MAZDA MODEL CX-9 2019 Owners Manual (in English)

▼Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS) Display
Displays the system status.

Refer to Lane-keep A
ssist System (LAS)
& Lane Departure Warning System
(LDWS) on page 4-147.
▼ Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) Display
*
Displays the currently set system status.

Refer to Mazda Radar
Cruise Control with
Stop & Go function (MRCC with Stop &
Go function) on page 4-134.
▼ Distance Recogn
ition Support
System (DRSS) Display*
Displays the distance between your
vehicle and the vehicle ahead.

Refer to Distance Recognition Support
System (DRSS) on page 4-126.
▼ Cruise Control Set Vehicle Speed
Display*
The vehicle speed preset using the cruise
control is displayed.

Refer to Cruise Control on page 4-203.
▼Compass Display
The direction the vehicle is moving is
displayed in one of eight directions while
the vehicle is being driven.

When Driving
Instrument Cluster and Display
*Some models.4-21
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

DisplayDirection
NN orth
SS outh
EE ast
WW est
NE Northeast
NW Northwest
SE Southeast
SW Southwest
▼Warning (Display Indication)
A message is displayed to notify the user
of the system operation status and
malfunctions or abnormalities.
If the warning ligh
t turns on/flashes
simultaneously or a symbol is indicated in
the display, check the information
regarding the warning light or symbol.
Refer to If a Warnin g Light Turns On or
Flashes on page 7-28.
For messages not indicating a symbol,
follow the instructions indicated in the
multi-information display.
Refer to Message Indicated in
Multi-information Disp lay on page 7-45.
When Driving
Instrument Cluster and Display
4-22
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

▼Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications
.
Center of Dashboard
Warning lights will appear in any of the highlighted areas
Instrument Cluster
▼
Warning Indication/Warning Lights
These lights turn on or flash to
notify the user of the system operation status or a system
malfunction.
Signal Warning Page
Brake System Warning Indication/Warning Light*1*27-28
ABS Warning Light*1
Electronic Brake
Force Distribu‐ tion SystemWa r n i n g 7-28
ABS warning 7-31
Charging System Warning Indication/Warning Light*17-28
Engine Oil Warning Light*17-28
High Engine Coolant Temperature Warning Indication 7-28
Power Steering Malfunction Indication 7-28
Master Warning Indication7-31
When Driving
Instrument Cluster and Display
4-23
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

SignalWarning Page
Electric Parking Brake (EPB) Warning Indication/Warning Light*17-31
Check Engine Light*17-31
Automatic Transaxle Warning Indication 7-31
*AWD Warning Indication7-31
Air Bag/Front Seat Belt Preten
sioner System Warning Light*17-31
*Tire Pressure Monitoring System Warning Light*1
Flashing
7-31
Turns on 7-37
(Amber/White) KEY Warning Indication Amber
7-31
White 7-37
(Amber) High Beam Control System (HBC) Warning Indication/Warning Light
*17-31
Blind Spot Monitoring (BSM) Warning Indication
7-31
(Amber)
*Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop
& Go function) Warning Indication 7-31
(Amber)Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Warning Indication
7-31
LED Headlight Warning Light*17-31
*Smart Brake Support/Smart City B
rake Support (SBS/SCBS) Warning In‐
dication 7-37
Low Fuel Warning Indication/Warning Light
7-37
Check Fuel Cap Warning Indication/Warning Light*17-37
Engine Oil Level Warning Light*17-37
Seat Belt Warning Light (Front seat)7-37
When Driving
Instrument Cluster and Display
4-24*Some models.
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

SignalWarning Page
(Red)
*Seat Belt Warning Light (Rear seat) 7-37
*Low Washer Fluid Level Warning Indication
7-37
Door-Ajar Warning Indication
7-37
Liftgate-Ajar Warning Indication 7-37
Door-Ajar Warning Light7-37
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If t he light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is appl ied.
▼Indication/Indicator Lights
These lights turn on or flash to
notify the user of the system operation status or a system
malfunction.
Signal Indicator Page
(Green)
*Seat Belt Indicator Light (Rear seat) 2-32
Front Passenger Air Bag Deactivation Indicator Light*12-78
Security Indicator Light*13-44
Wrench Indication
4-27
Shift Position Indication4-61
Lights-On Indication/Indicator Light 4-68
When Driving
Instrument Cluster and Display
*Some models.4-25
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

SignalIndicator Page
Headlight High-Beam Indicator Light Headlight
High-Low Beam 4-71
Flashing the Headlights 4-71
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-73
Hazard Warning Flasher4-80
*Mazda Radar Cruise Control with Stop & Go func tion (MRCC with Stop
& Go function) indicator Light*14-143
TCS/DSC Indicator Light*1
Traction Control System (TCS) 4-95
Dynamic Stabil‐ ity Control(DSC)4-97
Turns on 7-31
TCS OFF Indicator Light*14-96
Select Mode Indication 4-102
(Green)High Beam Control System (HBC) Indicator Light 4-112
Blind Spot Monitoring (BSM) OFF Indicator Light*1
Malfunction
7-31
Except malfunc‐ tion
4-119
(White)
*Mazda Radar Cruise Control with Stop & Go func tion (MRCC with Stop
& Go function) Main Indication 4-138
(Green)
*Mazda Radar Cruise Control with Stop & Go func
tion (MRCC with Stop
& Go function) Set Indication 4-138
When Driving
Instrument Cluster and Display
4-26*Some models.
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

SignalIndicator Page
Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Indication 4-150
*Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) OFF Indicator Light*14-154
*Smart City Brake Support (SCBS) Indication Advanced Smart
City Brake Sup‐ port (Advanced
SCBS)
4-160
Smart City
Brake Support (SCBS)4-163
*Smart Brake Support/Smart City B rake Support (SBS/SCBS) OFF Ind ica‐
tor Light*1
Advanced Smart City Brake Sup‐ port (Advanced SCBS)4-160
Smart City
Brake Support (SCBS)
4-163
Smart Brake
Support (SBS) System4-165
(White)
*Cruise Main Indication 4-204
(Green)
*Cruise Set Indication4-204
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda De aler.
▼Wrench Indicator Light
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to Maintenance Monitor on page
6-16.
When the engine oil replacement period
has arrived.
When Driving
Instrument Cluster and Display
*Some models.4-27
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit
necessary.
Your Authorized Mazda Dealer will be
able to reset the engine control unit or
see page 6-24 for the Vehicle engine
control unit reset procedure.

When Driving
Instrument Cluster and Display
4-28
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Instrument Cluster (Type B)

ƒSpeedometer.......................................................................................................... page 4-29
„ Tachometer............................................................................................................ page 4-2 9
… Multi-information Display (Type B)............................. ........................................ page 4-30
† Dashboard Illumination.........................................................................................page 4-34
▼Speedometer
The speedometer indicates the speed of the
vehicle.
▼Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.

STRIPED
ZONE
RED ZONE
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
When Driving
Instrument Cluster and Display
4-29
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

▼Multi-information Display (Type B)
INFO switchMulti-information Display (Type B)
The multi-information display in
dicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with S top & Go function (MRCC with Stop & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) Display
Cruise Control Display
Compass Display
Warning message
When Driving
Instrument Cluster and Display
4-30
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27
