NOTE
(SKYACTIV-D 2.2)
Inspect the engine oil level
periodically. When inspecting the
engine oil, if the engine oil level is
exceeds the “X” mark on the dipstick,
replace the engine oil. This should be
done by an Authorized Mazda Dealer.
When replacing the engine oil, inspect
the oil level using the oil dipstick and
refill so that the engine oil level is
within the range between MIN and
MAX as shown in the figure.
X Mark
MAX
MIN
Engine Coolant
▼ Inspecting Coolant Level
WA R N I N G
Do not use a match or live flame in the
engine compartment. DO NOT ADD
COOLANT WHEN THE ENGINE IS HOT:
A hot engine is dangerous. If the engine has
been running, parts of the engine
compartment can become very hot. You
could be burned. Carefully inspect the
engine coolant in the coolant reservoir, but
do not open it.
Pull over to a safe location, then switch
the ignition off and make sure the fan is
not running before attempting to work
near the cooling fan:
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if the
engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.
Do not remove either cooling
system cap when the engine and radiator
are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot out
under pressure and cause serious injury.
Maintenance and Care
Owner Maintenance
6-29
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

NOTE
Changing the coolant should be done by
an Authorized Mazda Dealer.
Inspect the antifreeze protection and
coolant level in the coolant reservoir at
least once a year―at the beginning of the
winter season ―and before traveling where
temperatures may drop below freezing.
Inspect the condition and connections of
all cooling system and heater hoses.
Replace any that are swollen or
deteriorated.
The coolant should be at full in the
radiator and between the F and L marks on
the coolant reservoir when the engine is
cool.
SKYACTIV-G 2.0 and SKYACTIV-G
2.5
SKYACTIV-G 2.5T
SKYACTIV-D 2.2
If it is at or near L, add enough coolant to
the coolant reservoir to provide freezing
and corrosion protection and to bring the
level to F.
Securely tighten the coolant reservoir tank
cap after adding coolant.
CAUTION
 Radiator coolant will damage paint.
Rinse it off quickly if spilled.
Maintenance and Care
Owner Maintenance
6-30
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

If the “FL22” mark is shown on or near
the cooling system cap, use of FL-22 is
recommended when replacing engine
coolant. Using engine coolant other than
FL-22 may cause serious damage to the
engine and cooling system.

If the coolant reservoir is empty or new
coolant is required frequently, consult an
Authorized Mazda Dealer.
Brake/Clutch Fluid
▼ Inspecting Brake/Clutch Fluid Level
WA R N I N G
If the brake/clutch fluid level is low, have
the brakes inspected:
A low brake/clutch fluid level is dangerous.
A low level could indicate brake lining wear
or a brake system leak which could cause
the brakes to fail and lead to an accident.
The brakes and clutch draw fluid from the
same reservoir.
Inspect the fluid level in the reservoir
regularly. It should be kept between the
MAX and MIN lines.
The level normally drops with
accumulated distance, a condition
associated with wear of brake and clutch
linings. If it is excessively low, have the
brake/clutch system inspected by an
Authorized Mazda Dealer.
Maintenance and Care
Owner Maintenance
6-31
CX-5_8HH4-EA-19A_Edition1
2018-11-21 10:03:20

Washer Fluid
▼Inspecting Washer Fluid Level
WA R N I N G
Use only windshield washer fluid or plain
water in the reservoir:
Using radiator antifreeze as washer fluid is
dangerous. If sprayed on the windshield, it
will dirty the windshield,
affect your
visibility, and could result in an accident.
Using Washer Fluid Without Anti-freeze
Protection in Cold Weather:
Operating your vehicle in temperatures
below 4 °C (40 °F) using washer fluid
without anti-freeze protection is dangerous
as it could cause impaired windshield
vision and result in an accident. In cold
weather, always use washer fluid with
anti-freeze protection.
NOTE
State or local regulations may restrict the
use of volatile organic compounds
(VOCs), which are commonly used as
anti-freeze agents in washer fluid. A
washer fluid with limited VOC content
should be used only if it provides adequate
freeze resistance for all regions and
climates in which the vehicle will be
operated.
Inspect fluid level in the washer fluid
reservoir; add fluid if necessary.
L F
The top of the float should be between F
and L.

Use plain water if washer fluid is
unavailable.
But use only washer flu id in cold weather
to prevent it from freezing.
NOTE
Front and rear washer fluid is supplied
from the same reservoir.
Maintenance and Care
Owner Maintenance
6-32
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Diesel Exhaust Fluid(DEF)
Diesel Exhaust Fluid (DEF) Handling
CAUTION
If DEF gets in your mouth, wash your
mouth with a large amount of water
immediately and seek medical attention.
If DEF is mistakenly swallowed, drink 1 to
2 cups of water immediately and seek
medical attention.
 If DEF gets in your eyes, rinse them with
running water immediately and seek
medical attention.
 Do not use DEF when 2 years have
elapsed from the production date
indicated on the container or the use
period has expired. If DEF with an expired
use period is used, the Selective Catalytic
Reduction (SCR) System may not operate
normally.
 Do not store DEF in the vehicle. DEF may
deteriorate or the interior may be
damaged due to fluid leakage from the
container.
 If DEF gets on the painted surface or the
interior, wash it off with water or wipe it
off with a wet cloth immediately.
Otherwise, it may damage the painted
surface or the interior.
 If DEF crystals form on the painted
surface or the interior, wipe them
off with
a wet cloth. Otherwise, it may damage
the painted surface or the interior.
 Store DEF in a place out of the reach of
children.
Do not put DEF into a
different container.
There may be foreign matter in the
container. If DEF containing foreign
matter is used, it could cause a problem
with the SCR system. In addition,
changing containers is dangerous
because it increases the risk of accidental
ingestion.
NOTE
DEF is a colorless, transparent,
odorless, and nonpoisonous solution
(urea: 32.5 %, aqueous solution
(AUS32)).
Store DEF in a cool, dark place.
DEF freezes at –11 °C (12 °F), however,
when the temperature increases, the
DEF returns to its original condition.
When opening the container, there may
be a smell of ammonia. Open the
container in a well-ventilated area.
If DEF gets on your hands, wash them
with running water immediately.
▼ Diesel Exhaust Fluid (DEF)
Replenishment
CAUTION

Use a Mazda genuine product or a
product conforming to ISO22241-1 for
DEF. If incompatible DEF is used, the
Selective Catalytic Reduction (SCR)
system may not operate normally. For
the recommended DEF, consult the
nearest Authorized Mazda Dealer.
 Do not dilute DEF with water. If diluted
DEF is used, it could cause a problem
with the SCR system or damage it.
Maintenance and Care
Owner Maintenance
6-33
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Do not add any
fluid other than DEF to
the urea tank. If any fluid other than DEF
is added, it could cause a problem with
the SCR system or damage it. Do not
switch the ignition ON, and contact an
Authorized Mazda Dealer.
 When adding DEF, use a bottle with an
anti-spill nozzle. If a bottle without an
anti-spill nozzle or a commercial
dispenser at a gasoline station is used, it
could cause leakage or the DEF to spray
out.
 Do not overfill the DEF. If the DEF is
overfilled, it may freeze during cold
temperatures (–11°C (12 °F) or less).
When urea freezes, it expands and could
cause tank breakage. Always use a bottle
with an auto-stop function and stop
adding fluid when the auto-stop
function operates.
NOTE
When adding DEF during low
temperatures (–11 °C (12 °F) or less),
move the vehicle to a warm location. If
the DEF starts to freeze, it may not flow
correctly and the correct amount may
not have been added. In addition, if the
fluid freezes in the urea tank, you may
not be able to tell if the correct amount
of fluid was added.
Replenishment of DEF by an Authorized
Mazda Dealer is recommended. If you
want to replenish the DEF yourself,
follow the replenishment procedure
below.

Replenishment Procedure
1. Check the remaining amount of Diesel Exhaust Fluid (DEF) on the
multi-information display.
(Instrument cluster (Type A))
Refer to Remaining Diesel Exhaust
Fluid (DEF) and Maximum Driving
Distance Display (SKYACTIV-D 2.2)
on page 4-21.
(Instrument cluster (Type B))
Refer to Remaining Diesel Exhaust
Fluid (DEF) and Maximum Driving
Distance Display (SKYACTIV-D 2.2)
on page 4-37.
3.8 L (1.0 US gal, 0.84 Imp gal) of
DEF or more needs to be added.
NOTE
The replenishment amount (reference)
according to the DEF level (%)
indication is as follows:
Percentage (%) indica-tion for remaining amount Reference replenish-
ment amount
*1
100 — 85 Replenishment unneces-
sary
80 — 60 About 3.8 L (1.0 US gal,
0.84 Imp gal)
55 — 40 About 5.7 L (1.5 US gal,
1.3 Imp gal)
35 — 20 About 7.6 L (2.0 US gal,
1.7 Imp gal)
15 — 0 About 9.5 L (2.5 US gal,
2.1 Imp gal)
*1 Even if DEF is added at theindicated replenishment amount,
100 % may not be indicated on the
display.

2. Stop the vehicle on level ground.
3. Switch the ignition OFF.
Maintenance and Care
Owner Maintenance
6-34
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

4. Open the fuel-filler lid.Refer to Refueling on page 3-33.
5. Open the cap of the DEF filler port.

Open Close
6. Remove the cap of a bottle containing
DEF, insert the bot tle into the DEF
filler port, and screw it in lightly until
it stops.

CAUTION
If too much DEF is added, the SCR
system might display a warning.
Contact an Authorized Mazda Dealer if
a warning is displayed. If the warning
remains displayed, the urea tank may
have a problem or it may be damaged.
NOTE
If excessive force is applied when
pressing in the bottom of the bottle,
the bottle or the DEF filler port may
be damaged.
When the urea tank is full, stop
adding DEF because the flow from
the bottle slows down by the bottle's
auto-stop function. If you continue
adding DEF, the urea tank will
overfill.
7. Press in the bottom of the bottle straight and add DEF.

Push to add
Release to stop
8. Remove the bottle in the reverse order
of the insertion. At this time, be careful
of DEF dripping from the bottle.
9. Tighten the cap of the DEF filler port
until you hear two or more click
sounds.
10. Switch the ign ition ON once.
11. Check the following while the vehicle is stopped.
No DEF level warning indication is
displayed on the multi-information
display.
Maintenance and Care
Owner Maintenance
6-35
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

The DEF level (%) indication on the
multi-information display shows an
increase.
(Instrument cluster (Type A))
Refer to Remaining Diesel Exhaust
Fluid (DEF) and Maximum Driving
Distance Display (SKYACTIV-D
2.2) on page 4-21.
(Instrument cluster (Type B))
Refer to Remaining Diesel Exhaust
Fluid (DEF) and Maximum Driving
Distance Display (SKYACTIV-D
2.2) on page 4-37.
12. Switch the ignition OFF.
If the above indications remain
unchanged even after one minute has
passed with the vehicle stopped:
If you have already added 3.8 L (1.0 US
gal, 0.84 Imp gal) of DEF according to
the DEF level (%) indication on the
multi-information display, prepare an
additional 3.8 L (1.0 US gal, 0.84 Imp
gal) of DEF or more and add it
following the replenishment procedure.
If you added the correct amount of DEF,
the DEF level (%) indication on the
multi-information display will show an
increase while the vehicle is being
driven. If the DEF level (%) shows no
increase or the speed restriction does not
cancel even while driving the vehicle,
consult an Authorized Mazda Dealer.
Body Lubrication
All moving points of the body, such as
door and hood hinges and locks, should be
lubricated each time the engine oil is
changed. Use a nonfreezing lubricant on
locks during cold weather.

Make sure the hood's secondary latch
keeps the hood from opening when the
primary latch is released.
Maintenance and Care
Owner Maintenance
6-36
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

Wiper Blades
CAUTION
Hot waxes applied by automatic car
washers have been known to
affect the
wiper's ability to clean windows.
 To prevent damage to the wiper blades,
do not use gasoline, kerosene, paint
thinner, or other solvents on or near
them.
 When the wiper lever is in the AUTO
position and the ignition is switched ON,
the wipers may move automatically in
the following cases:
 If the windshield above the rain sensor
is touched.
 If the windshield above the rain sensor
is wiped with a cloth.
 If the windshield is struck with a hand
or other object.
 If the rain sensor is struck with a hand
or other object from inside the vehicle.
Be careful not to pinch hands or fingers
as it may cause injury, or damage the
wipers. When washing or servicing the
vehicle, make sure the wiper lever is in
the OFF position.
Contamination of eith er the windshield or
the blades with foreign matter can reduce
wiper effectiveness. Common sources are
insects, tree sap, and hot wax treatments
used by some commercial car washes.

If the blades are not wiping properly, clean
the window and blades with a good
cleaner or mild de tergent; then rinse
thoroughly with clean water. Repeat if
necessary.
▼ Replacing Windshield Wiper Blades
When the wipers no longer clean well, the
blades are probably worn or cracked.
Replace them.
CAUTION

To prevent damage to the wiper arms
and other components, do not try to
sweep the wiper arm by hand.
 Do not bend the blade rubber
unnecessarily when replacing it.
Otherwise, the metal stiffener in the
blade may deform and the windshield
wiper operation may be adversely
affected.
NOTE
When raising both windshield wiper arms,
raise the driver's side wiper arm first.
When lowering the wiper arms, slowly
lower the wiper arm from the passenger's
side first while supporting it with your
hand. Forcefully lowering the wiper arms
could damage the wiper arm and blade,
and may scratch or crack the windshield.
1. Raise the wiper arm.
CAUTION
To prevent damage to the windshield
let the wiper arm down easily, do not
let it slap down on the windshield.
Maintenance and Care
Owner Maintenance
6-37
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20

2. Slide the blade component in thedirection of the arrow while pressing
the wiper arm tab to remove the blade
component from the wiper arm.

3. Pull the blade rubber in the direction ofthe arrow and slide it to a position
where the blade holder groove can be
checked.

Groove
4. Pull the end of the blade rubber fromthe blade holder groove in the direction
of the arrow and remove the blade
rubber from the blade holder.

Groove
Maintenance and Care
Owner Maintenance
6-38
CX-5_8HH4-EA-19A_Edition1 2018-11-21 10:03:20
