▼HomeLink Wireless Control System
CAUTION
HomeLink has been tested and
complies with FCC and Industry Canada rules. Changes or
modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the device.
NOTE
FCC ID: NZLMOBHL4
CANADA:4112A-MOBHL4
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1- This device may not cause harmful interference, and
2- This device must accept any interference received, including interference that may cause
undesired operation.
▼ Bluetooth® Hands-Free
Ty p e A
U.S.A. and Canada
FCC ID: NT8MBLUEC09 IC:3043A-MBLUEC09
This device complies wi
th Part 15 of the FCC Rules and with RSS -210 of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-45
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

WA R N I N G
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
The term “IC: ” before the radio certification number only sign ifies that Industry Canada
technical specifications were met.
The antenna used for this transmitter must not be co-located or operating in conjunction
with any other anten na or transmitter. End-users and installers must be provided with
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.
Mazda Bluetooth
® Hands-Free Customer Service
U.S.A.
Phone: 800-430-0153 (Toll-free)
Web: www.mazdausa.com/mazdaconnect
Canada
Phone: 800-430-0153 (Toll-free)
Web: www.mazdahandsfree.ca
Mexico
Brief description: Bluetooth mo dule for Hands-free telephone an d streaming audio
Name and address of the importer: Refer to "MEXICO" (page 8-13) in Importer/
Distributor section.
Brand name of the product: Visteon Corporation.
Model name of the product: MAZ
Names and addresses of where the warranty can be served: Refer to "MEXICO" (page
8-13) in Importer/Distributor section.
Names and addresses of where to acquire spare parts, consumable s and accessories: Refer
to "MEXICO" (page 8-13) in Importer/Distributor section.
Warranty period, items covered by the warranty and its possible limitations or exceptions:
Refer to the Warranty Booklet for detailed warranty information.
Warranty procedure:
Center of Attention to Client (CAC)
Phone: 01-800-01-MAZDA
Web: www.mazdamexico.com.mx
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-46
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Electrical specifications:
Voltage: 9-16V, Frequency: 2.4Ghz, Current: 270mA(Typ)
Ty p e B
U.S.A. and Canada
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-47
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Mexico
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-48
Mazda3_8GE4-EA-17F_Edition12017-4-7 11:59:21

▼Distance Recognition Sup
port System (DRSS)/Mazda Radar Cruise C ontrol
(MRCC)/Smart Bra ke Support (SBS)
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-49
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

MEMO
8-50
Mazda3_8GE4-EA-17F_Edition12017-4-7 11:59:21

9Specifications
Technical information about your Mazda.
Identification Numbers..................... 9-2 Vehicle Information Labels.......... 9-2
Specifications..................................... 9-4 Specifications............................... 9-4
Personalization Feat ures.................9-12
Personalization Features............. 9-12
9-1
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Vehicle InformationLabels
▼Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
▼Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼ Chassis Number
Open the cover shown in the figure to
check the chassis number.
▼Vehicle Emission Control
Information Label (U.S.A. and
Canada)
▼Tire Pressure Label
Specifications
Identification Numbers
9-2
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

▼Engine Number
Forward
Specifications
Identification Numbers
9-3
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.0 SKYACTIV-G 2.5
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 × 3.59 in) 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 1,997.6 ml (1,997.6 cc) 2,488.5 ml (2,488.5 cc)
Compression ratio 13.0
▼Electrical System
Item
Classification
Battery Q-85
*1
12V-60Ah/20HR*2 or 12V-65Ah/20HR*2
Spark-plug number
Mazda Genuine spark
plug*3PE5R-18-110 or PE5S-18-110
*1 Q-85 is designed for i-ELOOP sys
tem. Only Q-85 should be used to ensure correct operation of i-ELOOP
system. Consult an Authorized Mazda Dealer for details.
*2 Not for i-ELOOP system.*3 This spark plug provides the SK YACTIV-G engine with optimum performance. Contact an Authorized Mazda
Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-23.
Manual transaxle oil API Service
GL-4
SAE 75W-80
Automatic transaxle fluid Mazda Genuine ATF FZ
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
