MAZDA MODEL MPV 2005 Owners Manual (in English)

Black plate (231,1)
Accessory Socketsí
The ignition switch must be in the ACC
or ON position.
Only use genuine Mazda accessories or
the equivalent requiring no greater than
120 W (DC12 V, 10 A).
Front
Cap
Rear
CAUTION
To prevent accessory socket damage or
electrical failure, pay attention to the
following:
lDon't use accessories that require
more than 120 W (DC12 V, 10 A).
lDon't use accessories that are not
genuine Mazda accessories or the
equivalent.
lClose the cover when the accessory
socket is not in use.
lCorrectly insert the plug into the
accessory socket.
NOTE
To prevent discharging the battery, don't
use the socket for long periods with the
engine off or idling.
Interior Comfort
Interior Equipment
6-57íSome models. Mazda MPV_8T50-EA-04G_Edition1 Page231
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (232,1)
6-58
Mazda MPV_8T50-EA-04G_Edition1 Page232
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (233,1)
7In Case of an Emergency
Helpful information on what to do in an emergency.
Parking in an Emergency ............................................................. 7-2
Parking in an Emergency .......................................................... 7-2
Flat Tire ......................................................................................... 7-3
Spare Tire and Tool Storage ...................................................... 7-3
Changing a Flat Tire ................................................................. 7-9
Overheating ................................................................................. 7-16
Overheating ............................................................................. 7-16
Emergency Starting .................................................................... 7-18
Starting a Flooded Engine ....................................................... 7-18
Jump-Starting .......................................................................... 7-19
Push-Starting ........................................................................... 7-22
Emergency Towing ..................................................................... 7-23
Towing Description ................................................................. 7-23
Tiedown Hooks ....................................................................... 7-24
Recreational Towing ............................................................... 7-24
7-1
Mazda MPV_8T50-EA-04G_Edition1 Page233
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (234,1)
Parking in an Emergency
The hazard warning lights should always
be used when you stop on or near a
roadway.
The hazard warning lights warn other
drivers that your vehicle is a traffic hazard
and that they must take extreme caution
when near it.
Depress the hazard warning flasher and all
four turn signals will flash.
NOTE
lThe turn signals don't work when the
hazard warning lights are on.
lCheck local regulations about the use
of hazard warning lights while the
vehicle is being towed. They may
forbid it.
7-2
In Case of an Emergency
Parking in an Emergency
Mazda MPV_8T50-EA-04G_Edition1 Page234
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (235,1)
Spare Tire and Tool Storage
Spare tire and tools are stored in the locations illustrated in the diagram.
Spare tire Tool bag Jack
Spare tire lever
Lug wrenchJack leverTire clamp
Flat tire securing boltVinyl bag
In Case of an Emergency
Flat Tire
7-3
Mazda MPV_8T50-EA-04G_Edition1 Page235
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (236,1)
qJack
To remove the jack
1. Remove the cover.
2. Remove the tool bag.
3. Turn the wing bolt counterclockwise.
To secure the jack
Perform the removal procedure in reverse.
qSpare Tire
Your Mazda has a temporary spare tire.
The temporary spare tire is lighter and
smaller than a conventional tire, and is
designed only for emergency use and
should be used only for VERY short
periods. Temporary spares should
NEVER be used for long drives or
extended periods.
WARNING
Driving with a Temporary Spare Tire
on Ice or Snow:
Driving with a spare tire on the front
(driving) wheels on ice or snow is
dangerous. Handling will be affected.
You could lose control of the vehicle
and have an accident. Put the spare
tire on the rear axle and move a
regular tire to the front.
7-4
In Case of an Emergency
Flat Tire
Mazda MPV_8T50-EA-04G_Edition1 Page236
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (237,1)
CAUTION
To avoid damage to the temporary
spare or to the vehicle, observe the
following precautions:
lDon't exceed 80 km/h (50 mph).
lAvoid driving over obstacles.
Also, don't drive through an
automatic car wash. This tire's
diameter is smaller than a
conventional tire's, so the ground
clearance is reduced about 25 mm (1
in).
lDon't use a tire chain on this tire
because it won't fit properly.
lDon't use your temporary spare on
any other vehicle; it has been
designed only for your Mazda.
lDo not tow a trailer while using this
tire.
lUse only one temporary spare tire on
your vehicle at the same time.
To remove the spare tire
1. Have everyone get out of the vehicle
and away from the vehicle and traffic.2. For side-spoiler equipped vehicles,
remove the fasteners on both sides of
the spoiler cap by turning them
counterclockwise.
Pull the spoiler cap out.
NOTE
After installing the side spoiler cap,
make sure it is securely attached.
In Case of an Emergency
Flat Tire
7-5
Mazda MPV_8T50-EA-04G_Edition1 Page237
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (238,1)
3. Locate the spare tire carrier socket cap
on the right, in front of the second-row
seat. Unscrew it by turning it
counterclockwise.
4. Remove the spare tire lever and lug
wrench from the tool bag.
5. Raise the reclining lever and push the
front seatback forward and out of the
way.
Make sure the seatback is locked.
6. Insert the spare tire lever into the spare
tire carrier socket. Fit the lug wrench to
the opposite end of the spare tire lever.
Lug wrench
Spare tire
lever
7. Slowly turn the lug wrench
counterclockwise until the spare tire
reaches the ground and the cable
becomes loose.
CAUTION
lDo not loosen the cable too much as
this may cause damage to the spare
tire carrier.
lTurning the lug wrench with the seat
reclined could damage the seatback
material.
lApplying excessive lateral force
while the spare tire lever is attached
may result in damage to the socket.
NOTE
The spare tire lever remains locked in
the socket while the spare tire is being
lowered.
Unless the cable is rolled up
completely, the spare tire lever cannot
be removed from the socket.
7-6
In Case of an Emergency
Flat Tire
Mazda MPV_8T50-EA-04G_Edition1 Page238
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (239,1)
8. Rotate the small lever on top of the
retaining plate and pull the retaining
plate out from the center hole of the
tire.
NOTE
A flat tire which has been removed
from the vehicle for repair cannot be
carried in the spare tire carrier. Secure
the flat tire with the tire clamp and wing
nut in the luggage compartment (page
7-12).
To secure the spare tire
1. Place the tire with the outer side facing
upward, rotate the small lever on top of
the retaining plate and slide the
retaining plate through the center hole
of the tire.
Rotate the small lever into place.
Lever
Spare tire
2. Raise the spare tire slowly in reverse
order of removal.
WARNING
Carrier Placement for the Specialized
Temporary Spare Tire:
Placing the specialized temporary
spare tire in the spare tire carrier
wrong side up or using any tire other
than the small temporary spare tire
designed for use with this vehicle is
dangerous. It will result in poor
attachment and insufficient ground
clearance in the spare tire carrier and
the danger of the tire falling off. This
could result in someone being badly
injured or even killed.
Place the specialized temporary spare
tire in the spare tire carrier correctly.
In Case of an Emergency
Flat Tire
7-7
Mazda MPV_8T50-EA-04G_Edition1 Page239
Monday, June 28 2004 4:0 PM
Form No.8T50-EA-04G

Black plate (240,1)
CAUTION
Applying excessive lateral force while
the spare tire lever is attached may
result in damage to the socket.
NOTE
Unless the cable is rolled up
completely, the spare tire lever cannot
be removed from the socket.
3. Replace the spare tire carrier cap in the
socket and turn it until the spare tire is
pulled up tight.
WARNING
Loose Spare Tire Carrier Socket:
A loose spare tire carrier socket cap is
dangerous. The cable could be cut
causing the spare tire to fall off. This
could result in someone being badly
injured or even killed.
Always screw the spare tire carrier
socket cap completely tight and make
sure the spare tire is locked in the
highest position.
CAUTION
If you hear rattling from the spare tire
carrier while the vehicle is moving, the
spare tire carrier cable may be cut.
Have it repaired at an Authorized
Mazda Dealer as soon as possible.
7-8
In Case of an Emergency
Flat Tire
