MAZDA MODEL TRIBUTE 2008 (in English) Owner's Manual

Adjust1–7:Increasing this setting from 1 (lowest setting) to 7 (highest
setting) allows the radio volume to automatically change slightly with
vehicle speed to compensate for road and wind noise.
Recommended level is 1–3;SPEED OFF turns the feature off and level 7
is the maximum setting.
ALL SEATS (Occupancy mode, if equipped): Press SOUND
repeatedly to reach the Occupancy mode setting.
Press
SEEK/TRACKto select and optimize sound for ALL
SEATS, DRIVERS SEAT or REAR SEATS.
5. TUNE: In radio mode, turn
right / left to go up /down the
frequency band in individual
increments.
6. MENU: Press repeatedly to
access the following features:
AUTO PRESET ON/OFF: Press
SEEK/TRACKto toggle
between ON/OFF. Autoset allows you to set the strongest local radio
stations without losing your original manually set preset stations for
AM/FM1/FM2. To activate the autoset feature, toggle AUTOSET to ON,
and either wait five seconds for the search to initiate or press OK to
immediately initiate the search. (If you press another control within
those five seconds, the search will not initiate. ) The 10 strongest
stations will be filled and the station stored in preset 1 will begin playing.
If there are less than 10 strong stations, the system will store the last
one in the remaining presets.
RDS ON/OFF: Available only in FM mode. This feature allows you to
search RDS-equipped stations for a certain category of music format:
CLASSIC, COUNTRY, JAZZ/RB, ROCK, etc.
To activate, press MENU repeatedly until RDS (ON/OFF) appears in
the display. Use
SEEK/TRACKto toggle RDS ON/OFF. When
RDS is OFF, you will not be able to search for RDS equipped stations or
view the station name or type.
To change categories: Press MENU until RDS ON appears in the
display. Press CAT. Press
/until the desired category appears in
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
21

the display. Then pressSEEK/TRACKto find the next station
playing that category of music or SCAN for a brief sampling of all
stations playing that category of music.
COMPRESSION: Available only in CD/MP3 mode. Press MENU until
COMPRESSION ON/OFF appears in the display.
Use
SEEK/TRACKto toggle ON/OFF. When COMPRESSION is
ON, the system will bring the soft and loud CD passages together for a
more consistent listening level.
7. TEXT: In MP3 mode, press
TEXT repeatedly to view Album
(AL), Folder (FL), Song (SO)
and Artist (AR) in the display, if available.
In TEXT MODE, sometimes the display requires additional text to be
displayed. When th eindicator is active, press TEXT and then
press
SEEK/TRACKto view previous / additional display text.
8. AUX: Press AUX to access
LINE (auxiliary audio mode).
For location and further
information on auxiliary audio mode, refer to Auxiliary input jack
later in this chapter.
9. SAT (Satellite Radio, if equipped): This control is not
operational.
10. CD: Press to enter CD/MP3
mode. If a disc is already loaded
into the system, CD/MP3 play
will begin where it ended last. If no CD is loaded, NO DISC will
appear in the display.
11. AM/FM: Press repeatedly to
select AM/FM1/FM2 frequency
band.
12. SEEK/TRACK: In radio
mode, press to access the
previous/next strong radio
station.
In CD/MP3 mode,
press
SEEK/TRACKto
access the previous/next track.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
22

13.CAT (Category) /FOLD
(Folder):In Category mode,
use to select from various music
categories. To change RDS categories, ensure that RDS is ON in the
Menu listing. Press MENU again until RDS ON appears in the display.
Press CAT. PRESS UP OR DOWN TO CHANGE RDS CATEGORY will
appear in the display. Press
SEEK/TRACKto scroll through
all possible categories. When the desired category appears in the
display, press
SEEK/TRACKto find the next station playing
that selection or press SCAN for a brief sampling of all stations
playing that category of music.
In MP3 mode, press FOLD and then press
SEEK/TRACKto
access the previous/next folder.
14. ON/OFF/VOL (Volume): Press
to turn ON/OFF. Turn to
increase/decrease volume.
Note: If the volume is set above a
certain level and the ignition is
turned off, the volume will come
back on at a “nominal” listening
level when the ignition switch is
turned back on.
15. SHUFFLE: In CD and MP3
mode, press SHUFFLE to
engage shuffle mode. SHUFFLE
ON will appear in the display. If you wish to engage shuffle mode
right away, press
SEEK/TRACKto begin random play.
Otherwise, random play will begin when the current track is finished
playing. SHUFFLE and the track # will appear in the display.
To disengage, press SHUFFLE again. SHUFFLE OFF will appear in
the display.
For a single CD system, the system will shuffle within the current
disc.
For a CDX6 system, the system will shuffle between all loaded discs.
The disc # will appear in the top left hand corner of the display.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
23

16.SCAN:In radio mode, press
for a brief sampling of all strong
radio stations.
In CD/MP3 mode, press for a brief sampling of all tracks on the
current disc or folder.
17. DIRECT: Press to access the
desired radio station, track or
MP3 folder.
In radio mode, press DIRECT and then press the desired radio
frequency (i.e. 101.1) using the memory presets.
In CD mode, press DIRECT. The display will read DIRECT TRACK
MODE SELECT TRACK. Enter the desired track number using the
numbered controls. The system will then begin playing that track.
In MP3 folder mode, press DIRECT and the number of the desired
folder. The system will advance to that specific folder.
18. LOAD: For a single CD
system, this control is not
operational. To load a CD,
simply insert the disc label side up into the CD slot.
For a CD6 system, press LOAD. When the display reads SELECT
SLOT, choose the desired slot number using memory presets 1–6.
When the display reads LOAD CD#, load the desired disc, label side
up. If you do not choose a slot within 5 seconds, the system will
choose for you. Once loaded, the first track will begin to play.
To auto load up to 6 discs, press and hold LOAD until the display
reads AUTOLOAD#. Load the desired disc, label side up. The system
will prompt you to load discs for the remaining available slots. Insert
the discs, one at a time, label side up, when prompted. Once loaded,
the disc in preset #1 will begin to play.
19. CD slot:For a single CD
system, insert a CD/MP3, label
side up.
For a CD6 system, press LOAD and select a CD slot using the
memory presets. When prompted by the system, insert a CD/MP3
label side up.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
24

Auxiliary input jack
Your vehicle is equipped with an
Auxiliary Input Jack (AIJ). The
Auxiliary Input Jack provides a way
to connect your portable music
player to the in-vehicle audio
system. This allows the audio from a
portable music player to be played
through the vehicle speakers with
high fidelity. To achieve optimal
performance, please observe the
following instructions when
attaching your portable music
device to the audio system.
Required equipment: 1. Any portable music player designed to be used with headphones
2. An audio extension cable with stereo male 1/8 in. (3.5 mm) connectors at each end
To play your portable music player using the auxiliary input jack: 1. Begin with the vehicle parked and the radio turned off.
2. Ensure that the battery in your portable music player is new or fully charged and that the device is turned off.
3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable
to the AIJ in your vehicle.
4. Turn the radio on, using either a tuned FM station or a CD loaded into the system. Adjust the volume to a comfortable listening level.
5. Turn the portable music player on and adjust the volume to 1/2 the volume.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
25

6. Press AUX on the vehicle radio repeatedly until LINE IN appears in the display.
You should hear audio from your portable music player although it
may be low.
7. Adjust the sound on your portable music player until it reaches the level of the FM station or CD by switching back and forth between
the AUX and FM or CD controls.
Troubleshooting: 1. Do not connect the audio input jack to a line level output. Line level outputs are intended for connection to a home stereo and are not
compatible with the AIJ. The AIJ will only work correctly with
devices that have a headphone output with a volume control.
2. Do not set the portable music player’s volume level higher than is necessary to match the volume of the CD or FM radio in your audio
system as this will cause distortion and will reduce sound quality.
Many portable music players have different output levels, so not all
players should be set at the same levels. Some players will sound
best at full volume and others will need to be set at a lower volume.
3. If the music sounds distorted at lower listening levels, turn the portable music player volume down. If the problems persists, replace
or recharge the batteries in the portable music player.
4. The portable music player must be controlled in the same way manner when it is used with headphones as the AIJ does not provide
control (play, pause, etc.) over the attached portable music player.
5. For safety reasons, connecting or adjusting the settings on your portable music player should not be attempted while the vehicle is
moving. Also, the portable music player should be stored in a secure
location, such as the center console or the glove box, when the
vehicle is in motion. The audio extension cable must be long enough
to allow the portable music player to be safely stored while the
vehicle is in motion.
GENERAL AUDIO INFORMATION
Radio frequencies:
AM and FM frequencies are established by the Federal Communications
Commission (FCC) and the Canadian Radio and Telecommunications
Commission (CRTC). Those frequencies are:
AM: 530, 540–1700, 1710 kHz
FM: 87.7, 87.9–107.7, 107.9 MHz
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
26

Radio reception factors:
There are three factors that can affect radio reception:
• Distance/strength: The further you travel from an FM station, the
weaker the signal and the weaker the reception.
• Terrain: Hills, mountains, tall buildings, power lines, electric fences,
traffic lights and thunderstorms can interfere with your reception.
• Station overload: When you pass a broadcast tower, a stronger signal
may overtake a weaker one and play while the weak station frequency
is displayed.
CD/CD player care
Do:
• Handle discs by their edges only.
(Never touch the playing
surface).
• Inspect discs before playing.
• Clean only with an approved CD
cleaner.
• Wipe discs from the center out.
Don’t:
• Expose discs to direct sunlight or heat sources for extended periods
of time.
• Clean using a circular motion.
CD units are designed to play commercially pressed 4.75 in (12 cm)
audio compact discs only. Due to technical incompatibility, certain
recordable and re-recordable compact discs may not function
correctly when used in Mazda CD players.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
27

Do not use any irregular shaped
CDs or discs with a scratch
protection film attached.
CDs with homemade paper
(adhesive) labels should not be
inserted into the CD player as
the label may peel and cause the
CD to become jammed. It is
recommended that homemade
CDs be identified with
permanent felt tip marker rather
than adhesive labels. Ballpoint pens may damage CDs. Please
contact your authorized dealer for further information.
Audio system warranty and service
Refer to the Warranty Information Booklet for audio system warranty
information. If service is necessary, see your authorized Mazda
dealership.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Entertainment Systems
28

MANUAL HEATING AND AIR CONDITIONING SYSTEM 1.
Fan speed adjustment: Controls the volume of air circulated in
the vehicle.
2.
RRear defroster: Press to activate/deactivate the rear window
defroster. Refer to Rear window defroster later in this chapter for
more information.
3.
Defrost: Distributes outside air through the windshield
defroster vents and demister vents. Can be used to clear the
windshield of fog and thin ice. The system will automatically provide
outside air to reduce window fogging. Press this button again to
return to the previous air flow selection.
4.
: Distributes air through the windshield defroster vents,
demister vents, floor vents and rear seat floor vents. The system will
automatically provide outside air to reduce window fogging.
5.
Power: Press to activate/deactivate the climate control system.
When the system is off, outside air is shut out.
6.
: Distributes air through the instrument panel vents.
7.
: Distributes air through the instrument panel vents, demister
vents, floor vents and rear seat floor vents.
8.
: Distributes air through the demister vents, floor vents and rear
seat floor vents.
9. Temperature control: Controls the temperature of the airflow in
the vehicle.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Climate Controls
29

10.Passenger heated seat control (if equipped):Press to
activate/deactivate the passenger heated seat. See Heated seatsin
the Seating and Safety Restraints chapter.
11.
Recirculated air: Press to activate/deactivate air
recirculation in the vehicle. Recirculated air may reduce the amount
of time needed to cool down the interior of the vehicle and may also
help reduce undesired odors from reaching the interior of the
vehicle. Recirculated air engages automatically when MAX A/C is
selected or can be engaged manually in any airflow mode
except
(defrost). Recirculated air may turn off automatically in
all airflow modes except MAX A/C. When the ignition switch is
turned off and back on, the climate system will return to the
recirculated air mode only if the A/C button LED is illuminated and
the air distribution selection is either(panel) or(panel/floor).
12. MAX A/C: Distributes recirculated air through the instrument panel
vents to cool the vehicle. This re-cooling of the interior air is more
economical and efficient. Recirculated air may also help reduce
undesirable odors from entering the vehicle. Press the MAX A/C
button again for normal A/C operation.
13. A/C: Press to activate/deactivate air conditioning. Use with
recirculated air to improve cooling performance and efficiency.
Engages automatically in MAX A/C,
(defrost) and
(floor/defrost).
14.
Driver heated seat control (if equipped): Press to
activate/deactivate the driver heated seat. See Heated seatsin the
Seating and Safety Restraints chapter.
Outside temperature (if equipped): The outside temperature will
appear in the display and is labeled EXT TEMP.
Operating tips
• To reduce fog build up on the windshield during humid weather,
select
(defrost) or(floor/defrost).
• To reduce humidity build up inside the vehicle, do not drive with the
system off or with
(recirculated air) engaged and A/C off.
• Do not put objects under the front seats that will interfere with the
airflow to the back seats.
• Remove any snow, ice or leaves from the air intake area at the base of
the windshield.
• To improve the A/C cool down, drive with the windows slightly open
for 2-3 minutes after start up or until the vehicle has been “aired out.”
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Climate Controls
30
