlight
off*5 (page 4-43)
Time until headlights turn off 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/
0 seconds
*6
A―
Auto-light con-
trol (page 4-43) Timing by which lig
hts turn on Medium Light/
Medium Light/ Medium/
Medium Dark/ Dark A―
High Beam Con-
trol System
(HBC) (page
4-81)
Operational/non-operational
*1On On/Off A ―
Specifications
Personalization Features
9-15
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Index
Inspecting Engine Oil Level............. 6-24
Inspecting Washer Fluid Level......... 6-27
Interior Care...................................... 6-69Active driving display
maintenance................................. 6-71
Cleaning the floor mats............... 6-72
Cleaning the window interiors.....6-71
Instrument panel top (Soft pad)
maintenance................................. 6-71
Leather upholstery
maintenance................................. 6-70
Panel maintenance....................... 6-71
Plastic part maintenance.............. 6-71
Seat belt maintenance..................6-69
Upholstery and synthetic leather
maintenance................................. 6-70
Vinyl upholstery maintenance..... 6-69
Interior Lights................................. 5-130 Luggage Compartment Light.....5-130
Map Lights................................ 5-130
Overhead Lights........................ 5-130
i-ACTIVSENSE................................ 4-77
Active safety tec hnology............. 4-77
Adaptive Front Lighting System
(AFS)........................................... 4-80
Blind Spot Monitoring (BSM).....4-84
Camera and sensors..................... 4-78
Distance Recognition Support System
(DRSS).........................................4-96
Forward Sensing Camera
(FSC)......................................... 4-131
High Beam Control System
(HBC).......................................... 4-81
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-113
Mazda Radar Cruise Control
(MRCC)..................................... 4-102
Pre-crash safety technology.........4-78
Radar sensors (rear)...................4-139
Radar sensor (front)...................4-136Rear Cross Traffic Alert
(RCTA)........................................ 4-98
Smart Brake Support (SBS)...... 4-128
Smart City Brake Support
(SCBS)....................................... 4-124
Traffic Sign Recognition System
(TSR)........................................... 4-90
i-ELOOP............................................4-70 Control status display.................. 4-70
Display......................................... 4-70
i-ELOOP indicator l ight.............. 4-70
i-ELOOP warning beep .....................7-40
J
Jack...................................................... 7-4
Jump-Starting.................................... 7-16
K
Keyless Entry System......................... 3-3
Keys.....................................................3-2
Key suspend function.................... 3-8
Transmitter.............. .......................3-4
Key left-in-luggage compartment
warning beep (With the advanced keyless
function)............................................ 7-40
Key left-in-vehicle warning beep (With
the advanced keyless function)......... 7-40
Key removed from vehicle warning
beep................................................... 7-39
Key Suspend Function........................ 3-8
L
Label Information............................... 9-2
Lane Departure Warning sound........ 7-40
Lane-Change Signals........................ 4-49
Lane-keep Assist System (LAS) & Lane
Departure Warning System
(LDWS)........................................... 4-113
Leaving Home Light......................... 4-47
Liftgate.............................................. 3-20
10-5
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
