MAZDA MX5 MIATA 2016 Owners Manual

9–5
Specifications
Specifications
Capacities
(Approximate Quantities)
ItemCapacity
Engine oil With oil filter replacement
4.3 L (4.5 US qt, 3.8 Imp qt)
Without oil filter replacement 4.1 L (4.3 US qt, 3.6 Imp qt)
Coolant Manual transmission
6.0 L (6.3 US qt, 5.3 Imp qt)
Automatic transmission 5.9 L (6.2 US qt, 5.2 Imp qt)
Manual transmission oil 2.0 L (2.1 US qt, 1.8 Imp qt)
Automatic transmission fluid 7.2 L (7.6 US qt, 6.3 Imp qt)
Rear differential oil 0.6 L (0.6 US qt, 0.5 Imp qt)
Fuel tank 45.0 L (11.9 US gal, 9.90 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
Dimensions
U.S.A. and Canada
ItemVehicle specification
Overall length 3,915 mm (154.1 in)
Overall width 1,735 mm (68.3 in)
Overall height 16 inch wheel vehicle
1,235 mm (48.6 in)
17 inch wheel vehicle 1,240 mm (48.8 in)
Front tread 1,495 mm (58.9 in)
Rear tread 1,505 mm (59.3 in)
Wheelbase 2,310 mm (90.9 in)
Mexico
ItemVehicle specification
Overall length 3,915 mm (154.1 in)
Overall width 1,735 mm (68.3 in)
Overall height 16 inch wheel vehicle
1,225 mm (48.2 in)
17 inch wheel vehicle 1,230 mm (48.4 in)
Front tread 1,495 mm (58.9 in)
Rear tread 1,505 mm (59.3 in)
Wheelbase 2,310 mm (90.9 in)
MX-5_8EU4-EA-15D_Edition3.indb 52015/10/21 16:56:22

9–6
Specifications
Specifications
Weights
U.S.A. and Canada
ItemWeight
Manual transmission Automatic transmission
GVWR (Gross Vehicle Weight Rating) 1,245 kg (2,745 lbs)1,265 kg (2,789 lbs)
GAWR (Gross Axle Weight Rating) Front
628 kg (1,384 lbs) 642 kg (1,415 lbs)
Rear 620 kg (1,367 lbs) 626 kg (1,380 lbs)
Mexico
Item Weight
GVW (Gross Vehicle Weight) Total
1,242 kg (2,738 lbs)
Front 627 kg (1,382 lbs)
Rear 615 kg (1,356 lbs)
GAW (Permissible axle load) Front
630 kg (1,389 lbs)
Rear 615 kg (1,356 lbs)
Air Conditioner
The type of refrigerant used is indicated on a label attached to the ins\
ide of the engine
compartment. Check the label before recharging the refrigerant. Refer to Climate Control
System on page 5-2.
Item Classification
Refrigerant Type HFC134a (R-134a)
MX-5_8EU4-EA-15D_Edition3.indb 62015/10/21 16:56:22

9–7
Specifications
Specifications
Light Bulbs
Exterior light
Light bulbCategory
Wattage UNECE*1 (SAE)
Headlights High beam
LED*2— (—)
Low beam LED*2— (—)
Daytime running lights LED type
LED*2— (—)
Bulb type 21 W21W (7440)
Parking lights LED
*2— (—)
Front side-maker lights 5W5W (—)
Front turn signal lights 28/8— (7444NA)
Side turn signal lights 5
*3WY5W (—)
High-mount brake light LED*2— (—)
Rear turn signal lights 21WY21W (7443NA)
Rear side-maker lights 5W5W (—)
Brake lights LED
*2— (—)
Taillights LED*2— (—)
Reverse lights 21W21W (7440)
License plate lights 5W5W (—)
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.*3 Bulb replacement is not possible because it is built into the unit. Replace the unit.
Interior light
Light bulb Category
Wattage UNECE*1
Overhead light 10—
Trunk light 5—
*1 UNECE stands for United Nations Economic Commission for Europe.
MX-5_8EU4-EA-15D_Edition3.indb 72015/10/21 16:56:22

9–8
Specifications
Specifications
Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Inflation Pressure on page 6-41.
After adjusting the tire pressure, initialization of the tire pressure m\
onitoring system is
necessary to make the system operate normally.
Refer to Tire Pressure Monitoring System Initialization on page 4-96.
Standard tire
Tire size Inflation pressure
Front Rear
195/50R16 84V 200 kPa (2.0 bar, 29 psi) 200 kPa (2.0 bar, 29 psi)
205/45R17 84W 200 kPa (2.0 bar, 29 psi) 200 kPa (2.0 bar, 29 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108—147 N·m (12—14 kgf·m, 80—108 ft·lbf)
Fuses
Refer to Fuses on page 6-54.
MX-5_8EU4-EA-15D_Edition3.indb 82015/10/21 16:56:23

9–9
Specifications
Personalization Features
Personalization Features
The following personalization features can be set or changed by the cust\
omer or an
Authorized Mazda Dealer.
Personalization features which can be changed differ depending on the market and
specification.
Settings Change Method
Settings can be changed by operating the center display screen.
A: Refer to Settings on page 5-53.
B: Refer to Fuel Economy Monitor on page 4-59.
Settings can be changed by operating the vehicle switches.
C: Refer to Auto Lock/Unlock Function on page 3-15.
D: Refer to Transmitter on page 3-4.
E: Refer to Locking, Unlocking with Request Switch (W ith the advanced keyless function)
on page 3-12.
F: Refer to Outside Temperature Display on page 4-13.
Settings can be changed by an Authorized Mazda Dealer.
ItemFeatureFactory
Setting Available
Settings Settings
Change
Method
Safety
Lane Departure Warning
System (LDWS) (page
4-69). Distance by which the system uses
to determine the possibility of a lane
departure
Before
At/Before A—Warning sensitivity (likelihood of warning) Low
High/Low A—
Warning beep soundBeep Beep/Rumbl. A—
Warning beep volumeRumbl. HighHigh/Mid/Low A—
BeepHigh High/Low A—
Blind Spot Monitoring (BSM) system (page
4-74). Warning beep volume*1HighHigh/
Low/ Off A
—
MX-5_8EU4-EA-15D_Edition4.indb 92016/01/20 11:08:28

9–10
Specifications
Personalization Features
ItemFeatureFactory
Setting Available
Settings Settings
Change
Method
Vehicle
Door locks (page 3-15). Operation condition of auto lock/
unlock function Lock:
When
Driving
Unlock:
IGN Off Lock: When
Driving Unlock: In Park/
Lock: Out of
Park Unlock: In Park/
Lock: Shifting Out of Park/
Lock: When
Driving Unlock: IGN Off/
Lock: When Driving/ Off A
C
Keyless entry system (page 3-3). Method for unlocking door using
transmitter
Driver's:
Once, All Doors: Twice All Doors: Once/
Driver's: Once,
All Doors: Twice A
D
Time for locking door automatically60 seconds 90 seconds/
60 seconds/
30 seconds A
—
Advanced keyless entry system (page 3-8). Method for unlocking door using
request switch/transmitter
Driver's:
Once, All Doors: Twice All Doors: Once/
Driver's: Once,
All Doors: Twice A
D,
E
Time for locking door automatically60 seconds 90 seconds/
60 seconds/
30 seconds A
—
Auto-lock function operation/non-operational Off
On/Off A—
Beep volume when locking/unlocking MediumHigh/
Medium/ Low/Off A
D,
E
Illuminated entry system (page 5-132). Time until interior lights turn off
after closing door
15 seconds60 seconds/
30 seconds/
15 seconds/
7.5 seconds A
—Time until interior lights turn off automatically when any door is not
closed completely 30 minutes60 minutes/
30 minutes/
10 minutes A
—
Auto-wiper control (page 4-41). Operational/non-operational
OnOn/Off*2A—
Daytime running lights (page 4-39). Operational/non-operational
OnOn/Off A—
MX-5_8EU4-EA-15D_Edition3.indb 102015/10/21 16:56:24

9–11
Specifications
Personalization Features
ItemFeatureFactory
Setting Available
Settings Settings
Change
Method
Auto headlight off*3 (page
4-35). Time until headlights turn off
30 seconds120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off
*4
A —
Auto-light control (page 4-35). Timing by which lights turn on
MediumHigh/
Med. High/ Medium/
Med. Low/ Low A
—
High Beam Control System (HBC) (page 4-66). Operational/non-operational*5On
On/Off A—
Adaptive Front Lighting System (AFS) (page
4-65). Operational/non-operational*5On
On/Off A—
Lights-on reminder*6 (page
7-45). Warning beep volume
OffHigh/Low/Off A—
Coming home light (page 4-38). Time until headlights turn off
30 seconds120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off A
—
Leaving home light (page 4-39). Operational/non-operational
OnOn/Off A—
Turn indicator (page
4-40). Beep volume
LowHigh/Low A—
Three-flash turn signal (page 4-40). Operational/non-operational
OnOn/Off A—
System
Language Language indicated in display EnglishDepends on
market*7A —
TemperatureTemperature unit indicated in
display °F or °C
°F/°CAF
DistanceDistance unit indicated in display mi or kmmi/kmA—
Fuel Economy Monitor (page 4-59).
Ending display On/off OffOn/Off B—
Fuel economy resetting procedure Linkage/non-linkage with fuel
economy reset and trip meter reset
Off
On/Off B—
*1 Only the volume of the warning beep during Blind Spot Monitorin g (BSM) operation can be changed. The volume of the warning beep during Rear Cross Traffic Alert (RCTA) operation cannot be changed.*2 If the auto-wiper control is set to Off, the wiper lever position is set to intermittent operation.
MX-5_8EU4-EA-15D_Edition4.indb 112016/01/20 11:08:29

9–12
Specifications
Personalization Features
*3 If the setting is changed to Off, the following operation is performed according to the headlight switc\
h position:
 At position: Headlights turn off immediately after the ignition is switched off. At any position other than : Headlights do not turn off after the ignition is switched off.
*4 When set to Off, the lights-on reminder is operable.*5 Though these systems can be turned Of f, doing so will defeat the purpose of the system and Mazda recommends that these systems remain On.*6 The setting of the lights-on reminder can be changed with the time setti\
ng of auto headlight of f function set to Off. Refer to Lights-On Reminder on page 7-45.*7 Available only in display from the center display.
MX-5_8EU4-EA-15D_Edition4.indb 122016/01/20 11:08:29

10–1

10Index
MX-5_8EU4-EA-15D_Edition3.indb 12015/10/21 16:56:25

10–2
Index
A
Accessory Socket ..............................5-133
Adaptive Front Lighting System
(AFS)................................................... 4-65
Add-On Non-Genuine Parts and
Accessories
.........................................8-18
Advanced Key Advanced keyless entry system
......3-8
Operational range
............................3-9
Air Bag/Seat Belt Pretensioner System
Warning Beep
......................................7-45
Air Bag Systems
.................................2-24
Ambient Temperature Display
............4-13
Antilock Brake System (ABS)
............4-55
Audio Control Switch Adjusting the volume
....................5-55
Seek switch .................................... 5-56
Audio System
......................................5-13
AUX/USB mode
...........................5-57
Antenna
.........................................5-13
Audio control switch
.....................5-55
Audio set
[Type A (non-touchscreen)]
...........5-22
Audio set
[Type B (touchscreen)]
..................5-34
Operating tips for audio system
....5-14
Satellite radio
................................5-46
Automatic Transmission
.....................4-24
Active Adaptive Shift (AAS)
........4-26
Direct mode
...................................4-33
Driving tips .................................... 4-33
Manual shift mode .........................4-27
Shift-lock override
........................4-26
Shift-lock system
...........................4-26
Shift position indication
................4-25
Transmission ranges
......................4-25
Warning light
.................................4-25
B
Back Trim Storage Box .....................5-138
Battery
.................................................6-36
Maintenance
..................................6-38
Replacement
..................................6-38
Specifications
..................................9-4
Battery Runs Out
.................................7-23
Jump-starting
.................................7-23
Blind Spot Monitoring (BSM)
............4-74
Blind Spot Monitoring (BSM) System
Warning Beep
......................................7-48
Bluetooth® ...........................................5-74
Bluetooth® audio (Type A) ..........5-112
Bluetooth® audio (Type B) ..........5-114
Bluetooth® Hands-Free (Type A) ...5-96
Bluetooth® Hands-Free (Type B) ...5-102
Troubleshooting
..........................5-128
Body Lubrication
................................6-32
Brakes Brakes assist
..................................4-53
Foot brake ...................................... 4-51
Pad wear indicator
.........................4-52
Parking brake
................................4-52
Warning light
.................................4-52
Break-In Period
...................................3-43
C
Capacities ..............................................9-5
Carbon Monoxide
...............................3-24
Cell Phones
.........................................8-19
Child Restraint Child-restraint precautions
............2-15
Child-restraint system installation ...2-20
Installing child-restraint systems ...2-21
Climate Control System
........................5-2
Fully automatic type
........................5-9
Gas specifications
............................9-6
Manual type
.....................................5-5
Operating tips
..................................5-2
Vent operation
.................................5-3
Clock
...................................................5-26
MX-5_8EU4-EA-15D_Edition4.indb 22016/01/20 11:08:29
