5–107
Interior Features
Bluetooth®
Communication Settings
Select the icon on the home screen and display the Communication screen.
Select the
icon to change the setting.
Item Setting Function
SMS Notifi cations On/Off Notifi es when a new messages is received.
Incoming Call
Notifi cation On/Off Notifi
es when an incoming call is received.
Auto Download Call
history On/Off Downloads Call History automatically when the hands-free unit is
connected to the device.
Auto Download
Contacts
* On/Off Downloads the phonebook automatically when the hands-free unit is
connected to the device.
Auto Download Text On/Off Downloads SMS/MMS automatically when the hands-free unit is
connected to the device.
Ringtone Fixed/In-band/
Off Changes the ringtone setting.
Phone Volume Adjusts using
the slider. Adjusts the conversation volume.
VR and Ringtone Adjusts using
the slider. Adjusts the voice guidance and ringtone volume.
Contacts Sort Order First Name,
Last Name Displays the contact information in alphabetical order of the fi rst name.
Last Name, First Name Displays the contact information in alphabetical order of the last name.\

Preset Messages — Edits the preset message.
Refer to Receiving and Replying to Messages (available only with
SMS compatible phones) on page 5-105 .
Mobile 911 On/Off Mobile Utilizes the Mobile 911 function.
Reset Communication
Settings — Initializes all Communication Settings.
* Depending on the device, it may be necessary to acquire download permiss\
ion on the
device side.
.B[EB@%$&""@&EJUJPOJOEC







5–10 8
Interior Features
Bluetooth®
Audio Operation Using Voice Recognition
Main audio operation
The below commands are examples of the available commands.
When the talk button is pressed and the following command is spoken out,\
the audio can be
operated. The commands in the () can be omitted. The specifi ed name and number are put
into the {}.
Voice command Function Corresponding audio
source
(Go to/Play) AM (Radio) Switches the audio source to AM radio. All
(Go to/Play) FM (Radio) Switches the audio source to FM radio. All
(Go to/Play) Bluetooth (Audio) Switches the audio source to BT audio. All
(Go to/Play) Pandora Switches the audio source to Pandora
® All
(Go to/Play) Aha (Radio) Switches the audio source to Aha™ Radio. All
(Go to/Play) Stitcher Switches the audio source to Stitcher™ Radio. All
(Go to/Play) USB 1 Switches the audio source to USB 1. All
(Go to/Play) USB 2 Switches the audio source to USB 2. All
Play Playlist {Playlist name} Plays the selected playlist. USB
Play Artist {Artist name} Plays the selected artist. USB
Play Album {Album name} Plays the selected album. USB
Play Genre {Genre name} Plays the selected genre. USB
Play Folder {Folder name} Plays the selected folder. USB
Play Audiobooks Displays the list at the top level of the Audiobooks. USB
Play Podcasts Displays the list at the top level of the Podcasts. USB
NOTE
 y Some commands cannot be used depending on devices and use conditions. y If the Bluetooth ® device, USB, or AUX is not connected, the related commands cannot be
used.
.B[EB@%$&""@&EJUJPOJOEC







5–109
Interior Features
Bluetooth®
Gracenote Database
When a USB device is connected to this unit and the audio is played, the\
album name,
artist name, genre and title information are automatically displayed if \
there is a match in
the vehicle's database compilation to the music being played. The information stored in this
device uses database information in the Gracenote music recognition serv\
ice.
CAUTION
For information related to the most recent Gracenote database which can be used and
how to install it, go to the Mazda Hands Free Website:
http://www.mazdahandsfree.com
Introduction
Music recognition technology and related data are provided by Gracenote \
® . Gracenote is the
industry standard in music recognition technology and related content de\
livery. For more
information visit www.gracenote.com.
CD and music-related data from Gracenote, Inc., copyright © 2000 to p\
resent Gracenote.
Gracenote Software, copyright © 2000 to present Gracenote. One or mor\
e patents owned
by Gracenote apply to this product and service. See the Gracenote websit\
e for a non-
exhaustive list of applicable Gracenote patents. Gracenote, CDDB, MusicI\
D, MediaVOCS,
the Gracenote logo and logotype, and the “Powered by Gracenote” lo\
go are either registered
trademarks or trademarks of Gracenote in the United States and/or other \
countries.
Gracenote ® End User License Agreement
This application or device contains software from Gracenote, Inc. of Eme\
ryville, California
(“Gracenote”. The software from Gracenote (the “Gracenote Software” enables thi\
s
application to perform disc and/or fi le identifi cation and obtain music-related information,
including name, artist, track, and title information (“Gracenote Dat\
a” from online servers
or embedded databases (collectively, “Gracenote Servers” and to perform other functions.
You may use Gracenote Data only by means of the intended End-User functio\
ns of this
application or device.
You agree that you will use Gracenote Data, the Gracenote Software, and G\
racenote Servers
for your own personal non-commercial use only. You agree not to assign, copy, transfer or
transmit the Gracenote Software or any Gracenote Data to any third party\
. YOU AGREE
NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE, OR
GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
.B[EB@%$&""@&EJUJPOJOEC







5–110
Interior Features
Bluetooth®
You agree that your non-exclusive license to use the Gracenote Data, the \
Gracenote
Software, and Gracenote Servers will terminate if you violate these rest\
rictions. If your
license terminates, you agree to cease any and all use of the Gracenote \
Data, the Gracenote
Software, and Gracenote Servers. Gracenote reserves all rights in Gracen\
ote Data, the
Gracenote Software, and the Gracenote Servers, including all ownership r\
ights. Under no
circumstances will Gracenote become liable for any payment to you for an\
y information
that you provide. You agree that Gracenote, Inc. may enforce its rights under this Agreement
against you directly in its own name.
The Gracenote service uses a unique identifi er to track queries for statistical purposes. The
purpose of a randomly assigned numeric identifi er is to allow the Gracenote service to count
queries without knowing anything about who you are. For more information\
, see the web
page for the Gracenote Privacy Policy for the Gracenote service.
The Gracenote Software and each item of Gracenote Data are licensed to y\
ou “AS IS.”
Gracenote makes no representations or warranties, express or implied, re\
garding the
accuracy of any Gracenote Data from in the Gracenote Servers. Gracenote \
reserves the right
to delete data from the Gracenote Servers or to change data categories f\
or any cause that
Gracenote deems suffi cient. No warranty is made that the Gracenote Software or Gracenote
Servers are error-free or that functioning of Gracenote Software or Gracenote Servers wil\
l
be uninterrupted. Gracenote is not obligated to provide you with new enh\
anced or additional
data types or categories that Gracenote may provide in the future and is\
free to discontinue
its services at any time.
GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RESULTS THAT
WILL BE OBTAINED BY YOUR USE OF THE GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL GRACENOTE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST PROFITS OR
LOST REVENUES.
© 2000 to present. Gracenote, Inc.
Updating the database
The Gracenote media database can be updated using USB device.
1. Connect a USB device containing the software for updating Gracenote.
2. Select the
icon on the home screen and display the Settings screen.
3. Select the
tab and select the icon.
4. Select the
icon. The list of the update package stored in the USB device and the
version are displayed.
5. Select the package to use the update.
6. Select the
icon.
NOTE
Gracenote can be downloaded from the Mazda Hands-free Website.
.B[EB@%$&""@&EJUJPOJOEC







*Some models.5–111
Interior Features
Bluetooth®
Bluetooth ® Audio (Type A) *
Applicable Bluetooth ® specifi cation
Ver. 2.0 or higher
Response profi le
 y A2DP (Advanced Audio Distribution
Profi le) Ver. 1.0/1.2
 y AVRCP (Audio/Video Remote Control
Profi le) Ver. 1.0/1.3
A2DP is a profi le which transmits only
audio to the Bluetooth
® unit. If your
Bluetooth® audio device corresponds only
to A2DP, but not AVRCP, you cannot
operate it using the control panel of the
vehicle's audio system. In this case, the
Bluetooth
® audio device can be operated
by controlling the device itself, the same
as when a portable audio system without
the Bluetooth
® communication function is
connected to the AUX terminal.
Function A2DP AVRCP
Ver. 1.0 Ver. 1.3
Playback — X X
Pause — X X
File (Track) up/down — X X
Reverse — — X
Fast-forward — — X
Text display — — X
X: Available
—: Not available
NOTE
 y The battery consumption of Bluetooth ®
audio devices increases while
Bluetooth® is connected. y If a general mobile phone device is
USB connected during music playback
over the Bluetooth
® connection, the
Bluetooth® connection is disconnected.
For this reason, you cannot have music
playback over a Bluetooth
® connection
and music playback using a USB
connection at the same time.
 y  The system may not operate normally
depending on the Bluetooth ® audio
device.
How to Use the Bluetooth ® Audio
System
Switching to Bluetooth ® audio mode
To listen to music or voice audio recorded
to a Bluetooth
® audio device, switch to
the Bluetooth ® audio mode to operate
the audio device using the audio system
control panel. Any Bluetooth
® audio
device must be paired to the vehicle's
Bluetooth
® unit before it can be used.
Refer to Bluetooth ® Preparation (Type A)
on page 5-76 .
1. Turn on the Bluetooth
® audio device's
power.
2. Switch the ignition to ACC or ON.
Make sure that the “
” symbol is
displayed in the audio display. The
symbol is not displayed if an un-paired
Bluetooth
® audio device is being used
or the vehicle's Bluetooth ® unit has a
malfunction.
NOTE
Some Bluetooth ® audio devices need a
certain amount of time before the “
”
symbol is displayed.
.B[EB@%$&""@&EJUJPOJOEC







5–112
Interior Features
Bluetooth®
3. Press the media button () to
switch to the Bluetooth ® audio mode
and start playback.
If the current device version is lower
than AVRCP Ver. 1.3: “ BT Audio ” is
displayed.
If the current device is AVRCP Ver. 1.3:
The playback time is displayed.
NOTE
 y  If the Bluetooth ® audio device does not
begin playback, press the Play/Pause
button (4).
 y  If a call is received on a hands-free
mobile phone during playback from the
Bluetooth
® audio device, the playback is
stopped. Playback from the Bluetooth ®
audio device resumes after the call
ends.
Playback
1. To listen to a Bluetooth
® audio device
over the vehicle's speaker system,
switch the mode to Bluetooth
®
audio mode. (Refer to “Switching to
Bluetooth® audio mode”)
2. To stop playback, press the Play/Pause button (4).
3. Press the button again to resume playback.
Selecting a fi le (track)
Selects the next fi le (track)
Short-press the track up button (
).
Selects the beginning of the current fi le
(track)
Short-press the track down button (
).
Fast-forward/Reverse (AVRCP Ver. 1.3)
Fast-forward
Press and hold the fast-forward button
(
).
Reverse
Press and hold the reverse down button
(
).
Switching the display (only AVRCP Ver.
1.3)
For fi les with a song title and other
information that have been input, the
display switches between display of the
song title and other information each
time the text button (3) is pressed during
playback.
A lbum title
Song title
A r tist nam e
P layback tim e
NOTE
 y
 If title information is not available, “ NO
TITLE ” is displayed.
 y This unit cannot display some
characters. Characters which cannot be
displayed are indicated by an asterisk
(
).
.B[EB@%$&""@&EJUJPOJOEC







*Some models.5–113
Interior Features
Bluetooth®
Display scroll
Only 13 characters can be displayed at one
time. To display the rest of the characters
of a long title, press and hold the text
button (3). The display scrolls the next 13
characters. Press and hold the text button
(3) again after the last 13 characters have
been displayed to return to the beginning
of the title.
Bluetooth ® Audio Device
Information Display
If a Bluetooth ® audio device is connected,
the following information is displayed in
the audio display.
AVRCP Ver.
lower than 1.3 AVRCP
Ver. 1.3
Device name X X
Title — X
Artist name — X
Album name — X
File number — X
Playback time — X
Folder number — —
X: Available
—: Not available
NOTE
Some information may not display
depending on the device, and if the
information cannot be displayed, “ NO
TITLE ” is indicated.
Bluetooth ® Audio (Type B) *
Applicable Bluetooth ® specifi cation
Ver. 2.1 + EDR
Response profi le
 y A2DP (Advanced Audio Distribution
Profi le) Ver. 1.0/1.2
 y AVRCP (Audio/Video Remote Control
Profi le) Ver. 1.0/1.3/1.4
A2DP is a profi le which transmits only
audio to the Bluetooth
® unit. If your
Bluetooth® audio device corresponds only
to A2DP, but not AVRCP, you cannot
operate it using the control panel of the
vehicle's audio system. In this case, the
Bluetooth
® audio device can be operated
by controlling the device itself, the same
as when a portable audio system without
the Bluetooth
® communication function is
connected to the AUX terminal.
Function A2DP AVRCP
Ver. 1.0 Ver. 1.3 Ver. 1.4
Playback X X X X
Pause X X X X
File (Track)
up/down — X X X
Reverse — — X X
Fast-forward — — X X
Text display — — X X
Repeat — —
Depends on
device Depends
on
device
Shuffl e — — Depends on
device Depends
on
device
Scan — — Depends on
device Depends
on
device
Folder up/
down — — — X
X: Available
—: Not available
.B[EB@%$&""@&EJUJPOJOEC







5–114
Interior Features
Bluetooth®
NOTE
 y The battery consumption of Bluetooth ®
audio devices increases while
Bluetooth® is connected. y If a general mobile phone device is
USB connected during music playback
over the Bluetooth
® connection, the
Bluetooth® connection is disconnected.
For this reason, you cannot have music
playback over a Bluetooth
® connection
and music playback using a USB
connection at the same time.
 y  The system may not operate normally
depending on the Bluetooth ® audio
device.
.B[EB@%$&""@&EJUJPOJOEC







5–115
Interior Features
Bluetooth®
How to Use the Bluetooth ® Audio System
Switching to Bluetooth ® audio mode
To listen to music or voice audio recorded to a Bluetooth
® audio device, switch to the
Bluetooth® audio mode to operate the audio device using the audio system control p\
anel.
Any Bluetooth ® audio device must be paired to the vehicle's Bluetooth ® unit before it can be
used.
Refer to Bluetooth
® Preparation (Type B) on page 5-89 .
1. Turn on the Bluetooth
® audio device's power.
2. Switch the ignition to ACC or ON.
3. Select the
icon on the home screen and display the Audio screen.
4. When Bluetooth ® is selected, switches to the Bluetooth ® audio mode to begin playback.
NOTE
 y  If the Bluetooth ® audio device does not begin playback, select the icon. y If the mode is switched from Bluetooth ® audio mode to another mode (radio mode), audio
playback from the Bluetooth ® audio device stops.
Playback
To listen to a Bluetooth
® audio device over the vehicle's speaker system, switch the mode to
Bluetooth® audio mode. (Refer to “Switching to Bluetooth ® audio mode”)
After switching to the Bluetooth ® audio mode, the following icons are displayed in the
lower part of the display. Icons which can be used differ depending on the version of the
Bluetooth
® audio device which you are currently using.
Icon Function
Displays the Audio menu. Use to switch to a different audio source.
(AVRCP Ver. 1.4 only)
Displays the top level folder/fi le list.
Select the folder which you want to select.
The fi les in the selected folder are displayed.
Select the fi le you want to play.
(AVRCP Ver. 1.3 or higher)
Replays the song currently being played repeatedly.
When selected again, the songs in the folder are played repeatedly.
Select it again to cancel.
Icons change when the song is repeated or the folder is repeated.
(AVRCP Ver. 1.3 or higher)
Plays songs in the folder in random order.
When selected again, the songs on the device are played in random order.
Select it again to cancel.
Icons change during folder shuffl e or device shuffl e.
.B[EB@%$&""@&EJUJPOJOEC







5–116
Interior Features
Bluetooth®
Icon Function
Scans the titles in a folder and plays the beginning of each song to aid\
in fi nding a desired
song.
When selected again, the beginning of each song on the device is played.\
When selected again, the operation is canceled and the song currently be\
ing played
continues.
Returns to the beginning of the previous song.
Long-press to fast reverse. It stops when you remove your hand from the \
icon or the
commander knob.
Plays the Bluetooth ® audio. When selected again, playback is temporarily stopped.
Advances to the beginning of the next song.
Long-press to fast forward. It stops when you remove your hand from the \
icon or the
commander knob.
Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-40 .
Example of use (When searching for a
song from the top level of a device)
1. Select the
icon and display the
folder/fi le list at the top level.
2. When the folder is selected, folders/fi le
lists in the folder are displayed.
When the playlist is selected, the fi le
list is displayed.
3. Select the desired song.
NOTE
Select the icon to move to a folder one
level higher.
.B[EB@%$&""@&EJUJPOJOEC
