MAZDA MODEL B-SERIES 2008 Owners Manual (in English)

Item ApplicationMazda part name or
equivalentCapacity
Transfer case fluid
(4X4)4x4 VehiclesTransfer Case Fluid
1.25 quarts (1.2L)
Manual transmission
fluid5-speed manual MERCONV ATF 2.8 quarts (2.65L)
3
Automatic transmission
fluid (5R44E and
5R55E)4x2 vehicles with
2.3L I4 engine
MERCONVATF
4
9.9 quarts (9.4L)
5
4x2 vehicles with
3.0L or 4.0L
engines10.0 quarts (9.5L)
5
4x4 vehicles with
3.0L or 4.0L
engines10.3 quarts (9.8L)
5
Front axle fluid (4X4) 4x4 VehiclesSAE 80W-90 Premium
Rear Axle Lubricant3.6 pints (1.7L)
Rear axle fluid AllSAE 80W-90 Premium
Rear Axle Lubricant5.0-5.3 pints (2.4-2.5L)
6
Windshield washer fluid AllUltra-clear Windshield
Washer Concentrate2.75 quarts (2.6L)
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
261

Item ApplicationMazda part name or
equivalentCapacity
Fuel tankRegular cab
(Short wheel
base)—17 gallons (64.4L)
Cab Plus 4 19.5 gallons (73.8L)
1Brake fluid will drop slowly as the brakes wear and will rise when brake components are replaced.
Fluid levels below the MAX line that do not trigger the brake warning light are within the normal
operating range, there is no need to add fluid. If the levels are outside the normal operating range,
the performance of your brake system could be compromised, seek service from your authorized
dealer immediately.2Add the coolant type originally equipped in your vehicle. Do not mix different colors or types of
coolant. Do not use Mazda Extended Life Engine Coolant (orange in color). Refer toAdding
engine coolant, in this chapter.3Service refill capacity is determined by filling the transmission to the bottom of the filler hole with
the vehicle on a level surface.4Automatic transmissions that require MERCONV should only use MERCONV fluid or fluid that
is specified dual usage MERCON/MERCONV. Refer toscheduled maintenanceto determine
the correct service interval. Use of any fluid other than the recommended fluid may cause
transmission damage.5Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and
if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set
by the indication on the dipstick’s normal operating range.6Traction-Lok axles use 4.75–5.0 pints (2.2–2.4L) of rear axle lubricant. Add 4 oz. (118 ml) of
Additive Friction Modifier meeting Mazda specifications for complete refill of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 1/4 inch to 9/16 inch (6 mm to 14
mm) below the bottom of the filler hole.
If submerged in water, the rear axle lubricant should be changed.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
262

ENGINE SPECIFICATIONS
Engine 2.3L I4 engine 3.0L V6 engine 4.0L V6 engine
Cubic inches 138 182 245
Required fuel 87 octane 87 octane 87 octane
Firing order 1-3-4-2 1-4-2-5-3-6 1-4-2-5-3-6
Spark plug gap 0.049–0.053 inch
(1.25–1.35mm)0.051–0.057 inch
(1.29–1.45mm)0.052–0.056 inch
(1.32–1.42mm)
Ignition system EDIS EDIS EDIS
Compression
ratio9.7:1 9.6:1 9.7:1
Engine drivebelt routing
•2.3L I4 Engine without A/C (with A/C similar)
•3.0L V6 Engine without A/C
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
263

•3.0L V6 Engine with A/C
•4.0L V6 Engine
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
264

IDENTIFYING YOUR VEHICLE
Safety Compliance Certification Label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the structure (B-Pillar)
by the trailing edge of the driver’s
door or the edge of the driver’s
door.
Vehicle identification number (VIN)
The vehicle identification number is
located on the driver side
instrument panel.
Please note that in the graphic,
XXXX is representative of your
vehicle identification number.
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT:XXRC:XXDSO:
WB BRK INT TR TP/PS R AXLE TR SPR XXXXX
XXX X XX X XX X XX XXX
XXXXXXXXXXXXXXXXXXXX-XXXXXXX-XX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN
EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
VIN:XXXXXXXXXXXXXXXXX XXXXX
TYPE:XXX XXXXX DATE:XX/XX GVWR:XXXXXLB/ XXXXXKG
FRONT GAWR: XXXXL REAR GAWR: XXXXLB
AT XXX kPa/XX PSI COLD AT XXX kPa/XX PSI COLD XXXXKG WITH
XXXX/XXXXXXXTIRES
XXXX.XXRIMSXXXXKG WITH
XXXX/XXXXXXXTIRES
XXXX.XXRIMS
FOR MAZDA MOTOR CORPORATION
XXXXXXXXXXXXXXXXX
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
265

The Vehicle Identification Number (VIN) contains the following
information:
1. World manufacturer identifier
2. Brake system / Gross Vehicle
Weight Rating (GVWR) /
Restraint System
3. Vehicle line, series, body type
4. Engine type
5. Check digit
6. Model year
7. Assembly plant
8. Production sequence number
TRANSMISSION/TRANSAXLE CODE DESIGNATIONS
You can find a
transmission/transaxle code on the
Safety Compliance Certification
Label . The following table tells you
which transmission or transaxle
each code represents.
Description Code
Five-speed automatic (5R44E/5R55E) D
Five-speed manual (HD) J
Five-speed manual (R1) R
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT:XXRC:XXDSO:
WB BRK INT TR TP/PS R AXLE TR SPR XXXXX
XXX X XX X XX X XX XXX
XXXXXXXXXXXXXXXXXXXX-XXXXXXX-XX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN
EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
VIN:XXXXXXXXXXXXXXXXX XXXXX
TYPE:XXX XXXXX DATE:XX/XX GVWR:XXXXXLB/ XXXXXKG
FRONT GAWR: XXXXL REAR GAWR: XXXXLB
AT XXX kPa/XX PSI COLD AT XXX kPa/XX PSI COLD XXXXKG WITH
XXXX/XXXXXXXTIRES
XXXX.XXRIMSXXXXKG WITH
XXXX/XXXXXXXTIRES
XXXX.XXRIMS
FOR MAZDA MOTOR CORPORATION
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
266

CELL PHONES
Use of cell phones and other devices by driver:
WARNING: Use of any electrical devices such as cell phones,
computers, portable radios, vehicle navigation or other devices
by the driver while the vehicle is moving is dangerous. Dialing a
number on a cell phone while driving also ties-up the driver’s
hands. Use of these devices will cause the driver to be
distracted and could lead to a serious accident. If a passenger is
unable to use the device, pull off the right-of-way to a safe area
before use. If use of a cell phone is necessary despite this
warning, use a hands-free system to at least allow the hands
free to drive the vehicle. Never use a cell phone or other
electrical device while the vehicle is moving and, instead,
concentrate on the full-time job of driving.
In addition, the gasoline distributors are warning against using
cell phones during refueling procedures, due to their increased
concern about static electricity fires in the self-service pump
environment.
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Accessories
267

A
ABS (see Brakes) .....................151
Air cleaner filter ...............257, 259
Airbag supplemental restraint
system ..........................................86
and child safety seats ..............89
description ................................86
disposal ......................................91
driver airbag ........................86, 89
indicator light ...........................90
operation .............................86, 89
passenger airbag .................86, 89
Ambulance packages ....................7
Antifreeze
(see Engine coolant) ................234
Anti-lock brake system
(see Brakes) ......................151–152
Anti-theft system ........................66
Audio system
(see Radio) ......................19, 21, 27
Automatic transmission ............156
driving an automatic
overdrive .................................157
fluid, specification ..................259
Auxiliary input jack (Line in) ....32
Auxiliary power point .................54
Axle
lubricant specifications ..........259
traction lok ..............................155
B
Battery .......................................232
acid, treating emergencies .....232
jumping a disabled battery ....189
maintenance-free ....................232
servicing ..................................232Belt-Minder...............................82
Booster seats ...............................95
Brakes ........................................151
anti-lock ...........................151–152
anti-lock brake system (ABS)
warning light ...........................153
fluid, checking and adding ....252
fluid, specifications .................259
lubricant specifications ..........259
parking ....................................153
shift interlock ..........................156
Break-in period .............................5
Bulbs ............................................46
C
Cargo cage ...................................60
Cell phone warning ...................267
Changing a tire .........................179
Child safety restraints ................95
child seat belts .........................95
Child safety seats ........................99
attaching with tether straps ..102
in front seat ............................100
in rear seat ..............................100
tether anchorage hardware ...102
Child safety seats - booster
seats .............................................95
Chimes (warning) .......................17
Cleaning your vehicle
engine compartment ..............207
instrument panel ....................210
interior .....................................210
Mazda car care products .......211
plastic parts ............................209
washing ....................................206
waxing .....................................206
wheels ......................................207
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Index
268

wiper blades ............................209
Clock adjust
AM/FM Stereo ...........................20
AM/FM stereo CD .....................21
Premium AM/FM stereo
CD6/MP3 ...................................28
Clutch
fluid ..........................................252
operation while driving ..........159
recommended shift speeds ....160
Console ........................................54
Coolant
checking and adding ..............234
refill capacities ........................239
specifications ..........................259
Cruise control
(see Speed control) ....................57
Customer
Assistance ..................195–196, 198
D
Daytime running lamps
(see Lamps) ................................43
Dipstick
engine oil .................................226
Driveline universal joint and
slip yoke ....................................256
Driving under special
conditions ..................161, 164, 166
mud ..........................................165
sand .........................................165
snow and ice ...........................167
through water .................165, 167
E
Emergencies, roadside
jump-starting ..........................189Emergency Flashers .................168
Emission control system ..........248
Engine ........................................263
cleaning ...................................207
coolant .....................................234
idle speed control ...................232
lubrication specifications .......259
service points ..................222–224
starting after a collision .........168
Engine block heater .................150
Engine oil ..................................226
checking and adding ..............226
dipstick ....................................226
filter, specifications ................230
recommendations ...................230
specifications ..........................259
Event data recording ....................6
Exhaust fumes ..........................149
F
Foglamps .....................................42
Four-Wheel Drive vehicles .......161
driving off road .......................163
electronic shift ........................162
indicator light .........................162
preparing to drive your
vehicle .....................................155
Fuel ............................................240
calculating fuel economy .......245
cap ...........................................242
choosing the right fuel ...........243
comparisons with EPA fuel
economy estimates .................247
detergent in fuel .....................243
filling your vehicle
with fuel ..................240, 242, 245
filter, specifications ................240
fuel pump shut-off switch .....168
improving fuel economy ........245
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Index
269

octane rating ...................243, 263
quality ......................................244
running out of fuel .................244
safety information relating to
automotive fuels .....................240
Fuel pump shut-off switch .......168
Fuses ..................................169–170
G
Gas cap (see Fuel cap) ............242
Gas mileage
(see Fuel economy) .................245
Gauges .........................................17
H
Hazard flashers .........................168
Headlamps ...................................42
aiming ........................................44
bulb specifications ....................46
daytime running lights .............43
flash to pass ..............................43
high beam .................................42
replacing bulbs .........................47
turning on and off ....................42
Heating
heating and air conditioning
system .................................39–40
Hood ..........................................221
I
Ignition ...............................146, 263
Infant seats (see Safety seats) ..99
Inspection/maintenance (I/M)
testing ........................................250
Instrument panel
cleaning ...................................210cluster ........................................12
lighting up panel and
interior .......................................43
location of components ............12
J
Jack ............................................179
positioning ...............................179
storage .....................179, 182–183
Jump-starting your vehicle ......189
K
Keys .......................................62, 67
positions of the ignition .........146
L
Lamps
bulb replacement
specifications chart ..................46
daytime running light ...............43
fog lamps ...................................42
headlamps .................................42
headlamps, flash to pass ..........43
instrument panel, dimming .....43
interior lamps .....................46–47
replacing bulbs .........................47
Lane change indicator
(see Turn signal) ........................45
Lights, warning and indicator ....12
anti-lock brakes (ABS) ..........153
Load limits .................................129
Loading instructions .................135
Locks
doors ..........................................62
Lubricant specifications ...........259
Lug nuts ....................................187
M
Manual transmission .................159
2008 B-Series(mbs)
Owners Guide (post-2002-fmt)
USA(fus)
Index
270
