Page 36 of 256
TURN SIGNAL CONTROL
•Push down to activate the left
turn signal.
• Push up to activate the right turn
signal.
COURTESY/READING LAMPS (IF EQUIPPED)
The courtesy lamp lights when:
• any door is opened.
• the instrument panel dimmer
switch is held up until the
courtesy lamps come on.
• the remote entry controls are
pressed and the ignition is OFF.
The reading lamps can be turned on by moving the switch on the dome
lamp to either the left or the right.
BULBS
Replacing exterior bulbs
Check the operation of all the bulbs frequently.
Using the right bulbs
Replacement bulbs are specified in the chart below. Headlamp bulbs
must be marked with an authorized “D.O.T.” for North America to assure
lamp performance, light brightness and pattern and safe visibility.
NOTE: The correct bulbs will not damage the lamp assembly or void the
lamp assembly warranty and will provide quality bulb burn time.
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Lights
36
Page 55 of 256
KEYS
The key operates all locks on your vehicle. In case of loss, replacement
keys are available from your dealer.
You should always carry a second key with you in a safe place in case
you require it in an emergency.
Refer toSecuriLock Passive Anti-Theft System for more information.
POWER DOOR LOCKS (IF EQUIPPED)
Press the top of the control to
unlock all doors and the bottom to
lock all doors.
REMOTE ENTRY SYSTEM (IF EQUIPPED)
The remote entry system allows you to lock or unlock all vehicle doors
without a key.
The remote entry features only operate with the ignition in the LOCK
position.
If there is any potential remote keyless entry problem with your vehicle,
ensure ALL remote entry transmitters are brought to the dealership,
to aid in troubleshooting.
GENERAL INFORMATION: This device complies with part 15 of the FCC
rules and with RS-210 of Industry Canada. Operation is subject to the
following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation. Changes or
modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC rules and with RS-210 of
Industry Canada. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may
cause undesired operation.
UNLOCK
LOCK
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Locks and Security
Locks and Security
55
Page 57 of 256
Power door lock disabled
The UNLOCK feature on your power
door locks will not work from inside
the vehicle when:
•the ignition has been turned to the OFF position, and
• 20 seconds elapse after all vehicle doors are closed and locked using
the remote entry transmitter, or the power door lock control (while
the accompanying door is open).
The UNLOCK feature will work again after:
• a door has become ajar,
• the ignition is turned to the ON position, or
• using the UNLOCK
control on your remote entry transmitter.
Sounding a personal alarm
Press
to activate the alarm. The horn will sound for a maximum of
30 seconds and the parklamps will flash for a maximum of 3 minutes.
Press again or turn the ignition to ON to deactivate, or wait for the alarm
to timeout in 3 minutes.
Note: The personal alarm will only operate when the ignition is in the
OFF or ACC position.
Replacing the battery
The remote entry transmitter uses one coin type three-volt lithium
battery CR2032 or equivalent. The typical operating range for your
remote entry transmitter is approximately 10 meters (33 feet). A
decrease in the operating range could be caused by:
• weather conditions,
• nearby radio towers,
• structures around the vehicle and
• other vehicles parked next to the vehicle.
UNLOCK
LOCK
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Locks and Security
57
Page 59 of 256
3. Turn the key from the 2(LOCK) position to 3 (OFF).
4. Cycle eight times rapidly (within 10 seconds) between the 3 (OFF) position and 4 (ON). Note:The eighth turn must end in the 4 (ON)
position. The instrument lights in the cluster will come on for a bulb
check in the 4 (ON) position.
5. The doors will lock, then unlock, to confirm that the programming mode has been activated.
6. Within 20 seconds press any button on the remote entry transmitter. Note: If more than 20 seconds have passed you will need to start
the procedure over again.
7. The doors will lock, then unlock, to confirm that this remote entry transmitter has been programmed.
8. Repeat Step 6 to program each additional remote entry transmitter.
9. Turn the ignition to the 3 (OFF) position after you have finished programming all of the remote entry transmitters.
10. The doors will lock, then unlock, to confirm that the programming mode has been exited.
Illuminated entry
The interior lamps illuminate when the remote entry system is used to
unlock the door(s) or sound the personal alarm.
The illuminated entry system will turn off the interior lights if:
• the ignition switch is turned to the ON position, or
• the remote transmitter lock control is pressed, or
• after 25 seconds of illumination.
The dome lamp control (if equipped) must notbe set to the OFF
position for the illuminated entry system to operate.
3
2
1
5
4
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Locks and Security
59
Page 60 of 256
The inside lights will not turn off if:
•they have been turned on with the dimmer control, or
• any door is open.
The battery saver will shut off the interior lamps 30 minutes after the
last door is closed, even if the dimmer control is on.
SECURILOCK PASSIVE ANTI-THEFT SYSTEM
SecuriLock passive anti-theft system is an engine immobilization
system. This system is designed to prevent the engine from being started
unless a coded key programmed to your vehicle is used.
The SecuriLock passive anti-theft system is not compatible with
non-Mazda aftermarket remote start systems. Use of these systems may
result in vehicle starting problems and a loss of security protection.
Your vehicle comes with two coded keys; additional coded keys may be
purchased from your dealer. The dealer can program your spare keys to
your vehicle or you can program the keys yourself. Refer to
Programming spare keys for instructions on how to program the coded
key.
Note: A maximum of eight keys can be coded to your vehicle.
Note: Large metallic objects, electronic devices that are used to
purchase gasoline or similar items, or a second coded key on the same
key chain may cause vehicle starting issues. You need to prevent these
objects from touching the coded key while starting the engine. These
objects will not cause damage to the coded key, but may cause a
momentary issue if they are too close to the key when starting the
engine. If a problem occurs, turn the ignition off, remove all objects on
the key chain away from the coded key and restart the engine.
Theft indicator
The theft indicator is located in the instrument cluster.
• When the ignition is in the OFF position, the indicator will flash once
every 2 seconds to indicate the SecuriLock system is functioning as
a theft deterrent.
• When the ignition is in the ON position, the indicator will glow for 3
seconds, then turn off to indicate normal system functionality.
If a problem occurs with the SecuriLock system, the indicator will flash
rapidly or glow steadily when the ignition is in the ON position. If this
occurs, the vehicle should be taken to an authorized dealer for service.
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Locks and Security
60
Page 253 of 256
Remote entry system ...........55–56arming and disarming the
anti-theft system ......................57
illuminated entry ......................59
locking/unlocking doors .....55–56
replacement/additional
transmitters ...............................58
replacing the batteries .............57
S
Safety Belt Maintenance ............76
Safety belts (see Safety
restraints) ..................65, 67–68, 70
Safety defects, reporting ..........173
Safety restraints ..............65, 67–70 belt minder ...............................73
extension assembly ..................72
for adults .............................67–68
for children .........................89–90
lap belt ......................................70
safety belt maintenance ...........76
warning light and chime ..........72
Safety restraints - LATCH
anchors ......................................101
Safety restraints - tether
anchors ........................................98
Safety seats for children ............93
Seat belts
(see Safety restraints) ...............65
Seats ............................................63 child safety seats ......................93
SecuriLock passive anti-theft
system ..........................................60
Servicing your vehicle ..............188
Setting the clock AM/FM stereo ...........................18
AM/FM stereo CD .....................20 AM/FM stereo tape/CD/MP3 ....23
Premium AM/FM stereo
CD6/MP3 ...................................26
Snowplowing .................................7
Spare tire (see Changing the
Tire) ...................................149–150
Spark plugs, specifications .......245
Special notice ambulance conversions ..............7
utility-type vehicles ....................7
Specification chart,
lubricants ...........................243–244
Speed control ..............................49
Starting a flex fuel vehicle .......109
Starting your vehicle .......105–106, 108
jump starting ..........................157
Steering wheel tilting .........................................44
Stereo Single CD ..................................19
T
Tether anchors ............................98
Tilt steering wheel ......................44
Tires ...........................149, 227–228 changing ..........149–150, 153, 156
snow tires and chains ............239
tire grades ...............................228
treadwear ................................228
Towing .......................................128 recreational towing .................135
trailer towing ..........................128
wrecker ....................................162
Traction-lok rear axle ...............113
2004 Mazda B Series (mbs)
Owners Guide (post-2002-fmt)
USA English (fus)
Index
253
