10Specifications
Technical information about your Mazda.
Identification Numbers ............................................................... 10-2Vehicle Information Labels ..................................................... 10-2
Specifications ............................................................................... 10-3 Specifications .......................................................................... 10-3
10-1
Mazdaspeed6_8U01-EA-05H_Edition2 Page341
Thursday, September 29 2005 5:33 PM
Form No.8U01-EA-05H

Black plate (342,1)
Vehicle Information Labels
qVehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on
a plate attached to the left top side of the
dashboard. This plate can easily be seen
through the windshield.
qMotor Vehicle Safety Standard Label
qVehicle Emission Control
Information Label
qTire Pressure Label
10-2
Identification Numbers
Mazdaspeed6_8U01-EA-05H_Edition2 Page342
Thursday, September 29 2005 5:33 PM
Form No.8U01-EA-05H

Black plate (343,1)
Specifications
qEngine
Item Specification
Type DOHC-16V in-line, 4-cylinder
Bore×Stroke 87.5 × 94.0 mm (3.44 × 3.70 in)
Displacement 2,261 ml (2,261 cc, 137.9 cu in)
Compression ratio 9.5
qElectrical System
Item Classification
Battery 12V-48AH/5HR
12V-55AH/5HR
Alternator 12 V - 110 A
Starter 12 V - 1.4 kW
Spark-plug number L3K9 18 110A
*
L3Y3 18 110
Spark-plug gap 0.70 ―0.80 mm (0.028 ―0.031 in)
* ex factory
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on
the iridium alloy and platinum tips could be damaged.
q Lubricant Quality
Lubricant Classification
Engine oil Refer to the recommended SAE viscosity numbers on
page 8-12.
Manual transaxle oil API Service GL-4 (SAE 75W-90)
Transfer case oil API Service GL-5 (SAE 80W-90)
Rear differential oil API Service GL-5 (SAE 90)
API Service GL-5 (SAE 80W-90)
API Service GL-5 (SAE 75W-90)
*
Power steering fluid ATF M-III, M-V, or equivalent (e.g. Dexron® II)
Brake/Clutch fluid SAE J1703, or FMVSS116 DOT-3
* Not available from Mazda
Specifications
10-3
Mazdaspeed6_8U01-EA-05H_Edition2 Page343
Thursday, September 29 2005 5:33 PM
Form No.8U01-EA-05H

Black plate (344,1)
qCapacities
(Approximate Quantities)
Item Capacity
Engine oil With oil filter replacement
5.7 L (6.0 US qt, 5.0 Imp qt)
Without oil filter
replacement 5.3 L (5.6 US qt, 4.7 Imp qt)
Coolant 8.0 L (8.5 US qt, 7.0 Imp qt)
Manual transaxle oil 2.5 L (2.6 US qt, 2.2 Imp qt)
Transfer case oil 1.2 L (1.3 US qt, 1.1 Imp qt)
Rear differential oil 1.0 L (1.1 US qt, 0.9 Imp qt)
Fuel tank 60 L (15.9 US gal, 13.2 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
q Dimensions
Item Model
Overall length Without license plate holder
4,745 mm (186.8 in)
With license plate holder 4,765 mm (187.6 in)
Overall width 1,780 mm (70.1 in)
Overall height 1,430 mm (56.3 in)
Front tread 1,540 mm (60.6 in)
Rear tread 1,540 mm (60.6 in)
Wheelbase 2,675 mm (105.3 in)
qWeights
Item Weight
GVWR (Gross Vehicle Weight Rating) 2,065 kg (4,552 lb)
GAWR (Gross Axle Weight Rating) Front
1,111 kg (2,449 lb)
Rear 954 kg (2,103 lb)
CW (Curb Weight) 1,628 kg (3,589 lb)
qAir Conditioner
Gas complies with SAE J639 Maximum operating charge
HFC134a (R-134a) 0.47 kg (1.0 lb)
10-4
Specifications
Mazdaspeed6_8U01-EA-05H_Edition2 Page344
Thursday, September 29 2005 5:33 PM
Form No.8U01-EA-05H

Black plate (345,1)
qLight Bulbs
Exterior light
Light bulb Category
Wattage ECE R SAE
Headlights High beam 55 H1
―
Low beam 35 D2S ―
Front turn signal lights 27 ―#2357A
Parking lights 5 W5W ―
Fog lights 55 H11 H11
Side-marker lights 5 ――
High-mount brake light
*14 ――
Rear turn signal lights 21 WY21W ―
Brake lights/Taillights 21/5 W21/5W #7443
Taillights 5
*2W21/5W #7443
Reverse lights 18.4W16W #921
License plate lights 5W5W ―
*1 Bulb replacement is not possible because it is built into the unit. Replace the unit.
*2 Use a 21/5W type bulb.
Interior light
Light bulb Category
Wattage ECE R
Trunk light 3 ―
Overhead light/Map lights 5 W5W
Courtesy lights 5 W5W
Vanity mirror lights 1.2 ―
qTires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation
Pressure on page 8-26.
Standard tire Tire size Inflation pressure
Front Rear
215/45R18 93Y 260 kPa (38 psi) 260 kPa (38 psi)
Specifications
10-5
Mazdaspeed6_8U01-EA-05H_Edition2 Page345
Thursday, September 29 2005 5:33 PM
Form No.8U01-EA-05H

Black plate (346,1)
Temporary spare tireTire size Inflation pressure
T145/70D17 106M 420 kPa (60 psi)
q Fuses
Refer to the fuse rating on page 8-36.
10-6
Specifications
Mazdaspeed6_8U01-EA-05H_Edition2 Page346
Thursday, September 29 2005 5:33 PM
Form No.8U01-EA-05H

Black plate (347,1)
11Index
