key MAZDA MODEL 3 5-DOOR 2014 Owners Manual

Table of Contents
Pictorial Index
Interior, exterior views and part identification of your Mazda.1
Essential Safety Equipment
Important information about safety equipment, including seats, seat beltsystem, child-restraint systems and SRS air bags.2
Before Driving
Use of various features, including keys, doors, mirrors and windows.3
When Driving
Information concerning safe driving and stopping.4
Interior Features
Use of various features for ride comfort, including air-conditioning and audio
system.5
Maintenance and Care
How to keep your Mazda in top condition.6
If Trouble Arises
Helpful information on what to do if a problem arises with the vehicle.7
Customer Information and Reporting Safety Defects
Important consumer information including warranties and add-on equipment.8
Specifications
Technical information about your Mazda.9
Index10
.B[EB@%$&""@&EJUJPOJOEC







1–5
Pictorial Index
Exterior Overview
(4-Door)



Hood ...................................................................\
................................................... page 6-24



Windshield wiper blades ........................................................................\
............... page 6-33



Moonroof ...............................................................\
............................................... page 3-39



Doors and keys ........................................................................\
.............................. page 3-12



Fuel-fi ller lid ........................................................................\
................................. page 3-30



Wheels and Tires ........................................................................\
........................... page 6-41



Exterior lights ........................................................................\
................................ page 6-45



Trunk lid ....................................................................\
............................................ page 3-21



Antenna ................................................................\
................................................. page 5-16



Child safety locks ........................................................................\
.......................... page 3-20



Outside mirror ........................................................................\
............................... page 3-33
The equipment and installation position varies by vehicle
.B[EB@%$&""@&EJUJPOJOEC







1–6
Pictorial Index
Exterior Overview
(5-Door)



Hood ...................................................................\
................................................... page 6-24



Windshield wiper blades ........................................................................\
............... page 6-33



Moonroof ...............................................................\
............................................... page 3-39



Doors and keys ........................................................................\
.............................. page 3-12



Fuel-fi ller lid ........................................................................\
................................. page 3-30



Wheels and Tires ........................................................................\
........................... page 6-41



Exterior lights ........................................................................\
................................ page 6-45



Rear window wiper blade ........................................................................\
............. page 6-34



Liftgate ...............................................................\
................................................... pag e 3-21



Antenna ................................................................\
................................................. page 5-16



Child safety locks ........................................................................\
.......................... page 3-20



Outside mirror ........................................................................\
............................... page 3-33
The equipment and installation position varies by vehicle
.B[EB@%$&""@&EJUJPOJOEC







2–3
Essential Safety Equipment
Seats
Do not place an object such as a cushion between the seatback and your back: Putting an object such as a cushion between the seatback and your back is dangerous
because you will be unable to maintain a safe driving posture and the seat belt cannot
function at its full capacity in a collision, which could result in a serious accident, injury or
death.

Do not place objects under the seat: The object could get stuck and cause the seat to not be fi xed securely, and result in an
accident.

Do not stack cargo higher than the seatbacks: Stacking luggage or other cargo higher than the seatbacks is dangerous. During sudden
braking or a collision, objects can fl y around and become projectiles that may hit and
injure passengers.

Make sure luggage and cargo is secured before driving: Not securing cargo while driving is dangerous as it could move or be crushed during
sudden braking or a collision and cause injury.

Never allow a passenger to sit or stand on the folded seatback while the vehicle is
moving: Driving with a passenger on the folded seatback is dangerous. Allowing a child to sit up
on the folded seatback while the vehicle is moving is particularly dangerous. In a sudden
stop or even a minor collision, a child not in a proper seat or child-restraint system and
seat belt could be thrown forward, back or even out of the vehicle resulting in serious
injuries or death. The child in the baggage area could be thrown into other occupants
and cause serious injury.

Never give the car keys to children and do not allow them to play in the vehicle (4–
Door): Playing with the folding rear seats is dangerous. Once the seatbacks are back up, a child
in the trunk would not be able to get out the way they had entered. If you have small
children, keep the seatbacks locked.

Always leave your car locked and keep the car keys safely away from children (4–
Door): Leaving your car unlocked or the keys in reach of children is dangerous. Children who fi nd
their way into the trunk through an unlocked rear seatback or an open trunk can become
accidentally locked in the trunk. This could result in death or brain damage from heat
prostration, particularly in the summer. Always lock the doors and the trunk, and as an
added measure, keep the rear seatbacks locked, whether you have children in your home
or not.
.B[EB@%$&""@&EJUJPOJOEC







*Some models.3–1
3Before Driving
Use of various features, including keys, doors, mirrors and windows.


Keys ...................................................... 3-2 Keys ............................................... 3-2
Keyless Entry System .................... 3-3
Advanced Keyless Entry System ........ 3-9
Advanced Keyless Entry
System
* ........................................... 3-9
Operational Range ....................... 3-10
Doors and Locks ................................ 3-11 Door Locks ................................... 3-11
Liftgate/Trunk Lid ........................ 3-20
Inside Trunk Release Lever
(4-Door)
* ...................................... 3-25
Fuel and Emission ............................. 3-27 Fuel and Engine Exhaust
Precautions ................................... 3-27
Fuel-Filler Lid and Cap ................ 3-30
Steering Wheel................................... 3-32 Steering Wheel ............................. 3-32
Mirrors ............................................... 3-33 Mirrors ......................................... 3-33
Windows ............................................. 3-36 Power Windows ........................... 3-36
Moonroof
* ................................... 3-39 Security System ................................. 3-41
Modifi cation and Add-On
Equipment .................................... 3-41
Immobilizer System ..................... 3-41
Theft-Deterrent System
* .............. 3-43
Driving Tips ....................................... 3-45 Break-In Period ............................ 3-45
Money-Saving Suggestions ......... 3-45
Hazardous Driving ....................... 3-46
Floor Mat ..................................... 3-46
Rocking the Vehicle ..................... 3-47
Winter Driving ............................. 3-47
Driving In Flooded Area .............. 3-49
Overloading .................................. 3-50
Driving on Uneven Road ............. 3-51
Towing ................................................ 3-52 Trailer Towing .............................. 3-52
Recreational Towing .................... 3-52
.B[EB@%$&""@&EJUJPOJOEC







3–2
Before Driving
Keys
Keys
WARNING
Do not leave the key in your vehicle with
children and keep them in a place where
your children will not fi nd or play with
them: Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. Children may fi nd these keys to
be an interesting toy to play with and
could cause the power windows or
other controls to operate, or even make
the vehicle move.
CAUTION


3–3
Before Driving
Keys
A code number is stamped on the plate
attached to the key set; detach this plate
and store it in a safe place (not in the
vehicle) for use if you need to make a
replacement key (auxiliary key).
Also write down the code number and
keep it in a separate safe and convenient
place, but not in the vehicle.
If your key (auxiliary key) is lost, consult
your Authorized Mazda Dealer and have
your code number ready.
NOTE
The driver must carry the key to ensure the
system functions properly.
A uxi liar y key
Tr ansm itter
Key code num ber plate
To use the auxiliary key, pull it out of the
key (transmitter).
Keyless Entry System
This system uses the key buttons to
remotely lock and unlock the doors and
the liftgate, and opens the trunk lid.
The system can start the engine without
having to take the key out of your purse or
pocket.
It can also help you signal for attention.
Operating the theft-deterrent system is
also possible on theft-deterrent system-
equipped vehicles.
Press the buttons slowly and carefully.
System malfunctions or warnings are
indicated by the following warning lights
or beeps.
 y KEY Warning Light (Red) Refer to Warning/Indicator Lights on
page 4-16 .
 y Ignition Not Switched Off (STOP)
Warning Beep
 Refer to Ignition Not Switched Off (STOP) Warning Beep on page 7-35 .
 y Key Removed from Vehicle Warning
Beep
 Refer to Key Removed from Vehicle Warning Beep on page 7-35 .
If you have a problem with the key,
consult an Authorized Mazda Dealer.
If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to make the
lost or stolen key inoperative.
.B[EB@%$&""@&EJUJPOJOEC







3–4
Before Driving
Keys
CAUTION
Radio equipment like this is governed
by laws in the United States.
Changes or modifi cations not expressly
approved by the party responsible
for compliance could void the user's
authority to operate the equipment.
NOTE
 y The keyless entry system operation may
vary due to local conditions.
 y The keyless entry system is fully
operational (door/liftgate lock/unlock)
when the push button start is switched
off. The system does not operate if the
push button start is switched to any
position other than off.
 y If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be dead. To install a new battery,
refer to Replace Electrical Battery
(page 6-38 ).
 y Additional keys can be obtained at
an Authorized Mazda Dealer. Up to
6 keys can be used with the keyless
functions per vehicle. Bring all keys
to an Authorized Mazda Dealer when
additional keys are required.
Transmitter
Oper ation buttons
Oper ation indicator light
NOTE
 y
(With theft-deterrent system) The hazard warning lights fl ash when
the theft-deterrent system is armed or
turned off.
 Refer to Theft-Deterrent System on page 3-43 .
 y (With the advanced keyless function) A beep sound can be heard for
confi rmation when the doors and
liftgate are locked/unlocked using the
key. If you prefer, the beep sound can be
turned off.
 The volume of the beep sound can also be changed.
 Refer to Personalization Features on page 9-10 .
 Use the following procedure to change the setting.
1. Switch the ignition off and close all of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
.B[EB@%$&""@&EJUJPOJOEC







3–5
Before Driving
Keys
3. Within 30 seconds of opening the driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.
All of the doors and the liftgate lock and the beep sound activates at the
currently set volume. (If the beep
sound is currently set to not activate,
it will not activate.) The setting
changes each time the LOCK button
on the key is pressed and the beep
sound activates at the set volume. (If
the beep sound has been set to not
activate, it will not activate.)
4. The setting change is completed by doing any one of the following:
 y Switching the ignition to ACC or
ON.
 y Closing the driver's door. y Opening the liftgate/trunk lid. y Not operating the key for 10
seconds.
 y Pressing any button except the
LOCK button on the key.
 y Pressing a request switch.
The operation indicator light fl ashes when
the buttons are pressed.
Lock button
To lock the doors and the liftgate, press the
lock button and the hazard warning lights
will fl ash once.
(With the advanced keyless function)
A beep sound will be heard once.
To confi rm that all doors and the liftgate
have been locked, press the lock button
again within 5 seconds. If they are closed
and locked, the horn will sound.
NOTE
 y  TThe doors and the liftgate can be
locked by pressing the lock button while
any other door or the liftgate/trunk lid
is open. The hazard warning lights will
not fl ash.
 When the lock button is pressed while any door is open and then the door is
closed, all the doors and the liftgate are
locked.
 y Confi rm that all doors and the liftgate
are locked visually or audibly by use of
the double click.
 y Make sure all doors and the liftgate are
locked after pressing the button.
 y(With theft-deterrent system) When the doors are locked by pressing
the lock button on the key while the
theft-deterrent system is armed, the
hazard warning lights will fl ash once to
indicate that the system is armed.
Unlock button
To unlock the driver's door, press the
unlock button and the hazard warning
lights will fl ash twice.
(With the advanced keyless function)
A beep sound will be heard twice.
To unlock all doors and the liftgate, press
the unlock button again within 3 seconds
and two more beep sounds will be heard.
.B[EB@%$&""@&EJUJPOJOEC







3–6
Before Driving
Keys
NOTE
 y The system can be set to unlock all
doors by performing a single operation.
 Refer to Personalization Features on page 9-10 .
 Use the following procedure to change the setting.
1. Switch the ignition off and close all of the doors and the liftgate/trunk
lid.
2. Open the driver's door.
3. Within 30 seconds of opening the driver's door, press and hold the
UNLOCK button on the key for 5
seconds or longer. The sound of
the doors locking/unlocking can be
heard.
After this, the system switches the setting each time the UNLOCK
button is pressed (the sound of the
doors locking/unlocking can be
heard).
4. The setting change is completed by doing any one of the following:
 y Switching the ignition to ACC or
ON.
 y Closing the driver's door. y Opening the liftgate/trunk lid. y Not operating the key for 10
seconds.
 y Pressing any button except the
UNLOCK button on the key.
 y Pressing a request switch.
 y(Auto re-lock function) After unlocking with the key, all doors
and the liftgate will automatically lock
if any of the following operations are
not performed within about 60 seconds.
If your vehicle has a theft-deterrent
system, the hazard warning lights will
fl ash for confi rmation.
 The time required for the doors to lock automatically can be changed.
 Refer to Personalization Features on page 9-10 .
 y A door or the liftgate/trunk lid is
opened.
 y The push button start is switched to
any position other than off.
 y(With theft-deterrent system) When the doors are unlocked by
pressing the unlock button on the key
while the theft-deterrent system is
turned off, the hazard warning lights
will fl ash twice to indicate that the
system is turned off.
Trunk button (4–door)
To open the trunk lid, press and hold the
trunk button until the trunk lid opens.
.B[EB@%$&""@&EJUJPOJOEC
