ignition MAZDA MODEL 3 HATCHBACK 2019 (in English) Service Manual

The direction of the arrow ()
indicates that the fuel -filler lid is on the
left side of the vehicle.
▼ Dashboard Illumination
When the lights are turned on with the
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
not dim.
NOTE
When the ignition is switched ON in the
early evening or at dusk, the dashboard
illumination is dimmed for several
seconds until the light sensor detects the
brightness of the surrounding area,
however, the dimming may cancel after
the brightness is detected.
When the lights are turned on, the
lights-on indicator light in the
instrument cluster turns on.
Refer to Headlights on page 4-43.
The brightness of the instrument panel and
dashboard illuminations can be adjusted
by pressing the dashboard illumination
switch while the dashboard illumination is
dimmed.
The brightness decreases by pressing
the - switch. If you press the - switch
while the instrument cluster is at
maximum dimness, a sound is activated
to notify you that the current dimmer
setting is at ma ximum dimness.
The brightness increases by pressing the
+ switch.

1. Bright
2. Dim
Function for canceling illumination
dimmer
The illumination dimmer can be canceled
by pressing the + switch while the
instrument cluster i s at maximum dimness
and while the ignition is switched ON. If
you press the + swit ch again while the
illumination dimmer is canceled, a sound
is activated to no tify you that it is
canceled. If the in strument cluster's
visibility is reduced due to glare from
surrounding brightness, cancel the
illumination dimmer.
NOTE
When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
When Driving
Instrument Cluster and Display
4-18
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

▼Outside Temperature Display
When the ignition is switched ON, the
outside temperatur
e is displayed.

NOTE
Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and
vehicle conditions:
Significantly cold or hot temperatures.
Sudden changes in outside
temperature.
The vehicle is parked.
The vehicle is driven at low speeds.
Changing the Temperature Unit of the
Outside Temperature Display
The outside temperature unit can be
switched between Celsius and Fahrenheit.
Settings can be changed by operating the
center display screen.
Refer to the Settings section in the Mazda
Connect Owner's Manual.
NOTE
When the temperature unit indicated in the
outside temperature display is changed,
the temperature unit indicated in the
engine coolant gauge display changes in
conjunction with it.
▼ Distance-to-empty
This displays the approximate distance
you can travel on the remaining fuel based
on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.

NOTE
Even though the distance-to-empty
display may indicate a sufficient amount
of remaining driving distance before
refueling is required
, refuel as soon as
possible if the fuel level is very low or
the low fuel warning light illuminates.
The display will not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
indicating the remaining fuel supply
disappear.
If there is no past fuel economy
information such as after first
purchasing your vehicle or the
information is deleted when the battery
cables are disconnected, the actual
distance-to empty/range may differ from
the amount indicated.
When Driving
Instrument Cluster and Display
4-19
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

SignalWarning Refer to
Door-Ajar Warning Light 7-36
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
▼ Indication/Indicator Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Indicator Refer to
(Green)Seat Belt Indicator Light (Rear seat) 2-27
*Front Passenger Air Bag Deactivation Indicator Light
2-72
Security Indicator Light
3-40
(Green)KEY Indicator Light 4-5
Wrench Indication/Indicator Light*14-27
*Shift Position Indication
4-35
Lights-On Indicator Light
4-43
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-46
Flashing the Headlights 4-46
When Driving
Instrument Cluster and Display
4-24*Some models.
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

SignalIndicator Refer to
(White)
*Mazda Radar Cruise Control (MRCC) Standby Indication4-120
*Mazda Radar Cruise Control with Stop & Go func
tion (MRCC with Stop
& Go function) Standby Indication 4-129
*Cruising & Traffic Support (CTS) Standby Indication
4-141
(Green)
*Mazda Radar Cruise Control (MRCC) Set Indication4-120
*Mazda Radar Cruise Control with Stop & Go func
tion (MRCC with Stop
& Go function) Set Indication 4-129
*Cruising & Traffic Support (CTS) Set Indication
4-141
*Smart Brake Support (SBS) OFF Indicator Light*1
Smart Brake
Support (SBS) 4-155
Smart Brake
Support [Rear] (SBS-R)
4-159
Smart Brake
Support [Rear Crossing]
(SBS-RC) 4-164
(White)
*Cruise Standby Indication 4-210
(Green)
*Cruise Set Indication4-210
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the e ngine is started. If the light does not turn on or remains
turned on, have the ve hicle inspected at an Authorized Mazda De aler.
*2 The light turns on continuously w hen the parking brake is applied.
When Driving
Instrument Cluster and Display
4-26*Some models.
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Automatic TransmissionControls
▼Automatic Transmission Controls
1. Lock-release button
2. Selector lever

Indication Various Lockouts
Indicates that you must depress the
brake pedal and hold in the lock-re‐
lease button to shi ft (The ignition
must be switched ON).
Indicates the selector lever can be
shifted freely in to any position.
Indicates that you must hold in the
lock-release button to shift.
NOTE
The Sport AT has an option that is not
included in the tr aditional automatic
transmission that gives the driver the
option of selecting each gear instead of
leaving it to the transmission to shift
gears. Even if you intend to use the
automatic transmission functions as a
traditional automatic, you should also be
aware that you can inadvertently shift into
manual shift mode and an inappropriate
gear may be retained as the vehicle speed
increases. If you notice the engine speed
going higher or hear the engine racing,
confirm you have not accidentally slipped
into manual shift mode (page 4-35).
When Driving
Automatic Transmission
4-32
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Shift-Lock System
▼Shift-Lock System
The shift-lock system prevents shifting out
of P unless the brake pedal is depressed.

To shift from P:
1. Depress and hold the brake pedal.
2. Start the engine.
3. Press and hold the lock-release button.
4. Move the selector lever.
NOTE
When the ignition is
switched to ACC or
the ignition is switch ed off, the selector
lever cannot be shifted from P position.
The ignition cannot be switched to OFF
if the selector lever is not in P position.
▼ Shift-Lock Override
If the selector lever will not move from P
position using the proper shift procedure,
continue to hold down the brake pedal.
1. Remove the shift-lock override cover
using a cloth-wrapped flat head
screwdriver.
2. Insert a flat screwdriver and push it down.

1. Cover

3. Press and hold the lock-release button.
4. Move the selector lever.
Take the vehicle to an Authorized Mazda
Dealer to have the system checked.
When Driving
Automatic Transmission
4-33
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

M (Manual)
M is the manual shift mode position.
Gears can be shifted up or down by
operating the selector lever.
Refer to Manual Shift Mode on page
4-35.
▼Shift Position Indication
1. Shift position indication

The selector position is indicated when the
ignition is switched ON.
Gear position indication
In manual shift mode, the “M” of the shift
position indication illuminates and the
numeral for the select ed gear is displayed.
▼Active Adaptive Shift (AAS)
Active Adaptive
Shift (AAS)
automatically controls the transmission
shift points to best suit the road conditions
and driver input. This improves driving
feel. The transmission may switch to AAS
mode when driving up and down slopes,
cornering, driving at high elevations, or
depressing the accelerator pedal quickly
while the selector lever is in the D
position. Depending on the road and
driving conditions/vehicle operations, gear
shifting could be delayed or not occur,
however, this does not indicate a problem
because the AAS mode will maintain the
optimum gear position.
Manual Shift Mode
▼ Manual Shift Mode
The manual shift mode gives you the feel
of driving a manual transmission vehicle
by allowing you to operate the selector
lever manually. This allows you to control
engine rpm and torque to the drive wheels
much like a manual transmission when
more control is desired.
To change to manual shift mode, shift the
lever from D to M.

NOTE
Changing to manual shift mode while
driving will not damage the
transmission.
If you change to manual shift mode
when the vehicle is stopped, the gear
will shift to M1.
If you change to manual shift mode
without depressing the accelerator pedal
when driving in D range, 5th gear/6th
gear, the gear will shift to M4/M5.
To return to automatic shift mode, shift the
lever from M to D.
When Driving
Automatic Transmission
4-35
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Lighting Control
▼Headlights
Turn the headlight switch to turn
the headlights and other exterior lights on or off.
When the lights are turned on, the lights-on indicator light in the instrument cluster turns on.

NOTE
If the light switch is left on, the lights will automatically switch off approximately 30
seconds after switching the ignition off.
The time setting can be changed.
Refer to the Settings section in the Mazda Connect Owner's Manual.
To prevent discharging the battery, do not leave the lights on while the engine is off unless
safety requires them.
Without auto-light control
Switch Position
Headlights OffOff
On*1
Daytime running lights
On*2On*2Off
Taillights
Parking lights
License plate lights
Side-marker lights Off
On
*3On*1
*1 When the ignition is switched fr om ON to ACC or OFF, the headlights turn off if the auto headlight off
function has been canceled. If the auto headlight off function is enabled, the lights turn on for the set period
using the auto headlight off function, and then they turn off.
When Driving
Switches and Controls
4-43
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

*2 When the light switch is switched to a different position from the , position while the vehicle is
stopped, the daytime running lights turn off. When starting to drive the vehicle, the daytime running lights turn
on again.
*3 When the ignition is switched from ON to ACC or OFF, the headl ights remain on if the auto headlight off
function has been canceled. If the auto headlight off function is enabled, the lights turn on for the set period
using the auto headlight off function, and then they turn off.
With auto-light control
Switch Position*1Surround‐
ings are
bright
*2
Surround‐ ings are
dark
*3
Surround‐ ings are
bright
*2
Surround‐ ings are
dark
*3
Headlights Off Off On Off
On*4*5On*6
Daytime running lightsOff
On*7Off On*8Off Off
Taillights
Parking lights
License plate lights
Side-marker lights Off Off On
On
*9On*9On*6
*1 When the light switch is switched to OFF while the vehicle is stopped, the lights turn off. The light switch
returns automatically to the
position and the headlights ch ange to AUTO operation when you start
driving the vehicle.
*2 The level of brightness around the vehicle is of a sufficient level.*3 The level of brightness around the vehicle is of an insufficie nt level.*4 The daytime running lights can be disabled using the personali zation features (page 4-48). If the daytime
running lights are disabled, the headlights turn off directly a fter starting the engine. The headlights turn on
when you begin driving the vehicle.
*5 When the light switch is switched from the , , or position to the position while
the vehicle is stopped, the head lights turn off. When starting to drive the vehicle, the headlights turn on again.
*6 When the ignition is switched from ON to ACC or OFF, the headl ights turn off if the auto headlight off
function has been canceled. If the auto headlight off function is enabled, the lights turn on for the set period
using the auto headlight off function, and then they turn off.
*7 When the light switch is switched to a different position from the position while the vehicle is
stopped, the daytime running lights turn off. When starting to drive the vehicle, the daytime running lights turn
on again.
When Driving
Switches and Controls
4-44
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

*8 If one of the following operations is done from the position while the vehicle is stopped, the daytime
running lights turn off.
Switch the light s witch to the position.
Switch the light switch to the position, and then to the position again.
Switch the light switch to the position.
When starting to drive the vehicle, the daytime running lights turn on again.
*9 When the ignition is switched from ON to ACC or OFF, the headlights remain on if the auto headlight off
function has been canceled. If the auto headlight off function is enabled, the lights turn on for the set period
using the auto headlight off function, and then they turn off.
Auto-light control
When the headlight switch is in the
position and the ignition is switched ON, the
light sensor senses the surrounding lightness or darkness and automatically turns the
headlights and other exterior lights on or off.
CAUTION
 Do not shade the light sensor by adhering a st icker or a label on the windshield. Otherwise
the light sensor will not operate correctly.
 The light sensor also works as a rain sensor for the auto-wiper control. Keep hands and
scrapers clear of the windshield when the wiper lever is in the
position and the
ignition is switched ON as fingers could be pinched or the wipers and wiper blades could be
damaged when the wipers activa te automatically. If you are going to clean the windshield,
be sure the wipers are turned off completely when it is partic
ularly tempting to leave the
engine running. This is particularly important when clearing ice and snow.
NOTE
The headlights and other exterior lights may not turn off immediately even if the
surrounding area becomes well-lit because the light sensor determines that it is night time
if the surrounding area is continuously dark for several minute s such as inside long
tunnels, traffic jams inside tunn els, or in indoor parking lots.
When Driving
Switches and Controls
4-45
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10
