4. Turn the screw counterclockwise andremove it, and then partially peel back
the mudguard.

5. Disconnect the connector from the unitby pressing the tab on the connector
with your finger and pulling the
connector downward.

6. Turn the socket and bulb assembly to
remove it. Carefully remove the bulb
from its socket in the reflector by
gently pulling it straight backward out
of the socket.

7. Install the new bulb in the reverseorder of the removal procedure.
High-beam bulbs/Daytime running
lights
1. Make sure the ignition is switched off, and the headligh t switch is off.
2. Lift the hood.
3. Disconnect the connector from the unit by pressing the tab on the connector
with your finger and pulling the
connector downward.

Maintenance and Care
Owner Maintenance
6-44
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Rear turn signal lights, Brake lights/
Taillights/Rear side-marker lights (Bulb
type)
4–Door
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Pull the center of each plastic retainer
and remove the retainers.
3. Remove trunk end trim.
InstallationRemoval
4. Pull the center of each plastic retainer
and remove the retainers.
5. Peel back the trunk side trim.
Removal
Installation
6. Turn the socket and bulb assembly counterclockwise and remove it.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

Maintenance and Care
Owner Maintenance
6-47
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

9. Install the new bulb in the reverseorder of the removal procedure.
5–Door
(Left side)
1. Make sure the ignition is switched off, and the headlight switch is off.
2. Remove the cover.

3. Turn the socket and bulb assemblycounterclockwise and remove it.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

4. Disconnect the connector from the unit
by pressing the tab on the connector
with your finger and pulling the
connector.
Rear turn signal lights

Brake lights/Taillights/Rear
side-marker ligh ts (Bulb type)

Maintenance and Care
Owner Maintenance
6-49
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

5. Disconnect the bulb by pulling it out.Rear turn signal lights, Brake lights/
Taillights/Rear side-marker lights
(Bulb type)

6. Install the new bulb in the reverseorder of the removal procedure.
7. Insert the cover tabs and install the cover.
Tabs
NOTE
Verify that the cover is securely
installed.
(Right side)
1. Make sure the ignition is switched off,and the headligh t switch is off.
2. Turn the knob and remove the cover.
3. Turn the wing bolt and jack screw
counterclockwise.

4. Remove the jack
5. Turn the socket and bulb assemblycounterclockwise and remove it.
Maintenance and Care
Owner Maintenance
6-50
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

10. Turn the jack screw in the directionshown in the figure.

11. Turn the wing bolt completely tosecure the jack.
NOTE
If the jack is not completely secured, it
could rattle while driving. Make sure
the jack screw is sufficiently tightened.
12. Install the cover in the reverse order of the removal procedure.
13. Insert the cover tabs and install the cover.
Tabs
NOTE
Verify that the cover is securely
installed.
Reverse lights
4–Door
1. Make sure the ignition is switched off,
and the headligh t switch is off.
2. Pull the center of each plastic retainer
and remove the retainers.
3. Peel back the trunk lid trim.

Removal
Installation
4. Disconnect the electrical connectorfrom the bulb by pressing the tab on
the connector with your finger and
pulling the connector.

5. Turn the socket and bulb assemblycounterclockwise and remove it.
Maintenance and Care
Owner Maintenance
6-52
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

6. Disconnect the bulb from the socket.
7. Install the new bulb in the reverseorder of the removal procedure.
5–Door
1. Make sure the ignition is switched off, and the headlight switch is off.
2. Remove the cover.

3. Disconnect the electrical connectorfrom the bulb by pressing the tab on
the connector with your finger and
pulling the connector.

4. Turn the socket and bulb assemblycounterclockwise and remove it.
5. Disconnect the bulb from the socket.

6. Install the new bulb in the reverseorder of the removal procedure.
Maintenance and Care
Owner Maintenance
6-53
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

License plate lights
4–Door
1. Make sure the ignition is switched off,and the headlight switch is off.
2. Pull the center of each plastic retainer
and remove the retainers.
3. Peel back the trunk lid trim.

Removal
Installation
4. Disconnect the connector from the unit by pressing the tab on the connector
with your finger and pulling the
connector.

5. Turn the socket and bulb assembly
counterclockwise and remove it.
6. Disconnect the bulb from the socket.
7. Install the new bulb in the reverseorder of the removal procedure.
5–Door
1. Make sure the ignition is switched off, and the headligh t switch is off.
2. Wrap a flathead screwdriver with a
soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with a flathead screwdriver.
3. Disconnect the bulb by pulling it out.
4. Install the new bulb in the reverse
order of the removal procedure.
Maintenance and Care
Owner Maintenance
6-54
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Fuses
Your vehicle's electrical system is
protected by fuses.

If any lights, accessories, or controls do
not work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.

If the same fuse blows again, avoid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
▼ Fuse Replacement
Replacing the fuses on
the vehicle's left
side
If the electrical system does not work, first
inspect the fuses on the vehicle's left side.

1. Make sure the ignition is switched off,
and other switches are off.
2. Open the fuse panel cover.
3. Pull the fuse straight out with the fuse puller provided on the fuse block
located in the engine compartment.
4. Inspect the fuse and replace it if it isblown.
Normal Blown
5. Insert a new fuse of the same
amperage rating, and make sure it fits
tightly. If it does not fit tightly, have an
expert install it. We recommend an
Authorized Mazda Dealer.
If you have no spare fuses, borrow one
of the same rating from a circuit not
essential to vehicle operation, such as
the AUDIO or OUTLET circuit.
CAUTION
Always replace a fuse with a genuine
Mazda fuse or equivalent of the same
rating. Otherwise you may damage the
electric system.
Maintenance and Care
Owner Maintenance
6-57
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

6. Reinstall the cover and make sure thatit is securely installed.
Replacing the fuses under the hood
If the headlights or other electrical
components do not work and the fuses in
the cabin are normal, inspect the fuse
block under the hood. If a fuse is blown, it
must be replaced. Follow these steps:

1. Make sure the ignition is switched off, and other switches are off.
2. Remove the fuse block cover.
3. If any fuse but the MAIN fuse is
blown, replace it with a new one of the
same amperage rating .
Normal
Blown
WARNING
Do not replace the main fuse and
multiplex slow blow fuse by yourself.
Have an Authorized Mazda Dealer
perform the replacement:
Replacing these fuses by yourself is
dangerous because they are high
current fuses. Incorrect replacement
could cause an electrical shock or a
short circuit resulting in a fire.
4. Reinstall the cover and make sure that it is securely installed.
Maintenance and Care
Owner Maintenance
6-58
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Wa t e r M a r k s
Occurrence
Rain, fog, dew, and even tap water can
contain harmful minerals such as salt and
lime. If moisture containing these minerals
settles on the vehicle and evaporates, the
minerals will concentrate and harden to
form white rings. The rings can damage
your vehicle's finish.
Prevention
It is necessary to wash and wax your
vehicle to preserve its finish according to
the instructions in this section. These steps
should be taken immediately after you find
water marks on your vehicle's finish.
Paint Chipping
Occurrence
Paint chipping occurs when gravel thrown
in the air by another vehicle's tires hits
your vehicle.
How to avoid paint chipping
Keeping a safe distance between you and
the vehicle ahead reduces the chances of
having your paint chipped by flying
gravel.
NOTE
The paint chipping zone varies with the
speed of the vehicle. For example, when
traveling at 90 km/h (56 mph), the paint
chipping zone is 50 m (164 ft).
In low temperatures a vehicle's finish
hardens. This increases the chance of
paint chipping.
Chipped paint can lead to rust forming
on your Mazda. Before this happens,
repair the damage by using Mazda
touch-up paint according to the
instructions in this section. Failure to
repair the affected area could lead to
serious rusting and expensive repairs.

Follow all label and container directions
when using a chemical cleaner or polish.
Read all warnings and cautions.
▼ Maintaining the Finish
Wa s h i n g
CAUTION

When the wiper lever is in the
position and the ignition is switched ON,
the wipers may move automatically in
the following cases:
 If the windshield above the rain sensor
is touched or wiped with a cloth.
 If the windshield is struck with a hand
or other object from either outside or
inside the vehicle.
Keep hands and scrapers clear of the
windshield when the wiper lever is in the
position and the ignition is
switched ON as fingers could be pinched
or the wipers and wiper blades damaged
when the wipers activate automatically.
If you are going to clean the windshield,
be sure the wipers are turned off
completely (when it is most likely that the
engine is left running) this is particularly
important when clearing ice and snow.
Maintenance and Care
Appearance Care
6-64
