Page 502 of 585
*Some models.7–33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken
(Amber)
Forward
Obstruction
Warning/
Smart
City Brake
Support
(FOW/
SCBS)
Indicator
Light
*
The light turns on if the windshield and the radar
sensor are dirty or there is a malfunction in the
system. Verify the reason why the warning light is
illuminated on the audio display (page 7-24 ).
If the reason why the warning light is
illuminated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because of a
dirty radar sensor, clean the front emblem.
For any other reasons, have the vehicle
inspected at an Authorized Mazda Dealer.
KEY Warning Light
Take the appropriate action and verify that the warning light turns off.
Signal Cause Action to be taken
(Red)
(Flashing) The advanced key battery is dead. Replace the battery (page 6-39 ).
The advanced key is not within the
operation range.
Bring the advanced key into the operation
range (page 3-7 ). The advanced key is placed in areas inside
the cabin where it is diffi cult for the key to
be detected.
A key from another manufacturer similar to
the advanced key is in the operation range. Take the key from another manufacturer
similar to the advanced key out of the
operation range.
Without the ignition switched off, the
advanced key is taken out of the cabin, and
then all the door are closed. Bring the advanced key back into the
cabin.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 506 of 585
7–37
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Seat Belt Warning Beep
If the driver's seat belt is not fastened
when the ignition is switched ON, a beep
sound will be heard for about 6 seconds. If
the driver or the front passenger's seat belt
is not fastened and the vehicle is driven
at a speed faster than about 20 km/h (12
mph), a beep sound will be heard again for
a specifi ed period of time.
NOTE
y Some models do not have the seat
belt warning function for the front
passenger's seat.
y Placing heavy items on the front
passenger seat may cause the front
passenger seat belt warning function to
operate depending on the weight of the
item.
y To allow the front passenger seat
weight sensor to function properly, do
not place and sit on an additional seat
cushion on the front passenger seat.
The sensor may not function properly
because the additional seat cushion
could cause sensor interference.
y When a small child sits on the front
passenger seat, it is possible that the
warning beep will not operate.
Ignition Not Switched Off (STOP)
Warning Beep
If the driver's door is opened while
the ignition is switched to ACC, a
continuous beep sound will be heard to
notify the driver that the ignition has not
been switched off (STOP). Left in this
condition, the keyless entry system will
not operate, the car cannot be locked, and
the battery power will be depleted.
Key Removed from Vehicle
Warning Beep
A beep sound will be heard 6 times and
the KEY warning light (red) will fl ash
continuously if the ignition has not been
switched off, all the doors are closed, and
the key is removed from the vehicle. This
is to notify the driver that the key has been
removed from the vehicle and the ignition
has not been switched off.
NOTE
Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key is
carried together with a metal object or it
is placed in a poor signal reception area.
Request Switch Inoperable
Warning Beep (With the advanced
keyless function)
If the request switch is pressed with a door
open or ajar or the ignition has not been
switched off while the key is being carried,
a beep will be heard for about 2 seconds
to indicate that the doors and the liftgate/
trunk lid cannot be locked.
Key Left-in-luggage Compartment
Warning Beep (With the advanced
keyless function)
If the key is left in the trunk with all doors
locked and the trunk lid closed, a beep
sound is heard for about 10 seconds to
remind the driver the key has been left in
the trunk. If this happens, open the trunk
lid by pressing the electric trunk lid opener
and remove the key. A key removed from
the trunk may not function because its
functions may have been temporarily
suspended. To restore the key function,
perform the applicable procedure (page
3-8 ).
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 507 of 585
7–38
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Key Left-in-vehicle Warning Beep
(With the advanced keyless
function)
If a key is left in the vehicle cabin and all
the doors and the trunk are locked using
a separate key, a beep sound is heard for
about 10 seconds to remind the driver
that the key has been left in the vehicle
cabin. If this happens, open the door and
remove the key. A key removed from the
vehicle this way may not function because
its functions may have been temporarily
suspended. Perform the applicable
procedure to restore the functions of the
key (page 3-8 ).
i-ELOOP Warning Beep
The beep will activate if you attempt to
drive the vehicle under the following
conditions.
y The i-ELOOP indicator light is fl ashing
green.
y “i-ELOOP” charging" is indicated in the
Type B audio display.
The beep will stop when the vehicle is
stopped. Make sure the indicator light is
no longer illuminated and the message
is no longer displayed before driving the
vehicle.
Tire Infl ation Pressure Warning
Beep
The warning beep sound will be heard
for about 3 seconds when there is any
abnormality in tire infl ation pressures
(page 4-104 ).
Lane Departure Warning System
(LDWS) Warning Sound
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
y The volume of the LDWS warning
sound can be changed.
Refer to Personalization Features on
page 9-12 .
y The type of the LDWS warning sound
can be changed.
Refer to Personalization Features on
page 9-12 .
Blind Spot Monitoring (BSM)
System Warning Beep
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the BSM warning light is illuminated.
NOTE
A personalized function is available to
change the BSM warning beep sound
volume.
Refer to Personalization Features on
page 9-12 .
Reversing
If vehicles approach from the rear on the
left and right, the Blind Spot Monitoring
(BSM) warning beep operates.
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 553 of 585
8–42
Customer Information and Reporting Safety Defects
Declaration of Conformity
Declaration of Conformity
Keyless Entry System/Immobilizer System
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 573 of 585
9–12
Specifi cations
Personalization Features
Personalization Features
The following Personalization Feature is available. This setting can only be changed by an
Authorized Mazda Dealer.
Items in which the feature setting can be changed differ depending on the market and
specifi cation.
Item Feature Factory Setting Available Settings
Daytime running
lights The function of the daytime running lights can
be changed. On On/Off
The following Personalization Features can be changed by the vehicle owner. Items in which
the feature setting can be changed differ depending on the market and specifi cation.
Item Feature Factory Setting Available Settings
Power door lock Changes the auto lock/unlock function setting
for all the doors according to the vehicle speed,
the vehicle power supply condition, and the
selector lever position.
Refer to Auto Lock/Unlock Function on page
3-17 .
Refer to Settings on page 5-55 . Lock: When
Driving Unlock:
IGN Off Lock: Shifting from
Park Unlock: In Park/
Lock: Shifting from
Park/
Lock: When Driving
Unlock: IGN Off/
Lock: When Driving/
Off
Keyless entry
system The method for unlocking the doors using the
transmitter can be changed.
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-55 . Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice:
All Doors
The time required for the doors to relock
automatically after unlocking with the
transmitter can be changed.
Refer to Settings on page 5-55 . 60 seconds 90 seconds/
60 seconds/
30 seconds
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 574 of 585
9–13
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Advanced keyless
entry system The volume of the answer-back beep during
advanced keyless entry system operation can
be changed.
Refer to Locking, Unlocking with Request
Switch (With the advanced keyless function)
on page 3-13 .
Refer to Settings on page 5-55 . Medium High/
Medium/
Low/
Off
The function to automatically lock the doors
when leaving the vehicle while carrying the
key can be changed.
Refer to Settings on page 5-55 . Off On/Off
The method for unlocking the doors using the
request switch/transmitter can be changed.
Refer to Locking, Unlocking with Request
Switch, Door Handle (With the advanced
keyless function) on page 3-13
Refer to Transmitter on page 3-4 .
Refer to Settings on page 5-55 . Once: Driver's
Twice: All Doors Once: All Doors/
Once: Driver's Twice:
All Doors
The time required for the doors to relock
automatically after unlocking with the request
switch/transmitter can be changed.
Refer to Settings on page 5-55 . 60 seconds 90 seconds/
60 seconds/
30 seconds
Illumination entry The time required for the interior lamp to turn
off automatically can be changed (prevents
battery depletion when a door is open/ajar).
Refer to Settings on page 5-55 . 30 minutes 60 minutes/
30 minutes/
10 minutes
The time required for the interior lamp to turn
off automatically after all doors are closed can
be changed.
Refer to Settings on page 5-55 . 15 seconds 60 seconds/
30 seconds/
15 seconds/
7.5 seconds
Three-fl ash turn
signal The three-fl ash turn function can be changed.
Refer to Settings on page 5-55 . On On/Off
Auto-wiper control The auto-wiper control function can be
changed.
Refer to Settings on page 5-55 . On On/Off
Auto headlight off
*1 The time required for headlights to turn off
after ignition is switched off can be changed.
Refer to Settings on page 5-55 . 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/
Off
*2
Auto-light control The headlight illumination on/off timing based
on surrounding lightness/darkness can be
changed.
Refer to Settings on page 5-55 . Medium Light/
Medium Light/
Medium/
Medium Dark/
Dark
High Beam Control
System (HBC) The High Beam Control System (HBC)
function can be changed.
*3
Refer to Settings on page 5-55 . On On/Off
Turn indicator The turn indicator beep volume level can be
changed.
Refer to Settings on page 5-55 . High High/Low
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 579 of 585
10–2
Index
A
Accessory Socket .............................. 5-136
Active Driving Display ....................... 4-19
Adaptive Front Lighting System
(AFS).................................................. 4-46
Add-On Non-Genuine Parts and
Accessories ......................................... 8-18
Advanced Key
Advanced keyless entry system ...... 3-9
Advanced Key removed from vehicle
warning beep ....................................... 7-37
Operational range .......................... 3-10
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ......................... 7-36
Air Bag Systems ................................. 2-40
Ambient Temperature Display ............ 4-16
Antilock Brake System (ABS) ............ 4-79
Audio Control Switch
Adjusting the Volume .................... 5-58
Mute Switch .................................. 5-59
Seek Switch ................................... 5-58
Audio System ...................................... 5-16
AUX/USB/iPod mode ................... 5-59
Antenna ......................................... 5-16
Audio Control Switch ................... 5-58
Audio Set (Type A) ....................... 5-26
Audio Set (Type B) ....................... 5-38
Operating Tips for Audio System ... 5-17
Satellite Radio ............................... 5-48
Automatic Transaxle ........................... 4-30
Active Adaptive Shift (AAS) ........ 4-32
Direct Mode .................................. 4-39
Driving tips.................................... 4-40
Manual shift mode......................... 4-33
Shift-lock system ........................... 4-32
Shift position indication ................ 4-31
Warning light ................................. 4-31
B
Battery ................................................. 6-37
Maintenance .................................. 6-38
Specifi cations .................................. 9-4
Battery runs out ................................... 7-15
Jump-Starting ................................ 7-15
Blind Spot Monitoring (BSM)
System ............................................... 4-108
BSM OFF switch......................... 4-114
BSM warning light ...................... 4-113
Blind Spot Monitoring (BSM) .... 4-109
Care of radar sensors ................... 4-114
Blind Spot Monitoring (BSM) System
warning beep ....................................... 7-38
Blind Spot Monitoring (BSM) system
Rear Cross Traffi c Alert (RCTA) ... 4-111
Bluetooth® ........................................... 5-75
Bluetooth® Audio (Type A) ......... 5-114
Bluetooth® Audio (Type B) ......... 5-116
Bluetooth® Hands-Free (Type A) ... 5-95
Bluetooth® Hands-Free (Type B) ... 5-102
Troubleshooting .......................... 5-129
Body Lubrication ................................ 6-32
Bottle Holder ..................................... 5-138
Brakes
Brakes assist .................................. 4-70
Foot brake...................................... 4-68
Pad wear indicator ......................... 4-69
Parking brake ................................ 4-69
Warning light ................................. 4-69
Break-In .............................................. 3-45
C
Capacities .............................................. 9-5
Carbon Monoxide ............................... 3-29
Cell Phones ......................................... 8-19
Center Console .................................. 5-140
Child Restraint
Child-restraint precautions ............ 2-22
Installing child-restraint systems... 2-28
LATCH child-restraint systems ..... 2-36
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 582 of 585
10–5
Index
Interior Care ........................................ 6-69
Cleaning the Lap/Shoulder Belt
Webbing ........................................ 6-71
Cleaning the Upholstery and Interior
Trim ............................................... 6-70
Cleaning the Window Interiors ..... 6-71
Dashboard Precautions .................. 6-69
Maintenance of the Active Driving
Display .......................................... 6-71
Interior Lights ................................... 5-134
Luggage Compartment Light ...... 5-134
Map Lights .................................. 5-134
Overhead Lights .......................... 5-134
J
Jack ....................................................... 7-4
Jump-Starting ...................................... 7-15
K
Key Suspend Function .......................... 3-8
Key left-in-luggage compartment
warning beep (With the advanced keyless
function) .............................................. 7-37
Key left-in-vehicle warning beep (With
the advanced keyless function) ........... 7-38
Keyless Entry System ........................... 3-3
Keys ...................................................... 3-2
Key suspend function ...................... 3-8
Transmitter ...................................... 3-4
L
Label Information ................................. 9-2
Lane-Change Signals .......................... 4-52
Lane Departure Warning System
(LDWS) ............................................. 4-119
Canceling the system................... 4-123
LDWS warning ........................... 4-124
When the system operates ........... 4-122
Lane departure warning system (LDWS)
warning sound ..................................... 7-38 Liftgate ................................................ 3-21
Light Bulbs
Replacement .................................. 6-45
Specifi cations .................................. 9-9
Lighting Control.................................. 4-41
Lights-on reminder .............................. 7-36
Lubricant Quality .................................. 9-4
Luggage Compartment Light ............ 5-134
M
Maintenance
Information ...................................... 6-2
Scheduled ........................................ 6-4
Maintenance Monitor .......................... 6-20
Manual Transaxle Operation ............... 4-27
Recommendations for shifting ...... 4-29
Map Lights ........................................ 5-134
Mazda Radar Cruise Control (MRCC) ... 4-91
Close Proximity Warning .............. 4-94
Display Indication ......................... 4-94
Radar Sensor Handling ................. 4-99
Setting the System ......................... 4-95
Shift-up/Shift-down Request
Display .......................................... 4-99
Mazda Radar Cruise Control (MRCC)
System warnings ................................. 7-39
Meters and Gauges .............................. 4-12
Mirror Defroster .................................. 4-57
Mirrors
Outside mirrors.............................. 3-33
Rearview mirror ............................ 3-34
Money-Saving Suggestions ................ 3-45
Moonroof ............................................ 3-39
O
Odometer and Trip Meter .................... 4-13
Outside Mirrors ................................... 3-33
Outside Temperature Display .............. 4-16
Over Rev. buzzer ................................. 7-39
Overhead Console ............................. 5-139
Overhead Lights ................................ 5-134
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
Page 585 of 585
10–8
Index
Warning Sound is Activated ................ 7-36
Advanced Key removed from vehicle
warning beep ................................. 7-37
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ................... 7-36
Blind Spot Monitoring (BSM) System
warning beep ................................. 7-38
Collision warning .......................... 7-39
Ignition not switched off (STOP)
warning beep ................................. 7-37
Key left-in-luggage compartment
warning beep (With the advanced
keyless function) ........................... 7-37
Key left-in-vehicle warning beep (With
the advanced keyless function) ..... 7-38
Lane departure warning system
(LDWS) warning sound ................ 7-38
Lights-on reminder ........................ 7-36
Mazda Radar Cruise Control (MRCC)
System warnings ........................... 7-39
Over Rev. buzzer ........................... 7-39
Power steering warning buzzer ..... 7-39
Seat belt warning beep .................. 7-37
Tire infl ation pressure warning
beep ............................................... 7-38
i-ELOOP warning beep ................. 7-38
Warranty .............................................. 8-15
Weights.................................................. 9-8
Windows
Power windows ............................. 3-36
Windshield Washer ............................. 4-55
Windshield Wipers .............................. 4-53
Winter Driving .................................... 3-47
Wiper
Replacing Rear Window Wiper Blade
(5-Door)......................................... 6-35
Replacing Windshield Wiper
Blades ............................................ 6-33
/ C \ F C A & ( ' # * A ' F K V K Q P K P F D
