maintenance MAZDA MODEL B3000 2002 (in English) Repair Manual

Fluid Mazda Part
NameApplication Capacity
Transmission
fluid
1Mazda
MERCONtAT F5-speed manual 2.65L (2.8
quarts)2
Mazda
MERCONtV
AT F4x2 vehicles
with automatic
and 2.3L I4
engine9.4L (9.9
quarts)3
4x2 vehicles
with automatic
and 3.0L or 4.0L
engines9.5L (10.0
quarts)3
4x4 vehicles
with automatic
and 3.0L or 4.0L9.8L (10.3
quarts)3
Engine coolant4Premium Engine
Coolant2.3 L I4 engine
with manual
transmission10.0L (10.5
quarts)
2.3L I4 engine
with automatic
transmission9.7L (10.2
quarts)
3.0L V6 engine
with manual
transmission14.3L (15.1
quarts)
3.0L V6 engine
with automatic
transmission14.0L (14.8
quarts)
4.0L V6 engine
with manual
transmission13.0L (13.7
quarts)
4.0L V6 engine
with automatic
transmission12.5L (13.2
quarts)
Maintenance and Specifications
273

Fluid Mazda Part
NameApplication Capacity
Fuel tank N/A Regular cab
(Short wheel
base)62.4L (16.5
gallons)
Regular cab
(Long wheel
base)75.7L (20.0
gallons)
SuperCab 73.8L (19.5
gallons)
Transfer Case
FluidMazda
MERCONtAT F4x4 Vehicles 1.2L (1.25
quarts)
Front axle
lubricantMazda SAE
80W-90
Premium Rear
Axle Lubricant4x4 Vehicles 1.7L (3.6 pints)
Rear axle
lubricant
5Mazda SAE
80W-90
Premium Rear
Axle LubricantAll 2.4-2.5L (5.0-5.3
pints)
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll 2.6L (2.75
quarts)
1Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCONtand MERCONtV are not interchangeable. DO NOT
mix MERCONtand MERCONtV. Refer to the service maintenance
section to determine the correct service interval.
2Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
3Indicates only approximate dry-fill capacity. Some applications may vary
based on cooler size and if equipped with an in-tank cooler. The amount
of transmission fluid and fluid level should be set by the indication on
the dipstick's normal operating range.
4Use Mazda Premium Engine Coolant (green in color). DO NOT USE
Mazda Extended Life Engine Coolant (orange in color). Refer toAdding
engine coolant, in the Maintenance and Care chapter.
Maintenance and Specifications
274

5Traction-Lok axles use 2.2±2.4L (4.75±5.0 pints) of rear axle lubricant.
Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda
specifications for complete refill of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 6 mm to
14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
LUBRICANT SPECIFICATIONS
Item Mazda part name or equivalent
Front axle (4X4)SAE 80W-90 Premium Rear Axle
Lubricant
Rear axleSAE 80W-90 Premium Rear Axle
Lubricant
1
Brake fluid and clutch fluid (if
equipped)High Performance DOT 3 Motor
Vehicle Brake Fluid
Door weather strips Silicone Lubricant
Engine coolant Mazda Premium Engine Coolant
Engine oil 2.3L I4 and 3.0L V6
enginesSAE 5W-20 Premium Synthetic
Blend Motor Oil
Engine oil 4.0L V6 engines SAE 5W-30 Super Premium Motor
Oil
Hinges, door checks, latches,
striker plates, fuel filler door hinge
and seat tracksMulti-Purpose Grease
Transmission /steering/parking
brake linkages and pivots, brake
and clutch pedal shaft, clutch pilot
bearing and input shaft spline
(manual transmission).Premium Long-Life Grease
Power steering fluid, transfer case
fluid (4X4) and transmission fluid
(manual)MERCONtAT F
Automatic transmission (5R44E
and 5R55E)MERCONtVATF
2
Windshield washer fluidUltra-clear Windshield Washer
Concentrate
Maintenance and Specifications
275

1Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda
specifications for complete refill of Traction-Lok axles. If submerged in
water, the rear axle lubricant should be changed.
2Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCONtand MERCONtV are not interchangeable. DO NOT
mix MERCONtand MERCONtV. Refer to your service maintenance
section to determine the correct service interval.
ENGINE SPECIFICATIONS
Engine 2.3L I4 engine 3.0L V6 engine 4.0L V6 engine
Cubic inches 138 182 245
Required fuel 87 octane 87 octane 87 octane
Firing order 1-3-4-2 1-4-2-5-3-6 1-4-2-5-3-6
Spark plug gap 1.04-1.19mm
(0.041-0.047
inch)1.07-1.17mm
(0.042-0.046
inch)1.3-1.4 mm
(0.052-0.056
inch)
Ignition system EDIS EDIS EDIS
Compression
ratio9.7:1 9.14:1 9.0:1
VEHICLE DIMENSIONS
Vehicle dimensions Regular Cab
mm (in)SuperCab mm
(in)
(1) Overall length 4 763 (187.5) 5 153 (202.9)
(2) Overall width 1 785 (70.3) 1 785 (70.3)
(3) Overall height 4x2/4x4 1 575 (62.0) /
1 655 (65.2)1 585 (62.4) /
1 684 (66.3)
(4) Wheelbase 2 831 (111.4) 3 192 (125.7)
(5) Track - Front 1 486 (58.5) 1 485 (58.5)
(5) Track - Rear 1 455 (57.3) 1 455 (57.3)
Maintenance and Specifications
276

2
5
3
1
4
Maintenance and Specifications
277

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety Administration Regulations require
that a Certification Label be affixed to a vehicle and prescribe where the
Certification Label may be located. The Certification Label is located on
the front door latch pillar on the driver's side.
Vehicle identification number (VIN)
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel. (Please note that
in the graphic XXXX is
representative of your vehicle
identification number.)
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if equipped).
1
4
XXXXXXXXXXXXXXXXX
Maintenance and Specifications
278

A
ABS (see Brakes) .....................154
Air bag supplemental restraint
system ................................119±120
and child safety seats ............122
description ..............................120
disposal ....................................126
driver air bag ..........................124
indicator light .............14±15, 125
operation .................................124
passenger air bag ...................124
passenger deactivation
switch ......................................126
Air conditioning
manual heating and air
conditioning system .................69
Ambulance packages ....................7
Antifreeze (see Engine
coolant) .....................................245
Anti-lock brake system
(see Brakes) ......................154±155
Anti-theft system
warning light .............................16
Audio system
(see Radio) ......................21, 45, 53
Automatic transmission ............158
driving an automatic
overdrive .................................159
fluid, adding ............................263
fluid, checking ........................263
fluid, refill capacities ..............272
fluid, specification ..................276
Auxiliary power point .................84
Axle
lubricant specifications ..275±276
refill capacities ........................272
traction lok ..............................157
B
Battery .......................................243acid, treating emergencies .....243
charging system warning
light ............................................15
jumping a disabled battery ....201
maintenance-free ....................243
servicing ..................................243
voltage gauge ............................19
Bed extender ..............................95
BeltMinder .................................115
Brakes ........................................153
anti-lock ...........................154±155
anti-lock brake system (ABS)
warning light .....................14, 155
brake warning light ..................13
fluid, checking and adding ....262
fluid, refill capacities ..............272
fluid, specifications .........275±276
lubricant specifications ..275±276
parking ....................................155
shift interlock ..........................158
Break-in period .............................5
Bulbs ............................................75
C
Capacities for refilling fluids ....272
Cargo area shade ........................95
Cargo net .....................................95
CD-6 disc .....................................53
CD-single .....................................25
CD-single premium .....................45
Cell phone warning ...................279
Certification Label ....................278
Changing a tire .........................194
Child safety restraints ..............132
child safety belts ....................132
Child safety seats ......................135
Index
280

warning chime ..........................17
Heating
heater only system ...................68
heating and air conditioning
system .......................................69
Hood ..........................................233
I
Ignition ...............................148, 276
Infant seats (see Safety seats)..135
Inspection/maintenance (I/M)
testing ........................................260
Instrument panel
cleaning ...................................222
cluster ................................12, 222
lighting up panel and interior...74
location of components ............12
J
Jack ............................................194
positioning ...............................194
storage .............................194±197
Jump-starting your vehicle ......201
K
Keys ...................................102±103
key in ignition chime ...............17
positions of the ignition .........148
L
Lamps
bulb replacement
specifications chart ..................76
cargo lamps ...............................74
daytime running light ...............73
fog lamps ...................................73headlamps .................................73
headlamps, flash to pass ..........74
instrument panel, dimming .....74
interior lamps .....................75±76
replacing bulbs.. 75, 77±78, 80±81
Lane change indicator (see
Turn signal) .................................75
LATCH anchors .........................145
Lights, warning and indicator ....12
air bag ..................................14±15
anti-lock brakes (ABS) ....14, 155
anti-theft ...................................16
brake ..........................................13
charging system ........................15
check coolant ............................13
check engine .............................12
cruise indicator .........................15
door ajar ....................................16
fuel cap light .............................15
high beam .................................16
overdrive off ..............................16
safety belt .................................14
speed control ............................93
turn signal indicator .................16
Limited slip axle
(see Traction Loc) ....................157
Load limits .................................170
GAWR ......................................170
GVWR ......................................170
trailer towing ..........................170
Loading instructions .................172
Lubricant specifications ...275±276
Lumbar support, seats .............106
M
Manual transmission .................162
fluid capacities ........................272
lubricant specifications ..........276
reverse .....................................164
Index
283
