fuse MAZDA MODEL 6 2019 (in English) User Guide

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
2 IG2 30 A For protection of various circuits
3 INJECTOR
ENG. SUB 30 A
Engine control system
*
4 SCR1
EVVT 20 A
Engine control system*
5 P.WINDOW1 30 A Power windows
6 IG1 2 30 A For protection of various circuits
7― ― ―
8 ADD FAN DE 50 A Cooling fan
9D EFO G 4 0 A
Rear window defogger
*
10 DCDC DE 40 A ―
11 EPB R 20 A Electric parking brake (EPB) (RH)
12 EPB L 20 A Electric parking brake (EPB) (LH)
13 CABIN.+B 50 A For protection of various circuits
14 FAN GE 30 A
Cooling fan
*
15 ENG.MAIN 40 A Engine control system
16 ABS/DSC M 50 A ABS, Dynami c stability control system
17 HEATER 40 A
Air conditioner
*
18 WIPER 20 A Front window wiper and washer
19 FAN DE 50 A
Cooling fan
*
20 ADD FAN GE 30 A Cooling fan*
21 ENGINE3 15 A Engine control system
22 ENGINE2 15 A Engine control system
23 AUDIO27.5 A Audio system
24 METER2 10 A ―
25 SRS1 7.5 A Air bag
26 METER1 10 A Instrument cluster
27 ENGINE.IG1 7.5 A Engine control system
28 AT 15 A
Transaxle control system
*, Ignition switch
29 H/CLEAN 20 A ―
30 A/C 7.5 A Air conditioner
31 AT PUMP 15 A ―
32 HORN 15 A Horn
33 R.WIPER 15 A Theft-deterrent system
34 H/L HI 20 A Headlight high beam
35 ― ― ―
Maintenance and Care
Owner Maintenance
6-50*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
36 WIPER.DEI 20A Windshield wiper de-icer
37 ENG.+B 7.5 A Engine control system
38 H/L LOW L 15 A Headlight low beam (LH)
39 GLOW SIG 5 A ―
40 ENGINE1
ENGINE4 15 A Engine control system
41 C/U IG1 15 A Engine control system
42 ST.HEATER 15 A Heated steering wheel
43 ― ― ―
44 AUDIO1 25 A Audio system
45 ABS/DSC S 30 A ABS, Dynamic stability control system
46 FUEL PUMP 15 A Fuel system
*
47 FUEL WARM 25 AFuel warmer*
48TAIL 15 A Taillights, License plate lights
49 SCR2
FUEL PUMP2 25 A
Fuel system
*
50 HAZARD 25 A Hazard warning flashers, Turn signal lights/Front side-marker
lights, Parking lights
51 H/L LOW R 15 A Headlight low beam (RH)
52 OUTLET 25 A Accessory sockets
53 STOP 10 A Brake lights
54 ROOM 25 A Overhead light
Maintenance and Care
Owner Maintenance
*Some models.6-51
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Fuse block (Left side)
DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
1 P.SEAT D 30 A Power seat
*
2 P.SEAT P1 30 APower seat*
3 R.SEAT W1 20 ASeat warmer*
4 P.WINDOW2 25 A Power windows
5 SRS2/ESCL 15 A ―
6 D.LOCK25 A Power door locks
7 SEAT WARM 20 A Seat warmer
*
8 SUNROOF 10 AMoonroof*
9 R.OUTLET1 15 A ―
10 MIRROR 7.5 A Power control mirror
11 AT IND 7.5 A AT shift indicator
12 INTERIOR1 15 A For protection of various circuits
13 INTERIOR2 10 A Overhead light
14 R.OUTLET2 15 A Accessory sockets
15 USB 7.5 A USB power outlet
16 SCR3 15 A ―
Maintenance and Care
Owner Maintenance
6-52*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

DESCRIPTIONFUSE
RATING PROTECTED COMPONENT
17 SCR4 15 A ―
18 AUDIO3 15 A Audio system
*
19 R.SHADE 7.5 A ―
20 M.DEF 7.5 A Mirror defogger
21 ― ― ―
Maintenance and Care
Owner Maintenance
*Some models.6-53
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Temporary spare tire
(U.S.A. and Canada)
Tire sizeInflation pressure
T125/70R17 98M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/55R16 87M 320 kPa (3.2 bar, 46 psi)
T125/70R17 98M 420 kPa (4.2 bar, 60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following to rque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼ Fuses
Refer to Fuses on page 6-47.
