2Essential Safety Equipment
Use of safety equipment, including seats, seat belt system, child-restraint
systems and SRS air bags.
Seats ............................................................................................... 2-2Seats .......................................................................................... 2-2
Non-Adjustable Head Restraints ............................................... 2-4
Seat Warmer
í........................................................................... 2-5
Seat Belt Systems .......................................................................... 2-7 Seat Belt Precautions ................................................................ 2-7
Seat Belt .................................................................................. 2-11
Seat Belt Pretensioner and Load Limiting Systems ................ 2-13
Seat Belt Extender ................................................................... 2-15
Seat Belt Warning Light .......................................................... 2-16
Seat Belt Reminder ................................................................. 2-17
Child Restraint ............................................................................ 2-18 Child Restraint Precautions ..................................................... 2-18
Child-Restraint System Installation Position .......................... 2-22
Installing a Child-Restraint System ......................................... 2-23
SRS Air Bags ............................................................................... 2-25 Supplemental Restraint System (SRS) Precautions ................ 2-25
Supplemental Restraint System Components ......................... 2-29
How the SRS Air Bags Work .................................................. 2-30
SRS Air Bag Deployment Criteria .......................................... 2-34
Limitations to SRS Air Bag .................................................... 2-35
Driver and Passenger Occupant Classification System ........... 2-37
Monitoring and Maintenance .................................................. 2-41
2-1íSome models.
MX-5_8DG6-EA-13F_Edition1 Page13
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (14,1)
Seats
WARNING
Do not modify or replace the front
seats:Modifying or replacing the front seats
such as replacing the upholstery or
loosening any bolts is dangerous. The
front seats contain air bag
components essential to the
supplemental restraint system. Such
modifications could damage the
supplemental restraint system and
result in serious injury. Consult an
Authorized Mazda Dealer if there is
any need to remove or reinstall the
front seats.
Do not drive with damaged front seats: Driving with damaged front seats is
dangerous. A collision, even one not
strong enough to inflate the air bags,
could damage the front seats which
contain essential air bag
components. If there was a
subsequent collision, an air bag may
not deploy which could lead to
injuries. Always have an Authorized
Mazda Dealer inspect the front seats,
front seat belt pretensioners and air
bags after a collision.
Make sure the adjustable components
of a seat are locked in place: Adjustable seats and seatbacks that
are not securely locked are
dangerous. In a sudden stop or
collision, the seat or seatback could
move, causing injury. Make sure the
adjustable components of the seat
are locked in place by attempting to
slide the seat forward and backward
and rocking the seatback. Adjust the driver's seat only when the
vehicle is stopped:
Adjusting the driver's seat while the
vehicle is moving is dangerous. The
driver could lose control of the vehicle
and have an accident.
CAUTION
Be careful not to place your hands
and fingers around moving parts of
the front seat when adjusting the
seat positions to prevent injury.
qSeat Slide
To move a seat forward or backward, raise
the lever and slide the seat to the desired
position and release the lever.
Make sure the lever returns to its original
position and the seat is locked in place by
attempting to push it forward and
backward.
2-2
Essential Safety Equipment
Seats
MX-5_8DG6-EA-13F_Edition1 Page14
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (15,1)
qSeat Recline
WARNING
Do not drive with either front seat
reclined:
Sitting in a reclined position while the
vehicle is moving is dangerous
because you do not get the full
protection from seat belts. During
sudden braking or a collision, you
can slide under the lap belt and
suffer serious internal injuries. For
maximum protection, sit well back
and upright.
Always sit in the passenger seat
properly with the seatback upright and
feet on the floor: Your passenger seat has weight
sensors, sitting in the passenger seat
improperly out of position or with the
seatback reclined too far while the
vehicle is moving is dangerous as it
can take off weight from the seat
bottom and affect the weight
determination of the passenger
sensing system. As a result the
passenger will not have the
supplementary protection of the air
bag and seat belt pretensioner, which
could result in serious injury. Always
sit upright against the seatback with
your feet on the floor. Do not drive with the seatback
unlocked:
All of the seatbacks play an
important role in your protection in a
vehicle. Leaving the seatback
unlocked is dangerous as it can allow
passengers to be ejected or thrown
around and baggage to strike
occupants in a sudden stop or
collision, resulting in severe injury.
After adjusting the seatback at any
time, even when there are no other
passengers, rock the seatback to
make sure it is locked in place.
To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position and
release the lever.
Make sure the lever returns to its original
position and the seatback is locked in
place by attempting to push it forward and
backward.
Essential Safety Equipment
Seats
2-3
MX-5_8DG6-EA-13F_Edition1 Page15
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (16,1)
CAUTION
When returning a rear-reclined
seatback to its upright position,
make sure you hold onto the
seatback with your other hand while
operating the lever. If the seatback is
not supported, it will flip forward
suddenly and could cause injury.
qHeight Adjustment (Driver's Seat)í
To adjust the seat height, move the lever
up or down.
Up
Down
Non-Adjustable Head
Restraints
Your vehicle is equipped with non-
adjustable head restraints on the driver's
and front passenger's seatbacks. The non-
adjustable head restraints consist of a
trimmed foam covering over the upper
structure of the seatbacks and are intended
to help protect you and the front
passenger from neck injury. Adjust the
seatbacks to their upright, on-road
positions so that the head restraint is
positioned as close as possible to the back
of your head.
WARNING
Make sure the seatbacks are properly
adjusted to their upright, on-road
positions before the vehicle is driven: Driving with the seatbacks not
adjusted properly is dangerous. With
no support behind your head, your
neck could be seriously injured in a
collision.
2-4
Essential Safety Equipment
íSome models.
Seats
MX-5_8DG6-EA-13F_Edition1 Page16
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (17,1)
Seat Warmerí
The driver and passenger seats can be
warmed by rotating the applicable seat
warmer dial while the ignition is switched
ON.
The seat temperature increases as the
number on the dial increases. When the
seat warmers are not in use, rotate the seat
warmer dials to 0.
WARNING
ØBe careful when using the seat
warmer. The heat from the seat
warmer may be too hot for some
people, as indicated below, and
could cause a low-temperature
burn.
ØInfants, small babies, elderly
people, and physically
challenged people
ØPeople with delicate skin
ØPeople who are excessively
fatigued
ØPeople who are intoxicated
ØPeople who have taken sleep-
inducing medicine such as
sleeping pills or cold medicine
Ø Do not use the seat warmer with
anything having high moisture-
retention ability such as a blanket
or cushion on the seat. The seat
may be heated excessively and
cause a low-temperature burn.
Ø Do not use the seat warmer even
when taking a short nap in the
vehicle. The seat may be heated
excessively and cause a low-
temperature burn.
Ø Do not place heavy objects with
sharp projections on the seat, or
insert needles or pins into it. This
could cause the seat to become
excessively heated and result in
injury from a minor burn.
CAUTION
Do not use organic solvents to clean
the seat. It may damage the seat
surface and the heater.
Essential Safety Equipment
Seats
2-5íSome models.
MX-5_8DG6-EA-13F_Edition1 Page17
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (18,1)
NOTE
Use the seat warmer when the engine is
running, and do not continue to use it for a
long period of time.
2-6
Essential Safety Equipment
Seats
MX-5_8DG6-EA-13F_Edition1 Page18
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (19,1)
Seat Belt Precautions
Seat belts help to decrease the possibility of severe injury during accidents and sudden
stops. Mazda recommends that the driver and passenger always wear seat belts.
All of the seat belt retractors are designed to keep the lap/shoulder belts out of the way
when not in use.
The driver's seat belt has no provisions for child-restraint systems and has only an
emergency locking mode. The driver may wear it comfortably, and it will lock during a
collision.
However, the passenger's seat lap/shoulder belt retractors operate in two modes: emergency
locking mode, and for child-restraint systems, automatic locking mode.
Essential Safety Equipment
Seat Belt Systems
2-7
MX-5_8DG6-EA-13F_Edition1 Page19
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F

Black plate (20,1)
WARNING
Always wear your seat belt and make sure all occupants are properly restrained:Not wearing a seat belt is extremely dangerous. During a collision, occupants not
wearing seat belts could hit someone or things inside the vehicle or even be thrown
out of the vehicle. They could be seriously injured or even killed. In the same
collision, occupants wearing seat belts would be much safer.
Do not wear twisted seat belts: Twisted seat belts are dangerous. In a collision, the full width of the belt is not
available to absorb the impact. This puts more force on the bones beneath the belt,
which could cause serious injury or death. So, if your seat belt is twisted, you must
straighten the seat belt to remove any twists and to allow the full width of the belt to
be used.
Never use one seat belt on more than one person at a time: Using one seat belt for more than one person at a time is dangerous. A seat belt
used in this way cannot spread the impact forces properly and the two passengers
could be crushed together and seriously injured or even killed. Never use one belt for
more than one person at a time and always operate the vehicle with each occupant
properly restrained.
Do not operate a vehicle with a damaged seat belt: Using a damaged seat belt is dangerous. An accident could damage the belt
webbing of the seat belt in use. A damaged seat belt cannot provide adequate
protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt
systems in use during an accident before they are used again.
Have your seat belts changed immediately if the pretensioner or load limiter has
been expended: Always have an Authorized Mazda Dealer immediately inspect the seat belt
pretensioners and air bags after any collision. Like the air bags, the seat belt
pretensioners and load limiters will only function once and must be replaced after
any collision that caused them to deploy. A seat belt with an expended pretensioner
or load limiter is still better than wearing no seat belt at all; however, if the seat belt
pretensioners and load limiters are not replaced, the risk of injury in a collision will
increase.
2-8
Essential Safety Equipment
Seat Belt Systems
MX-5_8DG6-EA-13F_Edition1 Page20
Thursday, May 30 2013 10:49 AM
Form No.8DG6-EA-13F
