Page 131 of 524
4–5
When Driving
Start/Stop Engine
CAUTION
If the KEY warning light (red)
illuminates, or the push button
start indicator light (amber) fl ashes,
this could indicate a problem with
the engine starting system and the
inability to start the engine or switch
the ignition to ACC or ON. Have your
vehicle inspected at an Authorized
Mazda Dealer as soon as possible.
NOTE
y Under the following conditions, the
KEY warning light (red) fl ashes after
the push button start is pressed to
inform the driver that the push button
start will not switch to ACC even if it is
pressed from off.
y The key battery is dead. y The key is out of operational range. y The key is placed in areas where it is
diffi cult for the system to detect the
signal (page 3-7 ).
y A key from another manufacturer
similar to the key is in the
operational range.
y (Forced engine starting method) If the KEY warning light (red)
illuminates, or the push button start
indicator light (amber) fl ashes, this
could indicate that the engine may not
start using the usual starting method.
Have your vehicle inspected at an
Authorized Mazda Dealer as soon as
possible. If this occurs, the engine can
be force-started. Press and hold the
push button start until the engine starts.
Other procedures necessary for starting
the engine such as having the key in the
cabin, and depressing the clutch pedal
(manual transaxle) or the brake pedal
(automatic transaxle) are required.
y When the engine is force-started,
the KEY warning light (red) remains
illuminated and the push button
start indicator light (amber) remains
fl ashing.
y (Automatic transaxle) When the selector lever is in the neutral
(N) position, the KEY indicator light
(green) and the push button start
indicator light (green) do not illuminate.
7. Press the push button start after both the KEY indicator light (green) in the
instrument cluster and the push button
start indicator light (green) illuminate.
NOTE
y After starting the engine, the push
button start indicator light (amber)
turns off and the ignition switches to the
ON position.
y After pressing the push button start and
before the engine starts, the operation
sound of the fuel pump motor from near
the fuel tank can be heard, however, this
does not indicate a malfunction.
8. After starting the engine, let it idle for about ten seconds.
NOTE
y Whether the engine is cold or warm, it
should be started without the use of the
accelerator.
y If the engine does not start the fi rst
time, refer to Starting a Flooded Engine
under Emergency Starting. If the engine
still does not start, have your vehicle
inspected by an Authorized Mazda
Dealer (page 7-18 ).
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 132 of 524
4–6
When Driving
Start/Stop Engine
Engine Start Function When Key Battery is Dead
CAUTION
When starting the engine by holding
the transmitter over the push button
start due to a dead key battery or a
malfunctioning key, be careful not
to allow the following, otherwise the
signal from the key will not be received
correctly and the engine may not start.
Page 133 of 524
4–7
When Driving
Start/Stop Engine
NOTE
y The engine cannot be started unless the
clutch pedal is fully depressed (manual
transaxle) or the brake pedal is fully
depressed (automatic transaxle).
y If there is a malfunction with the push
button start function, the push button
start indicator light (amber) fl ashes.
In this case, the engine may start,
however, have the vehicle checked at an
Authorized Mazda Dealer as soon as
possible.
y If the push button start indicator light
(green) does not illuminate, perform the
operation from the beginning again. If
it does not illuminate, have the vehicle
checked at an Authorized Mazda Dealer.
y To switch the ignition position without
starting the engine, perform the
following operations after the push
button start indicator light (green) turns
on. 1. Release the clutch pedal (manual transaxle) or brake pedal (automatic
transaxle).
2. Press the push button start to switch the ignition position. The ignition
switches in the order of ACC, ON,
and off each time the push button
start is pressed. To switch the
ignition position again, perform the
operation from the beginning.
Emergency Operation for Starting the Engine
If the KEY warning light (red) illuminates,
or the push button start indicator light
(amber) fl ashes, this could indicate that
the engine may not start using the usual
starting method. Have your vehicle
inspected at an Authorized Mazda Dealer
as soon as possible. If this occurs, the
engine can be force-started. Press and hold
the push button start until the engine starts.
Other procedures necessary for starting the
engine such as having the key in the cabin,
and depressing the clutch pedal (manual
transaxle) or the brake pedal (automatic
transaxle) are required.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 134 of 524
4–8
When Driving
Start/Stop Engine
Turning the Engine Off
WARNING
Do not stop the engine while the vehicle
is moving: Stopping the engine while the vehicle
is moving for any reason other than in
an emergency is dangerous. Stopping
the engine while the vehicle is moving
will result in reduced braking ability
due to the loss of power braking, which
could cause an accident and serious
injury.
1. Stop the vehicle completely.
2. (Manual transaxle)
Shift into neutral and set the parking brake.
(Automatic transaxle)
Shift the selector lever to the P position and set the parking brake.
3. Press the push button start to turn off the engine. The ignition position is off.
CAUTION
When leaving the vehicle, make sure
the push button start is off .
NOTE
y The cooling fan in the engine
compartment could turn on for a few
minutes after the ignition is switched
from ON to OFF, whether or not the
A/C is on or off, to cool the engine
compartment quickly.
y When the push button start is pressed
from ON to ACC or OFF, the KEY
indicator light (green) may fl ash for
approximately 30 seconds indicating
that the remaining battery power of the
key is low.
Replace with a new battery before the key becomes unusable.
Refer to Battery Replacement on page 6-38 .
y (Automatic transaxle) If the engine is turned off while the
selector lever is in a position other than
P, the ignition switches to ACC.
Emergency Engine Stop
Continuously pressing the push button
start or quickly pressing it any number of
times while the engine is running or the
vehicle is being driven will turn the engine
off immediately. The ignition switches to
ACC.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 135 of 524
4–9
When Driving
Instrument Cluster and Display
Meters and Gauges
Type A
Type B
Steering Switc h ( W ith Tac hom eter)
( W ithou t Tac hom eter)
Som e m odels.
Instrum ent C lust er
Speedometer ............................................................\
.............................................. page
4-10
Odometer, Trip Meter and Trip Meter Selector .................................................... page 4-10
Tachometer ..............................................................\
.............................................. page 4-11
Fuel Gauge ........................................................................\
.................................... page 4-12
Dashboard Illumination..................................................\
....................................... page 4-12
Outside Temperature Display ........................................................................\
........ page 4-13
Cruise Control Set Vehicle Speed Display ............................................................ page 4-14
Trip Computer and INFO Switch ........................................................................\
.. page 4-14
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 136 of 524
4–10
When Driving
Instrument Cluster and Display
Speedometer
The speedometer indicates the speed of the
vehicle.
Odometer, Trip Meter and Trip Meter Selector
The display mode can be changed from
odometer to trip meter A to trip meter B
and then back to odometer by pressing the
selector while one of them is displayed.
The selected mode will be displayed.
Type A
Pr ess the selector
Pr ess the selector
Pr ess the selector
Odome ter
Trip m eter A
Trip m eter B
Type B
P r ess the selector
P r ess the selector
P r ess the selector
Odom eter
Tr ip m eter A
Tr ip m eter B
NOTE
When the ignition is switched to ACC or
off, the odometer or trip meters cannot be
displayed, however, pressing the selector
can inadvertently switch the trip meters or
reset them during an approximate ten-
minute period in the following cases:
y
After the ignition is switched to off from
ON.
y After the driver's door is opened.
Odometer
The odometer records the total distance
the vehicle has been driven.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 137 of 524
*Some models.4–11
When Driving
Instrument Cluster and Display
Trip meter
The trip meter can record the total distance
of two trips. One is recorded in trip meter
A, and the other is recorded in trip meter
B.
For instance, trip meter A can record the
distance from the point of origin, and
trip meter B can record the distance from
where the fuel tank is fi lled.
When trip meter A is selected, pressing
the selector again within one second will
change to trip meter B mode.
When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
The trip meter records the total distance
the vehicle is driven until the meter
is again reset. Return it to “0.0” by
depressing and holding the selector for
one second or more. Use this meter to
measure trip distances and to compute fuel
consumption. NOTE
y (Vehicles with type B audio) If the fuel economy data is reset using
the fuel economy monitor, or trip A
is reset using the trip meter when the
function which synchronizes the fuel
economy monitor and the trip meter is
on, the fuel economy data and trip A are
reset simultaneously.
Refer to Fuel Economy Monitor on page 4-54 .
y Only the trip meters record tenths of
kilometers (miles).
y The trip record will be erased when:
y The power supply is interrupted
(blown fuse or the battery is
disconnected).
y The vehicle is driven over 9999.9 km
(mile).
Tachometer *
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the
tachometer needle in the RED ZONE.
This may cause severe engine damage.
*1The r ange va r ies depending on the type
of gauge. *
1Str iped z one
*
1Red z one
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 138 of 524
4–12
When Driving
Instrument Cluster and Display
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
Fuel Gauge
The fuel gauge shows approximately
how much fuel is remaining in the tank
when the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Type A
Full1/4 Full
Type B
Full1/4 Full
If the low fuel warning light illuminates or
the fuel level is very low, refuel as soon as
possible.
Refer to Warning/Indicator Lights on page
4-16 .
NOTE
y After refueling, it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve since
the fuel moves in the tank.
y The display indicating a quarter or less
remaining fuel has more segments to
show the remaining fuel level in greater
detail.
y The direction of the arrow () indicates
that the fuel-fi ller lid is on the left side
of the vehicle.
Dashboard Illumination
Rotate the knob to adjust the brightness
of the instrument cluster and other
illuminations in the dashboard.
NOTE
y The brightness of dashboard
illuminations can be adjusted when
the headlights and Parking lights are
turned on.
y When the dashboard illumination
brightness cannot be adjusted any more,
a beep sound will be heard.
D im
Br ight
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 139 of 524
*Some models.4–13
When Driving
Instrument Cluster and Display
Canceling the illumination dimmer
When the headlight switch is in the
or
position, the illumination of the
instrument cluster dims.
When driving on snowy or foggy roads,
or in other situations when the instrument
cluster's visibility is reduced due to glare
from surrounding brightness, cancel the
illumination dimmer and increase the
illumination intensity.
To cancel the illumination dimmer, rotate
the knob clockwise fully. You will hear a
beep sound and the illumination dimmer
will be canceled.
NOTE
y This symbol () indicates the knob to
adjust the brightness of the dashboard
illumination.
y If the dashboard illumination knob is
kept at the illumination dimmer cancel
position, the instrument cluster will not
dim when the headlight switch is turned
to the
or position again. Rotate
the dashboard illumination knob
counterclockwise to activate the
illumination dimmer.
Outside Temperature Display *
When the ignition is switched ON, the
outside temperature is displayed.
NOTE
Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and vehicle
conditions:
y Signifi cantly cold or hot
temperatures.
y Sudden changes in outside
temperature.
y The vehicle is parked. y The vehicle is driven at low speeds.
The outside temperature unit can be
switched between Celsius and Fahrenheit
using the following procedure.
1. Press the INFO button with the ignition switched off and continue pressing the
INFO button for 5 seconds or longer
while switching the ignition ON. The
outside temperature display fl ashes.
2. Press the up
or down part of the
INFO switch to change the outside
temperature unit.
3. Press and hold the INFO button for 3 seconds or longer while the outside
temperature display is fl ashing. The
outside temperature display illuminates.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 140 of 524
*Some models.4–14
When Driving
Instrument Cluster and Display
Cruise Control Set Vehicle Speed Display*
The vehicle speed preset using the cruise
control is displayed.
Trip Computer and INFO Switch *
The following information can be selected
by pressing the up
or down part of the
INFO switch with the ignition switched
ON.
y Approximate distance you can travel on
the available fuel
y Average fuel economy y Current fuel economy y Average vehicle speed
If you have any problems with your trip
computer, consult an Authorized Mazda
Dealer.
Distance-to-empty mode
This mode displays the approximate
distance you can travel on the remaining
fuel based on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.
NOTE
y Even though the distance-to-empty
display may indicate a suffi cient amount
of remaining driving distance before
refueling is required, refuel as soon as
possible if the fuel level is very low or
the low fuel warning light illuminates.
y The display may not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
y The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
(indicating the remaining fuel supply)
disappear.
Average fuel economy mode
This mode displays the average fuel
economy by calculating the total fuel
consumption and the total traveled
distance since purchasing the vehicle, re-
connecting the battery after disconnection,
or resetting the data. The average fuel
economy is calculated and displayed every
minute.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - L/100
km (- - - mpg) will be displayed for about
1 minute before the fuel economy is
recalculated and displayed.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
