to inflate in side-impact collisions, not roll-over, rear-impact, frontal or
near-frontal collisions, unless the collision causes sufficient lateral
deceleration.WARNING: Several airbag system components get hot after
inflation. Do not touch them after inflation.
WARNING: If the side airbag
has deployed, the airbag will
not function again. The side
airbag system (including the
seat) must be inspected and
serviced by an authorized
dealer. If the airbag is not
replaced, the unrepaired area
will increase the risk of injury
in a collision.
Determining if the system is operational
The SRS uses a readiness light in the instrument cluster or a tone to
indicate the condition of the system. Refer to the Airbag readiness
section in the Instrument Cluster chapter. Routine maintenance of the
side airbag is not required.
A difficulty with the system is indicated by one or more of the following:
• The readiness light (same light as for front airbag system) will either
flash or stay lit.
• The readiness light will not illuminate immediately after ignition is
turned on.
• A series of five beeps will be heard. The tone pattern will repeat
periodically until the problem and/or light are repaired.
If any of these things happen, even intermittently, have the SRS serviced
at your authorized dealer immediately. Unless serviced, the system may
not function properly in the event of a collision.
Side-curtain airbag system (if equipped)
You can determine if you have a vehicle with a side-curtain airbag system
by looking near the top of the trim between the windows and see an
“SRS” label on the main pillars between the windows.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
131

WARNING: Do not place
objects or mount equipment on
or near the headliner at the
siderail that may come into
contact with a deploying
side-curtain airbags (if
equipped). Failure to follow
these instructions may
increase the risk of personal
injury in the event of a
collision.
WARNING: Do not lean your head on the door or window glass.
The side-curtain airbags (if equipped) could injure you as it
deploys from the headliner.
WARNING: Do not attempt to service, repair, or modify the
side-curtain airbags (if equipped), fuses, the A, B, or C pillar
trim, or the headliner on a vehicle containing side-curtain
airbags. See your authorized Mazda dealer.
WARNING: All occupants of the vehicle including the driver
should always wear their seat belts even when an airbag SRS
and side-curtain airbags (if equipped) are provided.
WARNING: To reduce risk of injury, do not obstruct or place
objects in the deployment path of the inflatable side-curtain
airbags (if equipped).
2008 Tribute Hybrid(thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
132

How do the side-curtain airbags (if equipped) work?
The design and development of the
side air curtain system included
recommended testing procedures
that were developed by a group of
automotive safety experts known as
the Side Airbag Technical Working
Group. These recommended testing
procedures help reduce the risk of
injuries related to the deployment of
side airbags (including side air
curtain systems).
The side-curtain airbags (if
equipped) consists of the following:
•An inflatable nylon curtain with a
gas generator concealed behind
the headliner and above the doors
(one on each side of vehicle).
• A headliner designed to flex open
above the side doors to allow side-curtain airbag deployment.
• The same warning light, electronic control and diagnostic unit as used
for the front airbags.
• Two crash sensors mounted at lower B-Pillar (one on each side).
• Two crash sensors located at the c-pillar behind the rear doors (one
on each side).
• Rollover sensor in the restraints control module (RCM).
The side-curtain airbags (if equipped), in combination with seat belts,
can help reduce the risk of severe injuries in the event of a significant
side impact collision or rollover event.
Children 12 years old and under should always be properly restrained in
the rear seats. The side-curtain airbags (if equipped) will not interfere
with children restrained using a properly installed child or booster seat
because it is designed to inflate downward from the headliner above the
doors along the side window opening.
The side-curtain airbags (if equipped) are designed to activate when the
vehicle sustains lateral deceleration sufficient to cause the RCM to
initiate side-curtain airbag (if equipped) inflation or when a certain
likelihood of a rollover event is detected by the rollover sensor.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
133

The side-curtain airbags are mounted to roof side-rail sheet metal,
behind the headliner, above the first and second row seats. In certain
lateral collisions or rollover events, the side-curtain airbags will be
activated, regardless of which seats are occupied. In certain rollover
events, the side-curtain airbag (if equipped) on both sides of the vehicle
will be inflated, regardless of which seats are occupied. The side-curtain
airbags (if equipped) are designed to inflate between the side window
area and occupants to further enhance protection provided in side
impact collisions and rollover events.
The fact that the side-curtain airbags (if equipped) did not activate in a
collision does not mean that there is a malfunction with the system.
Rather, it means the forces were not of the type sufficient to cause
activation. The side-curtain airbags (if equipped) are designed to inflate
in certain side impact collisions or rollover events, not in rear impact,
frontal or near-frontal collisions, unless the collision causes sufficient
lateral deceleration or rollover likelihood.WARNING: Several
side-curtain airbag (if
equipped) components get hot
after inflation. Do not touch
them after inflation.
WARNING: If the side-curtain airbags (if equipped) have
deployed, the side-curtain airbags will not function again unless
replaced. The side-curtain airbags (including the A, B and C
pillar trim) must be inspected and serviced by a authorized
dealer in accordance with the vehicle workshop manual. If the
side-curtain airbags are not replaced, the unrepaired area will
increase the risk of injury in a collision.
Determining if the side-curtain airbags are operational
The SRS uses a readiness light in the instrument cluster or a tone to
indicate the condition of the system. Refer to the Airbag readiness
section in the Instrument cluster chapter. Routine maintenance of the
airbag is not required.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
134

A difficulty with the system is indicated by one or more of the following:
•The readiness light (same light as for front airbag system) will either
flash or stay lit.
• The readiness light will not illuminate immediately after ignition is
turned on.
• A series of five beep sounds will be heard. The tone pattern will
repeat periodically until the problem and light are repaired.
If any of these things happen, even intermittently, have the SRS serviced
at your authorized Mazda dealership immediately. Unless serviced, the
system may not function properly in the event of a collision.
Disposal of airbags and airbag equipped vehicles
(including pretensioners)
See your authorized dealer. Airbags MUST BE disposed of by qualified
personnel.
SAFETY RESTRAINTS FOR CHILDREN
See the following sections for directions on how to properly use safety
restraints for children. Also see Airbag supplemental restraint system
(SRS) in this chapter for special instructions about using airbags.
Important child restraint precautions
You are required by law to use safety restraints for children in the U.S.
and Canada. If small children (generally children who are four years old
or younger and who weigh 40 lb. [18 kg] or less) ride in your vehicle, you
must put them in safety seats made especially for children. Many states
require that children use approved booster seats until they are eight
years old. Check your local and state or provincial laws for specific
requirements regarding the safety of children in your vehicle. When
possible, always place children under age 12 in the rear seat of your
vehicle. Accident statistics suggest that children are safer when properly
restrained in the rear seating positions than in the front seating position. WARNING: Never let a passenger hold a child on his or her lap
while the vehicle is moving. The passenger cannot protect the
child from injury in a collision.
Always follow the instructions and warnings that come with any infant or
child restraint you might use.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
135

Children and seat belts
If the child is the proper size, restrain the child in a safety seat. Children
who are too large for child safety seats (as specified by your child safety
seat manufacturer) should always wear seat belts.
Follow all the important safety restraint and airbag precautions that
apply to adult passengers in your vehicle.
If the shoulder belt portion of a combination lap and shoulder belt can
be positioned so it does not cross or rest in front of the child’s face or
neck, the child should wear the lap and shoulder belt. Moving the child
closer to the center of the vehicle may help provide a good shoulder belt
fit.WARNING: Do not leave children, unreliable adults, or pets
unattended in your vehicle.
Child booster seats
Children outgrow a typical convertible or toddler seat when they weigh
40 lb. (18 kg) and are around 4 years of age. Although the lap/shoulder
belt will provide some protection, these children are still too small for
lap/shoulder belts to fit properly, which could increase the risk of serious
injury in a crash.
To improve the fit of both the lap and shoulder belt on children who
have outgrown child safety seats, Mazda Motor Corporation recommends
use of a belt-positioning booster.
Booster seats position a child so that seat belts fit better. They lift the
child up so that the lap belt rests low across the hips and the knees
bend comfortably. Booster seats may also make the shoulder belt fit
better and more comfortably. Try to keep the belt near the middle of the
shoulder.
When children should use booster seats
Children need to use booster seats from the time they outgrow the
toddler seat until they are big enough for the vehicle seat and
lap/shoulder belt to fit properly. Generally this is when they weigh about
80 lb. (36 kg) (about 8 to 12 years old).
Booster seats should be used until you can answer YES to ALL of these
questions:
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
136

•Can the child sit all the way back
against the vehicle seat back with
knees bent comfortably at the
edge of the seat without
slouching?
• Does the lap belt rest low across the hips?
• Is the shoulder belt centered on the shoulder and chest?
• Can the child stay seated like this for the whole trip?
Types of booster seats
There are two types of belt-positioning booster seats:
• Those that are backless.
If your backless booster seat has a
removable shield, remove the
shield and use the lap/shoulder
belt. If a seating position has a
low seat back and no head
restraint, a backless booster seat
may place your child’s head (top
of ear level) above the top of the
seat. In this case, move the
backless booster to another
seating position with a higher seat back and lap/shoulder belts.
• Those with a high back.
If, with a backless booster seat,
you cannot find a seating position
that adequately supports your
child’s head, a high back booster
seat would be a better choice.
Either type can be used at any seating position equipped with
lap/shoulder belts if your child is over 40 lb. (18 kg).
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
137

Children and booster seats vary widely in size and shape. Choose a
booster that keeps the lap belt low and snug across the hips, never up
across the stomach, and lets you adjust the shoulder belt to cross the
chest and rest snugly near the center of the shoulder. The drawings
below compare the ideal fit (center) to a shoulder belt uncomfortably
close to the neck and a shoulder belt that could slip off the shoulder.
If the booster seat slides on the vehicle seat, placing a rubberized mesh
sold as shelf or carpet liner under the booster seat may improve this
condition.
The importance of shoulder belts
Using a booster without a shoulder belt increases the risk of a child’s
head hitting a hard surface in a collision. For this reason, you should
never use a booster seat with a lap belt only. It is best to use a booster
seat with lap/shoulder belts in the back seat- the safest place for children
to ride.WARNING: Move a child to a different seating location if the
shoulder belt does not stay positioned on the shoulder during
use.
WARNING: Follow all instructions provided by the
manufacturer of the booster seat.
WARNING: Never put the shoulder belt under a child’s arm or
behind the back because it eliminates the protection for the
upper part of the body and may increase the risk of injury or
death in a collision.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
138

WARNING: Never use pillows, books, or towels to boost a
child. They can slide around and increase the likelihood of
injury or death in a collision.
SAFETY SEATS FOR CHILDREN
Child and infant or child safety seats
Use a safety seat that is recommended for the size and weight of the
child. Carefully follow all of the manufacturer’s instructions with the
safety seat you put in your vehicle. If you do not install and use the
safety seat properly, the child may be injured in a sudden stop or
collision.
When installing a child safety seat:
• Review and follow the information
presented in the airbag
supplemental restraint system
(SRS) section in this chapter.
• Use the correct seat belt buckle
for that seating position (the
buckle closest to the direction the
tongue is coming from).
• Insert the belt tongue into the
proper buckle until you hear a
snap and feel it latch. Make sure the tongue is securely fastened in the
buckle.
• Keep the buckle release button pointing up and away from the safety
seat, with the tongue between the child seat and the release button,
to prevent accidental unbuckling.
• Place seat back in upright position.
• Put the seat belt in the automatic locking mode. Refer to Automatic
locking mode (passenger side front and outboard rear seating
positions) (if equipped) section in this chapter.
• LATCH lower anchors are recommended for use by children up to
48 lb. (22 kg) in a child restraint. Top tether anchors can be used for
children up to 60 lb. (27 kg) in a child restraint, and to provide upper
torso restraint for children up to 80 lb. (36 kg) using an upper torso
harness and a belt-positioning booster.
Mazda recommends the use of a child safety seat having a top tether
strap. Install the child safety seat in a seating position with LATCH and
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
139

tether anchors. For more information on top tether straps and anchors,
refer toAttaching safety seats with tether straps in this chapter. For
more information of LATCH anchors refer to Attaching safety seats with
LATCH (Lower Anchors and Tethers for Children) attachments in this
chapter.
WARNING: Carefully follow all of the manufacturer’s
instructions included with the safety seat you put in your
vehicle. If you do not install and use the safety seat properly,
the child may be injured in a sudden stop or collision.
WARNING: Rear-facing child seats or infant carriers should
never be placed in front of an active passenger airbag.
Installing child safety seats with combination lap and shoulder
belts
The rear seat head restraints must be removed when using a child
seat. WARNING: Airbags can kill or injure a child in a child seat.
NEVER place a rear-facing child seat in front of an active air
bag. If you must use a forward-facing child seat in the front
seat, move the seat all the way back.
1. Position the child safety seat in a seat with a combination lap
and shoulder belt.
WARNING: Children 12 and under should be properly
restrained in the rear seat whenever possible.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
140
