Page 110 of 124
110
Before
UseGetting
started
RoutingAddress
Book
Voice Recognition
Navigation
Set Up
RDM-TMC
Bluetooth Hands-Free
nMaking calls using a Bluetooth phone
Note
l
Park your vehicle before attempting to input telephone numbers using the on-screen
number buttons. 1. Press the MENU button.
2. The NAVIGATION MENU is displayed.
Press the on-screen button to scroll
down the menu. Press the on-screen
button to switch to the Bluetooth Phone
screen.
3. Input the telephone number using the number buttons.
• If a number has been input incorrectly short-
press the on-screen button to
delete the last digit of the number.
• Long-press the on-screen button to delete all of the digits.
• Press the on-screen button to return to the NAVIGATION MENU screen.
• Press the on-screen button to mute your voice during a call.
• Press the on-screen button to switch between a Hands-free call and call
using a Bluetooth phone.
• Press the on-screen button to erase the currently input telephone number
and replace it with the 911 emergency
number.
4. Press the on-screen button to place the call for the telephone number which
was input using the number buttons.
The call is canceled if the on-
screen button is pressed while the call is
being placed.
5. Press the on-screen button to end the call.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 7 E X Y V H E ] % T V M P % 1
Page 111 of 124
111
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
Bluetooth Hands-Free
nReceiving call using a Bluetooth phone
Note
l
If the on-screen button is pressed, the call received on the currently connected
mobile telephone is refused and the incoming call screen is no longer di\
splayed.
l If the phone number for the received call is unknown, “Unknown” is displayed on the
incoming call screen.
l If the caller cancels the call, the incoming call screen is no longer di\
splayed.
nMaking phone calls using the outgoing call record
1. The currently connected mobile telephone
receives calls.
2. The Incoming Call screen is displayed.
3. Press the on-screen button.
1. Press the MENU button.
2. The NAVIGATION MENU is displayed.
Press the on-screen button to scroll
down the menu.
Press the
on-screen button to switch to the Bluetooth
phone screen.
3. Press the on-screen button. • If there are 0 items in the call record, the
color of the on-screen button is
toned down.
• If you would like to return to the
NAVIGATION MENU, press the
on-screen button.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
Page 112 of 124
112
Before
UseGetting
started
RoutingAddress
Book
Voice Recognition
Navigation
Set Up
RDM-TMC
Bluetooth Hands-Free
Note
l
Park your vehicle before attempting to place calls using the outgoing call record. 4. The system switches to the Outgoing Calls
screen.
5. The names or telephone numbers in the outgoing call record are displayed. Press the
or on-screen button to scroll up
or down the list. Press the on-screen
button at the name or telephone number of
the person you would like to call.
• The name of the person is displayed if the telephone number is already registered in your
phonebook and the name can be retrieved
from the phonebook.
• Press the on-screen button to return to the Bluetooth Phone screen.
• If notification of the telephone number on an
outgoing call is restricted, it will not appear in
the outgoing call record.
• A maximum of 10 outgoing call records are
displayed.
• If the mobile telephone is not connected, the
on-screen button is toned down.
6. The system switches to the Bluetooth Phone screen when the call is made to the number
displayed in the outgoing call record.
The call is canceled if the on-
screen button is pressed while the call is
being placed.
7. Press the on-screen button to end the call.
) 9 C 2 % : - C ) 2 F S S O 4 E K I * V M H E ] % T V M P 4 1
Page 113 of 124
113
Before
UseGetting
started
RoutingAddress
Book
Voice Recognition
Navigation
Set Up
Bluetooth Hands-Free
nMaking calls using the incoming call record
Note
l
Park your vehicle before attempting to place calls using the incoming call record. 1. Press the MENU button.
2. The NAVIGATION MENU is displayed.
Press the on-screen button to scroll
down the menu.
Press the
on-screen button to switch to the Bluetooth
phone screen.
3. Press the on-screen button.
• If there are 0 items in the call record, the color of the on-screen button is toned
down.
• If you would like to return to the NAVIGATION
MENU, press the on-screen
button.
4. The system switches to the Incoming Calls screen.
The names or telephone numbers in the
incoming call record are displayed. Press the
or on-screen button to scroll up
or down the list. Press the on-screen
button at the name of the person you would
like to call.
• The name of the person is displayed if the telephone number is already registered in your
phonebook and the name can be retrieved
from the phonebook.
• Press the on-screen button to return to the Bluetooth Phone screen.
• If notification of the telephone number on an incoming call is restricted, it will not appear in
the incoming call record.
• A maximum of 10 incoming call records are displayed.
• If the mobile telephone is not connected, the
on-screen button is toned down.
5. The system switches to the Bluetooth Phone screen the system switches to the Bluetooth
Phone screen when the call is made to the
number displayed in the incoming call record.
The call is canceled if the on-
screen button is pressed while the call is
being placed.
6. Press the on-screen button to end the call.
) 9 C 2 % : - C ) 2 F S S O 4 E K I * V M H E ] % T V M P 4 1
Page 114 of 124
114
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
RDM-TMC
Bluetooth Hands-Free
nMaking calls using the phonebook
Downloading the phonebook
Downloads the phonebook data registered to the currently connected mobile \
telephone into
the navigation system.
1. Press the MENU button.
2. The NAVIGATION MENU screen is displayed.
Press the on-screen button to scroll
down the menu. Press the on-screen
button to switch to the Bluetooth Phone
screen.
3. Press the on-screen button to switch to the Bluetooth Setting screen.
4. Press the on-screen button to switch to the Download
Phonebook screen.
• Press the on-screen button to return to the Bluetooth Phone screen.
• If no mobile telephone is connected, the
on-screen
button cannot be pressed.
5. ”Downloading phonebook entries.” is displayed.
• If the on-screen button is pressed, the download is canceled and the system
returns to the Bluetooth Setting screen.
6. When the download is completed, “Download is completed” is displayed.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
Page 115 of 124
115
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
Bluetooth Hands-Free
Note
l
Park your vehicle before attempting to download the phonebook.
l If the download failed, a message indicating a failure is displayed.
l If the mobile telephone is non-PBAP-compliant, a message indicating a download failure is
displayed.
l Making an receiving calls from the Bluetooth phone screen is not possible during transfer of
phonebook data from the mobile telephone.
l Phonebook data recorded to the navigation screen cannot be called up using the voice
recognition commands. In addition, phonebook data recorded to the voice recognition
function cannot be called up from the navigation screen.
Making calls using the phonebook
Makes calls using the phonebook downloaded from the currently connected mobile
telephone. 1. Press the MENU button.
2. The NAVIGATION MENU screen is displayed.
Press the on-screen button to scroll
down the menu. Press the on-screen
button to switch to the Bluetooth Phone
screen.
3. Press the on-screen button to switch to the Bluetooth Phone screen.
4. Press the or on-screen button to scroll back and forth through the alphabets.
Press the on-screen button indicating the
initial letter in the person’s name you would
like to call.
5. The names/phone numbers registered to the selected initial letter are displayed
alphabetically.
Press the or on-screen button to
scroll up or down the list.
Press the on-screen button area which
indicates the name/phone number of the
person you would like to call to switch to the
screen containing the detailed information
recorded for that person.
• Press the on-screen button to return to the Bluetooth Phone screen.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
Page 116 of 124
116
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
RDM-TMC
Bluetooth Hands-Free
Note
l
Park your vehicle before attempting to place calls using the phonebook. 6. The detailed information registered to the
phonebook is displayed.
The phone numbers registered to each
category are displayed. Press the on-
screen button for the number you would like to
call.
• Press the on-screen button to return to the Phone Book screen.
7. The system switches to the Bluetooth Phone screen.
The call is made to the number registered to
the phonebook.
The call is canceled if the on-
screen button is pressed while the call is
being placed.
8. Press the on-screen button to end the call.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
Page 117 of 124
117
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
Bluetooth Hands-Free
nDeleting all registered devices
Note
l
Park your vehicle before attempting to delete the registered devices. 1. Press the MENU button.
2. The NAVIGATION MENU screen is displayed.
Press the on-screen button to scroll
down the menu. Press the on-screen
button to switch to the Bluetooth Phone
screen.
3. Press the on-screen button to switch to the Bluetooth Setting screen.
4. Press the on-screen button to switch to the delete
confirmation screen.
• Press the on-screen button to return to the Bluetooth Phone screen.
• If no Bluetooth device is registered, the
on-screen
button cannot be pressed.
5. “Delete all devices?” is displayed. Press the on-screen button to start deleting.
• The deleting operation cannot be canceled
once the on-screen button is
pressed.
• If the on-screen button is pressed
before pressing the on-screen
button, the message is cleared and the system
returns to the Bluetooth Setting screen.
6. “Deleting all devices.” is displayed. The message disappears when the deletion ends.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
Page 118 of 124
118
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
RDM-TMC
Bluetooth Hands-Free
nDeleting all phonebooks
Note
l
Park your vehicle before attempting to delete the phonebooks. 1. Press the MENU button.
2. The NAVIGATION MENU screen is displayed.
Press the on-screen button to scroll
down the menu. Press the on-screen
button to switch to the Bluetooth Phone
screen.
3. Press the on-screen button to switch to the Bluetooth Setting screen.
4. Press the on-screen button to switch to the delete
confirmation screen.
• Press the on-screen button to return to the Bluetooth Phone screen.
• If no telephone number is registered to the phonebook, the
on-screen
button cannot be pressed.
5. “Delete all phonebook entries?” is displayed. Press the on-screen button to
start deleting.
• The deleting operation cannot be canceled
once the on-screen button is
pressed.
• If the on-screen button is pressed
before pressing the on-screen
button, the message is cleared and the system
returns to the Bluetooth Setting screen.
6. “Deleting all phonebook entries.” is displayed. The message disappears when the deletion
ends.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
Page 119 of 124
119
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
Bluetooth Hands-Free
nDeleting all outgoing call records
Note
l
Park your vehicle before attempting to delete the outgoing call records. 1. Press the MENU button.
2. The NAVIGATION MENU screen is displayed.
Press the on-screen button to scroll
down the menu. Press the on-screen
button to switch to the Bluetooth Phone
screen.
3. Press the on-screen button to switch to the Bluetooth Setting screen.
4. Press the on-screen button to switch to the delete
confirmation screen.
• Press the on-screen button to return to the Bluetooth Phone screen.
• If there is no outgoing call record, the
on-screen
button cannot be pressed.
5. “Delete all recent outgoing calls?” is displayed. Press the on-screen
button to start deleting.
• The deleting operation cannot be canceled
once the on-screen button is
pressed.
• If the on-screen button is pressed
before pressing the on-screen
button, the message is cleared and the system
returns to the Bluetooth Setting screen.
6. “Deleting all recent outgoing calls.” is displayed. The message disappears when the
deletion ends.
) 9 C 2 % : - C ) 2 F S S O 4 E K I 8 L Y V W H E ] % T V M P 4 1
