¾Do not use the front bumper to push other vehicles or obstructions such as when pulling
out of a parking space. Otherwise, the radar sensor (front) could be hit and its position
deviated.
¾Do not remove, disassemble, or modify the radar sensor (front).
¾For repairs, replacement or paint work around the radar sensor (front), consult an
Authorised Mazda Repairer.
¾Do not modify the suspension. If the suspension are modified, the vehicle's posture could
change and the radar sensor (front) may not be able to correctly detect a vehicle ahead or
an obstruction.
NOTE
xUnder the following conditions, the
radar sensor (front) may not be able to
detect vehicles ahead or obstructions
correctly and each system may not
operate normally.
xThe rear surface of a vehicle ahead
does not reflect radio waves
effectively, such as an unloaded
trailer or an automobile with a
loading platform covered by a soft
top, vehicles with a hard plastic
tailgate, and round-shaped vehicles.
xVehicles ahead with low vehicle
height and thus less area for
reflecting radio waves.
xVisibility is reduced due to a vehicle
ahead casting off water, snow, or
sand from its tyres and onto your
windscreen.
xThe boot/luggage compartment is
loaded with heavy objects or the rear
passenger seats are occupied.
xIce, snow, or soiling is on the front
surface of the front emblem.
xDuring inclement weather such as
rain, snow, or sand storms.
xWhen driving near facilities or
objects emitting strong radio waves.
xUnder the following conditions, the
radar sensor (front) may not be able to
detect vehicles ahead or obstructions.
xThe beginning and end of a curve.
xRoads with continuous curves.
xNarrow lane roads due to road
construction or lane closures.
xThe vehicle ahead enters the radar
sensor's blind spot.
xThe vehicle ahead is running
abnormally due to accident or
vehicle damage.
xRoads with repeated up and down
slopes
xDriving on poor roads or unpaved
roads.
xThe distance between your vehicle
and the vehicle ahead is extremely
short.
xA vehicle suddenly comes close such
as by cutting into the lane.
xTo prevent incorrect operation of the
system, use tyres of the same specified
size, manufacturer, brand, and tread
pattern on all 4 wheels. In addition, do
not use tyres with significantly different
wear patterns or tyre pressures on the
same vehicle (Including the temporary
spare tyre).
xIf the battery power is weak, the system
may not operate correctly.
