▼Average Fuel Economy
The average fuel economy is calculated
every minute from the total traveled
distance on the trip me
ter and the total fuel
consumption, and the average fuel
economy for either TRIP A or TRIP B is
displayed.

The average fuel economy and trip meters
can be reset by pressing the INFO switch
for 1.5 seconds or more while in each
mode. After the data is cleared, the fuel
consumption is recalcu lated and the - - -
km/L (- - - mpg) for the 1 minute prior to
it being displayed is indicated.
▼ Current Fuel Economy
This displays the curr
ent fuel economy by
calculating the amount of fuel
consumption and the distance traveled.
The average fuel economy for TRIP A is
indicated by a blue arrow.

NOTE
Indicates the 0 positi on when the vehicle
speed is about 5 km/h (3 mph) or slower.
▼ Maintenance Monitor
The following maintenance period
notifications can be displayed by turning
the Maintenance Monitor on.
Scheduled Maintenance
Tire Rotation
Oil Change
When the remaining days to the
maintenance period is 15 days or less, or
the remaining distance is 1,000 km (600
miles) or shorter, a message is indicated
when the ignition is switched ON.
For the setting method and indications for
the maintenance monitor, refer to the
Maintenance Monitor.
Refer to Maintenance Monitor on page
6-15.
▼ Blind Spot Monitoring (BSM)
Display
Displays the system status.

Refer to Blind Spot M
onitoring (BSM) on
page 4-122.
When Driving
Instrument Cluster and Display
4-21
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display
Displays the system status.

Refer to Lane-keep A
ssist System (LAS)
& Lane Departure Warning System
(LDWS) on page 4-157.
▼ Traffic Sign Recognition System
(TSR) Display*
Displays the traffic sign.

Refer to Traffic Sign Display Indication on
page 4-132.
▼ Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display
*
Displays the currently set system status.

Refer to Mazda Radar
Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) on page 4-144.
▼ Distance Recognition Support
System (DRSS) Display*
Displays the distance between your
vehicle and the vehicle ahead.

Refer to Distance Recognition Support
System (DRSS) on page 4-136.
When Driving
Instrument Cluster and Display
4-22*Some models.
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

▼Cruise Control Set Vehicle Speed
Display*
The vehicle speed preset using the cruise
control is displayed.

Refer to Cruise Cont
rol on page 4-215.
▼Compass Display
The direction the vehicle is moving is
displayed in one of eight directions while
the vehicle is being driven.

Display
Direction
NN orth
S South
EE ast
WW est
NE Northeast
NW Northwest
SE Southeast
SW Southwest
▼Warning (Display Indication)
A message is displayed to notify the user
of the system operation status and
malfunctions or abnormalities.
If the warning light turns on/flashes
simultaneously or a symbol is indicated in
the display, check the information
regarding the warning light or symbol.
Refer to If a Warni
ng Light Turns On or
Flashes on page 7-23.
For messages not indicating a symbol,
follow the instructions indicated in the
multi-information display.
Refer to Message Indicated on
Multi-information Disp lay on page 7-40.
When Driving
Instrument Cluster and Display
*Some models.4-23
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications
.
Front Center of Headliner
Warning lights will appear in any of the highlighted areas
Instrument Cluster
▼
Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Warning Page
Brake System Warning Indication/Warning Light*1*27-23
ABS Warning Light*1
Electronic Brake
Force Distribu‐ tion System
Wa r n i n g
7-23
ABS warning 7-26
Charging System Warning Indication/Warning Light*17-23
Engine Oil Warning Light*17-23
High Engine Coolant Temperat ure Warning Indication 7-23
Power Steering Malfunction Indication 7-23
When Driving
Instrument Cluster and Display
4-24
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

SignalWarning Page
Master Warning Indication 7-26
Electric Parking Brake (EPB) Warning Indication/Warning Light*17-26
Check Engine Light*17-26
Automatic Transaxle Warning Indication 7-26
Air Bag/Front Seat Belt Pretensioner System Warning Light*17-26
Tire Pressure Monitoring System Warning Light*1
Flashing
7-26
Turns on 7-32
(Amber/White) KEY Warning Indication Amber
7-26
White 7-32
(Amber) High Beam Control System (HBC) Warning Indication/Warning Light
*17-26
Blind Spot Monitoring (BSM)
Warning Indication 7-26
(Amber)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) War ning Indication 7-26
(Amber)Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Warning Indication
7-26
LED Headlight Warning Light*17-26
*Smart Brake Support/Smart City B
rake Support (SBS/SCBS) Warning In‐
dication 7-32
Low Fuel Warning Indication/Warning Light
7-32
Check Fuel Cap Warning Indication/Warning Light*17-32
Engine Oil Level Warning Light*17-32
Seat Belt Warning Light (Front seat) 7-32
When Driving
Instrument Cluster and Display
*Some models.4-25
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

SignalWarning Page
(Red)Seat Belt Warning Light (Rear seat) 7-32
Low Washer Fluid Level Warning Indication
7-32
Door-Ajar Warning Indication7-32
Trunk lid-Ajar Warning Indication 7-32
Door-Ajar Warning Light7-32
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
▼Indication/Indicator Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Indicator Page
(Green)Seat Belt Indicator Light (Rear seat) 2-26
Front Passenger Air Bag Deactivation Indicator Light*12-67
Security Indicator Light*13-36
Wrench Indication
4-29
Shift Position Indication 4-66
Lights-On Indication/Indicator Light 4-74
When Driving
Instrument Cluster and Display
4-26
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

SignalIndicator Page
Headlight High-Beam Indicator Light Headlight
High-Low Beam 4-77
Flashing the Headlights 4-77
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-79
Hazard Warning Flasher4-85
AUTOHOLD Active Indicator Light*14-101
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) indicator Light 4-153
TCS/DSC Indicator Light*1
Traction Control
System (TCS) 4-106
Dynamic Stabil‐ ity Control(DSC)4-107
Turns on 7-26
DSC OFF Indicator Light*14-107
Select Mode Indication 4-113
(Green)High Beam Control System (HBC) Indicator Light 4-120
Blind Spot Monitoring (BS
M) OFF Indicator Light*1
Malfunction
7-26
Except malfunc‐ tion
4-127
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) Main Indication 4-148
(Green)
*Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function) Set Indication 4-148
When Driving
Instrument Cluster and Display
*Some models.4-27
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

SignalIndicator Page
Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Indication 4-160
*Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) OFF Indicator Light*14-164
Smart City Brake Sup port (SCBS) Indication Advanced Smart
City Brake Sup‐ port (Advanced
SCBS)
4-170
Smart City
Brake Support (SCBS)4-173
*Smart Brake Support/Sma rt City Brake Support (SBS/SCBS) OFF Ind ica‐
tor Light*1
Advanced Smart City Brake Sup‐ port (Advanced SCBS)4-170
Smart City
Brake Support (SCBS)
4-174
Smart Brake
Support (SBS) System4-176
(White)
*Cruise Main Indication 4-216
(Green)
*Cruise Set Indication4-216
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the e ngine is started. If the light does not turn on or remains
turned on, have the ve hicle inspected at an Authorized Mazda De aler.
When Driving
Instrument Cluster and Display
4-28*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Wrench Indication
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to Maintenance Monitor on page
6-15.
When the engine oil replacement period
has arrived.
NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit is
necessary.
Refer to Maintenance Monitor on page
6-15.

When Driving
Instrument Cluster and Display
4-29
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Instrument Cluster (Type B)

ƒSpeedometer.................................................... ...................................................... page 4-30
„ Tachometer..................................................... ....................................................... page 4-30
… Multi-information Display (Type B)............................. ........................................ page 4-31
† Dashboard Illumination......................................... ................................................page 4-35
▼Speedometer
The speedometer indicates the speed of the
vehicle.
▼Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.

STRIPED
ZONE
RED ZONE
*
1The range varies depending on the type
of gauge. *
1
*1
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
When Driving
Instrument Cluster and Display
4-30
