light MAZDA MODEL CX-5 2019 Owners Manual (in English)

Interior Equipment (View A)
ƒLighting control.....................................................................................................page 4-71
„ Turn and lane-change sig nal..................................................................................page 4-77
… Audio control switches......................................... .................................................page 5-15
† INFO switch.................................................... ................................... page 4-14, 4-30, 4-45
‡ Mazda Radar Cruise Control (MRCC) switches................................................ page 4-147
ˆ Cruise control switche s....................................................................................... page 4-214
‰ Wiper and washer lever......................................... ................................................ page 4-78
Š TCS OFF Switch................................................. ............................................... page 4-106
‹ Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) OFF
switch.................................................................................................................. page 4 -163
ΠParking sensor switch......................................................................................... page 4-235
 360° View Monitor switch..................................................................................page 4-182
Ž Power liftgate switch.......................................... ................................................... page 3-22
 Headlight leveling switch...................................... ................................................page 4-75
 Outside mirror switch.......................................... ..................................................page 3-32
‘ Door-lock switch................................................................................................... page 3-15
’ Power window switches........................................................................................ page 3-37
“ Power window lock switch................................................................................... page 3-37
” Door-lock knob..................................................................................................... page 3-18
Pictorial Index
Interior Overview
1-2The equipment and installatio n position varies by vehicle
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Interior Equipment (View C)
ƒHead restraint........................................................................................................ page 2-2 0
„ Seat belt...................................................... ........................................................... page 2-26
… Bottle holder....................................................................................................... page 5-103
† Overhead lights..................................................................................................... page 5-95
‡ Overhead console................................................................................................page 5-104
ˆ Moonroof switch................................................................................................... page 3-40
‰ Vanity mirror......................................................................................................... page 5-9 4
Š Sunvisor.................................................................................................................page 5-94
‹ Rearview mirror.................................................................................................... page 3-34
ΠVent........................................................... .............................................................. page 5-5
 Shift lever/Selector lever..................................... ........................................ page 4-59, 4-62
Ž Drive selection switch......................................... ................................................ page 4-111
 Commander switch................................................................................................page 5-19
 Electric Parking Brake (EPB) switch............................ ........................................ page 4-94
‘ AUTOHOLD switch................................................ ........................................... page 4-100
’ Cup holder..................................................... ..................................................... page 5-102
“ Front seat................................................................................................................. page 2-5
Pictorial Index
Interior Overview
1-4The equipment and installatio n position varies by vehicle
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Interior Equipment (View D)
ƒSeat belt................................................................................................................. page 2-26
„ Lever............................................................................................................ page 2-15, 2- 19
… Head restraint........................................................................................................ page 2-2 0
† USB power outlet............................................................................................... page 5-101
‡ Child safety locks.................................................................................................. page 3-19
ˆ Armrest box.................................................... .................................................... page 5-104
‰ Seat warmer switches........................................... ................................................. page 2-22
Š Cup holder.......................................................................................................... page 5-102
‹ Rear coat hook................................................. ................................................... page 5-107
ΠRear map lights..................................................................................................... page 5-95
 Door-lock knob................................................. .................................................... page 3-18
Ž Center console.................................................................................................... page 5-104
 External input terminal........................................
.................................................. page 5-16
 Accessory socket............................................... .................................................... page 5-99
‘ Power window switch........................................................................................... page 3-37
’ Bottle holder.................................................. ..................................................... page 5-103
“ Armrest..................................................................................................................page 2-19
” Rear seat...................................................... .......................................................... page 2-15
• ISOFIX lower anchors (Mexico)/LATCH lower anchors (Except Mexic o)......... page 2-51
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-5
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Make sure the lever returns to its original position and the seat is locked in place by
attempting to push it forward and backward.
(Power Seat)
To slide the seat, move the slide lifter switch on the outside of the seat to the front or back
and hold it. Release the switch at the desired position.
Height Adjustment
(Manual Seat)
To adjust the seat height, move the lever up or down.
(Power Seat)
To adjust the seat height, move the slide lifter switch up or down.
Height Adjustment for Front Edge of Seat Bottom (Power Seat)*
To adjust the front height of th e seat bottom, raise or lower the front of the slide lifter
switch.
Seat Recline
(Manual Seat)
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
(Power Seat)
To change the seatback angle, pr ess the front or rear side of the reclining switch. Release the
switch at the de sired position.
Lumbar Support Adjustment*
(Manual Seat)
To increase the seat firmness, move the lever downward. Move th e lever upward to decrease
firmness.
(Power Seat)
To increase the seat firmness, press and hold the front part of the switch to the desired
position, then release it.
Press the rear part of the switch to decrease firmness.
Before making adjustments to the driving position recommended by Mazda
Before making adjustments, move the steering wheel and seat to their default positions.
Essential Safety Equipment
Seats
2-6*Some models.
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

1. With your posture slightly slouched, move the seatback forward to the angle where yourwaist feels slightly cramped.
Manual Seat Power Seat
2. Move the seatback backward to a comfortable seated posture wi thout any feeling of
cramping in your waist.
Manual Seat Power Seat
Adjusting the seat position forward and back (sliding)
Adjust the seat to the position best for operating the accelera tor and brake pedals.
1. Place your left foot on the fo otrest, your right foot between the accelerator and brake
pedals, and position your heel to the position allowing easy sw itching between the
pedals.
Essential Safety Equipment
Seats
2-8
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

2. With your heel set on the floor, set your right foot on the brake pedal and move the seat
forward as far as possible until you feel a slight cramping in your ankle.
Manual Seat Power Seat
3. With your right foot set on th e brake pedal, move the seat back until you no longer feel
cramping in your ankle.
4. With your heel set on the floor, make sure you can move your foot between the brake
pedal and accelerator pedal smoothly.
5. Depress the accelerator pedal completely with your heel set on the floor and make sure that your ankle does not feel over-stretched.
Manual Seat Power Seat
Adjusting the seat height
Adjust the seat height to a position where you have a clear for ward view and you can drive
the vehicle easily.
1. With your back resting against the seatback, raise the seat to the height where you can see the rear edge area of the hood surface from the windshield.
Essential Safety Equipment
Seats
2-9
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

▼Adjusting the Fron
t Passenger's Seat
Power operation
Seat Slide
(Manual Seat)
To move a seat forward or backward, raise the lever and slide t he seat to the desired position
and release the lever.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
(Power Seat)
To slide the seat, move the slide lifter switch on the outside of the seat to the front or back
and hold it. Release the sw itch at the desired position.
Height Adjustment*
(Manual Seat)
To adjust the seat height, move the lever up or down.
(Power Seat)
To adjust the seat height, move the slide lifter switch up or down.
Seat Recline
(Manual Seat)
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
Essential Safety Equipment
Seats
*Some models.2-13
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

▼Rear Seat Recline
WA R N I N G
After adjusting the seatback, make sure
that it is firmly locked and the red
indication is not visible by attempting to
lightly move the seatback forward and
back:
If the red indication is visible, the seatback
is not locked. If the vehicle is driven with the
seatback unlocked, it may move
unexpectedly and the seating posture of
the occupant becomes unstable, resulting
in an accident.

Locked
position
Unlocked
position
Red indicator
CAUTION
When adjusting the seatback, always
support the seatback with your hand. If the
seatback is not supported by your hand, it
will move suddenly and could cause injury.
NOTE
When you adjust the left seatback, the
center seatback moves at the same time.
The left and right seatbacks of the rear seat
can be adjusted separately.
Recline the seatback w ith the lever pulled
up.
▼ Armrest*
The rear armrest in the center of the rear
seatback can be used (no occupant in the
center seat) or placed upright.

WA R N I N G
Never put your hands and fingers around
the moving parts of the seat and armrest:
Putting your hands and fingers around the
moving parts of the seat and armrest is
dangerous as they could get injured.
Essential Safety Equipment
Seats
*Some models.2-19
CX-5_8HE3-EA-18I_Edition1
2018-6-29 13:44:47

Seat Warmer*
The front/rear seats are electrically heated.
The ignition must be switched ON.
Press the seat warmer switch while the
ignition is switched ON to operate the seat
warmer. The indicator lights turn on to
indicate that the seat warmer is operating.
The mode changes as follows each time
the seat warmer switch is pressed.
When using the rear seat warmer, fold the
armrest forward.
Refer to Armrest on page 2-19.
Front
(Manual Climate Control)
OFF
High
Mid
Low
(Fully Automatic Climate Control)
OFF
High Mid
Low
Rear*
OFF
High
Mid
Low
WA R N I N G
Be careful when using the seat warmer:
The heat from the seat warmer may be too
hot for some people, as indicated as
follows, and could cause a
low-temperature burn.
 Infants, small children, elderly people,
and physically challenged people
 People with delicate skin
 People who are excessively fatigued
 People who are intoxicated
 People who have taken sleep-inducing
medicine such as sleeping pills or cold
medicine
Do not use the seat warmer with anything
having high moisture-retention ability such
as a blanket or cushion on the seat:
The seat may be heated excessively and
cause a low-temperature burn.
Do not use the seat warmer even when
taking a short nap in the vehicle:
The seat may be heated excessively and
cause a low-temperature burn.
Essential Safety Equipment
Seat Warmer/Seat Ventilation/Heated Steering Wheel
2-22*Some models.
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47

Do not place heavy objects with sharp
projections on the seat, or insert needles or
pins into it:
This could cause the seat to become
excessively heated and result in injury from
a minor burn.
CAUTION
(Rear)
Before folding a rear seatback, make sure
that the rear seat warmer switch is off. If
a rear seatback is folded while the rear
seat warmer is in operation, it may heat
the seat excessively and damage the seat
surface.
 Do not use organic solvents to clean the
seat. It may damage the seat surface and
the heater.
NOTE
Use the seat warmer when the engine is
running. Leaving the seat warmer on for
long periods with the engine not running
could cause the battery power to be
depleted.
When the engine is stopped while the
seat warmers are operating and then the
ignition is switched ON, the seat
warmers will not turn back on
automatically. To turn the seat warmers
back on, press the switch. In addition,
the seat warmer operation stops
automatically after the seat warmers
have operated for about 90 minutes.
(Vehicles with seat ventilation)
The front seat warmer cannot be used at
the same time as the seat ventilation.
Seat Ventilation*
The seat ventilation uses fans installed in
the seats to draw air around the seat
surface and ventilate them. The ignition
must be switched ON.
Press the seat ventila tion switch while the
ignition is switched ON to operate the seat
ventilation. The indicator lights turn on to
indicate that the seat ventilation is
operating. The mode changes as follows
each time the seat ventilation switch is
pressed.
OFF
High Mid
Low
CAUTION
 Do not use organic solvents to clean the
seat. It may damage the seat surface and
the seat ventilation parts.
 Do not place heavy objects with sharp
projections on the seat, or insert needles
or pins into it.
Essential Safety Equipment
Seat Warmer/Seat Ventilation/Heated St eering Wheel
*Some models.2-23
CX-5_8HE3-EA-18I_Edition1 2018-6-29 13:44:47
