keyless MAZDA MODEL 6 2019 Owner's Manual (in English)

3Before Driving
Use of various features, including keys, doors, mirrors and windows.
Keys.................................................... 3-2 Keys.............................................. 3-2
Keyless Entry System................... 3-3
Advanced Keyless Entry
System.................................................3-8 Advanced Keyless Entry System
*.....
...................................................... 3-8
Operational Range........................ 3-9
Doors and Locks.............................. 3-10 Door Locks................................. 3-10
Trunk Lid................. ................... 3-16
Inside Trunk Release Lever
*...... 3-18
Fuel and Emission........................... 3-19 Fuel and Engine Exhaust
Precautions................................. 3-19
Fuel-Filler Lid and Cap.............. 3-22
Mirrors............................................. 3-24 Mirrors........................................ 3-24
Windows........................................... 3-29 Power Windows..........................3-29
Moonroof
*.................................. 3-32
Security System............................... 3-35
Modification and Add-On
Equipment...................................3-35
Immobilizer System....................3-35
Theft-Deterrent System
*.............3-37
Driving Tips..................................... 3-39 Break-In Period.......................... 3-39
Saving Fuel and Protection of the
Environment............................... 3-39
Hazardous Driving.... ..................3-40
Floor Mat.................................... 3-40
Rocking the Vehicle....................3-41
Winter Driving............................3-41
Driving In Flooded A rea............ 3-43
Overloading................................ 3-44
Driving on Uneven Road............ 3-45
Turbocharger Information
*......... 3-46
Towing.............................................. 3-47 Trailer Towing............................ 3-47
Recreational Towing................... 3-47
*Some models.3-1
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

NOTE
The driver must carry the key to ensure the
system functions properly.
Auxiliary key
Transmitter
Key code number plate
To use the auxiliary key, pull out the
auxiliary key from th e transmitter while
pressing the knob.
Knob
Keyless Entry System
This system uses the key buttons to
remotely lock and unlock the doors, and
opens the trunk lid.
The system can start the engine without
having to take the key out of your purse or
pocket.
It can also help you signal for attention or
help.
Operating the theft-deterrent system is
also possible on theft-deterrent
system-equipped vehicles.

System malfunctions or warnings are
indicated by the following warning lights
or beeps.
For vehicles with the type A/type B
instrument cluster, check the displayed
message for more i nformation and, if
necessary, have the vehicle inspected at an
Authorized Mazda Dealer, according to
the indication.
KEY Warning Light (Red)
Refer to Contact Authorized Mazda
Dealer and Have Vehicle Inspected on
page 7-26.
Refer to Taking Action on page 7-32.
Ignition Not Switched Off (STOP)
Warning Beep
Refer to Ignition Not Switched Off
(STOP) Warning Beep on page 7-43.
Key Removed from Vehicle Warning
Beep
Refer to Key Removed from Vehicle
Warning Beep on page 7-43.
If you have a problem with the key,
consult an Authorized Mazda Dealer.

Before Driving
Keys
3-3
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

If your key is lost or stolen, consult an
Authorized Mazda Dealer as soon as
possible for a replacement and to make the
lost or stolen key inoperative.
CAUTION
Radio equipment like this is governed by
laws in the United States.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority
to operate the equipment.
NOTE
The keyless entry system operation may
vary due to local conditions.
The keyless entry system is fully
operational (door lock/unlock) when the
ignition is switched off. The system does
not operate if the ignition is switched to
any position other than off.
If the key does not operate when
pressing a button or the operational
range becomes too small, the battery
may be weak. To install a new battery,
refer to Key Battery Replacement (page
6-36).
Battery life is about 1 year. Replace the
battery with a new one if the KEY
indicator light (green) flashes in the
instrument cluster (for vehicles with a
type A/type B instrument cluster (page
4-13, 4-30), messages are displayed
in the instrument cluster). Replacing the
battery about once a year is
recommended because the KEY warning
light/indicator light may not illuminate
or flash depending on the rate of battery
depletion.
Additional keys can be obtained at an
Authorized Mazda Dealer. Up to 6 keys
can be used with the keyless functions
per vehicle. Bring all keys to an
Authorized Mazda Dealer when
additional keys are required.
▼Tr a n s m i t t e r
Operation buttons
Operation indicator light
NOTE
(With theft-deterrent system)
The hazard warning lights flash when
the theft-deterrent system is armed or
turned off.
Before Driving
Keys
3-4
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Refer to Theft-Deterrent System on page
3-37.
(With the advanced keyless function)
A beep sound can be heard for
confirmation when the doors are locked/
unlocked using the key. If you prefer, the
beep sound can be turned off.
The volume of the beep sound can also
be changed.
Refer to Other Equipment/Functions on
page 9-14.
The operation indicator light flashes when
the buttons are pressed.
Lock button
To lock the doors , press the lock button
and the hazard warning lights will flash
once.
(With the advanced keyless function)
A beep sound will be heard once.

To confirm that all doors have been
locked, press the lock button again within
5 seconds. If they are closed and locked,
the horn will sound.
NOTE
The doors can be locked by pressing the
lock button while any other door or the
trunk lid is open. The hazard warning
lights will not flash.
When the lock button is pressed while
any door is open and then the door is
closed, all the doors are locked.
Confirm that all doors are locked
visually or audibly by use of the double
click.
Make sure all doors are locked after
pressing the button.
(With theft-deterrent system)
When the doors are locked by pressing
the lock button on the key while the
theft-deterrent system is armed, the
hazard warning lights will flash once to
indicate that the system is armed.
Unlock button
To unlock the driver's door, press the
unlock button and the hazard warning
lights will flash twice.
(With the advanced k eyless function)
A beep sound will be heard twice.

To unlock all doors , press the unlock
button again within 3 seconds and two
more beep sounds will be heard.
NOTE
The system can be set to unlock all
doors by performing a single operation.
Refer to Other Equipment/Functions on
page 9-14.
(Auto re-lock function)
After unlocking with the key, all doors
will automatically lock if any of the
following operations are not performed
within about 60 seconds. If your vehicle
has a theft-deterrent system, the hazard
warning lights will flash for
confirmation.
The time required for the doors to lock
automatically can be changed.
Refer to Other Equipment/Functions on
page 9-14.
A door or the trunk lid is opened.
Before Driving
Keys
3-5
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

The ignition is switched to any
position other than off.
(With theft-deterrent system)
When the doors are unlocked by
pressing the unlock button on the key
while the theft-deterrent system is turned
off, the hazard warning lights will flash
twice to indicate that the system is
turned off.
Trunk button
To open the trunk lid, press and hold the
trunk button until the trunk lid opens.
Panic button
If you witness from a distance someone
attempting to break into or damage your
vehicle, press and hold the panic button to
activate the vehicle's alarm. Call
emergency services if necessary.
NOTE
The panic button will work whether any
door or the trunk lid is open or closed.
(Turning on the alarm)
Pressing the panic button for 1 second or
longer will trigger the alarm for about 2
minutes and 30 seconds, and the following
will occur:
The horn sounds intermittently.
The hazard warning lights flash.
(Turning off the alarm)
The alarm stops by pressing any button on
the key.
▼ Operational Range
The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.
Starting the Engine
NOTE
Starting the engine may be possible even
if the key is outside of the vehicle and
extremely close to a door and window,
however, always start the engine from
the driver's seat.
If the vehicle is started and the key is not
in the vehicle, the vehic
le will not restart
after it is shut off and the ignition is
switched to off.
The trunk is out of the assured
operational range, however, if the key
(transmitter) is operable the engine will
start.
With the advanced keyless function

Interior antenna
Operational range
Before Driving
Keys
3-6
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Without the advanced keyless function

Interior antennaOperational range
NOTE
The engine may not start if the key is
placed in the following areas:
Around the dashboard
In the storage compartments such as the
glove compartment or the center console
On the rear parcel shelf
▼Key Suspend Function
If a key is left in the vehicle, the functions
of the key left in the vehicle are
temporarily suspended to prevent theft of
the vehicle.
To restore the functions, press the unlock
button on the functi
ons-suspended key in
the vehicle.
Before Driving
Keys
3-7
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Advanced Keyless EntrySystem
*
WA R N I N G
Radio waves from the key may affect
medical devices such as pacemakers:
Before using the key near people who use
medical devices, ask the medical device
manufacturer or your physician if radio
waves from the key will affect the device.
The advanced keyless function allows you
to lock/unlock the door, or open the trunk
lid while carrying the key.

System malfunctions or warnings are
indicated by the following warning beeps.
Request switch Inoperable Warning
Beep
Refer to Request Switch Inoperable
Warning Beep (With the advanced
keyless function) on page 7-44.
Key Left-in-trunk Compartment
Warning Beep
Refer to Key Left-in-trunk
Compartment Warni ng Beep (With the
advanced keyless function) on page
7-44.
Key Left-in-vehicle Warning Beep
Refer to Key Left-i n-vehicle Warning
Beep (With the advanced keyless
function) on page 7-44.
NOTE
The advanced keyless entry system
functions can be deactivated to prevent
any possible adverse effect on a user
wearing a pacemaker or other medical
device. If the system is deactivated, you
will be unable to start the engine by
carrying the key. Consult an Authorized
Mazda Dealer for details. If the advanced
keyless entry system has been deactivated,
you can start the engine by following the
procedure indicated when the key battery
goes dead.
Refer to Engine Start Function When Key
Battery is Dead on page 4-8.
Before Driving
Advanced Keyless Entry System
3-8*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Operational Range
The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.
NOTE
When the battery power is low, or in
places where there are high-intensity radio
waves or noise, the operational range may
become narrower or the system may not
operate. For determining battery
replacement, Refer to Keyless Entry
System on page 3-3.
▼ Locking, Unlocking the Doors
Exterior antenna
Operational range80cm (31in)
80cm (31in)
NOTE
The system may not operate if you are
too close to the windows or door
handles.
If the key is left in the following areas
and you leave the vehicle, the doors may
be locked depending on the radio wave
conditions even if the key is left in the
vehicle.
Around the dashboard
In the storage compartments such as
the glove compartment or the center
console
On the rear parcel shelf
Next to a communication device such
as a mobile phone
▼
Opening the Trunk Lid
Exterior antenna
Operational range 80cm (31in)
Before Driving
Advanced Keyless Entry System
3-9
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

In the storage compartments such as
the glove compartment or the center
console
On the rear parcel shelf
Next to a communication device such
as a mobile phone
When the ignition is switched to ACC or
ON, the vehicle lock-out prevention
feature prevents you from locking
yourself out of the vehicle.
All doors and the trunk lid will
automatically unlock if they are locked
using the power door locks with any
door open.
The vehicle lock-out prevention feature
does not operate while the ignition is
switched off.
When all doors and the trunk lid are
locked using the power door lock with
any door or the trunk lid open, the
closed doors and the trunk lid are
locked. After that, when all doors and
the trunk lid are closed, all doors and
the trunk lid are locked. However, if the
key is inside the vehicle, all doors and
the trunk lid are auto matically unlocked.
(With the advanced keyless function)
The beep sound is heard for about 10
seconds to notify the driver that the key
has been left in the vehicle.
(Without the advanced keyless
function)
The horn sound is heard twice to notify
the driver that the key has been left in
the vehicle.
(Door unlock (control) system with
collision detection)
This system automatically unlocks the
doors and the trunk lid in the event the
vehicle is involved in an accident to
allow passengers to get out of the
vehicle immediatel y and prevent being
trapped inside. While the ignition is
switched ON and in the event the vehicle
receives an impact strong enough to
inflate the air bags, all the doors and the
trunk lid are automatically unlocked
after about 6 seconds have elapsed from
the time of the accident.
The doors and the trunk lid may not
unlock depending on how an impact is
applied, the force of the impact, and
other conditions of the accident.
If door-related systems or the battery is
malfunctioning, the doors and the trunk
lid will not unlock.
Before Driving
Doors and Locks
3-11
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Locking, Unlocking with Auxiliary
Key
Turn the auxiliary key toward the front to
lock, toward the
back to unlock.
To l o c k
All doors lock automatically when the
driver's door is locked using the auxiliary
key.
To u n l o c k
The driver’s door unlocks when the
auxiliary key is turned briefly to the
unlock position and then immediately
returned to the center position.
All doors unlock when the driver's door is
unlocked and the auxiliary key is held in
the unlock position for one second or
longer.
Lock Unlock
▼
Locking, Unlocking with Request
Switch, Door Handle (With the
advanced keyless function)
All doors can be locked/unlocked by
pressing the request switch on the front
doors while the key is being carried.
Front doors
Request switch
To l o c k
To lock the doors , press the request
switch and the hazard warning lights will
flash once.
A beep sound will be heard once.
To u n l o c k
Driver's door request switch
To unlock the driver's door, press the
request switch. A beep sound will be heard
twice and the hazard warning lights will
flash twice.
To unlock all doors, press the request
switch again within
3 seconds and two
more beep sounds will be heard.
Before Driving
Doors and Locks
3-12
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
