▼Outside Temperature Display
When the ignition is switched ON, the
outside temperatur
e is displayed.

NOTE
Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and
vehicle conditions:
Significantly cold or hot temperatures.
Sudden changes in outside
temperature.
The vehicle is parked.
The vehicle is driven at low speeds.
Changing the Temperature Unit of the
Outside Temperature Display
The outside temperature unit can be
switched between Celsius and Fahrenheit.
Settings can be changed by operating the
center display screen.
Refer to Other Equipment/Functions on
page 9-14.
NOTE
When the temperature unit indicated in the
outside temperature display is changed,
the temperature unit indicated in the
engine coolant gauge display changes in
conjunction with it.
▼ Tr i p C o m p u t e r
The following information can be selected
by pressing the INFO switch with the
ignition switched ON.
Distance-to-empty mode
Average fuel economy mode
Current fuel
economy mode
Compass mode
If you have any problems with your trip
computer, consult an Authorized Mazda
Dealer.
Distance-to-empty mode
This mode displays the approximate
distance you can travel on the remaining
fuel based on the fuel economy.

The distance-to-empty will be calculated
and displayed every second.

NOTE
Even though the distance-to-empty
display may indicate a sufficient amount
of remaining driving distance before
refueling is required , refuel as soon as
possible if the fuel level is very low or
the low fuel warning light illuminates.
The display may not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
(indicating the remaining fuel supply)
disappear.
When Driving
Instrument Cluster and Display
4-51
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

If there is no past fuel economy
information such as after first
purchasing your vehicle or the
information is deleted when the battery
cables are disconnected, the actual
distance-to empty/range may differ from
the amount indicated.
Average fuel economy mode
This mode displays the average fuel
economy by calculating the total traveled
distance and the total fuel consumption
since the vehicle was purchased or the past
data was reset. The average fuel economy
is calculated and displayed every minute.

To reset the displayed past data, press the
INFO switch for 1.5 seconds or longer.
After resetting the data, - - - L/100 km
(- - - mpg) is displayed for one minute
before the fuel economy is recalculated
and displayed.
NOTE
If TRIP A is reset using the trip meter
when the function which synchronizes
(resets) the fuel economy monitor and the
trip meter (TRIP A) is on, the displayed
past data is reset.
Current fuel economy mode
This mode displays the current fuel
economy by calculating the amount of fuel
consumption and the distance traveled.

Current fuel economy will be calculated
and displayed every 2 seconds.

When you've slowed to about 5 km/h (3
mph), - - - L/100 km (- - - mpg) will be
displayed.
Compass mode
The direction the vehicle is moving is
displayed in one of eight directions while
the vehicle is being driven.

Display Direction
NN orth
SS ou th
EE ast
WW est
NE Northeast
NW Northwest
SE Southeast
SW Southwest
When Driving
Instrument Cluster and Display
4-52
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Cruise Control Set Vehicle Speed
Display
The vehicle speed preset using the cruise
control is displayed.

Refer to Cruise Cont
rol on page 4-215.
When Driving
Instrument Cluster and Display
4-53
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications
.
Front Center of Headliner
Warning lights will appear in any of the highlighted areas
Instrument Cluster
▼
Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Warning Page
Brake System Warning Light*1*27-23
ABS Warning Light*1
Electronic Brake
Force Distribu‐ tion System
Wa r n i n g
7-23
ABS warning 7-26
Charging System Warning Light*17-23
Engine Oil Warning Light*17-23
Power Steering Malfunction Indicator Light*17-23
Master Warning Light*17-26
When Driving
Instrument Cluster and Display
4-54
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

SignalWarning Page
Electric Parking Brake (EPB) Warning Light*17-26
(Red)Brake Pedal Operation Demand Warning Light
*1
Flashing
4-99
Buzzer & Flash‐ ing
7-26
Check Engine Light*17-26
*Automatic Transaxle Warning Light*17-26
Air Bag/Front Seat Belt Pretensioner System Warning Light*17-26
Tire Pressure Monitoring System Warning Light*1
Flashing
7-26
Turns on 7-32
(Red) KEY Warning Light
*1
Turns on
7-26
Flashing 7-32
LED Headlight Warning Light*17-26
(Amber)
*Smart City Brake Suppor t (SCBS) Warning Light*17-32
Low Fuel Warning Light 7-32
Check Fuel Cap Warning Light*17-32
Engine Oil Level Warning Light*17-32
Seat Belt Warning Light (Front seat) 7-32
(Red)Seat Belt Warning Light (Rear seat) 7-32
*Low Washer Fluid Level Warning Light
7-32
Door-Ajar Warning Light
7-32
When Driving
Instrument Cluster and Display
*Some models.4-55
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
▼Indication/Indicator Lights
These lights turn on or flash to notify the user of the system
operation status or a system
malfunction.
Signal Indicator Page
(Green)Seat Belt Indicator Light (Rear seat) 2-67
*Front Passenger Air Bag Deactivation Indicator Light*12-67
(Green)KEY Indicator Light 4-5
Security Indicator Light*13-36
Wrench Indication/Indicator Light*14-58
Shift Position Indication
4-66
Lights-On Indication/Indicator Light 4-74
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-77
Flashing the Headlights 4-77
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-79
Hazard Warning Flasher4-85
(Green) Brake Pedal Operation demand Indicator Light 4-95
AUTOHOLD Active Indicator Light*14-101
When Driving
Instrument Cluster and Display
4-56*Some models.
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

SignalIndicator Page
TCS/DSC Indicator Light*1
Traction Control
System (TCS) 4-106
Dynamic Stabil‐ ity Control(DSC)4-107
Turns on 7-26
DSC OFF Indicator Light*14-107
*Select Mode Indication 4-113
*Blind Spot Monitoring (BSM) OFF Indicator Light*1
Malfunction
7-26
Except malfunc‐ tion
4-127
(Red)
*Smart City Brake Suppor t (SCBS) Indicator Light 4-173
*Smart City Brake Support (SCBS) OFF Indicator Light*14-174
(White)Cruise Main Indication 4-216
(Green)Cruise Set Indication 4-216
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda De aler.
When Driving
Instrument Cluster and Display
*Some models.4-57
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Wrench Indicator Light
When the ignition is switched ON, the
wrench indicator light turns on and then
turns off after a few seconds.

The wrench indicator light turns on under
the following conditions:
When the preset maintenance period has
arrived.
When it’s time to rep
lace the engine oil.
Refer to Maintenance Monitor on page
6-15.
NOTE
The wrench indicator light turns on
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit is
necessary.
Refer to Maintenance Monitor on page
6-15.
When Driving
Instrument Cluster and Display
4-58
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Active Driving Display*
Dust-proof sheet
Display
Optical
receiver
WA R N I N G
Always adjust the display brightness and position with the vehicle stopped:
Adjusting the display brightness and position wh ile driving the vehicle is dangerous as doing
so could distract your attention from the road ahead and lead to an accident.
CAUTION
 Do not place beverages near the active driving display. If water or other liquids are splashed
on the active driving displa y, it could cause damage.
 Do not place objects above the active driving display or apply stickers to the dust-proof
sheet/optical receiver as they will cause interference.
 A sensor is integrated to control the display's luminosity. If the optical receiver is covered,
the display's luminosity will lower making the display
difficult to view.
 Do not allow intense light to hit the optical receiver. Otherwise, it could cause damage.
NOTE
Wearing polarized sunglasses will reduce the visibility of the active driving display due to
the characteristics of the display.
If the battery has been removed and re-installed or the battery voltage is low, the adjusted
position may deviate.
The display may be difficult to view or temporarily affected by weather conditions such as
rain, snow, light, and temperature.
If the audio system is removed, the active driving display cannot be operated.
The active driving display indicates the following information:
Blind Spot Monitoring (BSM) Ope ration Conditions and Warnings
Refer to Blind Spot Monitoring (BSM) on page 4-122.
When Driving
Instrument Cluster and Display
*Some models.4-59
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Distance Recognition Support System (DRSS) Operation Conditions and Warnings
Refer to Distance Recognition Support System (DRSS) on page 4-1 36.
Traffic Sign Recognition System (TSR) traffic signs and Warnings
Refer to Traffic Sign Recognition System (TSR) on page 4-128.
Mazda Radar Cruise Control with S top & Go function (MRCC with Stop & Go function)
Operation Conditions and Warnings
Refer to Mazda Radar Cruise Con trol with Stop & Go function (MR CC with Stop & Go
function) on page 4-144.
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) Operation
Conditions and Warnings
Refer to Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) on
page 4-157.
Advanced Smart City Brake Support (Advanced SCBS) Warnings
Refer to Advanced Smart City Brake Support (Advanced SCBS) on p age 4-168.
Smart City Brake Support (SCBS) Warnings
Refer to Smart City Brake Support (SCBS) on page 4-171.
Smart Brake Support (SBS) Warnings
Refer to Smart Brake Support (SBS) on page 4-174.
Cruise Control Operation Conditions
Refer to Cruise Control on page 4-215.
Navigation Guidance (vehicles with navigation system)
Speed limit indicator (vehicles with navigation system)
Vehicle Speed
Each setting/adjustment for the active driving display can be p erformed on the center
display.
1. Select the
icon on the home screen and display the Settings screen.
2. Select the AD-Disp tab.
3. Select the desired item and perform the setting/adjustment.
Method for adjusting screen brightness (automatically/manually)
Screen brightness initial setting s (automatic adjustment is selected)
Screen brightness adjustment (m anual adjustment is selected)
Display position of active driving display (display height)
Active driving display angle adjustment (display angle correcti on)
Active driving display ON/OFF (indication)
Navigation guidance ON/OFF
When Driving
Instrument Cluster and Display
4-60
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
