MAZDA MX5 MIATA 2016 Owners Manual

8–43
Customer Information and Reporting Safety Defects
Declaration of Conformity
Declaration of Conformity
Keyless Entry System/Immobilizer System
MX-5_8EU4-EA-15D_Edition3.indb 432015/10/21 16:56:15

8–44
Customer Information and Reporting Safety Defects
Declaration of Conformity
Blind Spot Monitoring (BSM) System
(Canada) (U.S.A.)
MX-5_8EU4-EA-15D_Edition3.indb 442015/10/21 16:56:16

8–45
Customer Information and Reporting Safety Defects
Declaration of Conformity
HomeLink Wireless Control System
CAUTION
HomeLink has been tested and complies with FCC and Industry Canada rules. Changes or
modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the device.
NOTE
FCC ID: NZLMOBHL4
CANADA:4112A-MOBHL4
This device complies with part 15 of the FCC Rules. Operation is subject\
to the following
two conditions:
1- This device may not cause harmful interference, and
2- This device must accept any interference received, including interference that may cause
undesired operation.
Bluetooth® Hands-Free
Type A
U.S.A. and Canada
FCC ID: CB2MBLUEC09 IC:279B-MBLUEC09
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interferenc\
e that may cause
undesired operation.
WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
MX-5_8EU4-EA-15D_Edition3.indb 452015/10/21 16:56:17

8–46
Customer Information and Reporting Safety Defects
Declaration of Conformity
The term “IC: ” before the radio certification number only signifies that Industry Canada
technical specifications were met.
The antenna used for this transmitter must not be co-located or operatin\
g in conjunction
with any other antenna or transmitter. End-users and installers must be provided with
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.
Mazda Bluetooth
® Hands-Free Customer Service
 U.S.A.
Phone: 800-430-0153 (Toll-free)
Web: www.MazdaUSA.com/bluetooth Canada
Phone: 800-430-0153 (Toll-free)
Web: www.mazdahandsfree.ca
Mexico
 Brief description: Bluetooth module for Hands-free telephone and streaming audio Name and address of the importer: Refer to "MEXICO" (page 8-12) in Importer/
Distributor section.
 Brand name of the product: Johnson Controls Inc. Model name of the product: MAZ Names and addresses of where the warranty can be served: Refer to "MEXICO" (page
8-12) in Importer/Distributor section. Names and addresses of where to acquire spare parts, consumables and accessories: Refer
to "MEXICO" (page 8-12) in Importer/Distributor section. Warranty period, items covered by the warranty and its possible limitatio\
ns or exceptions:
Refer to the Warranty Booklet for detailed warranty information.  Warranty procedure:
Center of Attention to Client (CAC)
Phone: 01-800-01-MAZDA
Web: www.mazdamexico.com.mx Electrical specifications:
Voltage: 9-16V, Frequency: 2.4Ghz, Current: 270mA(Typ)
MX-5_8EU4-EA-15D_Edition3.indb 462015/10/21 16:56:17

8–47
Customer Information and Reporting Safety Defects
Declaration of Conformity
Type B
U.S.A. and Canada
MX-5_8EU4-EA-15D_Edition3.indb 472015/10/21 16:56:18

8–48
Customer Information and Reporting Safety Defects
Declaration of Conformity
Mexico
MX-5_8EU4-EA-15D_Edition3.indb 482015/10/21 16:56:18

9–1
9Specifications
Technical information about your Mazda.
Identification Numbers
......................................................................9-2
Vehicle Information Labels
...........................................................9-2
Specifications
........................................................................\
..............9-4
Specifications
........................................................................\
........9-4
Personalization Features
...................................................................9-9
Personalization Features
...............................................................9-9
MX-5_8EU4-EA-15D_Edition3.indb 12015/10/21 16:56:19

9–2
Specifications
Identification Numbers
Vehicle Information Labels
Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
Chassis Number
Open the cover shown in the figure to
check the chassis number.
Vehicle Emission Control
Information Label (U.S.A. and
Canada)
Tire Pressure Label
MX-5_8EU4-EA-15D_Edition3.indb 22015/10/21 16:56:20

9–3
Specifications
Identification Numbers
Engine Number
Forward
MX-5_8EU4-EA-15D_Edition3.indb 32015/10/21 16:56:21

9–4
Specifications
Specifications
Specifications
Engine
ItemSpecification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 × 3.59 in)
Displacement 1,997.6 ml (1,997.6 cc)
Compression ratio 13.0
Electrical System
ItemClassification
Battery 12V-45Ah/20HR
Spark-plug number Mazda Genuine spark plug
*1PE5R-18-110 or PE5S-18-110
*1 The spark plugs provide the SKYACTIV-G its optimum performance. Consult an Authorized Mazda Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on
the iridium alloy and platinum tips could be damaged.
Lubricant Quality
Lubricant Classification
Engine oil Refer to Recommended Oil on page 6-27.
Coolant FL-22 type
Manual transmission oil Mazda Original Long Life Gear Oil IS
*1
Automatic transmission fluid Mazda Genuine JWS3309
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
*1 Mazda Original Long Life Gear Oil IS is superior oil for optimum shift-feel. Using Mazda Original Long Life Gear Oil IS is recommended. If Mazda Original Long Life Gear Oil IS cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-90)). However, shifting in very low temperatures may become difficult.
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your
investment.
