sensor MAZDA MODEL CX-5 SKYACTIV-D 2019 Owner's Manual

WA R N I N G
Always check the area around the power
liftgate before opening/closing it:
Not checking for occupants and objects
around the power liftgate before opening/
closing it is dangerous. The jam-safe
equipment is designed to prevent jamming
in the event an obstruction is in the
liftgate's path. The system may not detect
certain objects obstructing the liftgate
depending on the way they are positioned
and their shape. However, if the jam-safe
function detects an obstruction and moves
the liftgate in the reverse direction, an
occupant in the liftgate's path could be
seriously injured.
CAUTION
Sensors are installed on both ends of the
power liftgate. Be careful not to allow the
sensors to be scratched or damaged by
sharp objects, otherwise the liftgate may
no longer open/close automatically. In
addition, if the sensor is damaged while the
liftgate is closing automatically, the system
will stop.
Sensor
NOTE
The jam-safe equipment does not activate
during easy closure operation when the
power liftgate is between the near-shut
position and fully closed position.
When the power liftgate is moving in the
open/close direction and an obstruction is
detected, the beep sound will be heard and
the liftgate moves in the reverse direction
and stops.
Liftgate easy closure
The Easy Closure system automatically
closes the liftgate completely from the
near-shut position.
This system also operates when the liftgate
is closed manually.
WA R N I N G
When closing a liftgate, always keep hands
and fingers away from the liftgate:
Placing hands or fingers around a liftgate is
dangerous because the liftgate closes
automatically from the near-shut position,
which could cause hands and fingers to be
pinched and injured.
NOTE
ï‚·If the electric liftgate opener is pressed
while the easy closure function is
operating, the liftgate can be opened.
ï‚·If the liftgate is opened/closed
repeatedly in a short period of time, the
easy closure function may not operate.
Wait for about 2 seconds and then try
again.
Before Driving
Doors and Locks
3-26
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Fuel and Engine Exhaust Precautions
â–¼Fuel Requirements (SKYACTIV-G 2.0, SKYACTIV-G 2.5, SKYACTIV-G 2.5T)
Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.

This vehicle will perform best with fuel listed in the table.
Fuel
Octane Rating* (Anti-knock index)
Regular unleaded fuel 87 [(R
M)/2 method] or above (91 RON or above)
U.S. federal law requires that octane ra
tings be posted on gasoline station pumps.
Fuel with a rating lower than 87 octane (91 R ON) will negatively affect the emission control
system performance and could also cause engine knocking and serious engine damage.
CAUTION
USE ONLY UNLEADED FUEL.
Leaded fuel is harmful to the catalytic co nverter and oxygen sensors and will lead to
deterioration of the emission control system and or failures.
 This vehicle can only use oxygenated fuels containing no more than 10 % ethanol by
volume. Damage to the vehicle may occur when ethanol exceeds this recommendation, or
if the gasoline contains any methanol. Stop us ing gasohol of any kind if your vehicle engine
is performing poorly.
 Never add fuel system additive s, otherwise the emission control system could be damaged.
Consult an Authorized Mazda Dealer for details.
Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10 %. Gasoline containing alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".

Vehicle damage and drivability problems resulting from the use of the following may not be
covered by the warranty.
ï‚·Gasohol containing more than 10 % ethanol.
ï‚·Gasoline or gasohol containing methanol.
ï‚·Leaded fuel or leaded gasohol.
Before Driving
Fuel and Emission
3-27
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Reducing glare from headlights
Manual day/night mirror
Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Day/Night lever
Day
Night
Auto-dimming mirror
The auto-dimming mirror automatically
reduces the glare of headlights from
vehicles at the rear when the ignition is
switched ON.

(With Homelink wireless control
system)
(Type A)
Press the OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto -dimming function,
press the ON button (
). The indicator
light will illuminate.
Indicator lightOFF button
ON button

(Type B)
Press the ON/OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto-dimming function,
press the ON/OF F button (
). The
indicator light will illuminate.
Indicator light
ON/OFF button
NOTE
ï‚·Do not use glass cleaner or suspend
objects on or around the light sensor.
Otherwise, light sensor sensitivity will
be affected and may not operate
normally.
(With Homelink wireless control
system)
(Type A)
Light sensor
Before Driving
Mirrors
3-38
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

(Type B)
Light sensor
(Without Homelink wireless control
system)

Light sensor
ï‚·(With Homelink wireless control
system)
For information regarding the 3 buttons
(Type A
,,/Type B , , )
on the auto-dimming mirror.
Refer to HomeLink Wireless Control
System on page 4-87.
ï‚·The auto-dimming function is canceled
when the ignition is switched ON and
the selector lever is in the R position.
Before Driving
Mirrors
3-39
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Drive Selection............................... 4-113Drive Selection
*........................4-113
i-ACTIV AWD............................... 4-115 i-ACTIV AWD Operation
*....... 4-115
Power Steering............................... 4-117 Power Steering..........................4-117
i-ACTIVSENSE............................. 4-118
i-ACTIVSENSE
*...................... 4-118
Adaptive Front Lighting System
(AFS)
*...................................... 4-121
High Beam Control System
(HBC)
*......................................4-122
Blind Spot Monitoring (BSM)
*.........
.................................................. 4-125
Traffic Sign Recognition System
(TSR)
*...................................... 4-130
Distance Recognition Support
System (DRSS)
*....................... 4-136
Rear Cross Traffic Alert (RCTA)
*.....
.................................................. 4-140
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)
*............... 4-144
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)
*.................................. 4-158
Advanced Smart City Brake Support
(Advanced SCBS)
*...................4-169
Smart City Brake Support
(SCBS)
*.................................... 4-172
Smart Brake Support (SBS)
*.... 4-175
360° View Monitor
*................. 4-178
Forward Sensing Camera (FSC)
*......
.................................................. 4-205
Radar Sensor (Front)
*.............. 4-210
Radar Sensors (Rear)
*.............. 4-213
Front Camera/Side Cameras/Rear
Camera
*.................................... 4-215
Cruise Control............................... 4-216 Cruise Control
*.........................4-216
4-2*Some models.
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Tire Pressure Monitoring
System.............................................4-221Tire Pressure Monitoring System
*.....
.................................................. 4-221
Diesel Particulate Filter................ 4-225 Diesel Particulate Filter
(SKYACTIV-D 2.2)..................4-225
Selective Catalytic Reduction (SCR)
System.............................................4-226 Selective Catalytic Reduction (SCR)
System...................................... 4-226
Rear View Monitor....................... 4-229
Rear View Monitor
*................. 4-229
Parking Sensor System................. 4-237 Parking Sensor System
*........... 4-237
*Some models.4-3
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

â–¼Dashboard Illumination
When the lights are turned on with the
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
not dim.
NOTE
ï‚·When the ignition is
switched ON in the
early evening or at dusk, the dashboard
illumination is dimmed for several
seconds until the light sensor detects the
brightness of the surrounding area,
however, the dimming may cancel after
the brightness is detected.
ï‚·When the lights are turned on, the
lights-on indicato r light in the
instrument cluster turns on.
Refer to Headlights on page 4-73.
The brightness of the instrument cluster
and dashboard illuminations can be
adjusted by rotating the knob.
ï‚·The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
ï‚·The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for canceling illumination
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
heard while the instrument cluster is
dimmed with the ignition switched ON. If
the instrument cluster's visibility is
reduced due to glare from surrounding
brightness, cancel the illumination
dimmer.
NOTE
ï‚·When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
ï‚·When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
â–¼Speed Unit Selector
In some countries, you may have to
change the speed units between km/h and
mph.
When pressing the selector knob, the
speed units in the instrument cluster will
change.

Selector knob
When Driving
Instrument Cluster and Display
4-19
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

(SKYACTIV-D 2.2)
If inconsistency in engine performance or
stalling occurs due to low fuel level
conditions, refuel the vehicle as soon as
possible and add at least 10 L (2.7 US gal,
2.2 Imp gal) of fuel.
â–¼Dashboard Illumination
When the lights are turned on with the
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
not dim.
NOTE
ï‚·When the ignition is
switched ON in the
early evening or at dusk, the dashboard
illumination is dimmed for several
seconds until the light sensor detects the
brightness of the surrounding area,
however, the dimming may cancel after
the brightness is detected.
ï‚·When the lights are turned on, the
lights-on indicato r light in the
instrument cluster turns on.
Refer to Headlights on page 4-73.
The brightness of the instrument cluster
and dashboard illuminations can be
adjusted by rotating the knob.
ï‚·The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
ï‚·The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for canceling illumination
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
heard while the instrument cluster is
dimmed with the ignition switched ON. If
the instrument cluster's visibility is
reduced due to glare from surrounding
brightness, cancel the illumination
dimmer.
NOTE
ï‚·The illumination dimmer can be
canceled by pressing the dashboard
illumination knob.
ï‚·When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
ï‚·When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
When Driving
Instrument Cluster and Display
4-35
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

ï‚·The direction of the arrow () indicates
that the fuel-filler lid is on the left side
of the vehicle.
â–¼ Dashboard Illumination
(Without auto-light control)
When the lights are
turned on with the
ignition switched ON, the brightness of
the dashboard illumi nation is dimmed.
(With auto-light control)
When the lights are turned on with the
ignition switched ON, the brightness of
the dashboard illumi nation is dimmed.
However, when the light sensor detects
that the surrounding area is bright such as
when the lights are turned on in the
daytime, the dashboard illumination does
not dim.
NOTE
ï‚·(With auto-lig ht control)
When the ignition is switched ON in the
early evening or at dusk, the dashboard
illumination is dimmed for several
seconds until the light sensor detects the
brightness of the surrounding area,
however, the dimming may cancel after
the brightness is detected.
ï‚·When the lights are turned on, the
lights-on indicator light in the
instrument cluster turns on.
Refer to Headlights on page 4-73.
The brightness of the instrument cluster
and dashboard illuminations can be
adjusted by rotating the knob.
ï‚·The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
ï‚·The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for canceling illumination
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
heard while the instrument cluster is
dimmed with the ignition switched ON. If
the instrument cluster's visibility is
reduced due to glare from surrounding
brightness, cancel the illumination
dimmer.
NOTE
ï‚·When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
ï‚·When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
â–¼Outside Temperature Display
When the ignition is switched ON, the
outside temperature is displayed.

When Driving
Instrument Cluster and Display
4-50
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

Active Driving Display*
Dust-proof sheet
Display
Optical
receiver
WA R N I N G
Always adjust the display brightness and position with the vehicle stopped:
Adjusting the display brightness and position while driving the vehicle is dangerous as doing
so could distract your attention from the road ahead and lead to an accident.
CAUTION
Do not place beverages near the active driving display. If water or other liquids are splashed
on the active driving display, it could cause damage.
 Do not place objects above the active driving display or apply stickers to the dust-proof
sheet/optical receiver as they will cause interference.
 A sensor is integrated to control the display's luminosity. If the optical receiver is covered,
the display's luminosity will lower ma king the display difficult to view.
 Do not allow intense light to hit the optical receiver. Otherwise, it could cause damage.
NOTE
ï‚·Wearing polarized sunglasses will reduce the visi bility of the active driving display due to
the characteristics of the display.
ï‚·If the battery has been removed and re-installed or the battery voltage is low, the adjusted
position may deviate.
ï‚·The display may be difficult to view or temporarily affected by weather conditions such as
rain, snow, light, and temperature.
ï‚·If the audio system is removed, the active driving display cannot be operated.
When Driving
Instrument Cluster and Display
4-58*Some models.
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20
