A\bTIVE DRIVING DI\fPLA\.Y
(IF EQUIPPED)
ACTIVE DRIVING DISPLAY
To change the settings/adjustments for the Active Driving Display:
1 \felect the \fettings icon on the Home screen.
2 \felect the AD-Disp \.tab.
3 \felect the desired item to change.
HEIGHT: Adjust the position of the virtual image of
the Active Driving Display up or down.
BRIGHTNESS CONTROL: Method for adjusting
screen brightness (automatically with instrument
cluster illumination or\. manually).
CALIBRATION: Brightness initialization setting
(when selecting automatic adjustment).
BRIGHTNESS: Brightness adjustment (when
selecting manual ad\.justment).
NAVIGATION: On/Off.
ACTIVE DRIVING DISPLA\XY: On/Off.
RESET: Reset to default settings.
NOTE:
•
If the display does not operate, switch the ignition
OFF and then switch it back ON. If it still does not
operate even with the igniti\.on switched ON, have the vehicle inspected at an Authorized
Mazda Dealer.
•
It may be difficult to view the display when wearing sunglasses.
Take off your sunglasses or adjust the luminosity.
•
If the battery has been removed and re-installed or the battery
voltage is low, the adjusted position may deviate.
•
The display may be difficult to view or be temporarily affected by
weather conditions such as \.rain, snow, light, and temperature.
Vehicle Speed Setting using cruise control
Navigation Turn\fBy\fTurn(TBT) direction, distance and lane guidance
Traffic Sign Recognition(TSR) using navigation
55Speed Limit
IF EQUIPPED
Lane Departure Warning
System (LDWS) operation conditions and warnings
Smart Brake Support (SBS) warnings
Vehicle Speed Setting using cruise control
CAUTION:
Always adjust the
display using the
\fettings screen
(AD-Disp tab).
DO NOT try to
adjust the angle
or open/close the
display by hand.
Fingerprints on
the display will
make it difficult to
view and manual
operation could
cause damage.
2940109_18b CX-3 SSG_060817.indd 196/8/17 2:38 PM

20 MAZDAUSA.COM
MAZDA RADAR CRUISE CONTROL (MRCC) SYSTEM
The MRCC system maintains vehicle speed and f\Xollowing distance using a radar sensor
to detect a vehicle ahead. The driver simply presets the vehicle speed between 19 mph
and 90 mph and the\X system will maintain a safe following distance without having to turn the cruise control off.
SETTING THE MRCC:
When the MODE switch is pushed, the
vehicle speed and t\.he distance between
vehicles while in headway control can be
set. The MR\b\b indication is shown in the
Active Driving Display.
NOTE: The radar for the MR\b\b is located
behind the Mazda emblem in the g\.rille.
Keep this area clean to avoid the system
not working properly.
How to set the speed:
1 Adjust the vehicle to the desired speed using the\. accelerator pedal.
2
Push the \fET + or \f\.ET – switch. The set speed and the in\.ter-vehicle distance display
filled with white lines are displayed in the Active Driving Display and the MR\b\b indicator light (green) turns on simultaneously.
MAZDA RADAR \bRUI\fE \bONTROL
(IF EQUIPPED)
OPERATION MODES
MODE DISPLAY
\bonstant \fpeed
Headway \bontrol
MRCC
WARNING:
MR\b\b shuts off
when it reaches the low mph limit.
The vehicle will not brake/stop by itself. \fwitch the
MR\b\b system off
when not in use.
Vehicle ahead
MRCC distance
between vehicles
Active Driving Display
MRCC set
vehicle speed
2940109_18b CX-3 SSG_060817.indd 206/8/17 2:39 PM

m{zd{ c x-3 21
MAZDA RADAR \bRUI\fE \bONTROL
(IF EQUIPPED)
How to set the distance between vehicles:
The distance between vehicles is increased by pushing the
switch and decreased by pushing the switch. The
distance between vehicles can be set to four levels.
Switching to conventional cruise control function: When the MODE switch is pushed while\. the MR\b\b system is turned on, the system is switched to conventional cruise
control function.
NOTE: The MR\b\b may apply the brakes when encountering
a semi truck (tractor trailer). This is normal. \fimp\.ly push the
accelerator pedal to override the system.
CLOSE PROXIMITY WARNING
While traveling in headway control, if your vehicle rapidly closes in
on a vehicle ahead because the other driver applied his or \.her brakes suddenly, a warning sound activates and the BRAKE! warning is
indicated in the display. Always verify the safety of the surrounding area and depress
the brake pedal while keeping a safe distance from the vehicle ahead. Additionally,
always keep a safe distance from the vehicles behind you.
DISTANCES BETWEEN
VEHICLES
(at 50 mph) DISPLAY
Long
(about 164 ft)
Medium (about 131 ft)
Short
(about 98 ft)
Extremely Short
(about 82 ft)
CANCEL/OFF
Distance
control
(Longer /
Shorter )
MODE (ON)
Cruise
control (SET+ /
RESUME/
SET –)
MRCC SET switch
2940109_18b CX-3 SSG_060817.indd 216/8/17 2:39 PM

22 MAZDAUSA.COM
WARNING:
\f\bB\f is only a
supplementary
system to reduce
damage in the event of a
collision; however, the \f\bB\f has limitations. Do
not rely solely on the \f\bB\f. Always keep your eyes
on the road.
\fMART \bITY BRAKE \fUPPORT
(IF EQUIPPED)
SMART CITY BRAKE SUPPORT (SCBS) SYSTEM
Between speeds of 2 mph and 50 mph\X, the SCBS attempts to
minimize damage if a collision is unavoidable. SCBS will alert the
driver of a possible collision when driv\Xen at speeds of 2 to 50 mph. SCBS may be able to stop the vehicle automatically to avoid a
collision with the \Xvehicle ahead when driven at speeds 2 to 18 mph.
Partial list of operating conditions: • Driver alert during vehicle speeds of 2 to 50 mph.
•
Vehicle automatic brake control during vehicle speeds of
2 to 18 mph.
•
\f\bB\f system has not been turned off.
NOTE: It may be possible to avoid a collision if the relative speed between your vehicle and the vehicle ahead is less than 12 mph.
Refer to your Owner’s Manual for a complete list of \f\bB\f operating
conditions and system details.
SAFETY SETTINGS
SCBS can be turned off using Safety Settings in MAZDA CONNECT (p. 10).
Forward Sensing Camera
2940109_18b CX-3 SSG_060817.indd 226/8/17 2:39 PM

m{zd{ c x-3 23
SMART BRAKE SUPPORT (SBS)
At speeds of 10 mph or higher\X, the SBS alerts the driver of a possible collision and attempts to reduce the severity of an imminent collision with the \Xvehicle ahead. SBS operates when the
vehicle is traveling at speeds hi\Xgher than the range of the SMART CITY BRAKE SUPPORT (SCBS).
Partial list of operating conditions: •
During vehicle speeds of 10 mph or higher\..
•
The \fB\f system has not been turned off.
\fB\f system can be turned off using \fafety \fettings in MAZDA \bONNE\bT (p. 10).
Refer to your Owner’s Manual for a complete list of \fB\f operating
conditions and system details.
COLLISION WARNING
If there is the possibility of a collision with a vehicle ahead, the beep sounds continuously and a warning is indicated in the
multi-information display.
Forward Sensing
Camera
Radar sensor
\fMART BRAKE \fUPPORT
(IF EQUIPPED)
WARNING:
\fB\f is only a
supplementary
system to reduce
damage in
the event of a
collision; however,
the \fB\f has
limitations. Do
not rely solely on
the \fB\f. Always
keep your eyes on
the road.
2940109_18b CX-3 SSG_060817.indd 236/8/17 2:39 PM

24 MAZDAUSA.COM
LANE DEPARTURE WARNING \fY\fTEM
(IF EQUIPPED)
LANE DEPARTURE WARNING SYSTEM (LDWS)
The LDWS recognizes the painted lane lines using the Forward Sensing Camera (FSC)
installed on the winds\Xhield.
If the vehicle deviates from its lane at speeds a\.bove 44 mph, the system alerts the driver
using the active driving display, flashing the LDW\f warning light and a warning beep to help the driver stay within the lines.
Forward Sensing Camera
2940109_18b CX-3 SSG_060817.indd 246/8/17 2:39 PM

m{zd{ c x-3 25
NOTE: Any driver vehicle input (e.g., turn signal, steering or
acceleration, hands off, Traction \bontrol \fystem switch off) will
cancel warning and steering assist.
LDW\f can be turned off. Refer to the Owner’s Manual for further information.
Use the LDW\f switch to turn the system ON or OFF.
WARNING:
The LDW\f is not
an automatic
driving system.
• The recognition
ability of the
LDW\f is limited.
• Over-reliance
on the system
could lead to
an accident.
• Always stay
on course using
the steering
wheel and
drive with care.
LANE DEPARTURE WARNING \fY\fTEM
(IF EQUIPPED)
ACTIVE DRIVING DISPLAY CONDITION
The painted road lane lines are not
recognized OR one side is \.recognized OR the vehicle speed is le\.ss than 37 mph.
Both side painted road lane
lines are recognized at vehicle speeds of 37 mph or more.
Warning is triggered when vehicle deviates from its lane (depending on personalization setting).
LDW\f OFF
LDWS switch
2940109_18b CX-3 SSG_060817.indd 256/8/17 2:39 PM

26 MAZDAUSA.COM
Active Driving Display
DI\fTAN\bE RE\bOGNITION \fUPPORT \fY\fTEM
(IF EQUIPPED)
DISTANCE RECOGNITION SUPPORT SYSTEM (DRSS)
The DRSS measures the distance between your vehicle and a vehicle ahead using
a radar sensor (front) while the vehicle speed is 19\X mph or faster and indicates a recommended distance to maintain between the vehicles. Furthermore, if your vehicle
approaches a vehicle ahead more closely than the appropriate distance to maintain between the vehicles, the vehicle ahead indication in the displ\Xay is illuminated in
amber to advise the driver to keep a safe distance from the vehicle ahead.
DISTANCE\fBETWEEN\fVEHICLES GUIDELINES*
DISPLAY Traveling at 25 mph Traveling at 50 mph
About 32 ft or lessAbout 65 ft or less
*The distance between vehicles differs depending on vehicle speed.
Vehicle
ahead
2940109_18b CX-3 SSG_060817.indd 266/8/17 2:39 PM

m{zd{ c x-3 27
TRAFFI\b \fIGN RE\bOGNITION
(IF EQUIPPED)
TRAFFIC SIGN RECOGNITION (TSR) SYSTEM
The TSR system helps prevent the driver from overlooking traffic signs and provides
support for safe driving by displaying traffic signs on the Active Driving Display. TSR
recognizes traffic signs using the \XForward Sensing Camera (FSC) or the navigation
system while driving.
When vehicle speed exceeds the speed lim\.it sign displayed in the Active Driving Display,
the system notifies the driver with an indication in the Active Driving Display and a
warning sound.
The T\fR displays the \fPEED LIMIT
, DO NOT ENTER , and traffic \fTOP signs.
NOTE: The T\fR system is not supported in some countries or regions. For more
information, consult an Authorized Mazda Dealer. The T\fR system operates only if the
navigation system \fD card (Mazda Genuine) is inserted into the \fD card slot. \bonsult an
Authorized Mazda Dealer for details.
SPEED LIMIT SIGN DISPLAYEDSPEED LIMIT SIGN RECOGNIZED
STOP SIGN RECOGNIZED AND DISPLAYED
2940109_18b CX-3 SSG_060817.indd 276/8/17 2:39 PM

28 MAZDAUSA.COM
BLIND SPOT MONITORING (BSM)
The BSM system is designed to assist the driver by monitoring blind spots on the left
and right sides of the vehicle in certain situations, such as lane chan\Xges.
•
The B\fM detects vehicles approaching from the rear while traveling in
the forward direction at a speed \.of 6.3 mph or more and notifies the
driver by turning on the B\fM w\.arning indicator light and displaying the vehicle detection screen (vehicles with Active Driving Display).
•
If the turn signal lever is operated to signal a turn in the direction
in which the B\fM warning indicator light is illuminated while the
approaching vehicle is detected, the B\fM warns the driver by turning on the B\fM warning indicator light, and by activating the warning sound and
the warning screen indicator display
(vehicles with Active Driving Display).
•
The detection area on this system
covers the driving lane\.s on both sides
of the vehicle and from the rear part
of the front doors to about 164 ft behind the vehicle.
• B\fM sensors are located under the
left and right rear bumper areas.
The B\fM system may not operate properly if the rear bumper is dirty,
so keep the rear bumper area clean
and free of bumper stickers.
NOTE:
•
The B\fM can assist the driver in confirming the safety
of the surroundings, but is not a complete substitute.
•
The driver is responsible for ensuring safe lane changes
and other maneuvers.
•
Always pay attention to the direction in which th\.e vehicle
is traveling and the vehicle’s surroundings.
Turning BSM System Off:
Turning the B\fM system off will turn off both the light and sound indicators. To turn the B\fM system off, push the B\fM OFF \.switch on the dash.
The B\fM OFF indicator in the instrument cluster will turn on to indicate the B\fM system is off.
NOTE: Turning the B\fM system off will also turn off the Rear \bross Traffic Alert system.
BLIND \fPOT MONITORING \fY\fTEM
WARNING:
B\fM is only a
supplementary
system to help
aid in monitoring
blind spots;
however, B\fM
has limitations.
The system may
not detect all
vehicles, especially
a motorcycle. Do
not rely solely on
the B\fM. Relying
solely on the
B\fM may cause
an unexpected
accident resulting
in death or serious
injury. Make sure
to look over your
shoulder before
changing lanes.
Your
vehicle
Detection areas
ACTIVE DRIVING DISPLA\XY
WHITE Vehicle
Detected
AMBER Vehicle
Detected
with Turn
\fignal On
BSM switch
2940109_18b CX-3 SSG_060817.indd 286/8/17 2:39 PM
