The Forward Sensing Camera (FSC)
recognizes a do not enter sign as a
sign targeted for your vehicle and the
vehicle passes it.
When the Forward Sensing Camera
(FSC) recognizes the do not enter sign
and a certain period of time has elapsed
since the vehicle passed the sign, display
of the do not enter sign stops.
Stop sign
A stop sign is displayed when all of the
following conditions are met:
The vehicle speed is about 30 km/h
(19 mph) or slower.
The Forward Sensing Camera (FSC)
recognizes a stop sign as a sign
targeted for your vehicle.
When a certain period of time has
elapsed since the stop sign was
displayed, display of the stop sign stops.
When Driving
i-ACTIVSENSE
4-133
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

▼Excessive Speed Warning
If the vehicle speed exceeds the speed limit sign displayed in
the active driving display/
instrument cluster, the area aro und the speed limit sign flashes 3 times in amber and the
warning sound is activated 3 tim es at the same time. If the vehicle speed continues to exceed
the displayed speed limit sign, the indication stops flashing and remains on. Check the
surrounding conditions and adjust the vehicle speed to the lega l speed using the appropriate
operation such as depressing the brake pedal.
6060
Active driving display indication
Instrument cluster (Type A) Active driving display indication
Instrument cluster (Type A)
While 60 mph is displayed
50 mph is displayed
Instrument cluster (Type B) Instrument cluster (Type B)
*1: Indication color in excessive speed area changes.
*1
Some models.
When Driving
i-ACTIVSENSE
4-134
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

The excessive speed warning is initially set to inoperable. If you want to activate the
excessive speed warning, change the setting in the personalizat ion features. In addition, the
warning pattern and the warning activation timing differ depending on the setting contents.
Refer to Safety Equipment on page 9-11.
Warning pattern
Off: The excessive speed warning is not activated.
Visual: The area around the speed limit sign displayed in the d isplay flashes 3 times in
amber, and if the vehicle speed continues to exceed the display ed speed limit sign, the
indication stops flashing and remains on.
Audio & Visual: The area around t he speed limit sign displayed in the display flashes 3
times in amber and the warning sound is activated 3 times at th e same time. If the vehicle
speed continues to exceed the displayed speed limit sign, the i ndication stops flashing and
remains on.
Warning activation timing
 0: If the vehicle speed exceeds the speed limit sign displayed in the display, the
excessive speed warning is activated.
 5: If the vehicle speed exceeds the speed limit sign displayed in the display by 5 km/h
(3 mph), the excessive speed warning is activated.
 10: If the vehicle speed exceed s the speed limit sign displayed in the display by 10
km/h (5 mph), the excessive speed warning is activated.
NOTE
In the following cases, the excessive speed warning stops operating.
The vehicle speed is less than the speed of the displayed speed limit sign. (If the
activation timing for the exce ssive speed warning is changed in the personalization
features, the excessive speed warning stops operating when the vehicle speed is less
than the changed vehicle speed.
A speed limit sign indication has been updated and the vehicle speed is lower than the
updated indication.
Display of the speed limit sign stops.
The warning indication is displayed at the same time the excessive speed warning sound
is activated if the vehicle speed exceeds the speed indicated on the speed limit sign.
Refer to Warning Sound is Activated on page 7-42.
If the Forward Sensing Camera (FSC) incorrectly recognizes the actual speed limit sign
at a lower speed, the excessive speed alarm is activated even if the vehicle is driven at the
legal speed.
When Driving
i-ACTIVSENSE
4-135
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Distance Recognition Support System (DRSS)*
The DRSS measures the distance between your vehicle and a vehicle ahead using a radar
sensor (front) while the vehicle speed is about 30 km/h (19 mph ) or faster, and if your
vehicle approaches a vehicle ahead more closely than what is ap propriate for maintaining
distance between the vehicles according to the vehicle speed, a notification in the active
driving display is indicated to advise you to keep a safe dista nce from the vehicle ahead.
WA R N I N G
Do not rely completely on the DRSS and always drive carefully:
The ability to detect a vehicle ahead is limite d depending on the type of vehicle ahead, the
weather conditions, and the traffic conditions. Therefore, if the accelerator and brake pedals
are not operated correctly it could lead to an accident. Always verify the safety of the
surrounding area and depress the brake pedal or accelerator pedal while keeping a safer
distance from vehicles ahead or on-coming vehicles.
NOTE
The DRSS operates when all of the following conditions are met:
The ignition is switched ON.
The DRSS is on.
The selector lever is in a position other than reverse (R).
The vehicle speed is 30 km/h or faster (19 mph or faster).
The objects which activate the system are 4-wheeled vehicles.
The DRSS may also operate in the presence of motorcycles and bicycles.
The DRSS may not operate normally under the following conditions:
The Dynamic Stability Control (DSC) has a malfunction.
The vehicle ahead is traveling at an extremely slow speed.
The system does not operate with the following objects:
Vehicles approaching in the opposite direction.
Stationary objects (stopped vehicles, obstructions)
▼ Indication on Display
The DRSS operation status is indicated in the active driving di
splay or multi-information
display. Regarding malfunctions, check the vehicle conditions o r have it inspected by an
Authorized Mazda Dealer according to the content of the display ed message.
When Driving
i-ACTIVSENSE
4-136*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

NOTE
When the ignition is switched off, the operation status be fore the system was turned off is
maintained. For example, if the ignition is switched off with the DRSS operable, the
system will be operable when the ignition is switched ON the next time.
The DRSS can be turned on/off and the system's sensitivity can be changed.
Refer to Safety Equipment on page 9-11.

Multi-information display Multi-information display
Active driving display
Instrument Cluster (Type A)
Instrument Cluster (Type B) Vehicle ahead
display
Vehicle ahead
display
Active driving display
Vehicle ahead
display
Vehicle ahead
display
When Driving
i-ACTIVSENSE
4-137
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Distance-between-vehicles guidelines*1
Indication on displayDistance be‐
tween vehi‐cles guide‐ lines
(During
travel at
about 40
km/h (25 mph) Distance be‐
tween vehi‐cles guide‐ lines
(During
travel at
about 80
km/h (50 mph)
Multi-information display
Active driving dis‐play
Instrument cluster (Type
A) Instrument cluster (Type
B)
About 25 m
(82 ft) About 50 m
(164 ft)
About 20 m
(66 ft)About 40 m
(131 ft)
About 15 m
(49 ft)About 30 m
(98 ft)
When Driving
i-ACTIVSENSE
4-138
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Indication on displayDistance be‐
tween vehi‐ cles guide‐ lines
(During
travel at
about 40
km/h (25 mph) Distance be‐
tween vehi‐cles guide‐ lines
(During
travel at
about 80
km/h (50 mph)
Multi-information display
Active driving dis‐play
Instrument cluster (Type
A) Instrument cluster (Type
B)
About 10 m
(33 ft) About 20 m
(66 ft)
Illuminated in amber*2Illuminated in amber*2
Illuminated in
amberAbout 10 m
(32 ft) or less
About 20 m
(65 ft) or less
*1 The distance between vehicles differs depending on vehicle spe
ed.
*2 Indication when the distance setting for notifying the driver that the vehicle approaches
a vehicle ahead is Near.
When Driving
i-ACTIVSENSE
4-139
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Mazda Radar Cruise Control with Stop & Go function(MRCC with Stop & Go function)
*
The MRCC with Stop & Go function system is designed to maintain headway control*1
with a vehicle ahead according to your vehicle's speed using a radar sensor (front) to detect
the distance to the vehicle ahead and a preset vehicle speed wi thout you having to use the
accelerator or brake pedals.
*1 Headway Control: Control of the distance between your vehicle and the vehicle ahead
detected by the Mazda Radar Cruise Control (MRCC) system.
Additionally, if your vehicle starts closing in on the vehicle ahead such as if the vehicle
ahead brakes suddenly, a warning sound and a warning indication in the display are
activated simultaneously to alert you to maintain a sufficient distance between the vehicles.
If the vehicle ahead stops while you are following behind it, y our vehicle will stop and be
held stopped automatically (stop hold control), and headway con trol will resume when you
resume driving the vehicle such as by pressing the RES switch.
Also refer to the following befo re using the MRCC with Stop & G o function.
AUTOHOLD (page 4-99)
Forward Sensing Camera (FSC) (page 4-204)
Radar sensor (front) (page 4-209)
WA R N I N G
Do not rely completely on the MRCC with Stop & Go function:
The MRCC with Stop & Go function system has detection limitations depending on the type of
vehicle ahead and its conditions, the weather conditions, and the road conditions.
Additionally, the system may be unable to dece lerate sufficiently to avoid hitting the vehicle
ahead if the vehicle ahead applies the brakes sudd enly or another vehicle cuts into the driving
lane, which could result in an accident.
Always drive carefully and verify the surroundi ng conditions and depress the brake pedal or
accelerator pedal while keeping a safer distance from vehicles ahead or on-coming vehicles.
Do not use the MRCC with Stop & Go function system in the following locations, using the
MRCC with Stop & Go function system at the following locations may result in an unexpected
accident:
 General roads other than high ways (Driving under these conditions using the MRCC with
Stop & Go function system is not possible.)
 Roads with sharp curves and where vehicle
traffic is heavy and there is
insufficient space
between vehicles.
When Driving
i-ACTIVSENSE
4-144*Some models.
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

During headway control travel, the system accelerates and decelerates your vehicle in
conjunction with the speed of the vehicle ahead. However, if it is necessary to accelerate
for a lane change or if the vehicle ahead brakes suddenly causing you to close in on the
vehicle rapidly, accelerate using the accelerator pedal or decelerate using the brake
pedal depending on the conditions.
While the MRCC with Stop & Go function system is in use, it does not cancel even if the
selector lever is operated and any intended engine braking does not occur. If deceleration
is required, lower the set speed or depress the brake pedal.
The sound of the automatic brakes operating may be heard, however, it does not indicate
a problem.
The brake lights turn on while the MRCC with Stop & Go function automatic braking is
operating.
▼ Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop & Go
function) Display Indication
The MRCC with Stop & Go function setting status and operation c onditions are indicated
on the multi-information display and the active driving display.
Instrument cluster (Type A)
Multi-information Display
MRCC Distance
between vehicle
display
MRCC Set vehicle speed
Vehicle ahead display
Vehicle ahead display
MRCC Distance
between vehicle
display
MRCC Set
vehicle speed
Active driving display
When Driving
i-ACTIVSENSE
4-146
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Instrument cluster (Type B)
Multi-information DisplayMRCC Distance
between vehicle
display
MRCC Set vehicle speed Vehicle ahead display
Vehicle ahead display MRCC Distance
between vehicle
display
MRCC Set
vehicle speed
Active driving display
If there is a problem with the MRCC with Stop & Go function sys tem, a message is
displayed on the multi-information display. Check the center di splay to verify the problem
and then have your vehicle inspected by an Authorized Mazda Dea ler.
Refer to Message Indicated on Display on page 7-38.
▼ Close Proximity Warning
If your vehicle rapidly closes in on the vehicle ahead because
the vehicle ahead applies the
brakes suddenly while you are traveling in headway control, the warning sound activates
and the brake warning is indicat ed in the display. Always verify the safety of the
surrounding area and depress the brake pedal while keeping a sa fer distance from the
vehicle ahead. Additionally, keep a safer distance from the veh icles behind you.
NOTE
In the following cases, the warnings and brakes may not operate even if your vehicle starts
closing in on the vehicle ahead.
You are driving your vehicle at the same speed as the vehicle ahead.
Directly after the MRCC with Stop & Go function system has been set.
Directly after the accelerator pedal is released.
Another vehicle cuts into the driving lane.
When Driving
i-ACTIVSENSE
4-147
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
