Power Steering
▼Power Steering
Power steering is only operable when
the engine is running. If the engine is off
or if the power steering system is
inoperable, you can still steer, but it
requires more physical effort.
If the steering feels stiffer than usual
during normal driving or the steering
vibrates, consult an Authorized Mazda
Dealer.
The warning indication notifies the
driver of system abnormalities and
operation conditions.
Refer to Power Steering Malfunction
Indication/Indicator Light on page
7-28.
CAUTION
Never hold the steering wheel to the
extreme left or right for more than 5
seconds with the engine running. This
could damage the power steering system.
When Driving
Power Steering
4-81
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

i-ACTIVSENSE*
▼i-ACTIVSENSE
i-ACTIVSENSE is a collective term
covering a series of advanced safety and
driver support systems which make use of
cameras and sensors. The systems consist
of active safety and pre-crash safety
systems.
These systems are designed to assist the
driver in safer drivi
ng by reducing the load
on the driver and helping to avert
collisions or reduce their severity.
However, because each system has its
limitations, always drive carefully and do
not rely solely on the systems.
▼ Active Safety Technology
Active Safety Technology supports safer
driving by helping the driver to recognize
potential hazards and avert accidents.
Driver awareness support systems
Nighttime visibility
Adaptive Front Lighting System
(AFS)...........................................page 4-87
High Beam Control System (HBC) ............
.....................................................page 4-88
Left/right side and rear side detection
Lane Departure Warning System
(LDWS).......................................page 4-90
Blind Spot Monitoring (BSM) ....................
.....................................................page 4-93
Road sign recognition
Traffic Sign Recognition System
(TSR)...........................................page 4-98
Inter-vehicle distance recognition
Distance & Speed Alert (DSA)...................
...................................................page 4-104
Front obstruction detection when
passing cross
Front Cross Traffic Alert (FCTA) ...............
...................................................page 4-109
Rear obstruction detection when leaving
a parking space
Rear Cross Traffic Alert (RCTA)................
...................................................page 4-112
Full-surround recognition
360°View Monitor.................... page 4-164
Driver fatigue detection
Driver Attention Alert (DAA) ....................
...................................................page 4-105
Driver Monitoring (
DM).......... page 4-107
Driver support systems
Inter-vehicle distance
Mazda Radar Cruise Control
(MRCC).................................... page 4-116
Mazda Radar Cruise Control with Stop &
Go function (MRCC with Stop & Go
function)....................................page 4-124
Lane departure
Lane-keep Assist System (LAS) .................
...................................................page 4-150
Inter-vehicle distance and lane keeping
Traffic Jam Assist (TJA).......... page 4-135
When Driving
i-ACTIVSENSE
4-82*Some models.
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

▼Pre-Crash Safety Technology
Pre-crash safety technology is designed to
assist the driver in averting collisions or
reducing their severity in situations where
they cannot be avoided.
Collision damage reduction
Forward driving
Smart Brake Support
(SBS)...... page 4-153
Reverse driving
Smart Brake Support [Rear]
(SBS-R).................................... page 4-156
Smart Brake Support [Rear Crossing]
(SBS-RC).................................. page 4-160
▼ Camera and Sensors
Forward Sensing Camera (FSC)
The Forward Sensing Camera (FSC)
detects lane indications and recognizes
headlights, taillights and city lights during
nighttime driving. I
n addition, it also
detects the vehicle ahead, pedestrians, or
obstructions. The following systems use
the Forward Sensing Camera (FSC).
High Beam Control system (HBC)
Lane Departure Warning System
(LDWS)
Traffic Sign Recogn ition System (TSR)
Distance & Speed Alert (DSA)
Driver Attention Alert (DAA)
Driver Monitoring (DM)
Mazda Radar Cruise Control (MRCC)
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function)
Lane-keep Assist System (LAS)
Traffic Jam Assist (TJA)
Smart Brake Support (SBS)
The Forward Sensing Camera (FSC) is
installed at the top of the windshield near
the rearview mirror.
Refer to Forward Sensing Camera (FSC)
on page 4-198.
Front radar sensor
The front radar sensor detects radio waves
reflected off a vehicle ahead sent from the
radar sensor. The following systems use
the front radar sensor.
Distance & Speed Alert (DSA)
Mazda Radar Crui se Control (MRCC)
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function)
Traffic Jam Assist (TJA)
Smart Brake Support (SBS)
The front radar sensor is mounted behind
the radiator grille.
Refer to Front Radar Sensor on page
4-202.
Front side radar sensor
The front side radar sensors detects radio
waves reflected off a vehicle ahead sent
from the radar sensor. The following
systems use the front side radar sensor.
Front Cross Traffic Alert (FCTA)
The front side radar sensors are installed
inside the front bumper, one on the left
side and one on the right side.
Refer to Front Side Radar Sensor on page
4-204.
When Driving
i-ACTIVSENSE
4-83
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Rear side radar sensor
The rear side radar sensors detects radio
waves reflected off a vehicle approaching
from the rear or an obstruction sent from
the radar sensors. The following systems
use the rear side radar sensor.
Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)
Smart Brake Support [Rear Crossing]
(SBS-RC)
The rear side radar sensors are installed
inside the rear bumper, one on the left side
and one on the right side.
Refer to Rear Side R adar Sensor on page
4-206.
Rear/rear corner/rear side ultrasonic
sensor
The ultrasonic sensor detects ultrasonic
waves reflected off obstructions at the rear
sent from the ultra sonic sensors. The
following systems use the ultrasonic
sensor.
Smart Brake Support [Rear] (SBS-R)
Smart Brake Support [Rear Crossing]
(SBS-RC)
The ultrasonic sensors are mounted in the
rear bumper.
Refer to Rear/Rear corner/Rear Side
Ultrasonic Sensor on page 4-207.
Front camera/side cameras/rear camera
The front camera, side cameras, and rear
camera shoot images of the area
surrounding the vehicle. The 360°View
Monitor uses each camera.
Cameras are installed to the front bumper,
door mirrors, and rear bumper.
Refer to Front Camera/Side Cameras/Rear
Camera on page 4-208.
Driver monitoring camera
The driver monitoring camera detects
changes in the driver's facial features and
estimates the amount of accumulated
fatigue and sleepiness of the driver. The
following system s use the driver
monitoring camera.
Driver Monitoring (DM)
The driver monitoring camera is mounted
in the center display.
Refer to Driver Monitoring Camera on
page 4-209.
▼ i-ACTIVSENSE Status Symbol
(Warning/Risk Avoidance Support
System)
*
The driver is notified of the status of the
following systems using the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system).
Lane Departure Warning System
(LDWS)
Blind Spot Monitoring (BSM)
Distance & Speed Alert (DSA)
Front Cross Traffic Alert (FCTA)
Rear Cross Traffic Alert (RCTA)
Lane-keep Assist System (LAS)
NOTE
The status of the system turned on using
the personalization feature is displayed.
When Driving
i-ACTIVSENSE
4-84*Some models.
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

i-ACTIVSENSE status symbol
(warning/risk avoidance support
system) (white)
System stand-by status
If none of the systems are activated or if
there is a problem with the system, the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) (white) is
displayed.
NOTE
For example, even when the Blind Spot
Monitoring (BSM) is operating normally,
if the Lane Departure Warning System
(LDWS) has a problem, the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) (white) is
displayed.
i-ACTIVSENSE status symbol
(warning/risk avoidance support
system) (green)
System activated status
If any one of the systems is activated, the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) (green) is
displayed.
NOTE
Even if the i-ACTIVSENSE status symbol
(warning/risk avoidance support system)
(green) is displayed, systems which do not
meet the operation conditions will not
operate.
i-ACTIVSENSE status symbol
(warning/risk av oidance support
system) (amber)
System warning status
If any system warning is activated, the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) (amber) is
displayed.
i-ACTIVSENSE status symbol
(warning/risk avoidance support
system) (non-display)
System OFF status
When all systems are switched off using
the personalization feature or the
i-ACTIVSENSE switch, the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) does not
display.
▼i-ACTIVSENSE Switch*
The operation status of all of the following
systems can be changed by operating the
i-ACTIVSENSE switch.
Lane Departure Warning System
(LDWS)
Blind Spot Monitoring (BSM)
Distance & Speed Alert (DSA)
Front Cross Traffic Alert (FCTA)
When Driving
i-ACTIVSENSE
*Some models.4-85
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

Rear Cross Traffic Alert (RCTA)
Lane-keep Assist System (LAS)
Smart Brake Support (SBS)
Smart Brake Support [Rear] (SBS-R)
Smart Brake Support [Rear Crossing]
(SBS-RC)
NOTE
For the systems which can be canceled
using the i-ACTIVESENSE switch, they
cannot be canceled when the following
systems are operating, even if you press
the i-ACTIVSENSE switch.
Mazda Radar Cruise Control (MRCC)
Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function)
Traffic Jam Assist (TJA)
If you switch the ignition OFF while you
have canceled some or all of the systems
using the i-ACTIVESENSE switch, the
operational status of each system will
vary when the ignition ON is switched
again.
Systems which maintain their status
before the ignition is switched OFF
Lane Departure Warning System
(LDWS)
Blind Spot Monitoring (BSM)
Distance & Speed Alert (DSA)
Front Cross Traffic Alert (FCTA)
Rear Cross Traffic Alert (RCTA)
Lane-keep Assist System (LAS)
Systems which are restored to
operational status automatically
Smart Brake Support (SBS)
Smart Brake Support [Rear] (SBS-R)
Smart Brake Support [Rear Crossing]
(SBS-RC)
If a system is canceled using the
personalization feature, the system
remains canceled even if the
i-ACTIVSENSE switch is pressed.
The systems which can be canceled vary
depending on whether the
i-ACTIVSENSE switch is short or
long-pressed.
When the i-ACTIVSENSE switch is
pressed and released immediately
When pressing and immediately releasing
the i-ACTIVSENSE swi tch, the following
systems are canceled and the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) turns off.
Lane Departure Warning System
(LDWS)
Blind Spot Monitoring (BSM)
Distance & Speed Alert (DSA)
Front Cross Traffic Alert (FCTA)
Rear Cross Traffic Alert (RCTA)
Lane-keep Assist System (LAS)
If the i-ACTIVSENSE switch is pressed
again, the systems return to their original
status, and the i-ACTIVSENSE status
symbol (warning/risk avoidance support
system) turns on.
When Driving
i-ACTIVSENSE
4-86
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

NOTE
You can select systems you want to cancel
using the personalization features.
Refer to the Settings section in the Mazda
Connect Owner's Manual.
When the i-ACTIVSENSE switch is
pressed and held
When pressing and holding the
i-ACTIVSENSE switch, the following
systems are canceled in addition to the
systems which are canceled by pressing
and immediately releas ing the switch. The
i-ACTIVSENSE status symbol (warning/
risk avoidance support system) turns off
and the SBS OFF indicator light turn on.
Smart Brake Support (SBS)
Smart Brake Support [Rear] (SBS-R)
Smart Brake Support [Rear Crossing]
(SBS-RC)
If the i-ACTIVSENSE switch is pressed
again, the systems return to their original
status, the SBS OFF indicator light turns
off and the i-ACTIVSENSE status symbol
(warning/risk avoidance support system)
turns on.
Adaptive Front Lighting
System (AFS)
*
▼Adaptive Front Lighting System
(AFS)
The adaptive front lighting system (AFS)
automatically adjusts the headlight beams
to the left or right in conjunction with the
operation of the steering wheel after the
headlights have been turned on and the
vehicle speed is about 2 km/h (2 mph) or
higher.
A system malfunction or operation
conditions are indicated by a warning.
Refer to Exterior Light Warning
Indication/Warning Light on page 7-33.
NOTE
The Adaptive Front Lighting System (AFS)
can be switched to on/off using the
personalization function.
Refer to the Settings section in the Mazda
Connect Owner's Manual.
When Driving
i-ACTIVSENSE
*Some models.4-87
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

High Beam ControlSystem (HBC)
*
▼ High Beam Control System (HBC)
The HBC determines the conditions in
front of the vehicle using the Forward
Sensing Camera (FSC) while driving in
darkness to automatically switch the
headlights between high and low beams.
Refer to Forward Sen
sing Camera (FSC)
on page 4-198.
While driving the vehicle at a speed of
about 30 km/h (19 mph) or more, the
headlights are switched to high beams
when there are no vehicles ahead or
approaching in the opposite direction.
The system switches the headlights to low
beams when one of th e following occurs:
The system detects a vehicle or the
headlights/lights of a vehicle
approaching in the opposite direction.
The vehicle is driven on roads lined with
streetlamps or on roads in well-lit cities
and towns.
The vehicle is driven at less than about
20 km/h (12 mph).
The headlight high-beam indicator light
turns on while the high beams are on.
1. Forward Sensing Camera (FSC)*1
*1 The recognition distance of the Forward Sensing
Camera (FSC) varies according to the
surrounding conditions.
The warning light turns on when the
system has a malfunction.
Refer to High Be am Control System
(HBC) Warning Indication/Warning Light
(Amber) on page 7-33.
CAUTION
 Do not adjust the vehicle height, modify
the headlight units, or remove the
camera, otherwise the system will not
operate normally.
 Do not rely excessively on the HBC and
drive the vehicle while paying sufficient
attention to safety. Switch the headlights
between the high beams and low beams
manually if necessary.
NOTE
The timing in which the system switches
the headlights changes under the
following conditions. If the system does
not switch the headlights appropriately,
manually switch between high and low
beams according to the visibility as well as
road and traffic conditions.
When there are sources of light in the
area such as street lamps, illuminated
signboards, and traffic signals.
When there are reflective objects in the
surrounding area such as reflective
plates and signs.
When visibility is reduced under rain,
snow and foggy conditions.
When driving on roads with sharp turn
or hilly terrain.
When Driving
i-ACTIVSENSE
4-88*Some models.
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

When the headlights/rear lamps of
vehicles in front of you or in the
opposite lane are dim or not
illuminated.
When there is insufficient darkness such
as at dawn or dusk.
When the luggage compartment is
loaded with heavy objects or the rear
passenger seats are occupied.
When visibility is reduced due to a
vehicle in front of you spraying water
from its tires onto your windshield.
▼To Operate the System
The HBC operates to s
witch the headlights
automatically between high and low
beams after the igni tion is switched ON
and the headlight sw itch is in the AUTO
and low beam position.
The HBC determines that it is dark based
on the brightness of the surrounding area.
At the same time, the HBC indicator light
(green) in the instrument cluster
illuminates.

NOTE
Operation of the HBC function can be
disabled.
Refer to the Settings section in the Mazda
Connect Owner's Manual.
▼ Manual Switching
Switching to low beams
Switch the headlight switch to the
position, or press the high beam control
switch.
The HBC indicator ligh
t (green) turns off.
1. High beam control switch

If the HBC is turned off using the high
beam control switch, press the high beam
control switch again to turn the HBC back
on.
Switching to high beams
Shift the lever to the high beam position.
The HBC indicator ligh t (green) turns off
and the headlight high-beam indicator
light is illuminated.
When Driving
i-ACTIVSENSE
4-89
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Lane Departure WarningSystem (LDWS)
*
▼Lane Departure Warning System
(LDWS)
The LDWS alerts the driver that the
vehicle may be deviating from its lane. If
the white (yellow) lin
es on the traffic lane
are detected using the Forward Sensing
Camera (FSC) and the system determines
that the vehicle may be deviating from its
lane, it notifies the driver by flashing the
LDWS warning light and activating the
LDWS warning beep, and by the
multi-information display.
Refer to Forward Sen sing Camera (FSC)
on page 4-198.
Use the LDWS when you drive the vehicle
on roads with white (yellow) lines.
1. Forward sensing camera (FSC)
2. Multi-information display
WA R N I N G
Do not rely completely on the LDWS.
 The LDWS system is not designed to
compensate for a driver’s lack of caution
and relying too much on the system
could lead to an accident.
 The functions of the LDWS have
limitations. Always stay on course using
the steering wheel and drive with care.
 Do not use the LDWS under the following
circumstances, otherwise it may result in
an accident.
 The vehicle is driven on slippery roads
such as icy or snow-covered roads, and
unpaved roads.
 Tires of a different specified size are
used, such as a temporary spare tire.
 Tires with insufficient tread are used.
 The tire pressures are not adjusted to
the specified pressure.
 The vehicle is being used to tow a
camper or boat trailer.
 Tire chains are used.
 The vehicle is driven on roads with lane
lines other than white (yellow) lines,
such as an expressway.
CAUTION
Heed the following cautions so that the
LDWS can operate normally.
Do not modify the vehicle's suspensions.
 Always use wheels of the specified type
and size for the front and rear wheels.
Consult an Authorized Mazda Dealer for
tire replacement.
When Driving
i-ACTIVSENSE
4-90*Some models.
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58
