2-44
Form No. 8R29-EA-02I
shuseizumi_J56J_8R29_EA_02I.book Page 44 Saturday, September 7, 2002 12:58 PM

3-1
Form No. 8R29-EA-02I
3Knowing Your Mazda
Explanation of basic operations and controls; opening/closing and adjustment
of various parts.
Doors and Locks
............................................................................ 3-2
Keys ........................................................................................... 3-2
Keyless Entry System ................................................................ 3-3
Door Locks ................................................................................ 3-7
Trunk Lid ................................................................................. 3-10
Trunk Release Slide Lever ....................................................... 3-12
Power Windows ....................................................................... 3-14
Fuel-Filler Lid and Cap ........................................................... 3-16
Hood ........................................................................................ 3-17
Sunroof .................................................................................... 3-18
Security System
........................................................................... 3-20
Immobilizer System ................................................................ 3-20
Theft-Deterrent System ........................................................... 3-22
Steering Wheel and Mirrors
...................................................... 3-25
Steering Wheel ........................................................................ 3-25
Mirrors ..................................................................................... 3-25
shuseizumi_J56J_8R29_EA_02I.book Page 1 Saturday, September 7, 2002 12:58 PM

3-2
Knowing Your Mazda
Form No. 8R29-EA-02I
Doors and Locks
Your Mazda has two kinds of keys:
primary and secondary.
Here’s what the keys are used for:
If you must leave your vehicle with
another person, such as a parking
attendant, protect items by locking the
glove box and trunk lid with the primary
key. Keep that key and give the other
person only the secondary key.
A code number is stamped on the plate
attached to the key set; detach this plate
and store it in a safe place (not in the
vehicle) for use if you need to make a
replacement key.
Also write down the code number and
keep it in another safe and handy place,
but not in the vehicle.
If your key is lost, consult your
Authorized Mazda Dealer with the code
number ready.Keys
Keys and Children:Leaving children in a vehicle with the
ignition key is dangerous. This could
result in someone being badly injured
or even killed. They could play with
power windows or other controls, or
even make the vehicle move. Don’t
leave the keys in your vehicle with
children.
•
To avoid damage to the key, do not:
Drop the key.
Get the key wet.
Expose the key to any kind of
magnetic field.
Expose the key to high
temperatures on places such as
the dashboard or hood, under
direct sunlight.
•
When starting the engine, do not let
the following materials touch the
key grip. The engine may not start:
Spare keys.
Keys for other vehicles equipped
with an immobilizer system.
Metal objects that touch or pass
through the hole in the key.
Devices for electronic purchases,
and security passage.
WARNING
CAUTIONLock Operates Primary
key Secondary
key
Ignition switch and
steering column lockYe s Ye s
Doors Yes Yes
Glove box Yes No
Trunk lid Yes No
Key code number plateSecondary key
(Gray) Primary key
(Black)
shuseizumi_J56J_8R29_EA_02I.book Page 2 Saturday, September 7, 2002 12:58 PM

3-3
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I
This system locks and unlocks the doors
and opens the trunk.
It can also help you signal for attention in
an emergency.
Press the button slowly and accurately.
Keyless Entry System
To avoid damage to the transmitter, do
not:
•
Drop it.
•
Get it wet.
•
Disassemble it.
•
Expose it to heat or sunlight.
CAUTION
NOTE
•
The keyless entry system is
designed to operate up to about 2.5
m (8 ft) from the center of the
vehicle, but this may vary because
of local conditions.
•
The system doesn’t operate when
the ignition switch is in the ON
position.
•
If the transmitter does not operate
when pressing a button or the
operation range becomes too small,
the battery may be dead. To install a
new battery, refer to Maintenance
(page 3-5).
•
Additional transmitters can be
obtained at an Authorized Mazda
Dealer. Up to 3 transmitters can be
used with the keyless entry system
per vehicle. Bring all transmitters to
an Authorized Mazda Dealer when
the electronic codes need to be
reset.
shuseizumi_J56J_8R29_EA_02I.book Page 3 Saturday, September 7, 2002 12:58 PM

3-4
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I

TransmitterLock button
To lock the doors, press the LOCK button
and the hazard warning lights will flash
once.
To confirm that all the doors have been
locked, press the LOCK button again
within 5 seconds. If they are closed and
locked, the horn will sound and the hazard
warning lights will flash once.
Unlock button
To unlock the driver’s door, press the
UNLOCK button and the hazard warning
lights will flash twice.
To unlock all the doors, press the
UNLOCK button again within 5 seconds
and the hazard warning lights will flash
twice.
Trunk button
To open the trunk, press the button.
Panic button
You can use the button to turn on the
alarm, which allows you to signal for
attention in an emergency.
NOTE
This device complies with part 15 of
the FCC Rules and with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions: (1)
This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation. (Outside
transmissions may momentarily
interfere with the device’s operation.)
NOTE
If the LOCK and UNLOCK button are
pressed sequentially, the hazard
warning lights may not flash correctly.
Panic buttonLock button
Trunk buttonUnlock button
NOTE
Confirm that all the doors are locked
visually or aurally by use of the double
click.
NOTE
After unlocking with the transmitter,
all doors will automatically lock if one
of the doors is not opened within about
30 seconds.
shuseizumi_J56J_8R29_EA_02I.book Page 4 Saturday, September 7, 2002 12:58 PM

3-5
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I
Turning on the alarm
Pressing the button once will trigger the
alarm for about 2 minutes and 30 seconds,
and do the following:
•
The horn sounds intermittently.
•
The hazard warning lights flash.
Turning off the alarm
Press any button on the transmitter.

Transmitter MaintenanceNOTE
The alarm will work whether any door
is open or closed.
•
Make sure the battery is installed
with the correct pole facing upward.
Battery leakage could occur if it is
not installed correctly.
•
When replacing the battery, be
careful not to bend the electrical
terminals or get oil on them. Also
be careful not to get dirt in the
transmitter as it could damage it.
•
Danger of battery explosion if it is
incorrectly replaced.
•
Replace only with the same type
battery (CR2025 or the equivalent).
•
Dispose of used batteries according
to the following instructions.
Insulate the plus and minus
terminals of the battery using
cellophane or equivalent tape.
Never disassemble.
Never throw the battery into fire
and/or water.
Never deform or crush.
CAUTION
shuseizumi_J56J_8R29_EA_02I.book Page 5 Saturday, September 7, 2002 12:58 PM

3-6
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I
Replacing the transmitter battery
1. Insert a small screwdriver into the slot
and gently pry open the transmitter.
2. Press the portion of the battery
indicated by A and remove the battery.3. Install a new battery (CR2025 or the
equivalent) into the front portion of the
holder with the positive pole ( )
facing up. Press on the B portion of the
battery to set the battery.
4. Align the front and back covers and
snap the transmitter shut.
Slot
Back cover
A
Do not press any buttons when
replacing the battery. The electronic
code could be altered and cause the
keyless entry system to malfunction.
If the keyless entry system fails to
operate, contact an Authorized Mazda
Dealer.
BBack cover
Front
coverFront o
fholder
CAUTION
shuseizumi_J56J_8R29_EA_02I.book Page 6 Saturday, September 7, 2002 12:58 PM

3-7
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I

Service
If you have a problem with the keyless
entry system, consult an Authorized
Mazda Dealer.
If your transmitter is lost or stolen, bring
all remaining transmitters to an
Authorized Mazda Dealer as soon as
possible for a replacement and to make
the lost or stolen transmitter inoperative.
•
Changes or modifications could
cause malfunctions and void the
keyless entry system warranty.
•
Damage to your keyless entry
system may prevent other systems
from operating properly and may
affect the vehicle warranty
coverage.
CAUTION
Door Locks
Unattended Children and Pets:Leaving a child or an animal
unattended in a parked vehicle is
dangerous. In hot weather,
temperatures inside a vehicle can
become high enough to cause brain
damage or even death. Always take all
children and animals with you or
leave a responsible person with them.
Keys and Children:
Leaving children in a vehicle with the
ignition key is dangerous. This could
result in someone being badly injured
or even killed. They could play with
power windows or other controls, or
even make the vehicle move. Don’t
leave the keys in your vehicle with
children.
Unlocked Doors:
Unlocked doors in a moving vehicle
are dangerous. Passengers can fall
out if a door is accidentally opened
and can more easily be thrown out in
an accident. So keep all doors locked
when driving.
NOTE
Always remove the key from the
ignition switch, close all windows, and
lock all doors when leaving your
vehicle unattended. This discourages
intruders and thieves.
WARNING
shuseizumi_J56J_8R29_EA_02I.book Page 7 Saturday, September 7, 2002 12:58 PM

3-8
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I

Locking, Unlocking with Key
The driver’s door can be locked/unlocked
with the key.
Turn the key toward the front to unlock,
toward the back to lock.

Locking, Unlocking with
Transmitter
The doors can be locked/unlocked by
operating the keyless entry system
transmitter, refer to keyless entry system
(page 3-3).

Locking, Unlocking with Door-
Lock Button
To lock any door from the inside, push its
door-lock button.
To unlock, pull it out.
This does not operate the other door lock.To lock any door with the door-lock
button from the outside, push its door-
lock button and close the door.
This does not operate the other door lock.
Unlock
Lock
UnlockLock
NOTE
•
Lockout prevention keeps you from
locking the driver’s door with the
key in the ignition switch at ACC or
LOCK.
If you try to lock the driver’s door
when the key is in the ignition
switch and any door is open, the
door lock immediately unlocks.
•
When locking the doors this way, be
careful not to leave the key inside
the vehicle.
Door-lock button
shuseizumi_J56J_8R29_EA_02I.book Page 8 Saturday, September 7, 2002 12:58 PM

3-9
Knowing Your Mazda
Doors and Locks
Form No. 8R29-EA-02I

Power Door Locks
Locking, unlocking with key
All doors lock automatically when the
driver’s door is locked with the key. All
doors unlock when the driver’s door is
unlocked and the key is held in the unlock
position a second longer.Locking, unlocking with door-lock
switch
All doors lock automatically when LOCK
is pushed. They all unlock when the
unmarked part of the door-lock switch is
pushed.

Rear Door Child Safety Locks
These locks are intended to help prevent
children from accidentally opening the
rear doors. Use them both whenever a
child rides in the vehicle.
If you slide the child safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can be opened only by lifting the
outside handle.NOTE
Holding the key in the unlocked
position in the driver’s door lock for
about a second unlocks all doors. To
unlock only the driver’s door, insert the
key into the driver’s door lock and turn
the key briefly to the unlock position
and then immediately return it to the
center position.
Unlock
Lock
Unlock
Lock
Lock
Unlock
shuseizumi_J56J_8R29_EA_02I.book Page 9 Saturday, September 7, 2002 12:58 PM
