Introduction
nExtremely low or high temperatures may interfere with normal operationThe inside of the vehicle can become very hot or cold when it is parked for extended
periods in direct sunlight or in cold places with the engine turned off. The navigation system
may not operate normally under such circumstances. Turn off the navigation system until
the inside of the vehicle has cooled down or warmed up. If the system does not operate
thereafter, consult an Authorized Dealer, we recommend an Authorized Mazda Dealer.
This navigation system utilizes GPS* satellite signals, a speed sensor and gyrosensor to track
and display your vehicle’s current position, and to guide you from your starting point to your
destination along a calculated route.
* : GPS (Global Positioning System) is a position detecting system utilizing the signals from GPS satellites deployed by the U.S. Defense Department.
The beep sound and voice guidance related to the navigation system operation are not heard
while a Bluetooth Hands-Free is being used.
Screens displayed in this manual may differ from those on the actual display.
Direct sunlight or other outside light sources makes it difficult to view the images on the
display. For moonroof-equipped vehicles, close the sunshade to better view the display.
Use This Product Safety
Navigation System
Beep sound and voice guidance restrictions while using Bluetooth Hands-Free
Screens
LCD (Liquid crystal display)
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41

14
RoutingAddress
Book
Getting started
Menu
Menu appears when pressing . MENU
Destination Entry and Route Search ( page 30)
Address Book ( page 46)
Cancel Guidance ( page 41)
Route Options ( page 42)
Volume ( page 55)
Set Clock ( page 15)
Navigation Set Up ( page 16)
Bluetooth Phone ( page 108)
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41

25
Getting started
Screen Names and Functions
Screens Before Setting Route
(1) Map Orientation control( page 28)
(2) GPS (Global Positioning System) marker( page 57)(3) ClockClock will be displayed when you set up
Clock on Navigation Set Up On.
(4) Vehicle marker
Shows the current position and
direction of your vehicle.
(5) Scale display
Displays the scale of the map.
(6) Distance from current position Displays the distance from the current
position to the position pointed by . (7) Current Road Name
Shows the name of the road you are
currently driving on.
(8) Set Destination buttonThe position indicated by the mark “ ” in the
scroll map is used as destination, memory
point or way point.
(9) Store Memory Point button
Stores markers on the map.
(10) POI (Point of Interest) Display button ( page 38)
(11) Zoom in ( page 28)
(12) Zoom out
( page 28)
Screens During Route Guidance
(1) Distance and Time to Destination displayDisplays the time* and distance to the
destination or way point.
Selecting this will display the next and
further information on the way point or
time and distance to the destination.
(* Either required time or estimated time
arrival)
(2) Route display Shows the provided route as a thick
blue line. (3) Turn Arrow displayShows the direction to turn at the next
junction and the distance to the junction.
(4) Route Preferences button( page 42)
MAP
(4)
(3)(1)
(2)(7)
(8) (10)
(9)(5)(11)(12) MAP SCROLL
(6)
(4)
(3)
(1)
(2)
)9C2%:-C)2FSSO4EKI8YIWHE]%TVMP41

50
Before
UseGetting
started
RoutingAddress
Book
Voice Recognition
Voice Recognition
The voice recognition or the Bluetooth Hands-free system can be activated by pressing the
talk button on the steering wheel. The target operation in each mode (status) differs
depending on whether the switch is pressed with a short or long press. For details, refer to the
following switch operation list. ( page 52)
l Bluetooth Hands-Free Outline
By connecting a Bluetooth equipped mobile telephone to the hands-free unit equipped on the
vehicle, making and receiving calls are possible.
For details, refer to the "Bluetooth Hands-Free" in the owner's manual.
l Voice Recognition Outline
Voice control can be carried out by simply pressing the talk button and using a voice
command ( page 53) spoken into the microphone.
Vo i c e
Recognition
Structure
l Microphone surface
Voice entry recognition.
lTalk button on the steering wheel switch
Use for switching to voice recognition or Bluetooth
Hands-free.
Microphone
Talk button
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41

51
Before
UseGetting
started
RoutingAddress
Book
Voice Recognition
Note
If there is no setting for the Bluetooth Hands-Free system, the TEL commands (Phone/
Telephone) are not available.
Note
After the navigation system has been set, voice recognition needs approximately 2 minutes
for activation on preparation. Wait momentarily.
Select the
Language
Set up the language in advance.
Voice entry recognition.
1
Press
2select
select select
3
Select your preferred language from the list.
Note
To return to current position screen, press .
Voice
Recognition
Basic Usage
Pattern1
Press the talk button on the steering wheel switch
with a short press while the system is in standby
mode.
2
Speak the desired voice command.
Cancel
Vo i c e
Recognition
1
Long press the talk button on the steering wheel
switch during navigation voice recognition.
MENU
MAP
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41

52
Before
UseGetting
started
RoutingAddress
Book
Voice Recognition
Switch Operation List
Mode (status)Switch
operationTarget operation
Standby Short press
Voice recognition activated (All command-
waiting)
Long press Bluetooth hands-free voice recognition
activated (Short-cut operation).
For details, refer to the "Bluetooth Hands
Free" in the owner's manual.
During navigation voice
recognition Short press (No operation.)
Long press Voice recognition ended.
During TEL voice
recognition (No call) Short press Voice recognition interrupted.
Long press Voice recognition ended.
During TEL voice
recognition (During a call) Short press Voice recognition interrupted.
Long press Voice recognition stopped, returns to call.
During call Short press Call ended.
Long press Call ended.
Call received from user A Short press Call accepted.
Long press Call rejected.
During call with user A Short press Voice recognition interrupted.
Long press Call ended.
Call received from user B
during call with user A Short press User B call accepted, user A put on hold.
Long press User B call rejected.
During call with user A
and user B on hold Short press Switches to user B, user A put on hold.
Long press Switches to user B, call with user A ended.
During call with user B
and user A on hold Short press Switches to user A, user B put on hold.
Long press Switches to user A, user B call ended.
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41

65
Audio Operation
Contents
Audio system
nAudio OperationlOperating Tips for Audio system ................................................... 66(Radio Reception), (Operating Tips for In-Dash CD Changer),
(Operating tips for MP3), (CD-TEXT)
l
Operating Tips for Display ............................................................. 72lBeep sound and voice guidance restrictions while using Bluetooth
Hands-Free........................................................................\
............ 72
lPower/Volume/Sound Controls ...................................................... 73(Power ON/OFF), (Volume adjustment), (Audio sound adjustment),
(Sound quality adjustment), (Volume balance adjustment),
(AudioPilot®), (Centerpoint®)
l
Operating the Radio ...................................................................... 76(Radio ON), (Band selection), (Tuning), (Manual tuning), (Seek tuning),
(Scan tuning), (Preset channel tuning), (Auto memory tuning),
(Audio Sound Adjustment), (Satellite Radio (SAT))
l
Operating the Satellite Radio ........................................................ 79(What is satellite radio?), (How to subscribe to satellite radio),
(Satellite Radio Activation), (Selecting Sirius Radio Mode),
(Channel Selection), (Scanning for Subscribed Channels),
(Unsubscribed Channels), (Invalid Channels), (Preset Channel Programming),
(Preset Channel Call-up), (Category Mode On/Off), (Category Change),
(Channel Selection Within a Category),
(
Channel Number, Channel Name, Category, Artist, Song Titles and Info Display),
(Programming Your Favorites into Memory), (Seek Alert), (Instant Replay),
(Displaying the SIRIUS ID (ESN)), (Initialization of ID Code),
(Changing the PIN Code), (Individual Channel Locking), (Lock Cancellation),
(Master Code), (Error Signs)
l
Operating the Bluetooth Audio ...................................................... 91(What is Bluetooth Audio?), (Bluetooth audio device programming),
(Deleting the link to a Bluetooth audio device),
(Changing programmed Bluetooth device),
(How to use the Bluetooth Audio system), (Setting the Passcode),
(Setting the PIN code)
l
Operating the In-Dash CD Changer ............................................ 100(Inserting the CD), (During CD playback), (During MP3 CD playback),
(Normal insertion), (Inserting CDs into desired tray number),
(Multiple insertion), (Normal ejection),
(Ejecting CDs from desired tray number), (Multiple ejection),
(Playing), (Fast-forward/Reverse), (Track search), (Disc search),
(Folder search (during MP3 CD playback)), (Music scan),
(Repeat play), (Random play), (Audio sound adjustment)
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41

72
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
RDM-TMC
Audio Operation
Navigation
Set Up
l
The liquid crystal display may not open if the power supply had been interrupted due to the
vehicle battery being disconnected.
l If the liquid crystal display stays open/closed (or partly opened) and does not move when
the liquid crystal display is pressed, switch the ignition switch and then on again. Then try
the open/close operation again. If the liquid crystal display still does not move, contact an
Authorized Mazda Dealer.
The beep sound and voice guidance related to the audio operation are not heard while a
Bluetooth Hands-Free is being used.
Operating Tips for Display
nDo not place any objects on the dashboard. If you drop any objects onto
the dashboard or spill liquid on it, it may result in system malfunction.
nBe careful not to pinch your hands or fingers when the liquid crystal
display is closed.
nDo not open/close the liquid crystal display manually. It may damage the
equipment.
Beep sound and voice guidance restrictions while using Bluetooth Hands-Free
)9C2%:-C)2FSSO4EKI8LYVWHE]%TVMP41
