*Some models.9–10
Specifi cations
Specifi cations
Interior light
Light bulb Category
Wattage ECE R
Trunk light (4–Door) 3 —
Luggage compartment light (5–Door) 5 —
Overhead lights (Front)/Map lights
* 8 —
Overhead light (Front) * 10 —
Overhead light (Rear) * 10 —
Vanity mirror lights * 2 —
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fi tted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and infl ation pressure.
Refer to Tire Infl ation Pressure on page 6-41 .
After adjusting the tire pressure, initialization of the tire pressure monitoring system is
necessary to make the system operates normally.
Refer to Tire Pressure Monitoring System Initialization on page 4-107 .
Standard tire
(U.S.A. and Canada)
Tire size Infl ation pressure
Front Rear
P205/60R16 91H 250 kPa (36 psi) 250 kPa (36 psi)
215/45R18 89W 250 kPa (36 psi) 250 kPa (36 psi)
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 572 of 585
9–11
Specifi cations
Specifi cations
(Mexico)
Tire size Infl ation pressure
Front Rear
P205/60R16 91H 250 kPa (2.5 bar, 36 psi) 250 kPa (2.5 bar, 36 psi)
Tire size Infl ation pressure
Up to 3 persons —Full load
215/45R18 89W Front 240 kPa (2.4 bar, 35 psi) 280 kPa (2.8 bar, 41 psi)
Rear 230 kPa (2.3 bar, 33 psi) 300 kPa (3.0 bar, 44 psi)
1 person's weight: About 75 kg
Temporary spare tire
Tire size Infl ation pressure
T125/70D16 96M 420 kPa (60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108—147 N~m (12—14 kgf~m, 80—108 ft~lbf)
Fuses
Refer to Fuses on page 6-58 .
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 573 of 585
9–12
Specifi cations
Personalization Features
Personalization Features
The following Personalization Feature is available. This setting can only be changed by an
Authorized Mazda Dealer.
Items in which the feature setting can be changed differ depending on the market and
specifi cation.
Item Feature Factory Setting Available Settings
Daytime running
lights The function of the daytime running lights can
be changed. On On/Off
The following Personalization Features can be changed by the vehicle owner. Items in which
the feature setting can be changed differ depending on the market and specifi cation.
Item Feature Factory Setting Available Settings
Power door lock Changes the auto lock/unlock function setting
for all the doors according to the vehicle speed,
the vehicle power supply condition, and the
selector lever position.
Refer to Auto Lock/Unlock Function on page
3-17 .
Refer to Settings on page 5-55 . Lock: When
Driving Unlock:
IGN Off Lock: Shifting from
Park Unlock: In Park/
Lock: Shifting from
Park/
Lock: When Driving
Unlock: IGN Off/
Lock: When Driving/
Off
Keyless entry
system The method for unlocking the doors using the
transmitter can be changed.
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-55 . Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice:
All Doors
The time required for the doors to relock
automatically after unlocking with the
transmitter can be changed.
Refer to Settings on page 5-55 . 60 seconds 90 seconds/
60 seconds/
30 seconds
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 574 of 585
9–13
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Advanced keyless
entry system The volume of the answer-back beep during
advanced keyless entry system operation can
be changed.
Refer to Locking, Unlocking with Request
Switch (With the advanced keyless function)
on page 3-13 .
Refer to Settings on page 5-55 . Medium High/
Medium/
Low/
Off
The function to automatically lock the doors
when leaving the vehicle while carrying the
key can be changed.
Refer to Settings on page 5-55 . Off On/Off
The method for unlocking the doors using the
request switch/transmitter can be changed.
Refer to Locking, Unlocking with Request
Switch, Door Handle (With the advanced
keyless function) on page 3-13
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-55 . Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice:
All Doors
The time required for the doors to relock
automatically after unlocking with the request
switch/transmitter can be changed.
Refer to Settings on page 5-55 . 60 seconds 90 seconds/
60 seconds/
30 seconds
Illumination entry The time required for the interior lamp to turn
off automatically can be changed (prevents
battery depletion when a door is open/ajar).
Refer to Settings on page 5-55 . 30 minutes 60 minutes/
30 minutes/
10 minutes
The time required for the interior lamp to turn
off automatically after all doors are closed can
be changed.
Refer to Settings on page 5-55 . 15 seconds 60 seconds/
30 seconds/
15 seconds/
7.5 seconds
Three-fl ash turn
signal The three-fl ash turn function can be changed.
Refer to Settings on page 5-55 . On On/Off
Auto-wiper control The auto-wiper control function can be
changed.
Refer to Settings on page 5-55 . On On/Off
Auto headlight off
*1 The time required for headlights to turn off
after ignition is switched off can be changed.
Refer to Settings on page 5-55 . 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/
Off
*2
Auto-light control The headlight illumination on/off timing based
on surrounding lightness/darkness can be
changed.
Refer to Settings on page 5-55 . Medium Light/
Medium Light/
Medium/
Medium Dark/
Dark
High Beam Control
System (HBC) The High Beam Control System (HBC)
function can be changed.
*3
Refer to Settings on page 5-55 . On On/Off
Turn indicator The turn indicator beep volume level can be
changed.
Refer to Settings on page 5-55 . High High/Low
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 575 of 585
9–14
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Lights-on reminder
*4 The volume of the lights-on reminder warning
alarm can be changed.
Refer to Settings on page 5-55 . Off High/Low/Off
Blind Spot
Monitoring (BSM)
system The volume of the BSM warning beep can be
changed.
*5
Refer to Settings on page 5-55 . High High/
Low/
Off
Lane Departure
Warning System
(LDWS) The warning sound for the Lane Departure
Warning System (LDWS) can be changed.
*6
Refer to Settings on page 5-55 . Beep Beep/Rumble Strip
The volume of the warning sound
for the Lane Departure Warning
System (LDWS) can be changed.
Refer to Settings on page 5-55 . Rumble
strip High High/Mid/Low
Beep High High/Low
The sensitivity of the warning for the Lane
Departure Warning System (LDWS) can be
changed.
Refer to Settings on page 5-55 . Low High/Low
The warning timing in which the Lane
Departure Warning System (LDWS)
determines that the vehicle may be deviating
from its lane can be changed.
Refer to Settings on page 5-55 . Before line At line/Before line
Meter display The distance unit can be changed.
Refer to Settings on page 5-55 . Miles or Km Miles/Km
The display language can be changed.
Refer to Settings on page 5-55 . English, French,
or Spanish English/
French/
Spanish
The temperature unit can be changed.
Refer to Settings on page 5-55 . F° or C° F°/C°
Forward Obstruction
Warning (FOW) The system can be changed so that Forward
Obstruction Warning (FOW) does not
operate.
*3
Refer to Settings on page 5-55 . On On/Off
The distance at which the collision warning
activates can be changed.
Refer to Settings on page 5-55 . Near Near/Far
The volume of the collision warning can be
changed.
Refer to Settings on page 5-55 . High High/Low/Off
Smart City Brake
Support (SCBS) The system can be changed so that Smart City
Brake Support (SCBS) does not operate.
*3
Refer to Settings on page 5-55 . On On/Off
Fuel Economy
Monitor Setting can be changed so that the ending
screen of the Fuel Economy Monitor is
displayed.
Refer to Fuel Economy Monitor on page 4-86 . OFF ON/OFF
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 576 of 585
9–15
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Fuel economy
resetting procedure Setting can be changed so that the fuel
economy reset is linked with the trip meter
reset.
Refer to Fuel Economy Monitor on page 4-86 . OFF ON/OFF
Active driving
display Setting can be changed so that the Turn-by-
Turn (TBT) of the Active driving display is not
displayed.
Refer to Active driving display on page 4-19 . On On/Off
*1 If the setting is changed to Off, the following operation is performed according to the headlight switch position:
y At position: Headlights turn off immediately after the ignition is switched off. y At any position other than : Headlights do not turn off after the ignition is switched off.
*2 When set to Off, the lights-on reminder is operable.
*3 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends
that these systems remain On.
*4 The setting of the lights-on reminder can be changed with the time setting of auto headlight off function set to
Off. Refer to Lights-On Reminder on page 7-36 .
*5 Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation can be changed. The
volume of the warning beep during Rear Cross Traffi c Alert (RCTA) operation cannot be changed.
*6 For vehicles with an audio system other than the on-screen function type, the warning sound cannot be changed.
The warning sound is only a beep.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 577 of 585
9–16
MEMO
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 578 of 585
10–1
10Index
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 579 of 585
10–2
Index
A
Accessory Socket .............................. 5-136
Active Driving Display ....................... 4-19
Adaptive Front Lighting System
(AFS).................................................. 4-46
Add-On Non-Genuine Parts and
Accessories ......................................... 8-18
Advanced Key
Advanced keyless entry system ...... 3-9
Advanced Key removed from vehicle
warning beep ....................................... 7-37
Operational range .......................... 3-10
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ......................... 7-36
Air Bag Systems ................................. 2-40
Ambient Temperature Display ............ 4-16
Antilock Brake System (ABS) ............ 4-79
Audio Control Switch
Adjusting the Volume .................... 5-58
Mute Switch .................................. 5-59
Seek Switch ................................... 5-58
Audio System ...................................... 5-16
AUX/USB/iPod mode ................... 5-59
Antenna ......................................... 5-16
Audio Control Switch ................... 5-58
Audio Set (Type A) ....................... 5-26
Audio Set (Type B) ....................... 5-38
Operating Tips for Audio System ... 5-17
Satellite Radio ............................... 5-48
Automatic Transaxle ........................... 4-30
Active Adaptive Shift (AAS) ........ 4-32
Direct Mode .................................. 4-39
Driving tips.................................... 4-40
Manual shift mode......................... 4-33
Shift-lock system ........................... 4-32
Shift position indication ................ 4-31
Warning light ................................. 4-31
B
Battery ................................................. 6-37
Maintenance .................................. 6-38
Specifi cations .................................. 9-4
Battery runs out ................................... 7-15
Jump-Starting ................................ 7-15
Blind Spot Monitoring (BSM)
System ............................................... 4-108
BSM OFF switch......................... 4-114
BSM warning light ...................... 4-113
Blind Spot Monitoring (BSM) .... 4-109
Care of radar sensors ................... 4-114
Blind Spot Monitoring (BSM) System
warning beep ....................................... 7-38
Blind Spot Monitoring (BSM) system
Rear Cross Traffi c Alert (RCTA) ... 4-111
Bluetooth® ........................................... 5-75
Bluetooth® Audio (Type A) ......... 5-114
Bluetooth® Audio (Type B) ......... 5-116
Bluetooth® Hands-Free (Type A) ... 5-95
Bluetooth® Hands-Free (Type B) ... 5-102
Troubleshooting .......................... 5-129
Body Lubrication ................................ 6-32
Bottle Holder ..................................... 5-138
Brakes
Brakes assist .................................. 4-70
Foot brake...................................... 4-68
Pad wear indicator ......................... 4-69
Parking brake ................................ 4-69
Warning light ................................. 4-69
Break-In .............................................. 3-45
C
Capacities .............................................. 9-5
Carbon Monoxide ............................... 3-29
Cell Phones ......................................... 8-19
Center Console .................................. 5-140
Child Restraint
Child-restraint precautions ............ 2-22
Installing child-restraint systems... 2-28
LATCH child-restraint systems ..... 2-36
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 580 of 585
10–3
Index
Child Safety Locks for Rear Doors ..... 3-20
Climate Control System ........................ 5-2
Automatic Climate Control ............. 5-9
Dual-Zone Automatic Climate
Control........................................... 5-12
Gas specifi cations ............................ 9-8
Manual Climate Control .................. 5-5
Operating Tips ................................. 5-2
Vent Operation ................................ 5-3
Clock ................................................... 5-30
Collision warning ................................ 7-39
Control Status Display ........................ 4-87
Cruise Control ................................... 4-100
Cruise Control Switch ................. 4-100
Cruise Control Set Vehicle Speed
Display ................................................ 4-17
Cup Holder ........................................ 5-137
Customer Assistance ............................. 8-2
D
Dashboard Illumination ...................... 4-16
Daytime Running Lights ..................... 4-47
Defroster
Mirror ............................................ 4-57
Rear window ................................. 4-56
Dimensions ........................................... 9-6
Direct Mode
Automatic transaxle ...................... 4-39
Door Locks .......................................... 3-11
Drive selection .................................... 4-88
Driving In Flooded Area ..................... 3-49 Driving Tips
Automatic transaxle ...................... 4-40
Break-in ......................................... 3-45
Driving in fl ooded area.................. 3-49
Driving on uneven road ................. 3-51
Floor mat ....................................... 3-46
Hazardous driving ......................... 3-46
Money-saving suggestions ............ 3-45
Overloading ................................... 3-50
Rocking the vehicle ....................... 3-47
Winter driving ............................... 3-47
Driving on Uneven Road .................... 3-51
Dynamic Stability Control (DSC) ....... 4-81
DSC OFF Indicator Light.............. 4-82
DSC OFF Switch........................... 4-82
TCS/DSC Indicator Light ............. 4-81
E
Emergency Starting
Push-Starting ................................. 7-18
Starting a Flooded Engine ............. 7-18
Emergency Towing
Tiedown Hooks ............................. 7-22
Towing Description ....................... 7-21
Emission Control System .................... 3-28
Ending Screen Display ........................ 4-87
Engine
Coolant .......................................... 6-29
Engine Compartment Overview .... 6-26
Exhaust gas.................................... 3-29
Hood release .................................. 6-24
Oil .................................................. 6-27
Starting ............................................ 4-5
Essential information ............................ 6-2
Event Data Recorder ........................... 8-20
Exhaust Gas ........................................ 3-29
Exterior Care ....................................... 6-63
Aluminum Wheel Maintenance .... 6-68
Bright-Metal Maintenance ............ 6-67
Maintaining the Finish .................. 6-65
Plastic Part Maintenance ............... 6-69
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
