If the warning light flashes/message is
displayed and the beep sound is activated
simultaneously, have your vehicle
inspected at an Authorized Mazda Dealer.
▼ Blind Spot Monitoring (BSM)
System Warning Beep*
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Monit
oring (BSM) warning
light is illuminated.
NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Safety Equipment on page 9-11.
Reversing
The Blind Spot Monitoring (BSM)
warning sound is activated if there is a
possibility of collision with a vehicle
approaching from behind and from the
rear on the left and right sides of the
vehicle.
▼ Lane Departure Warning Sound*
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
The volume of the Lane-keep Assist
System (LAS) & Lane Departure
Warning System (LDWS) warning sound
can be changed.
Refer to Safety Equipment on page
9-11.
The type of the Lane-keep Assist System
(LAS) & Lane Departure Warning
System (LDWS) warning sound can be
changed.
Refer to Safety Equipment on page
9-11.
▼Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) System
War ni ng s
*
The Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) system warnings notify the
driver of system pr
oblems and precautions
on use when required. Check after hearing
a warning beep sound.
Warning beep What to check
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system is operating,
a single beep sound is
heard when “Front Ra‐
dar Sensor Blocked” is
displayed in the mul‐
ti-information display. Cancel the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system if the radar
sensor (front) becomes
dirty. Clean the area
around the radar sensor
(front).
The beep sounds inter‐
mittently while the vehi‐
cle is being driven. The distance between
your vehicle and the ve‐
hicle ahead is too close.
Verify the safety of the
surrounding area and re‐
duce vehicle speed.
While the Mazda Radar
Cruise Control with Stop
& Go function (MRCC
with Stop & Go func‐
tion) system is operating,
a single beep sound is
heard when “ Front Ra‐
dar Sensor System Mal‐
function” is displayed in
the multi-information
display. A malfunction in the
system may be indicated.
Check the center display
to verify the problem
and then have your vehi‐
cle inspected by an Au‐
thorized Mazda Dealer.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-45
Mazda6_8HK6-EA-19A_Edition1
2018-11-15 9:36:06

Function and how it can be changed (underlined item is initial setting)
The type of Lane-keep Assist System (LAS) & Lane Depar‐
ture Warning System (LDWS) warning can be changed. Vibration
/Beep/Rumbl.
The warning intensi‐
ty/volume of the sys‐
tem can be changed. Vibration High/Low
Rumbl.
High/Mid/Low
Beep High/Low
Blind Spot Monitoring (BSM) (page 4-122)
The system can be changed so that Blind Spot Monitoring
(BSM) does not operate.
*1On/Off
Warning beep volume
*2High/Low/Off
Distance Recognition Support System (DRSS) (page 4-136)
The system can be changed so that Distance Recognition
Support System (DRSS) does not operate.
*1On/Off
The distance at which the vehicle ahead and your vehicle in‐
dicated in the display flashes in white can be changed. Far/Med./Near
Traffic Sign Recognition System (TSR)*3 (page 4-128)
The Traffic Sign Recognition System (TSR) can be set to
inoperable.
*1On/Off
The warning pattern of the excessive speed warning can be
changed. Off
/Visual/Audio & Visual
The activation timing for the excessive speed warning can
be changed. +0 km/h (+0 mph)
/+5 km/h (+5 mph)/+10 km/h
(+10 mph)
360°View Monitor (page 4-177)
Setting can be changed so that the 360° view monitor is au‐
tomatically displayed when t he ignition is switched to ON. On/Off
Setting can be changed so that
the display of the estimated
forward line of progress is not displayed. On/Off
Setting can be changed so that the top view/front view dis‐
played while the vehicle is moving in the forward direction
after reversing is not displayed. On
/Off
Parking sensor system (page 4-236)
Display
*4/non-display On/Off
*1 Though these systems can be tur
ned Off, doing so will defeat the purpose of the system and Mazda
recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitori ng (BSM) operation can be changed. The
volume of the warning beep durin g Rear Cross Traffic Alert (RCTA) operation cannot be changed.
*3 This system functions only when t he navigation system is functioning.*4 When the ultrasonic sensors detect an obstruction, the content s indicated on the center display switches to the
360°View Monitor.
Specifications
Personalization Features
9-12
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Auto/Day/Night
:
(With auto-light control)
Switches screen automatically according to parking lights illum ination condition. However,
when the light sensor detects that the surrounding area is brig ht such as when the parking
lights are turned on in the dayti me, the screen is switched to the daytime screen
*1
(Without auto-light control)
Switches screen automatically according to parking lights illum ination condition.
*1
: Daytime screen setting
: Nighttime screen setting*1 The display is constantly on daytime screen when the illuminat ion dimmer is cancelled.

Sound quality
Method for changing functions using the center display
1. Select
on the home screen and display the setting screen.
2. Switch the tab to [Sound] and select the setting item you wan t to change.
Function and how it can be changed (underlined item is initial setting)
Sound quality
Bass (Low pitch sound) –6―0
―+6
(-Side: Low pitch reduction 、+Side: Low pitch enhance‐
ment)
Treble (Treble sound) –6―0
―+6
(-Side: Treble reduction 、+Side: Treble enhancement)
Fade (Front/Rear volume balance) Front: Front speaker volume enhancement
Rear: Rear speaker volume enhancement
Balance (Left/right volume balance) Right: Right speaker volume enhancement
Left: Left speaker v olume enhancement
Guidance Volume
(Volume adjustment during route guidance on
navigation screen) Left: Low volume
Right: High volume
ALC
*1 (Automatic volume adjustment) 0―7
(Adjustment at seven levels)
Bose
® Centerpoint*2 (Surround technology) ON/OFF
Bose® AUDIOPILOT*2 (Noise compensation
technology) ON/OFF
Beep (Audio operation sound)
ON/OFF
*1 Standard audio*2Bose® sound system
Specifications
Personalization Features
9-21
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Maintenance Monitor.................. 4-37
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display.......4-38
Message Indicated in Multi-
information Display (Type B)..... 7-40
Multi-information Display (Type
B)................................................. 4-31
Odometer..................................... 4-33
Outside Temperature Display...... 4-36
Speedometer................................ 4-30
Tachometer.................................. 4-30
Traffic Sign Recognition System
(TSR) Display..............................4-38
Trip Meter....................................4-33
Warning Indication/Warning
Lights........................................... 4-40
Warning (Display Indication)...... 4-39
Instrument Cluster (Type C)............. 4-46
Cruise Control Set Vehicle Speed
Display......................................... 4-53
Dashboard Illuminati on............... 4-50
Engine Coolant Temperature
Gauge........................................... 4-49
Fuel Gauge.................................. 4-49
Indication/Indi cator Lights.......... 4-56
Multi-information Display (Type
C)................................................. 4-47
Odometer..................................... 4-48
Outside Temperature Display...... 4-51
Speedometer................................ 4-46
Tachometer.................................. 4-46
Trip Computer............................. 4-51
Trip Meter....................................4-48
Warning Indication/Warning
Lights........................................... 4-54
Interior Care...................................... 6-60
Active driving display
maintenance................................. 6-62
Cleaning the floor mats............... 6-63
Cleaning the window interiors.....6-62Instrument panel top (Soft pad)
maintenance................................. 6-62
Leather upholstery
maintenance................................. 6-61
Panel maintenance....................... 6-62
Plastic part maintenance.............. 6-61
Seat belt maintenance..................6-60
Upholstery maintena nce.............. 6-61
Vinyl upholstery maintenance..... 6-60
Interior Lights................................... 5-84
Courtesy lights.............................5-84
Map lights....................................5-84
Overhead lights............................5-84
i-ACTIVSENSE.............................. 4-115 Active safety technology........... 4-115
Adaptive Front Lighting System
(AFS)......................................... 4-118
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-168
Blind Spot Monitoring (BSM) ............
................................................... 4-122
Camera and sensors................... 4-116
Distance Recognition Support System
(DRSS).......................................4-136
Forward Sensing Camera
(FSC)......................................... 4-204
High Beam Control System
(HBC)........................................ 4-119
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-157
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-144
Pre-crash safety technology....... 4-115
Radar sensors (rear)...................4-212
Radar sensor (front)...................4-209
Rear Cross Traffic Alert
(RCTA)...................................... 4-140
Smart Brake Suppor t (SBS)...... 4-174
10-6
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06

Index
Engine compartment overview.... 6-22
Key battery replacement..............6-36
Opening the hood........................ 6-20
Owner maintenance
precautions................................... 6-18
P
Parking Brake....................................4-95
Parking Sensor System................... 4-232
Park assist sensor system
operation.................................... 4-236
Sensor detection range.............. 4-234
Personalization Features................... 9-10
Power Steering................................ 4-114
Power Steering Warning Buzzer....... 7-44
Power Windows................................ 3-29
R
Radar Sensors (Rear)...................... 4-212
Radar Sensor (Front).......................4-209
Rearview Mirror................................3-26
Rear Coat Hooks............................... 5-94
Rear Cross Traffic Alert (RCTA).... 4-140
Rear Door Child Safet y Locks.......... 3-15
Rear Seat........................................... 2-15
Rear View Monitor......................... 4-224
Displayable range on the
screen......................................... 4-226
Picture quality adjustment......... 4-231
Rear view monitor operation..... 4-227
Rear view parking camera
location...................................... 4-225
Switching to the rear view monitor
display........................................4-225
Variance between actual road
conditions and displayed
image......................................... 4-230
Viewing the display................... 4-227
Rear Window Defogger.................... 4-83
Recommended Oil.............................6-23
Recording of Vehicle Data................ 8-23
Recreational Towing......................... 3-47
Registering Your Vehicle in A Foreign
Country.............................................. 8-19
Replacement Fuse..............................................6-47
Key battery.................................. 6-36
Light bulbs...................................6-43
Tires............................................. 6-40
Wheel........................................... 6-42
Wiper........................................... 6-30
Request Switch Inoperable Warning
Beep (With the advanced keyless
function)............................................ 7-44
Rocking the Vehicle.......................... 3-41
S
Safety Defects, Reporting................. 8-15
Saving Fuel and Protection of the
Environment...................................... 3-39
Scheduled Maintenance...................... 6-4
Seat Seat position memory.................. 2-11
Seats Front seat....................................... 2-5
Head restraint.............................. 2-17
Rear seat...................................... 2-15
Seat ventilation............................ 2-20
Seat warmer................................. 2-19
Seat Belt System Automatic locking....................... 2-24
Emergency locking...................... 2-24
Extender....................................... 2-28
Pregnant women.......................... 2-24
Seat belt precautions................... 2-22
3-point type................................. 2-25
Seat Belt Warning Beep.................... 7-42
Security System Immobilizer system..................... 3-35
Theft-deterrent system.................3-37
10-8
Mazda6_8HK6-EA-19A_Edition1 2018-11-15 9:36:06
