Page 81 of 524
3–7
Before Driving
Keys
Panic button
If you witness from a distance someone
attempting to break into or damage your
vehicle, press and hold the panic button to
activate the vehicle's alarm.
NOTE
The panic button will work whether any
door or the liftgate/trunk lid is open or
closed.
(Turning on the alarm)
Pressing the panic button for 1 second or
more will trigger the alarm for about 2
minutes and 30 seconds, and the following
will occur:
y The horn sounds intermittently. y The hazard warning lights fl ash.
(Turning off the alarm)
The alarm stops by pressing any button on
the key.
Operational Range
The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.
Starting the Engine
NOTE
y Starting the engine may be possible
even if the key is outside of the vehicle
and extremely close to a door and
window, however, always start the
engine from the driver's seat.
If the vehicle is started and the key is not in the vehicle, the vehicle will not
restart after it is shut off and the push
button start is switched to off.
y The luggage compartment/trunk is
out of the assured operational range,
however, if the key (transmitter) is
operable the engine will start.
With the advanced keyless function
I nter ior antenna
Oper ational r ange
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 82 of 524
3–8
Before Driving
Keys
Without the advanced keyless function
Oper ational r ange
I nter ior antenna
NOTE
The engine may not start if the key is
placed in the following areas:
y Around the dashboard y In the storage compartments such as the
glove compartment
y On the rear parcel shelf (4–door)
Key Suspend Function
If a key is left in the vehicle, the
functions of the key left in the vehicle are
temporarily suspended to prevent theft of
the vehicle.
The following are inoperable:
y Starting the engine using the push button
start.
y (With the advanced keyless function) Operating the request switches.
To restore these functions, perform any
one of the following:
y Press a button on the key which has had
its functions temporarily suspended.
y (Manual transaxle) When carrying another key, depress the
clutch pedal until the KEY indicator
light (green) illuminates.
(Automatic transaxle) When carrying another key, depress the brake pedal until the KEY indicator light
(green) illuminates.
Refer to Warning/Indicator Lights on page 4-16 .
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 83 of 524
*Some models.3–9
Before Driving
Advanced Keyless Entry System
Advanced Keyless Entry
System
*
WARNING
Radio waves from the key may aff ect
medical devices such as pacemakers: Before using the key near people who
use medical devices, ask the medical
device manufacturer or your physician
if radio waves from the key will aff ect
the device.
The advanced keyless function allows you
to lock/unlock the doors and liftgate, or
open the liftgate/trunk lid while carrying
the key without using the key.
System malfunctions or warnings are
indicated by the following warning beeps.
y Request switch Inoperable Warning
Beep
Refer to Request Switch Inoperable Warning Beep (With the advanced
keyless function) on page 7-35 .
y Key Left-in-luggage Compartment/
Trunk Warning Beep
Refer to Key Left-in-luggage Compartment Warning Beep (With the
advanced keyless function) on page 7-
35.
y Key Left-in-vehicle Warning Beep Refer to Key Left-in-vehicle Warning
Beep (With the advanced keyless
function) on page 7-36 .
NOTE
The advanced keyless entry system
functions can be deactivated to prevent
any possible adverse effect on a user
wearing a pacemaker or other medical
device. If the system is deactivated, you
will be unable to start the engine by
carrying the key. Consult an Authorized
Mazda Dealer for details. If the advanced
keyless entry system has been deactivated,
you can start the engine by following the
procedure indicated when the key battery
goes dead.
Refer to Engine Start Function When Key
Battery is Dead on page 4-6 .
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 84 of 524
3–10
Before Driving
Advanced Keyless Entry System
Operational Range
The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.
NOTE
When the battery power is low, or in
places where there are high-intensity radio
waves or noise, the operational range may
become narrower or the system may not
operate.
Locking, Unlocking the Doors and the Liftgate
Ext er ior antenna
Locking only
( 5- door )
Oper ational r ange 80c m ( 31i n)
80c m ( 31i n)
NOTE
The system may not operate if you are too
close to the windows or door handles, or
liftgate.
Opening the Liftgate/Trunk Lid
E xt er ior antenna
Oper ational r ange 80c m ( 31i n)
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 85 of 524
3–11
Before Driving
Doors and Locks
Door Locks
WARNING
Always take all children and pets with
you or leave a responsible person with
them: Leaving a child or a pet unattended in
a parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle
can become high enough to cause
brain damage or even death.
Do not leave the key in your vehicle with
children and keep them in a place where
your children will not fi nd or play with
them: Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed.
Keep all doors locked when driving: Unlocked doors in a moving vehicle
are dangerous. Passengers can fall out
if a door is accidentally opened and
can more easily be thrown out in an
accident.
Always close all the windows and
moonroof, lock the doors and take the
key with you when leaving your vehicle
unattended: Leaving your vehicle unlocked is
dangerous as children could lock
themselves in a hot vehicle, which
could result in death. Also, a vehicle left
unlocked becomes an easy target for
thieves and intruders.
After closing the doors, always verify
that they are securely closed:
Doors not securely closed are
dangerous, if the vehicle is driven with
a door not securely closed, the door
could open unexpectedly resulting in
an accident.
Always confi rm the safety around the
vehicle before opening a door: Suddenly opening a door is dangerous.
A passing vehicle or a pedestrian could
be hit and cause an accident.
NOTE
y When the ignition is switched to ACC
or ON, the vehicle lock-out prevention
feature prevents you from locking
yourself out of the vehicle.
All doors and the liftgate will automatically unlock if they are locked
using the power door locks with any
door open.
The vehicle lock-out prevention feature does not operate while the ignition is
switched off.
When any door is opened from the outside while the key is inside the
vehicle, the closed doors are locked. All
the doors are automatically unlocked by
closing the open door.
(With the advanced keyless function) The beep sound is heard for about 10 seconds to notify the driver that the key
has been left in the vehicle.
(Without the advanced keyless
function)
The horn sound is heard twice to notify the driver that the key has been left in
the vehicle.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 86 of 524
3–12
Before Driving
Doors and Locks
y (Door unlock (control) system with
collision detection)
This system automatically unlocks the
doors in the event the vehicle is involved
in an accident to allow passengers to
get out of the vehicle immediately and
prevent being trapped inside. While the
ignition is switched ON and in the event
the vehicle receives an impact strong
enough to infl ate the air bags, all the
doors are automatically unlocked after
about 6 seconds have elapsed from the
time of the accident.
The doors may not unlock depending on how an impact is applied, the force of
the impact, and other conditions of the
accident.
If door-related systems or the battery is malfunctioning, the doors will not
unlock.
Locking, Unlocking with Key
All doors and the liftgate lock
automatically when the driver's door is
locked with the key.
All doors and the liftgate unlock when the
driver's door is unlocked and the key is
held in the unlock position for one second
or longer.
Turn the key toward the front to lock,
toward the back to unlock.
Lock Unlock
NOTE
Holding the key in the unlocked position in
the driver's door lock for about a second
unlocks all doors and the liftgate. To
unlock only the driver's door, insert the
key into the driver's door lock and turn
the key briefl y to the unlock position and
then immediately return it to the center
position.
Locking, Unlocking with Request
Switch (With the advanced keyless
function)
All doors and the liftgate can be locked/
unlocked by pressing the request switch
on the front doors while the key is being
carried.
(5–door)
The request switch on the liftgate can only
be used to lock all doors and the liftgate.
Front doors
Reque st switch
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 87 of 524
3–13
Before Driving
Doors and Locks
Liftgate (5–door Lock only)
Reque st switch
To lock
To lock the doors and the liftgate, press
the request switch and the hazard warning
lights will fl ash once.
A beep sound will be heard once.
To unlock
Driver's door request switch
To unlock the driver's door, press the
request switch. A beep sound will be heard
twice and the hazard warning lights will
fl ash twice.
To unlock all doors and the liftgate, press
the request switch again within 3 seconds
and two more beep sounds will be heard.
Front passenger door request switch
To unlock all doors and the liftgate, press
the request switch. A beep sound will be
heard twice and the hazard warning lights
will fl ash twice.
NOTE
y The system can be set to unlock all
doors by performing a single operation.
Refer to Personalization Features on page 9-10 .
Use the following procedure to change the setting.
1. Switch the ignition off and close all of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer. The sound of
the doors locking/unlocking can be
heard.
After this, the system switches the setting of pressing the driver's
request switch once or twice to
unlock all doors and the liftgate
each time the UNLOCK button is
pressed (the sound of the doors
locking/unlocking can be heard).
4. The setting change is completed by doing any one of the following:
y Switching the ignition to ACC or
ON.
y Closing the driver's door. y Opening the liftgate/trunk lid. y Not operating the key for 10
seconds.
y Pressing any button except the
UNLOCK button on the key.
y Pressing a request switch.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 88 of 524
3–14
Before Driving
Doors and Locks
y Confi rm that all doors and the liftgate
are securely locked.
For the liftgate/trunk lid, move it without pressing the electric liftgate/
trunk lid opener to verify that the
liftgate/trunk lid has not been left ajar.
y All doors and the liftgate cannot be
locked when any door or the liftgate is
open.
y It may require a few seconds for the
doors to unlock after the request switch
is pressed.
y A beep sound is heard for confi rmation
when the doors and the liftgate are
locked/unlocked using the request
switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also be changed. Refer to Personalization
Features on page 9-10 .
Use the following procedure to change
the setting.
1. Switch the ignition off and close all of the doors and the liftgate/trunk
lid.
2. Open the driver's door. 3. Within 30 seconds of opening the
driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.
All of the doors and the liftgate lock and the beep sound activates at the
currently set volume. (If the beep
sound is currently set to not activate,
it will not activate.) The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)
4. The setting change is completed by doing any one of the following:
y Switching the ignition to ACC or
ON.
y Closing the driver's door. y Opening the liftgate/trunk lid. y Not operating the key for 10
seconds.
y Pressing any button except the
LOCK button on the key.
y Pressing a request switch.
y (With theft-deterrent system) The hazard warning lights fl ash when
the theft-deterrent system is armed or
turned off.
Refer to Theft-Deterrent System on page 3-43 .
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 89 of 524
3–15
Before Driving
Doors and Locks
y The setting can be changed so that
the doors and the liftgate are locked
automatically without pressing the
request switch.
Refer to Personalization Features on page 9-10 .
(Auto-lock function) A beep sound is heard when all doors and the liftgate are closed while the
advanced key is being carried. All doors
and the liftgate are locked automatically
after about three seconds when the
advanced key is out of the operational
range. Also, the hazard warning lights
fl ash once. (Even if the driver is in the
operational range, all doors and the
liftgate are locked automatically after
about 30 seconds.) If you are out of
the operational range before the doors
and the liftgate/trunk lid are completely
closed or another key is left in the
vehicle, the auto-lock function will not
work. Always make sure that all doors
and the liftgate/trunk lid are closed and
locked before leaving the vehicle. The
auto-lock function does not close the
power windows.
y Auto re-lock function After unlocking with the request
switch, all doors and the liftgate
will automatically lock if any of the
following operations are not performed
within about 60 seconds. If your
vehicle has a theft-deterrent system,
the hazard warning lights will fl ash for
confi rmation.
The time required for the doors to lock automatically can be changed.
Refer to Personalization Features on page 9-10 .
y Opening a door or the liftgate/trunk
lid.
y Switching the ignition to any position
other than off.
Locking, Unlocking with Transmitter
All doors and the liftgate can be locked/
unlocked by operating the keyless entry
system transmitter, refer to Keyless Entry
System (page 3-3 ).
. B [ E B @ % $ & " " @ & E J U J P O J O E C
Page 90 of 524
3–16
Before Driving
Doors and Locks
Locking, Unlocking with Door-Lock Switch
All doors and the liftgate lock
automatically when the lock side is
pressed. They all unlock when the unlock
side is pressed.
Driver's door
Unlock
Lock
Front passenger's door
Unlock Lock
To lock all the doors/liftgate from an open
front door, press the lock side of the door
lock switch and then close the door.
NOTE
When locking the doors this way, be
careful not to leave the key inside the
vehicle.
Auto Lock/Unlock Function
WARNING
Do not pull the inner handle on a front
door:
Pulling an inner handle on a front
door while the vehicle is moving is
dangerous. Passengers can fall out of
the vehicle if a front door accidentally
opens, which could result in death or
serious injury.
y When the vehicle speed exceeds 20
km/h (12 mph), all doors and the liftgate
lock automatically.
y When the ignition is switched off,
all doors and the liftgate unlock
automatically.
These functions can also be disabled so
that they do not operate.
Auto lock/unlock function setting
change using door-lock switch
The doors and the liftgate can set to lock
or unlock automatically by selecting any
one of the functions from the following
table and using the driver's door-lock
switch on the interior door panel.
. B [ E B @ % $ & " " @ & E J U J P O J O E C
