Anti-theft system:Flashes when
the SecuriLock Passive Anti-theft
System has been activated.
Throttle control/Powertrain:
Illuminates when a powertrain fault
has been detected. Contact your
authorized dealer as soon as
possible.
Door ajar: Illuminates when the
ignition is in the RUN position and
any door is open.
Turn signal: Illuminates when the
left or right turn signal or the
hazard lights are turned on. If the
indicators flash faster, check for a burned out bulb.
High beams: Illuminates when the
high beam headlamps are turned on.
Key-in-ignition warning chime: Sounds when the key is left in the
ignition in the OFF/LOCK or ACCESSORY position and the driver’s door
is opened.
Headlamps on warning chime: Sounds when the headlamps or parking
lamps are on, the ignition is off (the key is not in the ignition) and the
driver’s door is opened.
Parking brake ON chime: Sounds when the parking brake is left ON
and the vehicle is driven. If the warning stays on after the park brake is
off, contact your authorized dealer as soon as possible.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
16

5. Locate the vertical adjuster on the headlamp, then us ea4mm
socket to turn the adjuster
either counterclockwise (to
adjust up) or clockwise (to
adjust down) aligning the upper
edge of the light pattern to the
horizontal line.
6. Move the opaque cloth to cover the right-hand headlamp and
repeat Steps 4 and 5 for the
left-hand headlamp.
7. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE.
8. Close the hood and turn off the lamps.
TURN SIGNAL CONTROL
• Push down to activate the left
turn signal.
• Push up to activate the right turn
signal.
INTERIOR LAMPS
Cargo and dome lamp
Rear cargo lamp equipped with an
ON/OFF/DOOR control will light
when:
• the doors are closed and the
control is in the ON position.
• the control is in the DOOR
position and any door is open.
When the control is in the OFF position, it will not illuminate when you
open the doors.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Lights
35

Replacing headlamp bulbs 1. Make sure that the headlamp control is in the OFF position.
2. Open the hood.
3. Reach over the front bolster.
4. Remove the bulb by turning it counterclockwise and then
pulling it straight out.
WARNING: Handling Halogen Bulbs: When a halogen bulb
breaks, it is dangerous. These bulbs contain pressurized gas. If
one is broken, it will explode and serious injuries could be
caused by the flying glass. If the glass portion of the bulb is
touched with bare hands, body oil could cause the bulb to
overheat and explode when lit. Never touch the glass portion of
the bulb with your bare hands and always wear eye protection
when handling or working around halogen bulbs. 5. Disconnect the electrical connector from the bulb.
WARNING: Children and
Halogen Bulbs: Playing with a
halogen bulb is dangerous.
Serious injuries could be
caused by dropping a halogen
bulb or breaking in some other
way. Always keep halogen
bulbs out of the reach of
children.
6. Connect the electrical connector on the new bulb.
7. Insert the glass end of the new bulb into the headlamp assembly. When the grooves in the plastic base are aligned, turn the new bulb
clockwise to install.
Replacing front parking lamp/turn signal bulbs
For bulb replacement, see your authorized Mazda dealer.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Lights
38

Two step door unlocking
1. Pressand release to unlock the driver’s door.Note:The interior
lamps will illuminate if the control on the overhead lamp is in the
DOOR position.
2. Press
and release again within three seconds to unlock the
passenger doors, the liftgate and liftgate glass.
One step door unlocking
If the one step door unlocking feature is activated, press
and release
once to unlock all of the doors, the liftgate and liftgate glass. Note:The
interior lamps will illuminate (refer to the Illuminated entryfeature
later in this section), if the control on the overhead lamp is in the DOOR
position.
Switching from two step to one step door unlocking
Unlocking can be switched between two step and one step door
unlocking by pressing and holding both
andbuttons
simultaneously on the remote entry transmitter for approximately
4 seconds. The turn signal will flash twice to indicate that the vehicle has
switched to one step unlocking. Repeat the procedure to switch back to
two step unlocking.
Locking the doors
1. Pressand release to lock all the doors. Assuming all vehicle doors
and the liftgate are properly closed, the park/turn lamps will flash
once.
2. Press
and release again within three seconds to confirm that all
the doors and liftgate are closed and locked. Note:The doors will
lock again and the horn will chirp once.
If any of the doors or the hood are not properly closed, the horn will
chirp twice and park/turn lamps will not flash when the
control is
pressed.
Opening the liftgate (if equipped)
Presstwice within 3 seconds to open the liftgate glass.
Car finder
Press
twice within 3 seconds. The horn will chirp and the turn lamps
will flash. It is recommended that this method be used to locate your
vehicle, rather than using the panic alarm.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Locks and Security
64

Hitches
Do not use hitches that clamp onto the vehicle bumper. Use a load
carrying hitch. You must distribute the load in your trailer so that
10–15% of the total weight of the trailer is on the tongue.
Safety chains
Always connect the trailer’s safety chains to the frame or hook retainers
of the vehicle hitch. To connect the trailer’s safety chains, cross the
chains under the trailer tongue and allow slack for turning corners.
If you use a rental trailer, follow the instructions that the rental agency
gives to you.
Do not attach safety chains to the bumper.
Trailer brakes
Electric, manual, automatic or surge-type brakes, if compatible with the
vehicle, are safe if installed properly and adjusted to the manufacturer’s
specifications. The trailer brakes must meet local and Federal
regulations. WARNING: Do not connect a trailer’s hydraulic brake system
directly to your vehicle’s brake system. Your vehicle may not
have enough braking power and your chances of having a
collision greatly increase.
The braking system of the tow vehicle is rated for operation at the
GVWR not GCWR.
Trailer lamps
Trailer lamps are required on most towed vehicles. Make sure all running
lights, brake lights, turn signals and hazard lights are working. Do not
connect trailer lamps directly to your vehicle’s tail lamps. This can cause
damage to your vehicle’s electrical system. See your authorized Mazda
dealer or trailer rental agency for proper instructions and equipment for
hooking up trailer lamps.
Driving while you tow
When towing a trailer:
• Keep your speed no faster than 70 mph (112 km/h) during the first
500 miles (800 km) of towing a trailer, and don’t make full throttle
starts.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Tires, Wheels and Loading
158

HAZARD FLASHER CONTROL
The hazard flasher is located on the
steering column, just behind the
steering wheel. The hazard flashers
will operate when the ignition is in
any position or if the key is not in
the ignition.
Push in the flasher control and all
front and rear direction signals will
flash. Press the flasher control again
to turn them off. Use it when your
vehicle is disabled and is creating a
safety hazard for other motorists.
Note: With extended use, the flasher may run down your battery.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
188

The fuses are coded as follows:
Fuse/Relay Location Fuse Amp
Rating Passenger Compartment Fuse
Panel Description
1 30A Not used (spare)
2 15A Brake On/Off switch
3 15A Not used (spare)
4 30A Not used (spare)
5 10A Brake Shift Interlock (BSI), SPDJB
6 20A Turn signals, Stop lamps
7 10A Low beam headlamps (left)
8 10A Low beam headlamps (right)
9 15A Interior lights
10 15A Backlighting
11 10A Four wheel drive
12 7.5A Power mirror switch
13 7.5A Canister vent
14 10A FCIM (radio buttons), Front display module
15 10A Climate control
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
191

fog lamps ...................................32
headlamps .................................32
headlamps, flash to pass ..........33
instrument panel, dimming .....33
interior lamps .....................35–37
replacing bulbs .........................38
Lane change indicator
(see Turn signal) ........................35
Liftgate ..................................54, 64
Lights, warning and indicator ....12 anti-lock brakes (ABS) ..........167
Load limits .................................148
Loading instructions .................154
Locks childproof ..................................62
doors ..........................................62
Lubricant specifications ...........271
Lug nuts ....................................206
Luggage rack ...............................57
Lumbar support, seats ...............74
M
Manual transaxle fluid, checking and adding ....269
Manual transmission .................179 fluid capacities ........................271
lubricant specifications ..........271
reverse .....................................180
Mirrors .........................................48 fold away ...................................49
heated ........................................49
side view mirrors (power) .......48
Moon roof ....................................53
Motorcraft parts ........................256
O
Octane rating ............................260 Oil (see Engine oil) ..................244
Overdrive ...................................175
Overheating ...............................206
P
Parking brake ............................167
Passenger Occupant
Classification Sensor ...................83
Power distribution box
(see Fuses) ...............................193
Power door locks ........................62
Power mirrors .............................48
Power point .................................46
Power Seats .................................74
Power steering ..........................172
fluid, refill capacity ................271
fluid, specifications .................271
Power Windows ...........................47
Preparing to drive your
vehicle ........................................173
R
Radio ............................................19
Relays ........................................189
Remote entry system ...........63–64 illuminated entry ................66–67
locking/unlocking doors ...........64
opening the trunk .....................64
panic alarm ...............................65
replacement/additional
transmitters ...............................66
replacing the batteries .............65
Roof rack .....................................57
S
Safety defects, reporting ..........225
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Index
280

Safety restraints ..............81, 85–89 Belt-Minder
.............................92
extension assembly ..................90
for adults .............................86–88
for children .....................113–114
Occupant Classification
Sensor ........................................83
seat belt maintenance ..............91
warning light and chime ....91–92
Safety seats for children ..........117
Safety Compliance
Certification Label ....................274
Scheduled Maintenance ...........232
Seat Belt Maintenance ...............91
Seat belts (see
Safety restraints) ............81, 85–89
Seats ............................................72 child safety seats ....................117
heated ........................................76
SecuriLock passive anti-theft
system ..........................................68
Servicing your vehicle ..............238
Side-curtain airbags system
(if equipped) .............107, 109, 111
Snowplowing .................................7
Spark plugs, specifications .......273
Special notice ambulance conversions ..............7
Specification chart,
lubricants ...................................271
Speed control ..............................49
Starting your
vehicle ........................161–162, 164 jump starting ..........................207
Steering wheel controls ......................................52
tilting .........................................43 T
Tilt steering wheel ......................43
Tire Pressure Monitoring
System (TPMS)
Tires, Wheels and Loading ....143
Tires ...................................127–129 alignment ................................136
care ..........................................132
changing ..........................199, 201
checking the pressure ............132
inflating ...................................130
label .........................................142
replacing ..................................133
rotating ....................................136
safety practices .......................135
sidewall information ...............138
snow tires and chains ............148
spare tire .........................196, 199
terminology .............................129
tire grades ...............................128
treadwear ........................128, 132
Towing .......................................154 recreational towing .................160
trailer towing ..........................154
wrecker ....................................213
Transaxle fluid, checking and adding
(manual) .................................269
Transmission automatic operation ...............173
brake-shift interlock (BSI) ....173
fluid, checking and adding
(automatic) .............................267
fluid, refill capacities ..............271
lubricant specifications ..........271
manual operation ....................179
Trunk ...........................................64
Turn signal ..................................35
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Index
281
