MAZDA MODEL 3 SEDAN 2019 Owners Manual

Bottle Holder
▼Bottle Holder
Bottle holders are on the inside of the
doors.
1. Bottle holder

CAUTION
Do not use the bottle holders for containers
without caps. The contents may spill when
opening/closing the door or while driving
the vehicle.
Assist Grips
▼Assist Grips
WA R N I N G
Never hang heavy or sharp objects on the
assist grips and coat hooks:
Hanging heavy or sharp-ended objects
such as a coat hanger from the assist grips
or coat hooks is dangerous as they can
fly
off and hit an occupant in the cabin if a
curtain air bag was to deploy, which could
result in serious injury or death.
Do not use the assist grips when getting in
and out of the vehicle or getting out of a
seat:
An assist grip could break under a heavy
load resulting in injury.
Use the assist grips to support your body
while seated in the v ehicle and while the
vehicle is moving.
Interior Features
Interior Equipment
5-39
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Rear Coat Hooks
▼Rear Coat Hooks
WA R N I N G
Never hang heavy or sharp objects on the
assist grips and coat hooks:
Hanging heavy or sharp-ended objects
such as a coat hanger from the assist grips
or coat hooks is dangerous as they can
fly
off and hit an occupant in the cabin if a
curtain air bag was to deploy, which could
result in serious injury or death.
Always hang clothes on the coat hooks
and the assist grip s without hangers.
Storage Compartments
▼Storage Compartments
WA R N I N G
Keep storage boxes closed when driving:
Driving with the storage boxes open is
dangerous. To reduce the possibility of
injury in an accident or a sudden stop, keep
the storage boxes closed when driving.
Do not put articles in storage spaces with
no lid:
Putting articles in storage spaces with no
lid is dangerous as they could be thrown
around the cabin during sudden braking,
maneuvering, or acceleration and cause an
accident depending on how the article is
stored.
CAUTION
Do not leave lighters or eyeglasses in the
storage boxes while parked under the sun.
A lighter could explode or the plastic
material in eyeglasses could deform and
crack from high temperature.
Interior Features
Interior Equipment
5-40
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

▼Overhead Console*
This console box is designed to store
eyeglasses or other accessories.
Push and release to open.
▼Storage Pocket
To use, open the lid.
▼Glove Compartment
To open the glove compartment, pull the
knob toward you.
To close the glove compartment, firmly
press in the center of the glove
compartment lid.
▼Center Console
To slide the console lid, pull the knob and
slide it rearward.

To open the lid, pull
the knob, slide the lid
rearward, and then lift up the lid.
Interior Features
Interior Equipment
*Some models.5-41
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

NOTE
The lid can be opened/closed while it is
slid to the 1st and 2nd stages, but if the
rear seatback is folded, the lid cannot be
opened/closed while it is slid to the 2nd
stage because the rear seat (head
restraint) will contact it.

Center console divider
Small items can be placed using the center
console divider.
▼Luggage Compartment
NOTE
Loading golf bags (4–door)
(Some golf bags may not fit using the
following methods depending on their
sizes.)
Up to two golf bags can be carried in the
trunk.

First golf bag: Place the golf bag in the
luggage compartment with its bottom
pointed to the left and fit it into the front of
the compartment.
Second golf bag: Place the golf bag in the
luggage compartment with its bottom
pointed to the left and fit it into the back of
the compartment.
The arrows indicate the bottoms of the
golf bags.
Interior Features
Interior Equipment
5-42
Mazda3_8HE9-EA-18K_Edition3
2018-11-21 14:31:58

6Maintenance and Care
How to keep your Mazda in top condition.
Essential Information........................6-2 Introduction.................................. 6-2
Scheduled Maintenance.................... 6-4 Scheduled Maintenance................ 6-4
Owner Maintenance........................ 6-11 Owner Maintenance
Precautions..................................6-11
Hood........................................... 6-12
Engine Compartment
Overview.................................... 6-14
Engine Oil...................................6-15
Engine Coolant........................... 6-17
Brake/Clutch Fluid ..................... 6-18
Washer Fluid............................... 6-19
Body Lubrication...... .................. 6-20
Wiper Blades.............................. 6-20
Battery........................................ 6-25
Key Battery Replacement........... 6-27
Tires............................................ 6-30
Light Bulbs................................. 6-34
Fuses........................................... 6-37
Appearance Care............................. 6-43
Exterior Care.............................. 6-43
Interior Care................................6-49
6-1
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Introduction
▼Introduction
Be careful not to hurt yourself when
inspecting your vehicle
, replacing a tire, or
doing some kind of maintenance such as
car washing. In partic ular, wear thick work
gloves such as cotton gloves when
touching areas that are difficult to see
while inspecting or working on your
vehicle. Doing inspections or procedures
with your bare hands could cause injury.

If you are unsure about any procedure this
manual describes, we strongly urge you to
have a reliable and qualified service shop
perform the work, preferably an
Authorized Mazda Dealer.

Factory-trained Mazda technicians and
genuine Mazda parts are best for your
vehicle. Without this expertise and the
parts that have been designed and made
especially for your Mazda, inadequate,
incomplete, an d insufficient servicing may
result in problems. This could lead to
vehicle damage or an accident and
injuries.

For expert advice and quality service,
consult an Authorized Mazda Dealer.

To continue warranty eligibility and to
protect your investment, it is your
responsibility to properly maintain your
vehicle according to factory recommended
schedules outlined in this manual. As part
of this you must keep your maintenance
records, receipts, repair orders and any
other documents a s evidence this
maintenance was performed. You must
present these documents, should any
warranty coverage disagreement occur.
Failure to do so ca n result in your
warranty being voided either in whole or
in part.

This evidence may consist of the
following:
The Mazda Scheduled Maintenance
Record, refer to the Warranty Booklet,
must be completely filled out showing
mileage, repair order number, date for
each service, and signed by a qualified
automotive service technician who
service vehicles.
Original copies of rep air orders or other
receipts that include the mileage and
date the vehicle was serviced. Each
receipt should be signed by a qualified
automotive service technician.
For self maintenance, a statement that
you completed the maintenance
yourself, displaying mileage and the
date the work was performed. Also,
receipts for the repla cement parts (fluid,
filters, etc.) indi cating the date and
mileage must accompany this statement.

Maintenance and Care
Essential Information
6-2
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

NOTE
If you elect to perform maintenance
yourself or have your vehicle serviced at a
location other than an Authorized Mazda
Dealer, Mazda requires that all fluids,
parts and materials must meet Mazda
standards for durability and performance
as described in this manual.

Claims against the warranty resulting from
lack of maintenance, as opposed to
defective materials or authorized Mazda
workmanship, will not be honored.

Any auto repair shop using parts
equivalent to your Mazda's original
equipment may perform maintenance. But
we recommend that it always be done
by an Authorized M azda Dealer using
genuine Mazda parts.
Selecting “Vehicle Status Monitor”
enables the system to notify you of your
vehicle's approaching inspection/servicing
period. Refer to the In formation section in
the Mazda Connect Owner's Manual.

The malfunction diagnosis connector is
designed exclusively for connecting the
specially designed device to perform
on-board diagnosis.
Do not connect any devices other than the
specially designed malfunction diagnosis
devices for servicing. If any device other
than the malfunction diagnosis device is
connected, it may affect the vehicle's
electrical devices or lead to damage such
as battery depletion.
1. Malfunction diagnosis connector
Maintenance and Care
Essential Information
6-3
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Scheduled Maintenance
▼Scheduled Maintenance (U.S.A. and Puerto Rico)
Vehicles utilizing the vehicle status monitor feature:
The vehicle status monitor featur
e alerts you of maintenance needs by turning on the wrench
indicator light or displaying a message in the instrument panel , or both.
Every maintenance must be done within 16,000 km (10,000 miles), or 12 months (after the
previous maintenance) or when the display/wrench indication com es on, whichever comes
first.
If you drive your vehicle under any of the following conditions , follow the Severe Driving
Scheduled Maintenance and replace the engine oil and filter eve ry 8,000 km (5,000 miles)
or 6 months, whichever comes first.
Otherwise, follow the Normal Driving Scheduled Maintenance inte rvals.
1. The vehicle is idled for long periods or driven at low speeds , such as with police cars,
taxis, or driver's education school car.
2. Driving under dusty conditions.
3. Driving for long periods in co ld temperatures or driving regularly for short distances on‐
ly.
4. Driving under extremely high temperature conditions.
5. Driving continuously in mountainous regions.
If you are following the Severe Driving Scheduled Maintenance ( 8,000 km (5,000 miles) or
6 months oil replacemen t interval), it is recommended that you set the vehicle status monitor
manually.
Refer to the Information section in the Mazda Connect Owner's M anual. Please contact an
Authorized Mazda Dealer if necessary.
USA and Puerto Rico Residents (Normal Driving Scheduled Mainten ance):
Maintenance ItemNormal Driving Scheduled Maintenance Intervals
1st 2nd 3rd 4th 5th 6th 7th 8th
Engine oil & filter
*1RRRRRRRR
Spark plug Replace every 12 0,000 km (75,000 miles).
Air filter RR
Drive belts IIIIIIII
Engine coolant level IIIIIIII
Engine coolant
*2Replace at first 192,000 km ( 120,000 miles) or 120 months;
after that, every 96,000 km (60,000 miles) or 60 months.
Fuel lines & hoses
*3IIII
Hoses and tubes for emission
*3II
Brake lines, hoses and connections IIII
Maintenance and Care
Scheduled Maintenance
6-4
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

Maintenance ItemNormal Driving Scheduled Maintenance Intervals
1st 2nd 3rd 4th 5th 6th 7th 8th
Vacuum brake booster and hose With vacuum
boosterIIII
Brake and clutch fluid level IIIIIIII
Brake fluid With electrical
boosterRRRR
Disc brakes IIIIIIII
Tire rotation Rotate every 16,000 km (10,000 miles).
Tire inflation pressure and tire wear
*4IIIIIIII
Steering operation and linkages I I I I
Front and rear suspension, ball joints and wheel
bearing axial play IIII
Rear differential oil
*5
Transfer oil*5
Driveshaft dust boot II II
Bolts and nuts on chassis and body TTTT
Exhaust system and heat shields II
Emergency flat tire repair kit (if installed)
*6Inspect annually.
Cabin air filter Replace every 48 ,000 km (30,000 miles) or 24 months.
Function of all lights IIIIIIII
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
T: Ti g h t e n
Remarks:
*1 Reset the engine oil data whene ver replacing the engine oil regardless of the message/wrench indicator light
display.
*2 Use of FL-22 is recommended wh en replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or mileage/ kilometer period to ensure long-term reliability.
*4 Inspect a spare tire if installed.*5 If this component has been subm erged in water, the oil should be replaced.*6 Check the tire repair fluid exp iration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
Maintenance and Care
Scheduled Maintenance
6-5
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58

USA and Puerto Rico Residents (Severe Driving Scheduled Mainten ance):
Number of months or kilometers (miles), whichever comes first.
Months 6 12182430364248
× 1000 km 8 16 24 32 40 48 56 64
× 1000 miles 5 10 15 20 25 30 35 40
Engine oil & filter
*1RRRRRRRR
Maintenance Interval (other than engine oil &
filter replacement)
*21st 2nd 3rd 4th
Chart symbols:
R: Replace
Remarks:
*1 Reset the engine oil data whenever replacing the engine oil re gardless of the message/wrench indicator light
display.
*2 Follow Maintenance Interval lis ted in Normal Driving Scheduled Maintenance.
▼Scheduled Maintenance (Canada)
Vehicles utilizing the vehicle status monitor feature:
The vehicle status monitor feat
ure alerts you of engine oil replacement by turning on the
wrench indicator light or displaying a message in the instrumen t panel, or both.
Every engine oil replacement must be done within 16,000 km (10,000 miles) or 12 months
(after the previous oil replaceme nt) or when the display/wrench indicatior comes on, which‐
ever comes first.
If you drive your vehicle under any of the following conditions , replace the engine oil &
filter every 8,000 km (5,000 miles) or 6 months, whichever come s first.
1. The vehicle is idled for long periods or driven at low speeds , such as with police cars,
taxis, or driver's edu cation school vehicles.
2. Driving under dusty conditions.
3. Driving for long periods in co ld temperatures or driving regularly for short distances on‐
ly.
4. Driving under extremely high temperature conditions.
5. Driving continuously in mountainous regions.
If you are following 8,000 km (5, 000 miles) or 6 months maintenance interval, it is recom‐
mended that you set the vehicle status monitor manually.
Refer to the owner's manual section of mazda.ca for the Mazda C onnect owner's manual or
contact an Authorized Mazda Dealer if necessary.
Maintenance and Care
Scheduled Maintenance
6-6
Mazda3_8HE9-EA-18K_Edition3 2018-11-21 14:31:58
