MAZDA MODEL MX-5 MIATA 2019 Owners Manual

3. Attach the removed cap to the innerside of the fuel-filler lid.

Fuel-filler lid
Fuel-filler cap
4. Insert the refuelin g nozzle all the way
and begin refueling. Pull out the
refueling nozzle after the refueling
stops automatically.
5. To close the fuel-filler cap, turn it clockwise until a click is heard.
6. To close, press the fuel-filler lid until a
click sound is heard.

7. Make sure to lock both the doors whenleaving the vehicle.
Refer to Door Locks on page 3-11.
NOTE
Lock the doors after closing the
fuel-filler lid.
If the fuel-filler lid is closed after
locking the doors, the fuel-filler lid
cannot be locked.
CAUTION
(U.S.A. and Canada)
If the check fuel cap warning light
illuminates, the fuel-filler cap may not be
properly installed. If the warning light
illuminates, park your vehicle safely off the
right-of-way, remove th e fuel-filler cap and
reinstall it correctly. After the cap has been
correctly installed, the fuel cap warning
light may continue to illuminate until a
number of driving cycles have been
completed. A drive cycle consists of starting
the engine (after four or more hours with
the engine off) and driving the vehicle on
city and highway roads.
Continuing to drive with the check fuel cap
warning light illuminated could cause the
check engine light to illuminate as well.
Before Driving
Fuel and Emission
3-27
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Mirrors
Before driving, adjust the inside and
outside mirrors.
â–¼Outside Mirrors
WA R N I N G
Be sure to look over your shoulder before
changing lanes:
Changing lanes without taking into
account the actual distance of the vehicle
in the convex mirror is dangerous. You
could have a serious accident. What you
see in the convex mirror is closer than it
appears.
Mirror type
Flat type (driver's side)
Flat surface mirror.
Convex type (passenger side)
The mirror has single curvature on its
surface.
Power mirror adjustment
The ignition must be switched to ACC or
ON position.

To adjust:
1. Rotate the mirror switch to the left
or
right
to choose the left or right side
mirror.
2. Press the mirro r switch in the
appropriate direction.
Center position
Mirror switch
After adjusting the mirror, lock the control
by rotating the switch in the center
position.
Folding mirror
WA R N I N G
Always return the outside mirrors to the
driving position before you start driving:
Driving with the outsid e mirrors folded in is
dangerous. Your re ar view will be
restricted, and you could have an accident.
Manually fold the outside mirror rearward
until it is flush with the vehicle.
Before Driving
Mirrors
3-28
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Driver's side auto-dimming door
mirror*
The movement of the auto-dimming door
mirror is interlocked with the
auto-dimming rearv iew mirror in the
interior to automatically reduce glare from
rear on-coming vehicles.
Refer to Rearview Mirror on page 3-29.
NOTE
The passenger-side door mirror does not
have the auto-dimming feature.
â–¼ Rearview Mirror
WA R N I N G
Do not stack cargo or objects higher than
the seatbacks:
Cargo stacked higher than the seatbacks is
dangerous. It can block your view in the
rearview mirror, which might cause you to
hit another car when changing lanes.
Rearview mirror adjustment
Before driving, adjust
the rearview mirror
to center on the scene through the rear
window.

NOTE
For the manual day/night mirror, perform
the adjustment with the day/night lever in
the day position.
Reducing glare from headlights
Manual day/night mirror
Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Day/Night lever
Day
Night
Auto-dimming mirror
The auto-dimming mirror automatically
reduces the glare of headlights from
vehicles at the rear when the ignition is
switched ON.

Press the OFF button (
) to cancel the
auto-dimming function. The indicator light
will turn off.
To reactivate the auto -dimming function,
press the ON button (
). The indicator
light will illuminate.
Indicator lightOFF button
ON button

Before Driving
Mirrors
*Some models.3-29
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

NOTE
ï‚·Do not use glass cleaner or suspend
objects on or around the light sensor.
Otherwise, light sensor sensitivity will
be affected and may not operate
normally.

Light sensor
ï‚·For information regarding the 3 buttons
(
,,) on the auto-dimming
mirror.
Refer to HomeLink Wireless Control
System on page 4-56.
ï‚·The auto-dimming function is canceled
when the ignition is switched ON and
the shift/selector lever is in reverse (R).
Before Driving
Mirrors
3-30
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Power Windows
The windows can be opened/closed by
operating the power window switches.
WA R N I N G
Make sure the opening is clear before
closing a window:
Closing a power window is dangerous. A
person's hands, head, or even neck could
be caught by the window and result in
serious injury or even death. This warning
applies especially to children.
Never allow children to play with power
window switches:
Power window switches that are not locked
with the power window lock switch would
allow children to operate power windows
unintentionally, which could result in
serious injury if a child's hands, head or
neck becomes caught by the window.
Make sure nothing bloc ks the w indow just
before it reaches the fully closed position or
while fully holding up the power window
switch:
Blocking the power window just before it
reaches the fully closed position or while
fully holding up the power window switch
is dangerous.
In this case, the jam-safe function cannot
prevent the window from closing all the
way. If fingers are caught, serious injuries
could occur.
Before Driving
Windows
3-31
MX-5_8GV5-EA-18E_Edition32018-7-17 15:48:16

â–¼Opening/Closing Windows
The window opens while the switch is pressed and it closes whil
e the switch is pulled up
with the ignition switched ON. D o not open or close both windows at the same time.
The passenger window can be opened/closed when the power window lock switch on the
driver's door is in the unlock position. Keep this switch in th e locked position while children
are in the vehicle.

Open Close
Open
Driver's window
Power window
lock switch
Passenger's
window
Close
Unlocked positionLocked position
Master control switches Passenger's window switch
NOTE
ï‚·A power window may no longer open/close if you continue to press the switch after
opening/closing the power window. If the po
wer window does not open/close, wait a
moment and then operate the switch again.
ï‚·The passenger windows may be opened or closed using the master control switches on the
driver's door.
ï‚·The power window can be operated for about 40 seconds after the ignition is switched
from ON to ACC or off with all doors closed. If any door is opened, the power window
will stop operating.
For engine-off operation of the power window, the switch must be held up firmly
throughout window closure because the aut o-closing function will be inoperable.
ï‚·When the power window lock switch is in th e locked position, the light on the passenger
power window switch turns off. The light may be difficult to see depending on the
surrounding brightness.
Before Driving
Windows
3-32
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

â–¼Auto-opening
To fully open the window automatically,
press the switch completely down, then
release. The window will fully open
automatically.

To stop the window partway, pull up the
switch and then release it.
NOTE
ï‚·The power window cannot be fully
closed while the door is open.
ï‚·Power window system initialization
procedure
If the battery was disconnected during
vehicle maintenance, or for other
reasons (such as a switch continues to
be operated after the window is open/
closed), the window will not fully open
automatically.
The power window auto function will
only resume on the power window that
has been reset.
1. Close the doors and the convertible
top/roof.
2. Switch the ignition ON.
3. Make sure that the power window lock switch located on the driver's
door is not depressed.
4. Press the switch and fully open the
window.
5. Pull up the switch to fully close the
window and continue holding the
switch for about 2 seconds after the
window fully closed.
6. Make sure that the power windows
operate correctly using the door
switches.
After the system has been re-initialized,
passenger window can be fully opened
automatically using the master control
switches.

If the automatic power window
operation does not operate normally
while the doors or convertible top/
retractable hardtop are opened/closed,
reset it using the previous procedures.
Before Driving
Windows
3-33
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Convertible Top (Soft Top)
When opening/closing the convertible top, park the vehicle in a safe place where it does not
obstruct traffic.
Top latch assembly
Convertible top's handles
Convertible top
â–¼ Convertible Top Precautions
WA R N I N G
Sit in the seat with the seat belt correctly fastened when the vehicle is moving:
Standing in the vehicle, or sitting on the convertible top storage area or center console when
the vehicle is moving is a dangerous way to ri
de. During a sudden maneuver or collision you
could be seriously injured or even killed.
Always keep your hands and fingers away from the fastening mechanisms when moving the
convertible top:
It is dangerous to place your hands or fingers near the fastening mechanisms. Your hands or
fingers could be caught and injured by the mechanism.
CAUTION
 Remove leaves or other matter that may accumulate on and around the convertible top. If
leaves or other matter block the drain filter, water may enter the vehicle. Clean the drain
filter at least once a year.
Before Driving
Convertible Top (Soft Top)
3-34
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

Refer to Convertible Top Maintenance on page 6-59.
 Before opening the convertible top, make sure the rear window defogger switch is turned
off. Otherwise the heat generated from the defogger could damage the convertible top and
the internal material.
 Before lowering or raising the convertible top, stop in a safe place off the right-of-way and
park on a level surface.
 Make sure nothing is on the convertible to p or near the back window when raising or
lowering the convertible top.
Even small objects may interfere and cause damage.
 Do not drive through an automatic car wash; it may damage the convertible top.
 Do not raise or lower the convertible top when the temperature is below 5 °C (41 °F) ; this
will damage the convertible top material.
 Do not lower the convertible top when it's wet. If the convertible top dries while folded, it
will deteriorate and mold.
 Lowering the convertible top while it's wet can also cause water to drip into the passenger
compartment.
 Do not raise or lower the convertible top in a strong wind as it could damage the
convertible top or cause an unexpected accident.
NOTE
ï‚·The power windows go down automatically in conjunction with the convertible top
opening/closing. However, this is a function for improving the operability, and it does not
mean there is a problem. If the vehicle battery is disconnected for vehicle maintenance or
other reasons, the power windows will not go down automatically. If the power windows
do not go down, the automatic open/close mechanism for the windows must be reset.
Refer to Auto-opening on page 3-33.
ï‚·When lowering the convertible top, make sure objects inside the vehicle are not blown
away by the wind.
ï‚·Secure all loose objects inside before driving with the convertible top down.
ï‚·To help prevent burglary or vandalism and to ensure that the passenger compartment
stays dry, close the convertible top and both windows securely and lock both doors when
leaving the vehicle.
ï‚·The soft top is made of high quality material and if it is not maintained correctly, the
material could harden, becomes stained, or have an uneven gloss.
Before Driving
Convertible Top (Soft Top)
3-35
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16

â–¼Lowering the Convertible Top
CAUTION
Do not sit on the folded convertible top.
Otherwise, the convertible top could be
damaged or you may fall off and be
injured.
1. Make sure the parking brake is
applied.
2. If the engine is running, turn it off.
3. Make sure there are no objects which
have been placed in the area where the
convertible top is to be retracted.
4. With the lock release button depressed forward, pull back the top latch lever
to unlock it.

Top latch
Lock release button
5. Remove the striker from the anchor.

Anchor Striker
NOTE
If the power windows do not go down
automatically, fully open the windows
or open the doors.
6. Standing outside of the vehicle, hold
the convertible top along the front edge
and pull it toward the vehicle rear.

Front edge
NOTE
To lower the convertible top from
inside the vehicle, use the convertible
top's handles.

Convertible top's handles
Before Driving
Convertible Top (Soft Top)
3-36
MX-5_8GV5-EA-18E_Edition3 2018-7-17 15:48:16
