3-33
Knowing Your Mazda
Mirrors
Form No. 8T02-EA-03L

Rearview Mirror (With Day/
Night Function)
Before driving, adjust the rearview mirror
to center on the scene through the rear
window.
Do this with the day/night lever in the day
position.
Push the lever forward for day driving.
Pull it back to reduce glare from
headlights.
Day/Night lever
Day Night
Blocked View:
Cargo stacked higher than the
seatbacks is dangerous. It can block
your view in the rearview mirror,
which might cause you to hit another
car when changing lanes. Don ’t stack
things higher than the seatbacks.
Objects in the Storage Area:
Putting heavy or sharp objects in the
top storage area is dangerous.
During a sudden stop or collision,
they can become projectiles that
might hit and injure passengers.
Don ’t place heavy or sharp objects in
the top storage area.
Standing in a Moving Vehicle:
Standing in the vehicle, or sitting on
the convertible top storage area or
center console when it’ s moving is a
dangerous way to ride. During a
sudden maneuver or collision you
could be seriously injured or even
killed.
Sit in the seat with the seat belt on
when the vehicle is moving.
WARNING
J07S_8T02-EA-03L_Edition1.book Page 33 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

3-34
Form No. 8T02-EA-03L
J07S_8T02-EA-03L_Edition1.book Page 34 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-1
Form No. 8T02-EA-03L
4Before Driving Your Mazda
Important information about driving your Mazda.
Fuel and Engine Exhaust Precautions ......................................... 4-2
Fuel Requirements ..................................................................... 4-2
Emission Control System .......................................................... 4-4
Engine Exhaust (Carbon Monoxide) ......................................... 4-5
Before Starting the Engine ........................................................... 4-6
Before Getting In ....................................................................... 4-6
After Getting In ......................................................................... 4-6
Driving Tips ................................................................................... 4-7
Break-In Period ......................................................................... 4-7
Money-Saving Suggestions ....................................................... 4-7
Hazardous Driving ..................................................................... 4-8
Rocking the Vehicle ................................................................... 4-8
Winter Driving ........................................................................... 4-9
Driving In Flooded Area ......................................................... 4-11
Overloading ............................................................................. 4-11
Turbocharger Information (MAZDASPEED MX-5) .............. 4-12
To w i n g .......................................................................................... 4-13
Trailer Towing ......................................................................... 4-13
J07S_8T02-EA-03L_Edition1.book Page 1 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-2
Before Driving Your Mazda
Form No. 8T02-EA-03L
Fuel and Engine Exhaust Precautions
Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.
MX-5/miata
Your Mazda will perform best with fuel listed in the table.
* U.S. federal law requires that octane ratings be posted on gasoline station pumps.
You may use a regular unleaded fuel with an Octane Rating from 87 to 90 (91 to 95 RON)
but this will slightly reduce performance.
Fuel with a rating lower than 87 octane (91 RON) could cause the emission control system
to lose effectiveness. It could also cause engine knocking and serious engine damage.
MAZDASPEED MX-5
Use only premium unleaded fuel listed in the table.
* U.S. federal law requires that octane ratings be posted on gasoline station pumps.
Fuel Requirements
Fuel Octane Rating* (Anti-knock index)
Premium unleaded fuel 91 [ (R+M)/2 method] or above (96 RON or above)
Fuel Octane Rating
*(Anti-knock index)
Premium unleaded fuel 91 [ (R+M)/2 method] or above (96 RON or above)
•USE ONLY UNLEADED FUEL.
Leaded fuel is harmful to the catalytic converter or the oxygen sensor. The lead will
accumulate on the oxygen sensor and the catalyst inside the converter. This will result
in a malfunction of the emission control system, causing poor performance.
• Your vehicle can only use oxygenated fuels containing no more than 10% ethanol by
volume. Damage to your vehicle may occur when ethanol exceeds this
recommendation, or if the gasoline contains any methanol. Stop using gasohol of any
kind if your vehicle engine is performing poorly.
• Never add fuel system additives. Never add cleaning agents other than those specified
by Mazda. Other cleaning agents and additives may damage the system. Consult an
Authorized Mazda Dealer.
• (MAZDASPEED MX-5)

Never use fuel other than premium unleaded fuel for your vehicle. Use of other fuel
could cause poor engine performance and serious engine knocking.
CAUTION
J07S_8T02-EA-03L_Edition1.book Page 2 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-3
Before Driving Your Mazda
Fuel and Engine Exhaust Precautions
Form No. 8T02-EA-03L
Gasoline blended with oxygenates such as alcohol or ether compounds are generally
referred to as oxygenated fuels. The common gasoline blend that can be used with your
vehicle is ethanol blended at no more than 10%. Gasoline containing alcohol, such as
ethanol or methanol, may be marketed under the name "Gasohol".
Vehicle damage and drivability problems resulting from the use of the following may not
be covered by the Mazda warranty.
•Gasohol containing more than 10% ethanol.
• Gasoline or gasohol containing methanol.
• Leaded fuel or leaded gasohol.
J07S_8T02-EA-03L_Edition1.book Page 3 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-4
Before Driving Your Mazda
Fuel and Engine Exhaust Precautions
Form No. 8T02-EA-03L
Your vehicle is equipped with an emission control system (the catalytic converter is part of this
system) that enables your vehicle to comply with existing exhaust emissions requirements.
Emission Control System
Parking Over Flammable Objects:
Parking over or near anything flammable, such as dry grass, is dangerous. Even with
the engine turned off, the exhaust system could ignite it because the exhaust system
gets very hot during normal use. A resulting fire could cause serious injury or death.
Never park over or near anything flammable.
Ignoring the following precautions could cause lead to accumulate on the catalyst inside
the converter or cause the converter to get very hot. Either condition will damage the
converter and cause poor performance.
•USE ONLY UNLEADED FUEL.
• Don
’t drive your Mazda with any sign of engine malfunction.
• Don
’t coast with the ignition switch turned off.
• Don
’t descend steep grades in gear with the ignition switch turned off.
• Don
’t operate the engine at high idle for more than 5 minutes.
• Don
’t tamper with the emission control system. All inspections and adjustments must
be made by a qualified technician.
• Don
’t try to push-start or pull-start your vehicle.
NOTE
Under U.S. federal law, any modification to the original-equipment emission control
system before the first sale and registration of a vehicle is subject to penalties. In some
states, such modification made on a used vehicle is also subject to penalties.
NOTE
After driving some distance and turning off the engine, the sound of a valve opening and
closing can be heard behind the passenger seat, however this does not indicate an
abnormality. Your vehicle has a self-checking device and it operates after turning off the
engine.
WARNING
CAUTION
J07S_8T02-EA-03L_Edition1.book Page 4 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-5
Before Driving Your Mazda
Fuel and Engine Exhaust Precautions
Form No. 8T02-EA-03L
Engine Exhaust (Carbon Monoxide)
Carbon Monoxide:
Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is
colorless, odorless, and poisonous. When inhaled, it can cause loss of consciousness
and death. If you smell exhaust gas inside your vehicle, keep all windows fully open
and contact an Authorized Mazda Dealer immediately.
Exhaust Gas in Enclosed Area:
Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust
gas, which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur. Don’t run the engine when inside an
enclosed area.
Idling with the Windows Closed:
Exhaust gas is dangerous. When your vehicle is stopped with the windows closed and
the engine running for a long time even in an open area, exhaust gas, which contains
poisonous carbon monoxide, could enter the cabin. Loss of consciousness or even
death could occur. Open the windows or adjust the heating or cooling system to draw
fresh air.
Snow Blocking the Exhaust Gas:
Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust
pipe could be blocked by the snow, allowing exhaust gas to enter the cabin. Because
exhaust gas contains poisonous carbon monoxide, anyone in the cabin could be
injured or killed. Clear the snow from underneath and around your vehicle,
particularly the tail pipe, before starting the engine.
WARNING
J07S_8T02-EA-03L_Edition1.book Page 5 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-6
Before Driving Your Mazda
Form No. 8T02-EA-03L
Before Starting the Engine
•Be sure the windows, outside mirrors,
and outside lights are clean.
• Inspect inflation pressures and
condition of tires.
• Look under the vehicle for any sign of
a leak.
• If you plan to back up, make sure
nothing will be in your way. •
Are all doors closed and locked?
• Is the seat adjusted properly?
• Are the inside and outside mirrors
adjusted?
• Is everyone’
s seat belt fastened?
• Do all the lights work?
• Check all gauges.
• Check all warning lights when the
ignition switch is turned to the ON
position.
• Release the parking brake and make
sure the parking brake warning light
goes off.
Always be thoroughly familiar with your
Mazda.
Before Getting In
NOTE
Engine oil, engine coolant, brake/
clutch fluid, washer fluid, and other
fluid levels should be inspected. See
Maintenance, Section 8.
After Getting In
J07S_8T02-EA-03L_Edition1.book Page 6 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-7
Before Driving Your Mazda
Form No. 8T02-EA-03L
Driving Tips
No special break-in is necessary, but a few
precautions in the first 1,000 km (600
miles) may add to the performance,
economy, and life of your Mazda.
•Don
’t race the engine.
• Don
’t maintain one constant speed,
either slow or fast, for a long period of
time.
• Don
’t drive constantly at full-throttle or
high engine rpm for extended periods
of time.
• Avoid unnecessary hard stops.
• Avoid full-throttle starts. How you operate your Mazda determines
how far it will travel on a tank of fuel. Use
these suggestions to help save money on
fuel and repairs.
•
Avoid long warm-ups. Once the engine
runs smoothly, begin driving.
• Avoid fast starts.
• Keep the engine tuned. Follow the
maintenance schedule (page 8-3) and
have an Authorized Mazda Dealer
perform inspections and servicing.
• Use the air conditioner only when
necessary.
• Slow down on rough roads.
• Keep the tires properly inflated.
• Don
’t carry unnecessary weight.
• Don
’t rest your foot on the brake pedal
while driving.
• Keep the wheels in correct alignment.
• Keep windows closed at high speeds.
• Slow down when driving in crosswinds
and headwinds.
Break-In PeriodMoney-Saving Suggestions
Coasting:
Stopping the engine when going down
a hill is dangerous. This causes the
loss of power steering and power
brake control, and may cause damage
to the drivetrain. Any loss of steering
or braking control could cause an
accident. Never stop the engine when
going down a hill.
WARNING
J07S_8T02-EA-03L_Edition1.book Page 7 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-8
Before Driving Your Mazda
Driving Tips
Form No. 8T02-EA-03L
When driving on ice or in water, snow,
mud, sand, or similar hazard:
•Be cautious and allow extra distance
for braking.
• Avoid sudden braking and quick
steering.
• If your vehicle is not equipped with
ABS, brake with the pedal by using a
light up-down motion. Don
’t hold the
pedal down constantly.
If your vehicle is equipped with ABS,
don ’t pump the brakes. Continue to
press down on the brake pedal.
• If you get stuck, select a lower gear and
accelerate slowly. Don
’t spin the rear
wheels.
• For more traction in starting on
slippery surfaces such as ice or packed
snow, use sand, rock salt, chains,
carpeting, or other nonslip material
under the rear wheels. If you must rock the vehicle to free it from
snow, sand, or mud, depress the
accelerator slightly and slowly move the
shift lever from 1 (D) to R.
Hazardous Driving
Downshifting on Slippery Surfaces:
Downshifting into lower gear while
driving on slippery surfaces is
dangerous. The sudden change in tire
speed could cause the tires to skid.
This could lead to loss of vehicle
control and an accident. If it is
necessary to downshift on slippery
surfaces, be very careful.
NOTE
Use snow chains only on the rear
wheels.
WARNING
Rocking the Vehicle
Spinning the Wheels:
When the vehicle is stuck, spinning
the wheels at high speed is dangerous.
The spinning tire could overheat and
explode. This could cause serious
injuries. Don't spin the wheels at
more than 56 km/h (35 mph), and
don't allow anyone to stand behind a
wheel when pushing the vehicle.
Too much rocking may cause engine
overheating, transmission failure, and
tire damage.
WARNING
CAUTION
J07S_8T02-EA-03L_Edition1.book Page 8 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI
