MAZDA MODEL 3 5-DOOR 2014 Owners Manual

4–15
When Driving
Instrument Cluster and Display
Current fuel economy mode
This mode displays the current fuel
economy by calculating the amount of fuel
consumption and the distance traveled.
Current fuel economy will be calculated
and displayed every 2 seconds.
When you've slowed to about 5 km/h (3
mph), - - - L/100 km (- - - mpg) will be
displayed.
Average vehicle speed mode
This mode displays the average vehicle
speed by calculating the distance and the
time traveled since connecting the battery
or resetting the data.
Average vehicle speed will be calculated
and displayed every 10 seconds.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - km/h
(- - - mph) will be displayed for about
1 minute before the vehicle speed is
recalculated and displayed.
.B[EB@%$&""@&EJUJPOJOEC







4–16
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifi cations.
War ning/I ndicator lights will appear in any of the highlighted ar eas
Type A
Type B
C enter of D ashboar d ( W ith Tac hom eter)
( W ithou t Tac hom eter)
Instrum ent C lust er
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–17
When Driving
Instrument Cluster and Display
Warning Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Warning Lights Page
Master Warning Light *1 7-24
Brake System Warning Light *1*2 7-24
ABS Warning Light *1 7-24
Charging System Warning Light *1 7-24
Engine Oil Warning Light *1 7-24
Check Engine Light *1 7-24
(Red) High Engine Coolant Temperature Warning Light
*1
7-24
* Automatic Transaxle Warning Light *1 7-24
Power Steering Malfunction Indicator Light *1 7-24
Air Bag/Front Seat Belt Pretensioner System Warning Light *1 7-24
Low Fuel Warning Light 7-24
Check Fuel Cap Warning Light *1 7-24
Seat Belt Warning Light 7-24
Door-Ajar Warning Light 7-24
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–18
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light
7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–19
When Driving
Instrument Cluster and Display
Indicator Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Indicator Lights Page
* BSM OFF Indicator Light 4-71
(Green) KEY Indicator Light
3-9
Wrench Indicator Light *1 4-20
TCS/DSC Indicator Light *1 4-51 ,
4-52
DSC OFF Indicator Light *1 4-53
(Blue) Low Engine Coolant Temperature Indicator Light
4-20
* Shift Position Indication 4-25
Headlight High-Beam Indicator Light 4-36 ,
4-36
Turn Signal/Hazard Warning Indicator Lights 4-38 ,
4-45
Security Indicator Light *1 3-42
(Amber)
* Cruise Main Indicator Light 4-58
(Green)
* Cruise Set Indicator Light 4-58
.B[EB@%$&""@&EJUJPOJOEC







4–20
When Driving
Instrument Cluster and Display
Signal Indicator Lights Page
Lights-On Indicator Light 4-33
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
Wrench Indicator Light
When the ignition is switched ON, the
wrench indicator light is illuminated and
then turns off after a few seconds.
The wrench indicator light is illuminated
when the preset maintenance period
arrives. Verify the content and perform
maintenance.
Refer to Maintenance Monitor on page
6-20 .
Low Engine Coolant Temperature Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after the engine is warm.
If the low engine coolant temperature
indicator light remains illuminated after
the engine has been suffi ciently warmed
up, the temperature sensor could have
a malfunction. Consult an Authorized
Mazda Dealer.
.B[EB@%$&""@&EJUJPOJOEC







4–21
When Driving
Transaxle
Manual Transaxle
Operation
Manual Transaxle Shift Pattern
N eutr al position
The shift pattern of the transaxle is
conventional, as shown.
Depress the clutch pedal all the way down
while shifting; then release it slowly.
Your vehicle is equipped with a device to
prevent shifting to R (reverse) by mistake.
Push the shift lever downward and shift
to R.
WARNING
Do not use sudden engine braking on
slippery road surfaces or at high speeds: Shifting down while driving on wet,
snowy, or frozen roads, or while driving
at high speeds causes sudden engine
braking, which is dangerous. The
sudden change in tire speed could
cause the tires to skid. This could
lead to loss of vehicle control and an
accident.

Always leave the shift lever in 1 or R
position and set the parking brake when
leaving the vehicle unattended: Otherwise the vehicle could move and
cause an accident.
CAUTION


*Some models.4–22
When Driving
Transaxle
NOTE
 y(For vehicles with type B instrument
cluster*1 ) If the engine speed is about to exceed
the permissible engine speed, the buzzer
sounds.
 Refer to Over Rev. Buzzer on page 7-36 .
*1 To determine which instrument cluster is equipped on your Mazda,
Refer to Meters and Gauges on page
4-9 .
 y If shifting to R is diffi cult, shift back into
neutral, release the clutch pedal, and try
again.
Gear Shift Indication *
The gear shift indication supports you to
obtain optimum fuel economy and smooth
driving. It displays the selected gear
position in the instrument cluster as well
as notifi es the driver to change to the most
suitable gear position corresponding to the
actual driving condition.
Selected gear position Suitable gear position
Indication Condition
Numeral The selected gear position is
displayed.
and numeral Shift up or down to the indicated
gear position is recommended.
CAUTION
Do not rely solely on the shift-up/
shift-down recommendations by
indications. The actual driving
situation might require shift operations
diff erent from indication. To avoid the
risk of accidents, the road and traffi
c
conditions have to be judged correctly
by the driver before shifting.
NOTE
The gear shift indicator turns off when the
following operations are performed.
 y  The vehicle is stopped. y The vehicle is put in neutral. y The vehicle is driven in reverse. y The clutch is not fully engaged when
accelerating from a stop.
 y The clutch pedal remains depressed for
2 seconds or longer while driving.
Recommendations for Shifting (for Vehicles without Gear Shift
Indication)
Upshifting
For normal acceleration, Mazda
recommends these shift points:
Gear Vehicle speed
1 to 2 24 km/h (15 mph)
2 to 3 42 km/h (26 mph)
3 to 4 60 km/h (37 mph)
4 to 5 75 km/h (46 mph)
5 to 6 79 km/h (49 mph)
.B[EB@%$&""@&EJUJPOJOEC







4–23
When Driving
Transaxle
For cruising, Mazda recommends these
shift points:
Gear Vehicle speed
1 to 2 13 km/h (8 mph)
2 to 3 29 km/h (18 mph)
3 to 4 49 km/h (30 mph)
4 to 5 63 km/h (39 mph)
5 to 6 70 km/h (43 mph)
Downshifting
When you must slow down in heavy traffi c
or on a steep upgrade , downshift before
the engine starts to overwork. This reduces
the chance of stalling and gives better
acceleration when you need more speed.
On a steep downgrade , downshifting
helps maintain safe speed and prolongs
brake life.
.B[EB@%$&""@&EJUJPOJOEC







4–24
When Driving
Transaxle
Automatic Transaxle Controls
Lock-r elease button
I ndicates the shift leve r can be shifted fr eely into any position.
I ndicates that you m ust hold in the lock-r elease button to shift.
I ndicates that you m ust depr ess the br ake pedal and hold in the lock-r elease
button to shift ( The ignition m ust be switched ON ) .
V a rious L oc k ou t s:
NOTE
The Sport AT has an option that is not included in the traditional automatic transax\
le that
gives the driver the option of selecting each gear instead of leaving it\
to the transaxle to
shift gears. Even if you intend to use the automatic transaxle functions\
as a traditional
automatic, you should also be aware that you can inadvertently shift into manual shift mode
and an inappropriate gear may be retained as the vehicle speed increases. If you notice the
engine speed going higher or hear the engine racing, confi rm you have not accidentally
slipped into manual shift mode (page 4-27 ).
