MAZDA MODEL MAZDASPEED 3 2007 Owners Manual (in English)

Black plate (181,1)
NOTE
With the wiper lever in the OFF or INT
(Type A)/AUTO (Type B) position, the
wipers will operate continuously until
the lever is released.
If the washer doesn't work, inspect the
fluid level (page 8-28). If it's OK, consult
an Authorized Mazda Dealer.
Rear Window Wiper and
Washer (5 Door)
The ignition switch must be in the ON
position.
qRear Window Wiper
Turn the wiper on by turning the rear
wiper/washer switch.
ON―Normal
INT―Intermittent
qRear Window Washer
To spray washer fluid, turn the rear wiper/
washer switch to the
position. After
the switch is released, the washer will
stop.
NOTE
The washer with wiper function is
activated by rotating the rear wiper
switch all the way up. The washer only
function is activated by rotating the
switch all the way down.
If the washer doesn't work, inspect the
fluid level (page 8-28). If it's OK and the
washer still doesn't work, consult an
Authorized Mazda Dealer.
Driving Your Mazda
Switches and Controls
5-59
Mazda3_8V66-EA-06F_Edition3 Page181
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (182,1)
Rear Window Defroster
The rear window defroster clears frost,
fog, and thin ice from the rear window.
The ignition switch must be in the ON
position.
Press the switch to turn on the rear
window defroster. The rear window
defroster operates for about 10―15
minutes and turns off automatically.
The indicator light illuminates during
operation.
To turn off the rear window defroster
before the 10―15 minutes has elapsed,
press the switch again.
Manual Type Air-Conditioning
Indicator light
Fully Automatic Type Air-Conditioning
Indicator light
CAUTION
Don't use sharp instruments or window
cleaners with abrasives to clean the
inside of the rear window surface. They
may damage the defroster grid inside
the window.
NOTE
This defroster is not designed for
melting snow. If there is an
accumulation of snow on the rear
window, remove it before using the
defroster.
5-60
Driving Your Mazda
Switches and Controls
Mazda3_8V66-EA-06F_Edition3 Page182
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (183,1)
Horn
To sound the horn, press themark on
the steering wheel.
Hazard Warning Flasher
The hazard warning lights should always
be used when you stop on or near a
roadway in an emergency.
The hazard warning lights warn other
drivers that your vehicle is a traffic hazard
and that they must take extreme caution
when near it.
Hazard warning flasher
Depress the hazard warning flasher and all
the turn signals will flash.
NOTE
lThe turn signals don't work when the
hazard warning lights are on.
lCheck local regulations about the use
of hazard warning lights while the
vehicle is being towed. They may
forbid it.
Driving Your Mazda
Switches and Controls
5-61
Mazda3_8V66-EA-06F_Edition3 Page183
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (184,1)
5-62
Mazda3_8V66-EA-06F_Edition3 Page184
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (185,1)
6Interior Comfort
Use of various features for drive comfort, including air-conditioning and audio
system.
Climate Control System ............................................................... 6-2
Operating Tips ........................................................................... 6-2
Vent Operation .......................................................................... 6-3
Types of the Climate Control System ....................................... 6-5
Manual Type
í.......................................................................... 6-6
Fully Automatic Typeí........................................................... 6-11
Audio System ............................................................................... 6-16
Antenna ................................................................................... 6-16
Operating Tips for Audio System ........................................... 6-17
Audio Set ................................................................................ 6-27
Audio Control Switch Operation (Steering Wheel)
í............. 6-45
Auxiliary Input ........................................................................ 6-47
Safety Certification ................................................................. 6-51
Interior Equipment ..................................................................... 6-52
Sunvisors ................................................................................. 6-52
Interior Lights ......................................................................... 6-52
Information Display ................................................................ 6-55
Lighter ..................................................................................... 6-60
Ashtray .................................................................................... 6-61
Cup Holder .............................................................................. 6-61
Bottle Holder ........................................................................... 6-62
Storage Compartments ............................................................ 6-63
Accessory Sockets
í................................................................ 6-67
6-1íSome models.
Mazda3_8V66-EA-06F_Edition3 Page185
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (186,1)
Operating Tips
qOperating the Climate Control
System
Operate the climate control system with
the engine running.
NOTE
To prevent the battery from being
discharged, do not leave the fan control
dial on for a long period of time with
the ignition switch in the ACC position
when the engine is not running.
qClearing the Air Inlet
Clear all obstructions like leaves, snow
and ice from the hood and the air inlet in
the cowl grille to improve the system
efficiency.
qFoggy Windows
The windows may fog up easily in humid
weather. Use the climate control system to
defog the windows.
To help defog the windows, operate the
air conditioner to dehumidify the air.
NOTE
The air conditioner may be used along
with the heater to dehumidify the air.
qOutside/Recirculated Air Position
Use the outside air position in normal
conditions. The recirculated air position
should be used only when driving on
dusty roads or for quick cooling of the
interior.
qParking in Direct Sunlight
If the vehicle has been parked in direct
sunlight during hot weather, open the
windows to let warm air escape, then run
the climate control system.
qNot Using for a Long Period
Run the air conditioner about 10 minutes
at least once a month to keep internal
parts lubricated.
qCheck the Refrigerant before the
Weather Gets Hot
Have the air conditioner checked before
the weather gets hot. Lack of refrigerant
may make the air conditioner less
efficient. Consult an Authorized Mazda
Dealer for refrigerant inspection.
The air conditioner is filled with
HFC134a (R134a), a refrigerant that will
not damage the ozone layer.
If the air conditioner is low on refrigerant
or has a malfunction, consult an
Authorized Mazda Dealer.
qReplacement of the Cabin Air Filter
If your vehicle is equipped with an air
filter for the air conditioner, it is necessary
to change the filter periodically as
indicated in scheduled maintenance (page
8-3). Consult an Authorized Mazda
Dealer for replacement of the cabin air
filter.
6-2
Interior Comfort
Climate Control System
Mazda3_8V66-EA-06F_Edition3 Page186
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (187,1)
Vent Operation
Center vents
Side vents
qAdjusting the Vents
Directing airflow
Side Vents
To adjust the direction of airflow, open the
vents and rotate them left and right.
Push
Center Vents
To adjust the direction of airflow, move
the adjustment knob.
Knob
NOTE
When using the air conditioner, mist
may come out from the vents. This is
not a sign of trouble but a result of
humid air being suddenly cooled.
Interior Comfort
Climate Control System
6-3
Mazda3_8V66-EA-06F_Edition3 Page187
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (188,1)
qSelecting the Airflow Mode
Floor Vents Dashboard and Floor Vents Dashboard Vents
Defroster and Floor Vents
Defroster Vents
6-4
Interior Comfort
Climate Control System
Mazda3_8V66-EA-06F_Edition3 Page188
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (189,1)
Types of the Climate Control System
Manual type and fully automatic type climate control systems are explained separately.
Check your vehicle's climate control type and read the appropriate pages.
Manual Type ............................................................................................................ page 6-6
Fully Automatic Type ............................................................................................. page 6-11
Interior Comfort
Climate Control System
6-5
Mazda3_8V66-EA-06F_Edition3 Page189
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F

Black plate (190,1)
Manual Typeí
Air intake selector
A/C switch Mode selector dialTemperature control dial
Fan control dial
Some models.
qControl Switches
Temperature control dial
ColdHot
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
Fan control dial
This dial allows variable fan speeds.
0―Fan off
1―Low speed
2―Medium low speed
3―Medium high speed
4―High speed
6-6
Interior Comfort
íSome models.
Climate Control System
Mazda3_8V66-EA-06F_Edition3 Page190
Wednesday, August 23 2006 11:20 AM
Form No.8V66-EA-06F
