MAZDA MODEL CX-9 2019 Owners Manual (in English)

SignalWarning Page
Seat Belt Warning Light (Front seat) 7-37
*Seat Belt Warning Light (Rear seat)7-37
*Low Washer Fluid Level Warning Indication7-37
Door-Ajar Warning Indication
7-37
Liftgate-Ajar Warning Indication7-37
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If t he light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is appl ied.
▼Indication/Indicator Lights
These lights turn on or flash to
notify the user of the system operation status or a system
malfunction.
Signal Indicator Page
(Green)
*Seat Belt Indicator Light (Rear seat) 2-32
*Front Passenger Air Bag Deactivation Indicator Light*12-78
Security Indicator Light*13-44
Wrench Indication
4-44
(Blue)Low Engine Coolant Temperature Indicator Light 4-44
When Driving
Instrument Cluster and Display
*Some models.4-41
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

SignalIndicator Page
Shift Position Indication 4-61
Lights-On Indication/Indicator Light 4-68
Headlight High-Beam Indicator LightHeadlight
High-Low Beam 4-71
Flashing the Headlights 4-71
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-73
Hazard Warning Flasher4-80
*Mazda Radar Cruise Control with Stop & Go func tion (MRCC with Stop
& Go function) indicator Light*14-143
TCS/DSC Indicator Light*1
Traction Control System (TCS) 4-95
Dynamic Stabil‐ ity Control(DSC)
4-97
Turns on 7-31
TCS OFF Indicator Light*14-96
Select Mode Indication 4-102
(Green)
*High Beam Control System (HBC) Indicator Light4-112
*Blind Spot Monitoring (BSM) OFF Indicator Light*1
Malfunction
7-31
Except malfunc‐ tion
4-119
When Driving
Instrument Cluster and Display
4-42*Some models.
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

SignalIndicator Page
(White)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) Main Indication 4-138
(Green)
*Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function) Set Indication 4-138
*Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Indication 4-150
*Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) OFF Indicator Light*14-154
*Smart City Brake Support (SCBS) Indication Advanced Smart
City Brake Sup‐ port (Advanced SCBS)4-160
Smart City
Brake Support (SCBS)4-163
*Smart Brake Support/Smart City B rake Support (SBS/SCBS) OFF Ind ica‐
tor Light*1
Advanced Smart City Brake Sup‐ port (Advanced
SCBS)4-160
Smart City
Brake Support (SCBS)4-163
Smart Brake
Support (SBS) System4-165
(White)
*Cruise Main Indication 4-204
(Green)
*Cruise Set Indication4-204
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda De aler.
When Driving
Instrument Cluster and Display
*Some models.4-43
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Wrench Indicator Light
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to Maintenance Monitor on page
6-16.
When the engine oil
replacement period
has arrived.
NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit
necessary.
Your Authorized Mazda Dealer will be
able to reset the engine control unit or
see page 6-24 for the Vehicle engine
control unit reset procedure.

▼ Low Engine Coolant Temperature
Indicator Light (Blue)
The light illuminates continuously when
the engine coolant temperature is low and
turns off after th
e engine is warm.
When Driving
Instrument Cluster and Display
4-44
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Instrument Cluster (Type C)

ƒSpeedometer.......................................................................................................... page 4-45
„ Tachometer............................................................................................................ page 4-4 5
… Multi-information Display (Type C)............................. ........................................ page 4-46
† Dashboard Illumination.........................................................................................page 4-49
▼Speedometer
The speedometer indicates the speed of the
vehicle.
▼Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.

STRIPED
ZONE
RED ZONE
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
When Driving
Instrument Cluster and Display
4-45
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

▼Multi-information Display (Type C)
INFO switch
Multi-information Display (Type C)
The multi-information display in
dicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Trip Computer
Cruise Control Display
Compass Display
When Driving
Instrument Cluster and Display
4-46
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Odometer, Trip Meter and Trip
Meter Selector
The display mode can be changed from
odometer to trip meter A to trip meter B
and then back to odometer by pressing the
selector while one of them is displayed.
The selected mode will be displayed.

Selector knob
Press the selector knob Press the selector knob
Press the selector knob
Odometer
Trip meter A
Trip meter B

Odometer
The odometer records the total distance
the vehicle has been driven.
Trip meter
The trip meter can record the total distance
of two trips. One is re
corded in trip meter
A, and the other is recorded in trip meter
B.

For instance, trip me ter A can record the
distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.

When trip meter A is selected, pressing the
selector again within 1 second will change
to trip meter B mode.

When trip meter A is selected, TRIP A
will be displayed. When trip meter B is
selected, TRIP B will be displayed.

The trip meter records the total distance
the vehicle is driven until the meter is
again reset. Return it to “0.0” by
depressing and holding the selector for 1
second or more. Use this meter to measure
trip distances and to compute fuel
consumption.
NOTE
If TRIP A is reset using the trip meter
when the function which synchronizes
(resets) the fuel economy monitor and
the trip meter (TRIP A) is on, the fuel
economy data resets in conjunction with
TRIP A.
Refer to Fuel Economy Monitor on page
4-99.
Only the trip meters record tenths of
kilometers (miles).
The trip record will be erased when:
The power supply is interrupted
(blown fuse or the battery is
disconnected).
The vehicle is driven over 9999.9 km
(mile).
When Driving
Instrument Cluster and Display
4-47
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Engine Coolant Temperature Gauge
Displays the engine coolant temperature.
The white gauge indicates that the engine
coolant temperature is low, and the red
gauge indicates that the engine coolant
temperature is high and overheating.

CAUTION
If the engine coolant temperature gauge
needle (white)
flashes, there is a possibility
of overheating. Drive slowly to reduce
engine load until you can find a safe place
to stop the vehicle and wait for the engine
to cool down.
Refer to Overheating on page 7-23.
NOTE
If the engine coolant temperature is high
or the engine is hot, the engine output
may be limited.
The temperature unit (Centigrade/
Fahrenheit) of the engine coolant gauge
display changes in conjunction with the
temperature unit of the outside
temperature display.
Refer to Personalization Features on
page 9-10.
During normal driving, the engine
coolant temperature stabilizes at 100 °C
(210 °F) or less, and the gauge indicates
a range lower than 100 °C (210 °F).
▼ Fuel Gauge
The fuel gauge shows approximately how
much fuel is remaining in the tank when
the ignition is switched ON. We
recommend keeping the tank over 1/4 full.

Full
1/4 Full
Empty
If the low fuel w
arning light illuminates or
the fuel level is very low, refuel as soon as
possible.
Refer to Taking Action on page 7-37.
NOTE
After refueling, it may require some time
for the indicator to st abilize. In addition,
the indicator may deviate while driving
on a slope or curve since the fuel moves
in the tank.
The display indicating a quarter or less
remaining fuel has more segments to
show the remaining fu el level in greater
detail.
When Driving
Instrument Cluster and Display
4-48
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

The direction of the arrow () indicates
that the fuel-filler lid is on the left side
of the vehicle.
▼ Dashboard Illumination
When the lights are turned on with the
ignition switched ON, the brightness of
the dashboard illumination is dimmed.
NOTE
When the lights are turned on, the
lights-on indicato
r light in the
instrument cluster turns on.
Refer to Headlights on page 4-68.
The brightness of the instrument cluster
and dashboard illuminations can be
adjusted by rotating the knob.
The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for canceling illumination
dimmer
The illumination dimmer can be canceled
by rotating the dashboard illumination
knob to the right until a beep sound is
heard while the instrument cluster is
dimmed with the ignition switched ON. If
the instrument clust er's visibility is
reduced due to glare from surrounding
brightness, cancel the illumination
dimmer.
NOTE
When the illumination dimmer is
canceled, the instrument cluster cannot
be dimmed even if the lights are turned
on.
When the illumination dimmer is
canceled, the screen in the center
display switches to constant display of
the daytime screen.
▼ Outside Tempera
ture Display
When the ignition is switched ON, the
outside temperature is displayed.

NOTE
Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and
vehicle conditions:
Significantly cold or hot temperatures.
Sudden changes in outside
temperature.
The vehicle is parked.
The vehicle is driven at low speeds.
When Driving
Instrument Cluster and Display
4-49
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Changing the Temperature Unit of the
Outside Temperature Display
The outside temperature unit can be
switched between Celsius and Fahrenheit.
Settings can be changed by operating the
center display screen.
Refer to Personalization Features on page
9-10.
NOTE
When the temperature unit indicated in the
outside temperature display is changed,
the temperature unit indicated in the
engine coolant gauge display changes in
conjunction with it.
▼ Tr i p C o m p u t e r
The following inform
ation can be selected
by pressing the INFO switch with the
ignition switched ON.
Distance-to-empty mode
Average fuel economy mode
Current fuel economy mode
Compass mode
If you have any problems with your trip
computer, consult an Authorized Mazda
Dealer.
Distance-to-empty mode
This mode displays the approximate
distance you can travel on the remaining
fuel based on the fuel economy.

The distance-to-empty will be calculated
and displayed every second.

NOTE
Even though the distance-to-empty
display may indicate a sufficient amount
of remaining driving distance before
refueling is required, refuel as soon as
possible if the fuel level is very low or
the low fuel warning light illuminates.
The display may not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
(indicating the remaining fuel supply)
disappear.
If there is no past fuel economy
information such as after first
purchasing your vehicle or the
information is deleted when the battery
cables are disconnected, the actual
distance-to empty/range may differ from
the amount indicated.
Average fuel economy mode
This mode displays the average fuel
economy by calculating the total traveled
distance and the total fuel consumption
since the vehicle was purchased or the past
data was reset. The average fuel economy
is calculated and displayed every minute.

To reset the displayed past data, press the
INFO switch for 1.5 seconds or longer.
After resetting the data, - - - L/100 km
(- - - mpg) is displa yed for one minute
before the fuel economy is recalculated
and displayed.
When Driving
Instrument Cluster and Display
4-50
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27
