MAZDA MODEL 626 2001 Owners Manual

Form No. 8P95-EA-00G
Driving Your Mazda
5-27
NOTECruise control will cancel at
approximately 15 km/h (9 mph)
below the preset speed or below 40
km/h (25 mph).

049-7A1E
J94A4020
(J18T4017) To Increase Cruising Speed
Follow either of these procedures.
• Press and hold RESUME/ACCEL
switch. Release the switch when
the desire speed is reached. •
Accelereate to the desired speed,
then press SET/COAST switch and
release.
Your vehicle has a “tap-up” feature
that allows you to increase your
current speed in increments of 1.6
km/h (1 mph) by a momentary tap of
the RESUME/ACCEL switch.
Multiple taps will increase your
vehicle speed 1.6 km/h (1 mph) for
each tap. For example, if you are
currently set at 96 km/h (60 mph) and
tap the RESUME/ACCEL switch 5
times, your vehicle speed will increase
and set at 104 km/h (65 mph).

Form No. 8P95-EA-00G
Driving Your Mazda5-28
049-8AE
Accelerating with Cruise Control
On
Accelerate if you want to speed up
temporarily when the cruise control is
on. Greater speed will not interfere
with it or change the set speed.
Take your foot off the accelerator to
return to the set speed.

049-9A1E
J94A4021
(J18T4018) To Decrease Cruising Speed
Press and hold SET/COAST switch.
Release the switch at the speed you
want.
Your vehicle has a “tap-down” feature
that allows you to decrease your current speed in decrements of 1.6
km/h (1 mph) by a momentary tap of
the SET/COAST switch. Multiple taps
will decrease your vehicle speed 1.6
km/h (1 mph) for each tap. For
example, if you are currently set at
104 km/h (65 mph) and tap the
SET/COAST switch 5 times, your
vehicle speed will decrease and set at
96 km/h (60 mph).

Form No. 8P95-EA-00G
Driving Your Mazda
5-29

049-10A4E
J94A4022
(J18T4019) To Resume Cruising Speed at
More Than 40 km/h (25 mph)
If something besides the CRUISE
MAIN switch was used to cancel
cruising speed and the system is still
activated, the most recent set speed
will automatically resume when the RESUME/ACCEL switch is pressed.
If vehicle speed is below 40 km/h (25
mph), increase the vehicle speed up to
40 km/h (25 mph) and press the
RESUME/ACCEL switch.


049-11FE
NOTEWith an automatic transaxle
vehicle, the gear is automatically
selected when going uphill.

Form No. 8P95-EA-00G
Driving Your Mazda5-30050-1AEInstrument Cluster
TachometerTurn signal indicator
Speedometer
Turn signal indicator
Odometer/Trip meter selector Fuel gauge
Water temperature gauge
Warning and indicator lights
Odometer and Trip meter
J94S5002
Warning and indicator lights

Form No. 8P95-EA-00G
Driving Your Mazda
5-31

051-1AE
Gauges Speedometer
The speedometer shows speed in miles
and kilometers per hour.

051-2IE
Odometer/Trip meter
selector
J94A4023 Odometer and Trip Meter
The ignition switch must be in the ON
position. The display mode can be changed
from odometer to trip meter A to trip
meter B and then back to odometer by
pressing the selector. The selected
mode will be displayed.

Form No. 8P95-EA-00G
Driving Your Mazda5-32J16E4064Odometer
When this mode is selected, ODO will
be displayed.
The odometer records the total
distance the vehicle has been driven.
J16E4055Trip meter A
Trip meter B Trip meter
The trip meter can record the total
distance of two trips. One is recorded
in trip meter A, and the other is
recorded in trip meter B. For instance, trip meter A can record
the distance from the point of origin,
and trip meter B can record the distance
from where the fuel tank is filled.
When trip meter A is selected,
pressing the selector again within one
second will change the trip meter to B
mode.
When trip meter A is selected, TRIP A
will be displayed. When trip meter B
is selected, TRIP B will be displayed.
The trip meter records the total
distance the vehicle is driven until the
meter is again reset. Return it to “0.0”
by holding the selector depressed for
more than 1 second.

Form No. 8P95-EA-00G
Driving Your Mazda
5-33
Use this meter to measure trip
distances and to compute fuel
consumption.NOTE•Only the trip meters record
tenths of kilometers (miles).
• The trip record will be erased
when;
•The power supply is
interrupted (blown fuse or
the battery is disconnected).
• The vehicle is driven over
999.9 km (miles).
051-4AE
J94S5004
Normal range
Water Temperature Gauge
This gauge shows the temperature of
the engine coolant.
If the needle exceeds normal range
toward H, it indicates overheating.
CAUTION
!
Driving with an overheated engine
can cause serious engine damage
(page 6-2).

Form No. 8P95-EA-00G
Driving Your Mazda5-34
051-5EE
Warning light
J94S5005Fuel Gauge
The fuel gauge shows approximately
how much fuel is in the tank. We
recommend keeping the tank over 1/4
full. When the low fuel warning light
illuminates or when the needle is near
E, refuel as soon as possible.
051-7B1ERed
zone
J94A4027➀ 2.0-liter engine
➁ 2.5-liter engine
➁ ➀

Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute
(rpm). Use it while selecting shift points and
to prevent lugging and overrevving
(page 5-8).
051-8AE
CAUTION
!
Don’
t run the engine with the
tachometer needle in the RED
ZONE.
This may cause severe engine
damage.

Form No. 8P95-EA-00G
Driving Your Mazda
5-35


052-1AE
Dashboard Illumination
Dim
Bright
J94A4028When the parking lights or headlights
are on, rotate the thumb wheel to
adjust the brightness of the dashboard
lights.
Q053-1CE
Warning Lights/Beeps
Warning Lights Inspection
Inspect the warning lights by turning
the ignition switch to the ON position
with the engine off and the parking
brake on. Consult an Authorized
Mazda Dealer about any light that
doesn’ t come on.
If the brake system warning light is off
when the ignition switch is in the
START position, have the system
inspected by an Authorized Mazda
Dealer.
After starting the engine, make sure all
warning lights are off. If one stays on,
it’ s signaling for attention. The brake system warning light should
go off when the parking brake is
released.

Form No. 8P95-EA-00G


Driving Your Mazda5-36

Q053-2GE
 Brake System Warning
Light
This warning has two functions.
 Parking brake warning
The light comes on when the parking
brake is applied with the ignition
switch in the START or ON position.
It goes off when the brake is fully
released.
 Low brake fluid level warning
If the light stays on after the parking
brake is fully released, you may have a
brake problem. If it stays on:
1. Be sure the parking brake is fully
released.
2. Check the light. If this light is still on, drive to the
side of the road and park off the
right-of-way.
You may notice that the pedal is
harder to push or that it may go
closer to the floor. In either case, it
will take longer to stop the vehicle.
3. With the engine stopped, check the brake fluid level immediately and
add fluid as required (page 8-25). 4. After adding fluid, check the light
again.
If the warning light remains on, or
if the brakes do not operate
properly, do not drive the vehicle.
Have it towed to an Authorized
Mazda Dealer.
Even if the light goes off, have
your brake system inspected as
soon as possible.
