MAZDA MODEL CX-7 2012 Navigation Manual (in English)

11
Getting Started
Activation
The following operation procedure is for activating the navigation system.
Note
While on the Map screen, Press the Enter switch up or down to change the map scale.
Activating the Navigation System
1
With the ignition switched to ACC or ON, press the Navi switch on the steering
switch.
2
After a moment, the CAUTION screen is displayed.
*1 :Press the Enter switch up or down.
*2 :Press the Enter switch.
●If you are in agreement with the CAUTION
statement, Press the Enter switch up or down to set
the cursor to
*1. Press the
Enter switch to switch to the Map screen*2.
● To change the language, set the cursor to
*1. Press the Enter switch to
switch the screen to LANGUAGE SELECTION*2.
( page 12)
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

12
RoutingAddress
Book
Getting Started
The language can be changed using the Language setting displayed in the upper
part of the screen.
Before activating the navigation system
After activating the navigation system
1. Press the INFO switch to display the SETTINGS screen.
2. Select PREFERENCES and press the Enter switch.
3. Select SELECT LANGUAGE and press the Enter switch.
4. Select the desired language from the list.
■The following feature settings are possible, refer to the “Multi Information
Display” in the owner’s manual.
●
Clock: Constant display of time.
● Ambient Temperature Display: Constant display of ambient temperature.
● Settings: Used to change the multi information display settings. (Distance unit, Display
language)
The map information version can be upgraded. If you require the latest SD card of
the Navigation Map data, consult an Expert Dealer, we recommend an Authorized
Mazda Dealer.
Setting the Language
Select the desired language from the list. Press the
Enter switch to switch the screen to CAUTION.
( page 11)
Setting the Clock, Ambient Temperature Display and Other Settings
Upgrading the Map Information Version
1
With the ignition switched to ACC OFF, insert a finger into the
depression above the lid housing the SD card of the Navigation Map
data (next to the navigation display), and open it.
Outer lid
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

13
Getting Started
Notes
●After inserting the SD card of the Navigation Map data, firmly close all of the lids.
● If the inner lid is not firmly closed, the navigation system will not function.
2
Slide the notch of the inner lid sideways with your finger to open the inner lid.
3
The SD card of the Navigation Map data will be visible. Press in the currently
inserted SD card of the Navigation Map data with a finger. After pressing in the
SD card, it will eject partially. Grab the card with your fingers to pull it out.
4
Insert the new SD card of the Navigation Map data all the way in and
close all the lids.
If this screen is displayed, verify that the inner lid is not open. If this screen is
displayed even though the inner lid is closed, consult an Authorized Mazda Dealer.
●If the inner lid is closed while the SD card of the Navigation Map data is not
inserted all the way, the card could be damaged.
● Do not remove the SD card from the reader while the ignition is switched ON.
This will damage the SD card.
Inner lid
Caution
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

14
RoutingAddress
Book
Getting Started
Menu
The menu is displayed by pressing the Enter switch while the Map screen is
displayed.
Navigation Menu Screen
Set Destination ( page 22)
Find Local POI ( page 32)
Browse Map & Mark ( page 40)
Cancel/Edit Route ( page 34)
Navigation Setup ( page 15)
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

15
Getting Started
Navigation Set Up
●You can alter the map display conditions, the route guidance conditions and show the
system information.
■Stop your vehicle before performing the following operations. Do not change the settings and destination locations while driving. Minimize the time
spent viewing the monitor screen and listening to the voice guidance while driving.
Operating the system will distract the driver from looking ahead of the vehicle and may
cause an accident.
Always stop the vehicle in a safe location and set the parking brake before operating the
system.
Before StepsSelect
Warning
Open the
[Navigation
Setup]
■Auto ZoomThe Auto Zoom function automatically switches the map scale depending
on the distance between the next guidance point and the current position.
Used to switch the Auto Zoom function.
■Map ColorUsed to switch the map mode.
■Map DirectionUsed to switch the map direction.
■Show POI IconsUsed to display the selected POI icons on the Map screen.
■Guidance VolumeUsed to adjust the guidance volume.
Also adjustable using the audio volume knob during
transmission of the voice guidance.
Day: To switch to the daytime screen.
Night: To switch to the nighttime screen.
Auto: The screen switches between
daytime and nighttime displays in
conjunction with the on/off of the
vehicle’s exterior lights.
North Up: Geographic north is up.
Head Up: The direction you are heading is up.
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

16
RoutingAddress
Book
Getting Started
Navigation Set Up
Open the
[Navigation
Setup]
■Arrival TimeThe time which is displayed until reaching the destination or a
way point can be set as an estimated arrival time or the
remaining time.
Select to display the estimated arrival time, or to
display the remaining time.
■Average SpeedSet the average speed for each road to be driven.
(This function sets the standard speed (average vehicle speed
for each route) used for calculating the estimated arrival time
when calculating the route time.)
■Edit Memory PointUsed to edit the memory point or Home setting.( page 36, 38)
■Delete Previous PointUsed to delete the previously set destination.
■Operation GuideUsed to switch the operating guide display.
Operation Guide
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

17
Getting Started
Navigation Set Up
Open the
[Navigation
Setup]
■Auto Complete TextWhen entering text, the system displays possible candidates of
words which may match the one you are trying to input. If the
system narrows down the candidate to one, the word is
automatically displayed.
Used to switch the auto complete text.
■Adjust Current PositionUsed to adjust the vehicle position if it deviates from the Map
screen.
■Restore DefaultsRestores the default settings.
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

18
RoutingAddress
Book
Getting Started
Screen Names and Functions
Screens Before Setting Route
(1) Map Direction
( page 15)
(2) Clock(3) TemperatureDisplays the ambient temperature.
(4) Vehicle marker Shows the current position and
direction of your vehicle. (5) Scale display
Displays the scale of the map.
(6) Current Road Name Shows the name of the road you are
currently driving on.
(7) Operation Guide Displays the operational guidance.
( page 16)
Screens During Route Guidance
(1) The traveled distance to the destination and the estimated arrival
time/remaining travel time
Displays the remaining time to the
destination.
Estimated arrival time to the destination
or the estimated remaining driving time
can be displayed by selecting either of
them. ( page 16) (2) Route display
Shows the provided route as a thick
blue line.
(3) Turn Arrow display
Shows the direction to turn at the next
junction and the distance to the junction.
(4) Next Guided Street Name display
(4)
(2)
(6)
(3)(5)
(1)(7)
(3)(1)
(2)
(4)
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

19
Getting Started
The screen map can be scaled to 14 different sizes.
■Brightness/Contrast
Brightness and contrast of the navigation screen can be adjusted.
1. Press the INFO switch to display the SETTINGS screen.
2. Select PREFERENCES and press the Enter switch.
3. Select SCREEN ADJUSTMENT and press the Enter switch.
4. Select BRIGHTNESS/CONTRAST and press the Enter switch.
5. Select BRIGHTNESS or CONTRAST using the left or right switch.
6. Adjust the tone by pressing the Enter switch up or down.
7. After setting, press the Enter switch to finish the setting.
■Daytime/Night screen
When the headlights are on, daytime mode can also be selected (if a brighter screen is
needed at night). This selection can only be done when the headlights are on.
● The screen can be returned to the daytime screen while the headlights or running lights are
on by pushing the dashboard illumination knob. You will hear a beep sound and the
illumination dimmer will be canceled. With each press of the dashboard illumination knob,
the dashboard illumination will change from dim to full bright and back to dim again.
Adjusting the Map Scale
Press the Enter switch up or down while the Map screen is displayed to
zoom in or out of the Map screen.
Screen Adjustments
Scale bar
0#8687''DQQMMo+9Þ9Ü9Ý9Ý9å¬9Ý9äã“ã

20
RoutingAddress
Book
Getting Started
Character Entry
Street
Name, City
Name, and
Other
Input
Select the first several
characters on the
screen. (Step 1) Select your target
in the list.
(Step 2)
1.Press the Enter switch up or
down, select the letter, and press
the Enter switch. Pressing the
Enter switch with the cursor set
to Del erases one letter.
2.Set the cursor to Done and press the Enter switch. The Area
names, Point names, City
names, or Street names which
include the letters currently input
are displayed. ●
If a desired name is not in the
list, go back to Step 1, and try
fewer characters.
: The input character can be deleted.
: The list appears. : You can change the type of text.
●Examples
Street: CANAL Street: 52ND
Enter by selecting characters: Enter by selecting characters:
The name list including the
input spelling is displayed.
Street: MAIN STREET
Enter by selecting characters:
CA 5 2
MA
