MAZDA MODEL 6 2008 Quick Tips (in English)

ROADSIDE ASSISTANCE/WARRANTY
©2007 Calcar, Quick Tips®is a trademark
of Calcar, made in USA 5/07 46.658M DOT
Mazda North American Operations reserves
the right to change product specifications
at any time without incurring obligations.
9999-95-078C-08QT
8M81-19G217-AA
This Quick Tips® guide is
provided by Mazda North
American Operations to
make your Mazda ownership
experience more convenient.
For complete details and
operating instructions, see
your Owner’s Manual.If you have any questions about
your vehicle, you are invited to
contact your local dealer.
Or if you need additional help,
feel free to call our
Customer Assistance Center
at 1-800-222-5500
Monday through Friday,
8 a.m.- 4:45 p.m., Pacific
9 a.m.- 5:45 p.m., Eastern/Central Mazda Roadside Assistance
Exhilaration, liberation and inspiration,
are great reasons to drive a
Mazda car, truck or SUV. In addition
to all the other great standard
features, you also get peace of mind
with our basic warranty period
Emergency Roadside Assistance
Plan, it’s just a phone call away,
24 hours a day, 365 days a year,
call 1-800-866-1998.
Mazda ‘’bumper-to-bumper”
Limited Warranty and
Powertrain Warranty
Engineers design and build every
Mazda to give you driving pleasure
now and far down the road. We’re
so confident in our quality that we
cover the entire vehicle against defects
in materials and workmanship for
36 months/36,000 miles, whichever
comes first, plus we provide a
powertrain warranty for 60 months/
60,000 miles, whichever comes first.
Unleaded
Gasoline
87-octane
minimum
18-gallon/
68.0-liter tank
www.mazdausa.com
MAZDA6
Quick Tips®
Reference
Guide for
Controls and
Functions

DRIVER’S VIEW
1. Power window switches,
see Switches
2. Power door locks,
see Locks
3. Dual power mirrors,
see Switches
4. Instrument panel lighting,see Getting Started
5. Air vents
6. Turn signal/lighting
control lever,
see Driver Controls
7 . Traction Control System*,
see Instrument Cluster
8. Horn/Air bag
9. Wiper/washer control
lever,see Driver Controls
10. Clock setting buttons,see Getting Started
11. NAVI Display*,
see Owner’s Manual
12. Information display,see Information Display13. AMBAmbient temperature display,
see Information Display.
14. Hazard warning
switch, Press on/off.
15. Audio system,
see Audio Systems
16. Climate control panel,
see Climate Controls
17. Passenger air bag off
indicator,see Seats18. Accessory socket
19. Gearshift lever (A/T),
see Transmission
20. Cup holder
21. Seat warmer*,see Trunk/Console
22. Console, see Trunk/Console
23. Parking brake lever,
see Trunk/Console
24. NAVI Remote control*
Getting Started
MAZDA6 Quick Tips®are
designed to quickly familiarize
you with some important
features of your MAZDA6.
This Driver’s View tab is your
index to the Quick Tips
®, locate
the item you would like to
learn more about and then
turn to the listed tab.
Be sure to see the tab called
Getting Started, this section
contains important operating
tips about your MAZDA6.
Items identified in blue text
call out unique features.
Driver’s
View
HF
E C
P
R
N
D
M
20 123x1000rpm/m
4
5
6
7
8
0 20mph km/h
4060
80
100
120
140
TRIPA8
O.O20 406080100120
140
160
180
200
220
240
012
3
4
14 5
16
30 29
32
26 28 27
8 6 5 2 3 1
25
33
17
15
18
9 10 13 11 12
23
25
24 R
N
D P M
19
21 20
18 22
4
731
Always check the Owner’s Manual for more operating information and safety features
25. Storage
26. Cruise control, see Getting Started
27. Tilt/telescopic
steering-wheel lever,
see Getting Started
28. Audio control switches, see Getting Started
29. Remote trunk release
(Sedan only)
Push to open trunk.
30. Hood release handle
31. Headlight leveling switch*,see Getting Started
32. Bottle holder
CAUTION: Use plastic bottles
with caps, cups may spill
when door is closed.
33. Remote fuel-door
release
*Denotes optional equipment

GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Getting
Started
Getting
Started
Cruise
control
Operates
above
19 mph.
To activate:
Press and release ON/OFF (1).
To set speed: Press and release
SET/COAST (3) at desired speed.
To accelerate: Press and hold
RES/ACCEL (2); incremental
acceleration: Press and release
(2), each tap = plus 1 mph.
To decelerate: Press and hold SET/
COAST (3), release at desired speed;
or tap brake pedal, press and release
(3) at desired speed; incremental
deceleration: Press and release
(3), each tap = minus 1 mph.
To cancel: Tap brake pedal, clutch
pedal (manual transaxle) or press
CANCEL button (4) or ON/OFF (1).
Return to preset speed after
Remote keyless entry systemFunctions only with key removed
from ignition switch.
To lock doors: Press button (1);
press again within 5 seconds,
doors relock and horn beeps.
To unlock: Press (2) for driver’s
door; press again within 5 seconds to
unlock other doors, press and hold
for 3 seconds to lower front windows.
To open trunk: Press (4).
Panic alarm: Press (3); horn
sounds; to stop, press any button
on the transmitter or turn ignition
to ON position.
Tilt/telescopic
steering-wheel
lever
Pull lever (5)
down to unlock
column, adjust tilt
angle and length
of steering column.
WARNING: Do not adjust
steering-wheel while driving.
Instrument panel
lighting
To brighten/dim turn
thumbwheel up/down.
HID headlights
leveling switch*
Set position at 0 unless
vehicle is loaded heavily,
leveling switch adjusts
headlight angle to compensate
for weight of passengers and
cargo, see Owner’s Manual.
Remote window operationRemote keyless entry: Press unlock
button (2) twice and hold, doors
unlock and front windows fully open.
Key: Insert key in driver’s door
lock; turn toward front/rear of
vehicle and hold it, after doors
are unlocked/locked windows
will open/close.
ClockTo set: With ignition in ACC or
ON position, press (A) and hold
until beep sounds; 12 hr/24hr
will be displayed; press (B) to
select; press (A) again while
selection is flashing: Hr ADJUST
displays; press (B) to select hr;
press (A) when done, do the
same to set minutes.
1243
123
5Sedan
5-Door
10
Rear
center
position
seat belt
†
Connecting
seat belt: Pull
seat belt from
recess behind
head restraint (A) (Sedan) or left side
of cargo area (B) (5-Door) and
connect tongue (10) to anchor (11).
Wearing seat belt: Slowly pull out lap/
shoulder belt (12) and insert tongue
(13) into buckle (14) until click is heard.
Unfastening seat belt: Depress
buckle button (14) to release.
Tip: Leave center-rear lap portion
of seat belt fastened at all times
except when folding rear seat.
Stowing seat belt: Insert key or small
object in anchor buckle slot (15) to
release entire belt, let it fully retract,
then put tongues (10) and (13) together,
insert securely into recess (Aor B). CANCELbutton or braking: Press
and release RES/ACCEL button (2).
Tip: Cruise control will not
be canceled in Manual Mode
during gear changes.
Steering-
wheel
audio
controls
To increase/decrease
volume: Press (5).
Radio: Press (6) less than one
second to select next/previous
preset station, press (6) more
than one second until beep sound is
heard to seek next/previous station.
Cassette/CD: Press (6) to select
next selection/track, press (6)
to repeat current selection/track.
Press (7) to select AM, FM 1,
FM 2, Cassette* and CD mode.
Press (8) to mute Audio/NAVI system*.
/
/
M
O
D
EV
O
L5
678
RES
ACCEL ON
OFF
CANCELSET
COAST43
12
*Denotes optional equipment†See Owner’s Manual
CLOCK
SETABTILT
SET CLKAB
1511
10
14 13
AB
12

INSTRUMENT CLUSTER
Always check the Owner’s Manual for more operating information and safety features
Instrument
Cluster
Instrument
Cluster
H F
E C
P
R
N
D
M
2
1 2 2 13 12 14 11
0 1 2 3 x1000r/min
4
5
6
7
8
19 20 22 21 23 25 18 24 6
8
10 9
26
4 15
17
16
0 20 mph
km/h 40 60
80
100
120
140
TRIP A 8
O.O
20 40 60 80 100 120
140
160
180
200
220
240
7 5
3
18. Brake system
Parking brake on/low fluid level.
19. Check engine
Dealer inspection required.
20. Charging system
Dealer inspection required.
21. Engine oil pressure
22. Air bag readiness
Front, side and/or curtain air bag
malfunction; warning light
constantly flashes or stays on
or never comes on with ignition
on, dealer inspection required.
23. Door ajar
24. Immobilizer system on,
see Locks
25. Always fasten seat belts
26. Tire Pressure
Monitoring System
(TPMS),
see Trunk
8. Engine coolant
temperature gauge
If above normal range, stop
vehicle and turn off engine,
check coolant level when safe.
12. Automatic transaxle
Dealer inspection required
if light remains on.
13. High beams on
14. Traction Control
System (TCS)
Light flashes when in use;
dealer inspection required if
light remains on.
Enhances traction and safety
by regulating engine torque.
When TCS detects drive wheel
slippage it lowers engine torque
to prevent loss of traction.
15. Lights on*
16. Traction Control
System off
System turned off manually
or malfunctioning; dealer
inspection required.
17. Low fuel7. Odometer/tripmeter
selector
Press to select among trip A,
trip B, and odometer.
Press and hold to reset selected
trip meter.
WARNING LIGHTS
9. Cruise control,see Getting Started
10. Cruise Control Main
Power On,see Getting Started
11. Anti-lock Brake
System (ABS)
ABS malfunction, normal brakes
only, dealer inspection required.
ABS automatically reduces
hydraulic pressure to any wheel
on the verge of locking up.
You may feel a slight pulsing of
the brake pedal and hear a
clicking noise; this tells you the
ABS is functioning properly;
increase pressure on pedal for
maximum braking.
Tips: Maintain constant
pressure on the brake pedal.
Do not pump the brakes.
CRUISE
MAIN
CRUISE
GAUGES
1. Tachometer
2. Turn signals/hazard
warning on
3. Speedometer
4. Fuel gauge
5. Odometer/tripmeter
6. Gear indicator
Displays current gear of Sport AT.
*If equipped with black-out meter


DRIVER CONTROLS
Always check the Owner’s Manual for more operating information and safety features
Driver
Controls
Switches
12
= Fog lights on: Rotate knob
(2); functions only with headlight
low beams on
Turn signals right/left: Move lever
up/down.
Tip: Headlights switch off auto-
matically within 30 seconds if
lights are left on and switch is
in lock position or key removed.
Wiper/washer control lever
Intermittent wiper: One click down.
To change interval speed:
Rotate inner ring (3).
Normal wiper speed: Two
clicks down.
Fast wiper speed: Three
clicks down.
Single wipe: Push stalk up.
Washer: Pull stalk back.
Rear window wiper/washer
(5-Door)
To activate rear interval wiper:
Rotate knob (4) up to INT.
To activate rear normal speed
wiper: Rotate knob (4) up to ON.
To activate rear washer with
wipers operating: Rotate knob
(4) up to ; hold knob (4)
to continue washing; release
knob and wipers will continue
to operate.
To operate stand alone wipe/
wash function: Rotate knob
(4) down and hold, release
to stop.
Front window switches
One-touch down/up: Press/pull
AUTO switch (3) firmly and
release, window goes down/up
all the way, press/pull briefly
to stop, press/pull lightly and
hold for normal operation.
Tip: During closing window
operation, window will stop
and open partway if object
blocks window operation.
Rear window switches
Push/pull (4) to open/close.
Power window lockout switch
Press button (5), only driver's
window operates; press again
for normal operation.
Power window
initialization procedure
If battery is disconnected or power
window fuse is replaced, the auto
open/close and anti-pinch features
will not function.Resetting procedure:
1. Turn ignition switch
to “ON” position.
2. Make sure that power
window lock switch located
on driver’s door is not
depressed.
3. Press switch and fully open
power window.
4. Pull up switch to fully close
power window and continue
holding switch for about
2 seconds after window
fully closes.
5. Repeat steps 3- 4 for front
passenger power window
while seated in front
passenger seat.
6. Make sure power windows
operate correctly using
door switches.
Dual power
mirrors
Ignition switch
must be in ACC
or ON position.
Switch is on
driver’s door.
To adjust left/right mirror:
Press selector switch (1) left/
right, press switch (2) in direction
of desired movement.
Tip: To lock mirrors in place,
move selector switch (1) to
center position.
Power window
switches
With ignition ON.
All windows
controlled from
driver’s armrest;
passenger doors
have separate
switches.
Turn signal/lighting
control lever
OFF= Lights off
= Tail, parking and
dashboard lights on: Rotate
knob (1) to first notch
= Tail, parking, dashboard
and headlights on: Rotate knob
(1) to second notch
High beams on/off: Push lever
forward/pull back to detent.
To flash high beams: Pull lever
back slightly and release.
34
R
E
A
R
543
AU
TOA
U
TO
LR
2
1

Automatic transmission
P =Park
To move gearshift from Park:
Press firmly on brake pedal.
R =Reverse
N =Neutral
No gear engaged.
D (Overdrive)
For normal driving: Shifts through
all forward gears automatically.Manual
transmission
Depress clutch
pedal to start engine
and change gears.
WARNINGS: Do not shift into
1st above 20 mph or clutch
failure could occur.
Resting your foot on clutch
pedal while driving and using
the clutch to hold your vehicle
at a stand still while waiting
on a hill may reduce clutch life.
R
N
DP
M

LOCKS
Always check the Owner’s Manual for more operating information and safety features
Locks
Transmission
Key
Operates ignition and all locks.
Tip: Use key number plate
to purchase a new key;
store in safe place separate
from vehicle.
Retractable key
To fold/unfold press release
button (1).
Immobilizer system
Prevents engine from running
unless coded key is used; see
Owner’s Manual.
Remote
keyless entry
system,
see
Getting StartedChild-safety locks
Located at edge of rear doors.
To activate: Pull tab (4) up;
door opens from outside only.
To cancel: Push tab (4) down.
WARNINGS: Since children
may access either rear door,
child-safety locks for both
rear doors should be activated
Never leave a child in car
with key in the vehicle.
Manual door
locks
To lock: Press
front of button (2)
toward door handle.
To unlock: Pull front
of button away
from door handle.
Power door locks
To lock/unlock all doors from
inside vehicle: Press bottom/top
of switch (3).
To lock doors without key: With
door open, press bottom of door
lock switch, exit car, close doors.
To unlock: Use key to unlock driver’s
front door, rotate key to counter-
clockwise position for more than one
second to unlock other doors, hold
for 3 seconds to lower front windows.
Tip: Doors can be locked with
key in ignition (chime sounds
to alert you to key in ignition).
LOC
K UNL
OCK
3
2
Lock
Unlock
41
M (Sport A/T
manual shift mode)
Move shifter from
D to M to engage
manual shift mode,
M will be illuminated
for manual mode on
shift position indicator located
in the instrument panel.
Manual shifting of transmission
is achieved by moving shifter
back to upshift and forward to
downshift, move shifter from
M to D to engage automatic
shift mode.
Gear indicator
(A/T only)
Illuminated numeral of
gear indicatorlocated in
the instrument panel
displays current gear in
Automatic and Manual
shift modes.
MD
P
NR
2
P
R
N
D
M 7
2

SEATS
Always check the Owner’s Manual for more operating information and safety features
Seats
Seats
4
8
1
4
8
3
2
6 7 5
see Owner’s Manual for
additional information on this
feature and the air bag system.
Seat belt emergency
locking mode
Belts lockonly on hard acceleration,
braking, cornering or impacts of
about 5 mph or more.
Automatic locking mode
(all seat belts except
driver’s seat belt)
Must be used when installing
child-safety seat.
To activate: Pull belt fully out of
retractor, allow belt to retract until
click is heard; belt will only tighten.
To disengage: Unbuckle belt and
allow belt to retract fully.
Rear center position seat belt 5-Door: Seat belt stowage located
behind left side head rest, see
Getting Started.
Shoulder belt height
adjustment
To raise: Push
adjuster upward.
To lower: Pull
button (1) and
slide downward.
WARNING: Make sure adjuster
locks in one of its positions.
Manual controls
1. Fore-aft adjustment
Lift lever and hold, slide
seat, release lever.
2. Raise/lower seat
Pull/push lever repeatedly to
desired height and release.
3. Seatback angle
To adjust: Lift and hold lever, lean
forward or backward, release lever.
4. Head restraint
To raise/lower: Pull up/push in
release button (8) and push down.
WARNINGS: Do not adjust
seats while driving.
Seat belts must always be
worn when vehicle is in motion.
Air bags are supplemental
and do not replace seat
belt usage.
Always wear your seat belt
and properly secure children
12 and under in the rear seat.
Even with a deactivation
system, never place rear-facing
infant-safety seat in front
of any air bag, an infant is
in serious danger of being
injured or killed.
If you must install a forward-
facing child-safety seat in the front
seating position, move vehicle
seat as far back as possible.
Use age appropriate child
restraints,see Owner’s Manual
and state or province laws.
5. Lumbar adjustment
Rotate knob to increase/
decrease firmness.
Power driver’s seat6. Raise/lower front of
seat cushion
Pull/push front of switch vertically.
Fore/aft adjustment
Slide switch horizontally.
Raise/lower rear of
seat cushion
Pull/push rear of switch vertically.
Raise/lower seat
Pull/push center of switch
vertically.
7. Seatback angle
Press front/rear of switch.
Tip: Verify side air bags
by locating “SRS AIRBAG”
indicator tags on outboard
side of front seatbacks.
Folding rear seatbacks,
see Trunk/Console
Child-safety seat
To install in rear outboard seats: Use
dual locking mode retractor seat
belts; see Owner’s Manual for proper
installation and child seat tether
and LATCH system instructions.
Passenger air bag
deactivation indicator light
Front air bag deactivation indicator
light provides current status of
front passenger air bag and
pretensioner system.
If total seated weight on front
passenger seat is less than
approximately 66 lb., front
passenger air bag deactivation
indicator light illuminates,
air bag/pretensioner will not
deploy/activate in an accident.
If the total seated weight is greater
than approximately 93 lb., light
does not illuminate, and the air
bag/pretensioner will deploy/activate
in an appropriate accident,
1
*Denotes optional equipment

CLIMATE CONTROLS
Always check the Owner’s Manual for more operating information and safety features
Climate
Controls
Information
Display
2. Fan control
Rotate knob clockwise/
counterclockwise to increase/
decrease fan speed.
3. Temperature control
Cooler/warmer = rotate knob
counterclockwise/clockwise
4. A/C= air conditioner
Press to turn on/off.6. Rear window defogger
Press on/off; shuts off with
ignition or automatically after
15 minutes of operation; also
operates heated side mirrors.
Tip: The word “heated” is
imprinted on glass reflector
of side mirrors, this indicates
they are heated.
7. OFF
Control positions for
maximum defrost
Fan to maximum, temperature
to maximum hot, selected.
Tips: To help prevent windshield
fogging in humid weather,
select .
To prevent fogging, never
drive with system off.
Objects placed under the
front seats may interfere
with air flow to the rear.
AMBPress AMB button (2) to display
ambient temperature, press again
to switch display to temperature
set for air conditioner.
Tip: To change from Fahrenheit
to Centigrade or vice versa:
Press AMB button (2) for 2
seconds or more.
1. Air flow selections
= air to dash
= air to dash and floor
= air to floor
= air to floor and
windshield
= air to windshield (defrost)
(Manual Climate Control)5. Air intake control
= recirculate inside air;
use for maximum cooling
= fresh air
WARNING: Do not use
position in cold
weather, windows may
fog and hamper vision.
8. Windshield defroster switch
Press: Fresh air position is
automatically selected, A/C
automatically turns ON.
Automatic operation
Press AUTO (9) for automatic
operation; rotate outer dial to set
temperature, see Owner’s Manual.
Tip: Automatic climate control
display viewed via information
display, see below.
9187
A/C
PUSHAUTO CHPUSHOFF
FRONT
MODE012
3
4
A/C
321
45662354
Manual A/CAutomatic A/C
Information displayInformation display (1) has
the following functions:
Clock, audio display, automatic
climate control display and
ambient/cabin temperature
display (AMB).
88:8.8 FM1 88.9 88.8CHCD MD 123456ST RPT RDM AUTO-M8AMB FOAUTOA/C ECO
12

AM/FM STEREO/CASSETTE/CD CHANGER
Always check the Owner’s Manual for more operating information and safety features
Audio
Systems
Audio
Systems
1. Power/Volume
Press to turn on/off; rotate
to increase/decrease volume.
2. SEEK/TRACK/APC
Radio: Press to
automatically seek higher/
lower frequency.
CD: Press to select
next/previous track.
Cassette*: Press to
automatically advance tape to
beginning of next selection/
replay selection; to stop this
operation, press button again.
3. LOAD
To load multiple discs*: Press
and hold LOAD (3) until
beep sound is heard; insert
CD when “In” is displayed.
To eject disc: Press Eject (11).
12. Scan/Auto-Memory
Press to briefly sample next
listenable selections; functions
in all modes.
Radio: Press and hold until a beep
sound is heard; system auto-
maticallyscans and temporarily
stores six strong stations in each
band; press again to cancel.
13. Tuning/Audio Control
Tune: Rotate counterclockwise/
clockwise for lower frequency/
higher frequency.
Audio control: Press to select
ALC/BASS/TREB/FADE/BAL/BEEP
(Automatic level control) can be
turned on and off; rotate right/left
to adjust selected feature.
ALC ON = Audio volume
decreases/increases with
vehicle speed
ALC OFF = Audio volume does
not decrease/increase with
changes in vehicle speed14. Fast forward
Press to fast forward
through a track.
15. Cassette eject button*
16. Reverse
Press to reverse through a track.
17. Program Random
Press for random play.
18. Cassette door*
19. Repeat
Press to replay current
CD/tape selection.
20. Dolby® Noise Reduction*
Reduces tape noise and hiss;
press to activate/deactivate.
21. Disc up *
Press to skip forward to
beginning of next CD.
22. Disc down *
Press to skip back to
beginning of previous CD.
23. Display, see Information Display
VOL PUSH POWER
SEEK
TRACK
APC
1DBCV2DBC 56 3RPT4PROG
RDMV
FM 1/2 AM SAT CD MEDIA
TUNE PUSH AUDIO CONT.
TEXT
SCAN
AUTO-M DISP/ESN
LOAD
25679108311124
13114
88:8.8 FM1 88.9 88.8CHCD MD 1 2 3 4 5 6 ST RPT RDM AUTO-M8AMB FOAUTOA/C ECO
22
23
15201816171921
*Denotes optional equipment†SAT button is standard but requires
SIRIUS subscription/additional hardware
Tips: Always remove antenna before entering a car wash.
To remove antenna; rotate counter-clockwise,
to install rotate clockwise.
To eject specific disc: Press
and hold Eject (11) until beep
sound is heard; within five
seconds press the desired tray
number 1-6 (4).
4. Memory preset buttons
To set: Tune to station, press and
hold until beep sound is heard.
5. FM1/2
Press to select between FM1/FM2
station preset buttons (4).
6. AM
Press to select AM frequency band.
7. SAT
†, Satellite ready capability.
8. CD slot
9. CD, Press to play CD.
10. MEDIA
Press to play cassette tape.
11. CD eject button

HOMELINK®
Always check the Owner’s Manual for more operating information and safety features
HomeLink®
Interior
Lights
Auto-dimming rear
view mirror*
Auto-dimming function changes
are based on outside lighting
conditions and if bright headlights
are visible in rear view mirror.
Press on (2), off (3).
5. Moonroof tilt switch
Press rear of switch to
tilt rear of moonroof.
Press front of switch to close.
6. Moonroof slide switch
Press rear of switch to open
moonroof.
Press front of switch to close.
Illuminated visor mirrors
Mirrors lighted when covers
open; off when closed. Rolling code synchronization
procedure
Refer to your garage door opener or
device instruction manual to confirm
your system is equipped with a
rolling code feature.
Tip: This procedure is easier
to perform with the assistance
of another person.
To synchronize: Press programming
button on garage door opener
motor; press/hold for 2 seconds
and release the programmed
HomeLink
®button 2 times
within 30 seconds of pressing
the garage door opening
motor programming button.
Some devices may require you
to press/hold and release a
third time to complete
programming procedure.
If indicator light stays on,
programming is complete.
To erase all existing programming;
press and hold two outer
HomeLink
®buttons (1) on mirror,
continue to hold buttons until
indicator light flashes.
1. Map/reading light switch
Press on/off.
2. Interior light switch
DOOR = light on when
door open
OFF = light always off
3. Interior map/reading
light
4. Sunglass holder
Press concaved lip to open.
To program or reprogram:
Press and hold two outer
HomeLink
®buttons (1) for 20
seconds and no more than
30 seconds, release only after
indicator light (4) begins to
flash; hold transmitter for the
device to be programmed
between 1-3 inches to
HomeLink
®; press transmitter
button and desired HomeLink®
button (1) simultaneously until
HomeLink®indicator light (4)
goes from slow to rapid flashing.
Verify device operation by
pressing HomeLink
®button (1)
that was just programmed.
Tip: You do not need to
repeat the first step to program
the other two hand-held
transmitters for the remaining
HomeLink
®buttons.
For further information, contact
HomeLink
®at 1-800-355-3515,
www.homelink.comor your
authorized Mazda Dealer. HomeLink
®Wireless
Control System*
Located on rear view mirror.
HomeLink
®provides three
programmable buttons that
will replace three hand-held
device transmitters.
Tip: It is recommended to
park outside of garage when
programming HomeLink
®.
WARNING: When programming
a garage door or gate opener,
disconnect power to these
devices before programming,
continuous operation of these
devices could damage the motor.
*Denotes optional equipment
11423
T
I
L
TSL
ID
E
121
43356
OFFDOO
R
